Abstract base-class for Time/database functionObjects. More...

Inheritance diagram for functionObject:

[legend]

Collaboration diagram for functionObject:

Public Member Functions
	ClassName ("functionObject")

virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const Time &runTime)
	Construct from components. More...

	functionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from dictionary. More...

autoPtr< functionObject >	clone () const
	Return clone. More...

	functionObject (const functionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~functionObject ()
	Destructor. More...

const word &	name () const
	Return the name of this functionObject. More...

virtual bool	read (const dictionary &)
	Read and set the functionObject if its data have changed. More...

virtual wordList	fields () const =0
	Return the list of fields required. More...

virtual bool	executeAtStart () const
	Return true if the functionObject should be executed at the start. More...

virtual bool	execute ()=0
	Called at each ++ or += of the time-loop. More...

virtual bool	write ()=0
	Called at each ++ or += of the time-loop. More...

virtual bool	end ()
	Called when Time::run() determines that the time-loop exits. More...

virtual scalar	timeToNextAction ()
	Called by Time::adjustTimeStep(). Allows the functionObject to. More...

virtual scalar	maxDeltaT () const
	Return the maximum time-step for stable operation. More...

virtual void	movePoints (const polyMesh &mesh)
	Update topology using the given map. More...

virtual void	topoChange (const polyTopoChangeMap &map)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

void	operator= (const functionObject &)=delete
	Disallow default bitwise assignment. More...

Static Public Member Functions
static autoPtr< functionObject >	New (const word &name, const Time &, const dictionary &)
	Select from dictionary, based on its "type" entry. More...

Public Attributes
Switch	log
	Switch write log to Info. More...

Switch	executeAtStart_
	Switch execute at start time. More...

Static Public Attributes
static bool	postProcess
	Global post-processing mode switch. More...

Protected Attributes
const Time &	time_
	Reference to time. More...

Detailed Description

Abstract base-class for Time/database functionObjects.

See also: Foam::functionObjectList Foam::functionObjects::timeControl

Source files

Definition at line 247 of file functionObject.H.

Constructor & Destructor Documentation

◆ functionObject() [1/3]

functionObject	(	const word &	name,
		const Time &	runTime
	)

Construct from components.

Definition at line 44 of file functionObject.C.

◆ functionObject() [2/3]

functionObject	(	const word &	name,
		const Time &	runTime,
		const dictionary &	dict
	)

Construct from dictionary.

Definition at line 57 of file functionObject.C.

References dict, and functionObject::read().

Here is the call graph for this function:

◆ functionObject() [3/3]

functionObject ( const functionObject & )

delete

Disallow default bitwise copy construction.

◆ ~functionObject()

~functionObject ( )

virtual

Destructor.

Definition at line 135 of file functionObject.C.

Member Function Documentation

◆ ClassName()

ClassName ( "functionObject" )

◆ type()

virtual const word& type ( ) const

pure virtual

Runtime type information.

Referenced by objectRegistryFunctionObject::cannotFindObject(), fieldAverage::fieldAverage(), fieldCoordinateSystemTransform::fieldCoordinateSystemTransform(), fieldsExpression::fieldsExpression(), Qdot::Qdot(), shearStress::shearStress(), wallHeatFlux::wallHeatFlux(), and wallShearStress::wallShearStress().

Here is the caller graph for this function:

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		functionObject	,
		dictionary	,
		(const word &name, const Time &runTime, const dictionary &dict)	,
		(name, runTime, dict)
	)

◆ clone()

autoPtr<functionObject> clone ( ) const

inline

Return clone.

Definition at line 304 of file functionObject.H.

References NotImplemented.

◆ New()

Foam::autoPtr< Foam::functionObject > New	(	const word &	name,
		const Time &	runTime,
		const dictionary &	dict
	)

static

Select from dictionary, based on its "type" entry.

Definition at line 72 of file functionObject.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::Info, Foam::libs, dictionary::lookup(), Foam::name(), Foam::nl, dlLibraryTable::open(), and string::remove().

Here is the call graph for this function:

◆ name()

const Foam::word & name ( ) const

Return the name of this functionObject.

Definition at line 141 of file functionObject.C.

Referenced by objectRegistryFunctionObject::cannotFindObject(), fieldAverage::fieldAverage(), fieldCoordinateSystemTransform::fieldCoordinateSystemTransform(), fieldsExpression::fieldsExpression(), fieldValue::New(), sampledSets::sampleLocalType(), and sampledSurfaces::sampleLocalType().

