Performs a file copy/replacement once a specified time has been reached. More...

Inheritance diagram for timeActivatedFileUpdate:

Collaboration diagram for timeActivatedFileUpdate:

Public Member Functions
	TypeName ("timeActivatedFileUpdate")
	Runtime type information. More...

	timeActivatedFileUpdate (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

virtual	~timeActivatedFileUpdate ()
	Destructor. More...

virtual bool	read (const dictionary &)
	Read the timeActivatedFileUpdate data. More...

virtual wordList	fields () const
	Return the list of fields required. More...

virtual bool	execute ()
	Execute file updates. More...

virtual bool	write ()
	Do nothing. More...

Public Member Functions inherited from functionObject
	ClassName ("functionObject")

virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const Time &runTime)
	Construct from components. More...

	functionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from dictionary. More...

autoPtr< functionObject >	clone () const
	Return clone. More...

	functionObject (const functionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~functionObject ()
	Destructor. More...

const word &	name () const
	Return the name of this functionObject. More...

virtual bool	executeAtStart () const
	Return true if the functionObject should be executed at the start. More...

virtual bool	end ()
	Called when Time::run() determines that the time-loop exits. More...

virtual scalar	timeToNextAction ()
	Called by Time::adjustTimeStep(). Allows the functionObject to. More...

virtual scalar	maxDeltaT () const
	Return the maximum time-step for stable operation. More...

virtual void	movePoints (const polyMesh &mesh)
	Update topology using the given map. More...

virtual void	topoChange (const polyTopoChangeMap &map)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

void	operator= (const functionObject &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &, const dictionary &)
	Select from dictionary, based on its "type" entry. More...

Public Attributes inherited from functionObject
Switch	log
	Switch write log to Info. More...

Switch	executeAtStart_
	Switch execute at start time. More...

Static Public Attributes inherited from functionObject
static bool	postProcess
	Global post-processing mode switch. More...

Protected Attributes inherited from functionObject
const Time &	time_
	Reference to time. More...

Detailed Description

Performs a file copy/replacement once a specified time has been reached.

Usage

Example usage to update the fvSolution dictionary at 0.1, 0.2 and 0.3s during the run:

fileUpdate1
{
    type            timeActivatedFileUpdate;

    libs            ("libutilityFunctionObjects.so");

    writeControl    timeStep;
    writeInterval   1;
    fileToUpdate    "$FOAM_CASE/system/fvSolution";
    fileVsTime
    (
        (-1 "$FOAM_CASE/system/fvSolution.0")
        (0.10 "$FOAM_CASE/system/fvSolution.10")
        (0.20 "$FOAM_CASE/system/fvSolution.20")
        (0.35 "$FOAM_CASE/system/fvSolution.35")
    );
}

Source files

Definition at line 78 of file timeActivatedFileUpdate.H.
