Mesh consisting of general polyhedral cells. More...

Inheritance diagram for polyMesh:

[legend]

Collaboration diagram for polyMesh:

[legend]

Public Types
enum	readUpdateState { UNCHANGED , POINTS_MOVED , TOPO_CHANGE , TOPO_PATCH_CHANGE }
	Enumeration defining the state of the mesh after a read update. More...

enum	cellDecomposition { FACE_PLANES , FACE_CENTRE_TRIS , FACE_DIAG_TRIS , CELL_TETS }
	Enumeration defining the decomposition of the cell for. More...

typedef polyMesh	Mesh

typedef polyBoundaryMesh	BoundaryMesh

Public Types inherited from IOobject
enum	objectState { GOOD , BAD }
	Enumeration defining the valid states of an IOobject. More...

enum	readOption { MUST_READ , MUST_READ_IF_MODIFIED , READ_IF_PRESENT , NO_READ }
	Enumeration defining the read options. More...

enum	writeOption { AUTO_WRITE = 0 , NO_WRITE = 1 }
	Enumeration defining the write options. More...

enum	fileCheckTypes { timeStamp , timeStampMaster , inotify , inotifyMaster }
	Enumeration defining the file checking options. More...

Public Types inherited from HashTable< regIOobject * >
typedef regIOobject *	value_type
	Type of values the HashTable contains. More...

typedef regIOobject * &	reference
	Type that can be used for storing into HashTable::value_type. More...

typedef const regIOobject * &	const_reference
	Type that can be used for storing into constant. More...

typedef label	size_type
	The type that can represent the size of a HashTable. More...

Public Member Functions
	TypeName ("polyMesh")
	Runtime type information. More...

	polyMesh (const IOobject &io)
	Construct from IOobject. More...

	polyMesh (const IOobject &io, pointField &&points, faceList &&faces, labelList &&owner, labelList &&neighbour, const bool syncPar=true)
	Move construct from IOobject or from components. More...

	polyMesh (const IOobject &io, pointField &&points, faceList &&faces, cellList &&cells, const bool syncPar=true)
	Move construct without boundary with cells rather than. More...

	polyMesh (const IOobject &io, pointField &&points, const cellShapeList &shapes, const faceListList &boundaryFaces, const wordList &boundaryPatchNames, const wordList &boundaryPatchTypes, const word &defaultBoundaryPatchName, const word &defaultBoundaryPatchType, const wordList &boundaryPatchPhysicalTypes, const bool syncPar=true)
	Move construct from cell shapes. More...

	polyMesh (const IOobject &io, pointField &&points, const cellShapeList &shapes, const faceListList &boundaryFaces, const wordList &boundaryPatchNames, const PtrList< dictionary > &boundaryDicts, const word &defaultBoundaryPatchName, const word &defaultBoundaryPatchType, const bool syncPar=true)
	Move construct from cell shapes with patch information in dictionary. More...

	polyMesh (polyMesh &&)
	Move constructor. More...

	polyMesh (const polyMesh &)=delete
	Disallow default bitwise copy construction. More...

virtual	~polyMesh ()
	Destructor. More...

fileName	meshDir () const
	Return the local mesh directory (dbDir()/meshSubDir) More...

const fileName &	pointsInstance () const
	Return the current instance directory for points. More...

const fileName &	facesInstance () const
	Return the current instance directory for faces. More...

IOobject::writeOption	pointsWriteOpt () const
	Return the points write option. More...

IOobject::writeOption	facesWriteOpt () const
	Return the points write option. More...

void	setPointsInstance (const fileName &)
	Set the instance for the points files. More...

void	setInstance (const fileName &)
	Set the instance for mesh files. More...

virtual const pointField &	points () const
	Return raw points. More...

virtual const faceList &	faces () const
	Return raw faces. More...

virtual const labelList &	faceOwner () const
	Return face owner. More...

virtual const labelList &	faceNeighbour () const
	Return face neighbour. More...

virtual const pointField &	oldPoints () const
	Return old points for mesh motion. More...

virtual const pointField &	oldCellCentres () const
	Return old cell centres for mesh motion. More...

const polyBoundaryMesh &	boundaryMesh () const
	Return boundary mesh. More...

const boundBox &	bounds () const
	Return mesh bounding box. More...

const Vector< label > &	geometricD () const
	Return the vector of geometric directions in mesh. More...

label	nGeometricD () const
	Return the number of valid geometric dimensions in the mesh. More...

const Vector< label > &	solutionD () const
	Return the vector of solved-for directions in mesh. More...

label	nSolutionD () const
	Return the number of valid solved-for dimensions in the mesh. More...