Here is the caller graph for this function:

◆ read()

bool read ( const dictionary & dict )

virtual

Read and set the functionObject if its data have changed.

Reimplemented in fieldValue, phaseForces, moleFractions, massFractions, specieReactionRates, reactionRates, adjustTimeStepToChemistry, sampledSurfaces, sampledSets, probes, patchProbes, sixDoFRigidBodyState, sixDoFRigidBodyControl, rigidBodyState, rigidBodyPoints, rigidBodyForces, timeControl, objectRegistryFunctionObject, LagrangianFieldValue, LagrangianDistribution, particles, dsmcFields, cloudInfo, cloudSurfaceDistribution, meshToMeshAdjustTimeStep, multiValveEngineState, writeObjects, writeDictionary, userTimeStep, timeStep, timeActivatedFileUpdate, time, systemCall, stopAtTimeStep, stopAtFile, stopAtClockTime, stopAt, setWriteIntervalFunctionObject, setTimeStepFunctionObject, residuals, removeObjects, codedFunctionObject, checkMesh, scalarTransport, phaseScalarTransport, movingForces, forcesBase, forces, forceCoeffs, yPlus, wallShearStress, wallHeatTransferCoeff, wallHeatFlux, uniform, turbulenceIntensity, turbulenceFields, totalEnthalpy, streamlines, shearStress, scale, regionSizeDistribution, readFields, randomise, processorField, pressure, power, patchCutLayerAverage, nearWallFields, log, layerAverage, interfaceHeight, histogram, volFieldValue, surfaceFieldValue, fieldValueDelta, fieldsExpression, fieldCoordinateSystemTransform, fieldAverage, cutLayerAverage, CourantNo, comfort, bXiProgress, blendingFactor, age, Qdot, adjustTimeStepToCombustion, writeVTK, wallBoilingProperty, populationBalanceSizeDistribution, populationBalanceMoments, adjustTimeStepToNucleation, and fluidMaxDeltaT.

Definition at line 147 of file functionObject.C.

References dict, Foam::log(), and dictionary::lookupOrDefault().

Referenced by functionObject::functionObject(), bXiProgress::read(), checkMesh::read(), codedFunctionObject::read(), time::read(), timeStep::read(), userTimeStep::read(), writeObjects::read(), and objectRegistryFunctionObject::read().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ fields()

virtual wordList fields ( ) const

pure virtual

Return the list of fields required.

Implemented in moleFractions, massFractions, specieReactionRates, reactionRates, adjustTimeStepToChemistry, sampledSurfaces, sampledSets, probes, sixDoFRigidBodyState, rigidBodyState, rigidBodyPoints, timeControl, LagrangianFieldValue, LagrangianDistribution, particles, dsmcFields, cloudInfo, cloudVolumeFraction, cloudVolume, cloudSurfaceDistribution, cloudSurfaceAreaPerUnitVolume, cloudSurfaceArea, cloudMass, cloudLagrangianVolumeFraction, cloudKineticEnergy, cloudGravitationalPotentialEnergy, cloudFlux, cloudBoundaryCollisionFlux, cloudAge, cloud, meshToMeshAdjustTimeStep, multiValveEngineState, writeObjects, writeDictionary, userTimeStep, timeStep, timeActivatedFileUpdate, time, systemCall, stopAt, setWriteIntervalFunctionObject, setTimeStepFunctionObject, residuals, removeObjects, codedFunctionObject, checkMesh, scalarTransport, phaseScalarTransport, forcesBase, yPlus, XiReactionRate, writeCellVolumes, writeCellCentres, wallShearStress, wallHeatTransferCoeff, wallHeatFlux, uniform, turbulenceIntensity, turbulenceFields, totalEnthalpy, streamlines, shearStress, regionSizeDistribution, readFields, processorField, power, patchCutLayerAverage, nearWallFields, layerAverage, interfaceHeight, histogram, fieldValueDelta, fieldValue, fieldsExpression, fieldExpression, fieldCoordinateSystemTransform, fieldAverage, cutLayerAverage, comfort, bXiProgress, age, fvModel, Qdot, adjustTimeStepToCombustion, writeVTK, wallBoilingProperty, populationBalanceSizeDistribution, populationBalanceSetSizeDistribution, populationBalanceMoments, phaseMap, phaseForces, adjustTimeStepToNucleation, and fluidMaxDeltaT.

◆ executeAtStart()

bool executeAtStart ( ) const

virtual

Return true if the functionObject should be executed at the start.

Reimplemented in timeControl, dsmcFields, cloudSurfaceDistribution, cloudFlux, cloudBoundaryCollisionFlux, cloud, scalarTransport, phaseScalarTransport, and fieldAverage.