const labelIOList &	tetBasePtIs () const
	Return the tetBasePtIs. More...

const indexedOctree< treeDataCell > &	cellTree () const
	Return the cell search tree. More...

const pointZoneList &	pointZones () const
	Return point zones. More...

const faceZoneList &	faceZones () const
	Return face zones. More...

const cellZoneList &	cellZones () const
	Return cell zones. More...

const globalMeshData &	globalData () const
	Return parallel info. More...

label	comm () const
	Return communicator used for parallel communication. More...

label &	comm ()
	Return communicator used for parallel communication. More...

const objectRegistry &	thisDb () const
	Return the object registry. More...

bool	moving () const
	Is mesh moving. More...

bool	topoChanged () const
	Has the mesh topology changed this time-step. More...

bool	changing () const
	Is mesh changing. More...

virtual void	setPoints (const pointField &)
	Reset the points. More...

virtual tmp< scalarField >	movePoints (const pointField &)
	Move points, returns volumes swept by faces in motion. More...

void	resetMotion () const
	Reset motion. More...

pointZoneList &	pointZones ()
	Return non-const access to the pointZones. More...

faceZoneList &	faceZones ()
	Return non-const access to the faceZones. More...

cellZoneList &	cellZones ()
	Return non-const access to the cellZones. More...

void	addPatches (const List< polyPatch * > &, const bool validBoundary=true)
	Add boundary patches. More...

void	addZones (const List< pointZone * > &pz, const List< faceZone * > &fz, const List< cellZone * > &cz)
	Add mesh zones. More...

virtual void	addPatch (const label insertPatchi, const polyPatch &patch)
	Add/insert single patch. More...

void	addedPatches ()
	Complete addition of single patches. More...

virtual void	reorderPatches (const labelUList &newToOld, const bool validBoundary)
	Reorder and trim existing patches. If validBoundary the new. More...

readUpdateState	readUpdate ()
	Update the mesh based on the mesh files saved in. More...

void	topoChangeZones (const polyTopoChangeMap &)
	Update zones using the given map. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &map)
	Redistribute or update using the given distribution map. More...

void	removeBoundary ()
	Remove boundary patches. More...

void	resetPrimitives (pointField &&points, faceList &&faces, labelList &&owner, labelList &&neighbour, const labelList &patchSizes, const labelList &patchStarts, const bool validBoundary=true)
	Reset mesh primitive data. Assumes all patch info correct. More...

void	swap (polyMesh &)
	Swap mesh. More...

void	printAllocated () const
	Print a list of all the currently allocated mesh data. More...

void	clearGeom ()
	Clear geometry. More...

void	clearAddressing (const bool isMeshUpdate=false)
	Clear addressing. More...

void	clearOut ()
	Clear all geometry and addressing unnecessary for CFD. More...

void	clearPrimitives ()
	Clear primitive data (points, faces and cells) More...

void	clearTetBasePtIs ()
	Clear tet base points. More...

void	clearCellTree ()
	Clear cell tree data. More...

void	removeFiles (const fileName &instanceDir) const
	Remove all files from mesh instance. More...

void	removeFiles () const
	Remove all files from mesh instance() More...

void	findCellFacePt (const point &p, label &celli, label &tetFacei, label &tetPti) const
	Find the cell, tetFacei and tetPti for point p. More...

void	findTetFacePt (const label celli, const point &p, label &tetFacei, label &tetPti) const
	Find the tetFacei and tetPti for point p in celli. More...

bool	pointInCell (const point &p, label celli, const cellDecomposition=CELL_TETS) const
	Test if point p is in the celli. More...

label	findCell (const point &p, const cellDecomposition=CELL_TETS) const
	Find cell enclosing this location and return index. More...

virtual bool	writeObject (IOstream::streamFormat fmt, IOstream::versionNumber ver, IOstream::compressionType cmp, const bool write=true) const
	Write the underlying polyMesh. More...

void	operator= (const polyMesh &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from objectRegistry
	TypeName ("objectRegistry")
	Declare type name for this IOobject. More...

	objectRegistry (const Time &db, const label nIoObjects=128)
	Construct the time objectRegistry given an initial estimate. More...

	objectRegistry (const IOobject &io, const fileName &dbDir, const label nIoObjects=128)
	Construct a sub-registry given an IObject to describe the registry. More...

	objectRegistry (const IOobject &io, const label nIoObjects=128)
	Construct a sub-registry given an IObject to describe the registry. More...

	objectRegistry (objectRegistry &&)=default
	Move constructor. More...

	objectRegistry (const objectRegistry &)=delete
	Disallow default bitwise copy construction. More...

virtual	~objectRegistry ()
	Destructor. More...

const Time &	time () const
	Return time. More...

const objectRegistry &	parent () const
	Return the parent objectRegistry. More...

const fileName &	dbDir () const
	Local directory path of this objectRegistry relative to the time. More...

fileName	path (const word &instance, const fileName &local="") const
	Return complete path with alternative instance and local. More...

wordList	toc (const word &className) const
	Return the list of names of IOobjects of given class name. More...

wordList	sortedToc (const word &className) const
	Return the sorted list of names of IOobjects of given class name. More...

template<class Type >
wordList	toc () const
	Return the list of names of the IOobjects of given type. More...

template<class Type >
wordList	toc (const wordRe &name) const
	Return the list of objects whose name matches the input regExp. More...

template<class Type >
wordList	toc (const wordReList &name) const
	Return the list of objects whose name matches the input regExp. More...

const objectRegistry &	subRegistry (const word &name, const bool forceCreate=false) const
	Lookup and return a const sub-objectRegistry. Optionally create. More...

template<class Type >
HashTable< const Type * >	lookupClass (const bool strict=false) const
	Lookup and return all objects of the given Type. More...

template<class Type >
HashTable< Type * >	lookupClass (const bool strict=false)
	Lookup and return all objects of the given Type. More...

template<class Type >
bool	foundObject (const word &name) const
	Is the named Type in registry. More...

template<class Type >
const Type &	lookupObject (const word &name) const
	Lookup and return the object of the given Type and name. More...

template<class Type >
Type &	lookupObjectRef (const word &name) const
	Lookup and return the object reference of the given Type. More...

template<class Type >
bool	foundType (const word &group=word::null) const
	Is the Type in registry. More...

template<class Type >
const Type &	lookupType (const word &group=word::null) const
	Lookup and return the object of the given Type. More...

label	getEvent () const
	Return new event number. More...

const objectRegistry &	thisDb () const
	Return the object registry. More...

virtual void	rename (const word &newName)
	Rename. More...

bool	checkIn (regIOobject &) const
	Add an regIOobject to registry. More...

bool	checkOut (regIOobject &) const
	Remove an regIOobject from registry. More...

void	clear ()
	Remove all regIOobject owned by the registry. More...

bool	cacheTemporaryObject (const word &name) const
	Return true if given name is in the cacheTemporaryObjects set. More...

template<class Object >
bool	cacheTemporaryObject (Object &ob) const
	Cache the given object. More...

void	resetCacheTemporaryObject (const regIOobject &ob) const
	Reset the cache state of the given object. More...

bool	checkCacheTemporaryObjects () const
	Check that all objects in the cacheTemporaryObjects set. More...

virtual bool	modified () const
	Return true if any of the object's files have been modified. More...

virtual bool	dependenciesModified () const
	Cache pointers to objects who's dependencies have been modified. More...

virtual bool	readIfModified ()
	Read object if modified. More...

virtual bool	read ()
	Read dependent objects. More...

void	readModifiedObjects ()
	Read the objects that have been modified. More...

void	printToc (Ostream &os) const
	Print the list of object names and their type. More...

virtual bool	writeData (Ostream &) const
	writeData function required by regIOobject but not used More...

void	operator= (const objectRegistry &)=delete
	Disallow default bitwise assignment. More...

template<class Type >
Foam::wordList	toc () const

template<class Type >
Foam::wordList	toc (const wordRe &name) const

template<class Type >
Foam::wordList	toc (const wordReList &patterns) const

template<class Type >
Foam::HashTable< const Type * >	lookupClass (const bool strict) const

template<class Type >
Foam::HashTable< Type * >	lookupClass (const bool strict)

fileName	path () const
	Return complete path. More...

Public Member Functions inherited from regIOobject
	TypeName ("regIOobject")
	Runtime type information. More...

	regIOobject (const IOobject &, const bool isTime=false)
	Construct from IOobject. Optional flag for if IOobject is the. More...

	regIOobject (const regIOobject &)
	Copy constructor. More...

	regIOobject (regIOobject &&)
	Move constructor. More...

	regIOobject (const regIOobject &, bool registerCopy)
	Copy constructor, transferring registry registration to copy. More...

	regIOobject (const word &newName, const regIOobject &, bool registerCopy)
	Copy constructor with new name, transferring registry registration. More...

	regIOobject (const IOobject &, const regIOobject &)
	Copy constructor with new IO parameters. More...

virtual	~regIOobject ()
	Destructor. More...

virtual bool	global () const
	Return true if object is global, i.e. same for all processors. More...