Definition at line 161 of file functionObject.C.

◆ execute()

virtual bool execute ( )

pure virtual

Called at each ++ or += of the time-loop.

foamPostProcess overrides the usual executeControl behaviour and forces execution (used in post-processing mode)

Implemented in moleFractions, massFractions, specieReactionRates, reactionRates, adjustTimeStepToChemistry, sampledSurfaces, sampledSets, probes, sixDoFRigidBodyState, sixDoFRigidBodyControl, rigidBodyState, rigidBodyPoints, timeControl, LagrangianFieldValue, LagrangianDistribution, particles, dsmcFields, cloudInfo, cloudVolumeFraction, cloudVolume, cloudSurfaceDistribution, cloudSurfaceAreaPerUnitVolume, cloudSurfaceArea, cloudMass, cloudLagrangianVolumeFraction, cloudKineticEnergy, cloudGravitationalPotentialEnergy, cloudFlux, cloudBoundaryCollisionFlux, cloudAge, cloud, meshToMeshAdjustTimeStep, multiValveEngineState, writeObjects, writeDictionary, userTimeStep, timeStep, timeActivatedFileUpdate, time, systemCall, stopAt, setWriteIntervalFunctionObject, setTimeStepFunctionObject, residuals, removeObjects, codedFunctionObject, checkMesh, scalarTransport, phaseScalarTransport, forcesBase, forceCoeffs, yPlus, XiReactionRate, writeCellVolumes, writeCellCentres, wallShearStress, wallHeatTransferCoeff, wallHeatFlux, uniform, turbulenceIntensity, turbulenceFields, totalEnthalpy, streamlines, shearStress, regionSizeDistribution, readFields, processorField, power, patchCutLayerAverage, nearWallFields, layerAverage, interfaceHeight, histogram, fieldValueDelta, fieldValue, fieldsExpression, fieldExpression, fieldCoordinateSystemTransform, fieldAverage, cutLayerAverage, comfort, bXiProgress, age, fvModel, Qdot, adjustTimeStepToCombustion, writeVTK, wallBoilingProperty, populationBalanceSizeDistribution, populationBalanceSetSizeDistribution, populationBalanceMoments, phaseMap, phaseForces, adjustTimeStepToNucleation, and fluidMaxDeltaT.

◆ write()

virtual bool write ( )

pure virtual

Called at each ++ or += of the time-loop.

foamPostProcess overrides the usual writeControl behaviour and forces writing always (used in post-processing mode)

Implemented in moleFractions, massFractions, specieReactionRates, reactionRates, adjustTimeStepToChemistry, sampledSurfaces, sampledSets, probes, patchProbes, sixDoFRigidBodyState, rigidBodyState, rigidBodyPoints, timeControl, LagrangianFieldValue, LagrangianDistribution, particles, dsmcFields, cloudInfo, cloudVolumeFraction, cloudVolume, cloudSurfaceDistribution, cloudSurfaceAreaPerUnitVolume, cloudSurfaceArea, cloudMass, cloudLagrangianVolumeFraction, cloudKineticEnergy, cloudGravitationalPotentialEnergy, cloudFlux, cloudBoundaryCollisionFlux, cloudAge, cloud, meshToMeshAdjustTimeStep, multiValveEngineState, writeObjects, writeDictionary, userTimeStep, timeStep, timeActivatedFileUpdate, time, systemCall, stopAt, setWriteIntervalFunctionObject, setTimeStepFunctionObject, residuals, removeObjects, codedFunctionObject, checkMesh, scalarTransport, phaseScalarTransport, forcesBase, forceCoeffs, yPlus, XiReactionRate, writeCellVolumes, writeCellCentres, wallShearStress, wallHeatTransferCoeff, wallHeatFlux, uniform, turbulenceIntensity, turbulenceFields, totalEnthalpy, streamlines, shearStress, regionSizeDistribution, readFields, processorField, power, patchCutLayerAverage, nearWallFields, layerAverage, interfaceHeight, histogram, volFieldValue, surfaceFieldValue, fieldValueDelta, fieldValue, fieldsExpression, fieldExpression, fieldCoordinateSystemTransform, fieldAverage, cutLayerAverage, components, comfort, bXiProgress, age, fvModel, Qdot, adjustTimeStepToCombustion, writeVTK, wallBoilingProperty, populationBalanceSizeDistribution, populationBalanceSetSizeDistribution, populationBalanceMoments, phaseMap, phaseForces, adjustTimeStepToNucleation, and fluidMaxDeltaT.