virtual bool	globalFile () const
	Return true if object is global, i.e. same for all processors. More...

const fileName &	caseName () const

fileName	path () const
	Return complete path. More...

fileName	objectPath () const
	Return complete path + object name. More...

fileName	filePath () const
	Return complete path + object name if the file exists. More...

bool	checkIn ()
	Add object to registry. More...

bool	checkOut ()
	Remove object from registry. More...

void	addWatch ()
	Add file watch on object (if registered and READ_IF_MODIFIED) More...

bool	registered () const
	Is this object registered with the registry? More...

bool	ownedByRegistry () const
	Is this object owned by the registry? More...

void	store ()
	Transfer ownership of this object to its registry. More...

void	release ()
	Release ownership of this object from its registry. More...

label	eventNo () const
	Event number at last update. More...

label &	eventNo ()
	Event number at last update. More...

bool	upToDate (const regIOobject &) const
	Return true if up-to-date with respect to given object. More...

bool	upToDate (const regIOobject &, const regIOobject &) const
	Return true if up-to-date with respect to given objects. More...

bool	upToDate (const regIOobject &, const regIOobject &, const regIOobject &) const
	Return true if up-to-date with respect to given objects. More...

bool	upToDate (const regIOobject &, const regIOobject &, const regIOobject &, const regIOobject &) const
	Return true if up-to-date with respect to given objects. More...

void	setUpToDate ()
	Set up to date (obviously) More...

bool	headerOk ()
	Read and check header info. More...

Istream &	readStream (const word &, const bool read=true)
	Return Istream and check object type against that given. More...

void	close ()
	Close Istream. More...

virtual bool	readData (Istream &)
	Virtual readData function. More...

const labelList &	watchIndices () const
	Return file-monitoring handles. More...

labelList &	watchIndices ()
	Return file-monitoring handles. More...

virtual bool	write (const bool write=true) const
	Write using setting from DB. More...

void	operator= (const IOobject &)=delete
	Assign to IOobject. More...

void	operator= (const regIOobject &)=delete
	Disallow default assignment. More...

const fileName &	caseName (const bool global) const

fileName	path (const bool global) const
	Return complete path including the processor sub-directory. More...

fileName	objectPath (const bool global) const
	Return complete path + object name including the processor. More...

fileName	filePath (const bool global) const
	Return complete path + object name if the file exists. More...

Public Member Functions inherited from IOobject
	TypeName ("IOobject")
	Runtime type information. More...

	IOobject (const word &name, const fileName &instance, const objectRegistry &registry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true)
	Construct from name, instance, registry, io options. More...

	IOobject (const word &name, const fileName &instance, const fileName &local, const objectRegistry &registry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true)
	Construct from name, instance, local, registry, io options. More...

	IOobject (const fileName &path, const objectRegistry &registry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true)
	Construct from path, registry, io options. More...

	IOobject (const IOobject &io, const objectRegistry &registry)
	Construct from copy resetting registry. More...

	IOobject (const IOobject &io, const word &name)
	Construct from copy resetting name. More...

	IOobject (const IOobject &io)=default
	Copy constructor. More...

autoPtr< IOobject >	clone () const
	Clone. More...

autoPtr< IOobject >	clone (const objectRegistry &registry) const
	Clone resetting registry. More...

virtual	~IOobject ()
	Destructor. More...

const Time &	time () const
	Return time. More...

const objectRegistry &	db () const
	Return the local objectRegistry. More...

const word &	name () const
	Return name. More...

const word &	headerClassName () const
	Return name of the class name read from header. More...

word &	headerClassName ()
	Return name of the class name read from header. More...

string &	note ()
	Return non-constant access to the optional note. More...

const string &	note () const
	Return the optional note. More...

bool &	registerObject ()
	Register object created from this IOobject with registry if true. More...

bool	registerObject () const
	Register object created from this IOobject with registry if true. More...

readOption	readOpt () const

readOption &	readOpt ()

writeOption	writeOpt () const

writeOption &	writeOpt ()

word	group () const
	Return group (extension part of name) More...

word	member () const
	Return member (name without the extension) More...

const fileName &	rootPath () const

const fileName &	caseName (const bool global) const

fileName &	instance () const
	Return the instance directory, constant, system, <time> etc. More...

void	updateInstance () const
	If the instance is a time directory update to the current time. More...

void	updateTimeInstance () const
	Update instance to the current time. More...

const fileName &	local () const

fileName	path (const bool global) const
	Return complete path including the processor sub-directory. More...

fileName	objectPath (const bool global) const
	Return complete path + object name including the processor. More...