◆ end()

bool end ( )

virtual

Called when Time::run() determines that the time-loop exits.

Reimplemented in timeControl, systemCall, stopAtFile, stopAt, codedFunctionObject, and interfaceHeight.

Definition at line 167 of file functionObject.C.

◆ timeToNextAction()

Foam::scalar timeToNextAction ( )

virtual

Called by Time::adjustTimeStep(). Allows the functionObject to.

insert a write time earlier than that already in use by the run time. Returns the write time, or vGreat.

Reimplemented in timeControl, and meshToMeshAdjustTimeStep.

Definition at line 173 of file functionObject.C.

◆ maxDeltaT()

Foam::scalar maxDeltaT ( ) const

virtual

Return the maximum time-step for stable operation.

Reimplemented in adjustTimeStepToChemistry, fvModel, adjustTimeStepToCombustion, adjustTimeStepToNucleation, and fluidMaxDeltaT.

Definition at line 179 of file functionObject.C.

◆ movePoints()

void movePoints ( const polyMesh & mesh )

virtual

Update topology using the given map.

Reimplemented in timeControl, specieReactionRates, reactionRates, sampledSurfaces, sampledSets, probes, cloud, streamlines, patchCutLayerAverage, layerAverage, volFieldValue, surfaceFieldValue, cutLayerAverage, and populationBalanceSizeDistribution.

Definition at line 185 of file functionObject.C.

Referenced by surfaceFieldValue::movePoints(), and volFieldValue::movePoints().

Here is the caller graph for this function:

◆ topoChange()

void topoChange ( const polyTopoChangeMap & map )

virtual

Update topology using the given map.

Reimplemented in timeControl, cloudSurfaceDistribution, specieReactionRates, reactionRates, sampledSurfaces, sampledSets, probes, cloud, streamlines, patchCutLayerAverage, layerAverage, volFieldValue, surfaceFieldValue, cutLayerAverage, and populationBalanceSizeDistribution.

Definition at line 189 of file functionObject.C.

Referenced by surfaceFieldValue::topoChange(), and volFieldValue::topoChange().

Here is the caller graph for this function:

◆ mapMesh()

void mapMesh ( const polyMeshMap & )

virtual

Update from another mesh using the given map.

Reimplemented in specieReactionRates, reactionRates, sampledSurfaces, sampledSets, probes, timeControl, cloudSurfaceDistribution, cloud, streamlines, patchCutLayerAverage, layerAverage, volFieldValue, surfaceFieldValue, cutLayerAverage, and populationBalanceSizeDistribution.

Definition at line 193 of file functionObject.C.

Referenced by surfaceFieldValue::mapMesh(), and volFieldValue::mapMesh().

Here is the caller graph for this function:

◆ distribute()

void distribute ( const polyDistributionMap & )

virtual

Redistribute or update using the given distribution map.

Reimplemented in specieReactionRates, reactionRates, sampledSurfaces, sampledSets, timeControl, cloudSurfaceDistribution, cloud, streamlines, patchCutLayerAverage, layerAverage, volFieldValue, surfaceFieldValue, cutLayerAverage, and populationBalanceSizeDistribution.

Definition at line 197 of file functionObject.C.

Referenced by surfaceFieldValue::distribute(), and volFieldValue::distribute().

Here is the caller graph for this function:

◆ operator=()

void operator= ( const functionObject & )

delete

Disallow default bitwise assignment.

Member Data Documentation

◆ time_

const Time& time_

protected

Reference to time.

Definition at line 258 of file functionObject.H.

Referenced by nearWallFields::calcAddressing(), movingForces::CofR(), nearWallFields::createFields(), readFields::loadField(), turbulenceFields::processField(), and fieldAverage::readMeanFieldType().

◆ postProcess

bool postProcess

static

Global post-processing mode switch.

Definition at line 269 of file functionObject.H.

Referenced by CloudFunctionObjectList< CloudType >::CloudFunctionObjectList(), fieldAverage::execute(), functions::functions(), and populationBalanceSetSizeDistribution::write().

◆ log

Switch log

Switch write log to Info.

Definition at line 272 of file functionObject.H.

◆ executeAtStart_

Switch executeAtStart_

Switch execute at start time.

Definition at line 275 of file functionObject.H.

Referenced by fvModel::fvModel().

The documentation for this class was generated from the following files:

src/OpenFOAM/db/functionObjects/functionObject/functionObject.H
src/OpenFOAM/db/functionObjects/functionObject/functionObject.C