fileName	relativePath () const
	Return the path relative to the case directory. More...

fileName	relativeObjectPath () const
	Return complete relativePath + object name. More...

fileName	filePath (const bool global) const
	Return complete path + object name if the file exists. More...

bool	readHeader (Istream &)
	Read header. More...

bool	headerOk ()
	Read header of local object without type-checking. More...

template<class Type >
void	warnNoRereading () const
	Helper: warn that type does not support re-reading. More...

bool	writeHeader (Ostream &) const
	Write header. More...

bool	writeHeader (Ostream &, const word &objectType) const
	Write header. Allow override of type. More...

bool	good () const

bool	bad () const

InfoProxy< IOobject >	info () const
	Return info proxy. More...

void	operator= (const IOobject &)

template<class Name >
Foam::word	groupName (Name name, const word &group)

Public Member Functions inherited from HashTable< regIOobject * >
bool	set (const word &, const regIOobject * &newElmt)
	Set a new hashedEntry, overwriting existing entries. More...

void	set (const HashTable< regIOobject *, word, string::hash > &)
	Insert all the entries from the given HashTable,. More...

	HashTable (const label size=128)
	Construct given initial table size. More...

	HashTable (Istream &, const label size=128)
	Construct from Istream. More...

	HashTable (const UList< word > &keyList, const UList< regIOobject * > &elmtList)
	Construct from a list of keys and list of elements. More...

	HashTable (const HashTable< regIOobject *, word, string::hash > &)
	Copy constructor. More...

	HashTable (HashTable< regIOobject *, word, string::hash > &&)
	Move constructor. More...

	HashTable (std::initializer_list< Tuple2< word, regIOobject * >>)
	Construct from an initialiser list. More...

	~HashTable ()
	Destructor. More...

label	capacity () const
	The size of the underlying table. More...

label	size () const
	Return number of elements in table. More...

bool	empty () const
	Return true if the hash table is empty. More...

bool	found (const word &) const
	Return true if hashedEntry is found in table. More...

iterator	find (const word &)
	Find and return an iterator set at the hashedEntry. More...

const_iterator	find (const word &) const
	Find and return an const_iterator set at the hashedEntry. More...

List< word >	toc () const
	Return the table of contents. More...

List< word >	sortedToc () const
	Return the table of contents as a sorted list. More...

List< const_iterator >	sorted () const
	Return a sorted list of constant iterators. More...

Ostream &	printInfo (Ostream &) const
	Print information. More...

bool	insert (const word &, const regIOobject * &newElmt)
	Insert a new hashedEntry. More...

void	insert (const HashTable< regIOobject *, word, string::hash > &)
	Insert all the entries from the given HashTable. More...

bool	erase (const iterator &)
	Erase a hashedEntry specified by given iterator. More...

bool	erase (const word &)
	Erase a hashedEntry specified by the given key. More...

label	erase (const UList< word > &)
	Remove entries given by the listed keys from this HashTable. More...

label	erase (const HashTable< AnyType, word, AnyHash > &)
	Remove entries given by the given keys from this HashTable. More...

Foam::label	erase (const HashTable< AnyType, word, AnyHash > &rhs)

void	resize (const label newSize)
	Resize the hash table for efficiency. More...

void	clear ()
	Clear all entries from table. More...

void	clearStorage ()
	Clear the table entries and the table itself. More...

void	shrink ()
	Shrink the allocated table to approx. twice number of elements. More...

void	transfer (HashTable< regIOobject *, word, string::hash > &)
	Transfer the contents of the argument table into this table. More...

regIOobject * &	operator[] (const word &)
	Find and return a hashedEntry. More...

const regIOobject * &	operator[] (const word &) const
	Find and return a hashedEntry. More...

regIOobject * &	operator() (const word &)
	Find and return a hashedEntry, create it null if not present. More...

void	operator= (const HashTable< regIOobject *, word, string::hash > &)
	Assignment operator. More...

void	operator= (HashTable< regIOobject *, word, string::hash > &&)
	Move assignment operator. More...

void	operator= (std::initializer_list< Tuple2< word, regIOobject * >>)
	Assignment to an initialiser list. More...

bool	operator== (const HashTable< regIOobject *, word, string::hash > &) const
	Equality. Hash tables are equal if the keys and values are equal. More...

bool	operator!= (const HashTable< regIOobject *, word, string::hash > &) const
	The opposite of the equality operation. Takes linear time. More...

iterator	begin ()
	Iterator set to the beginning of the HashTable. More...

const_iterator	begin () const
	const_iterator set to the beginning of the HashTable More...

const_iterator	cbegin () const
	const_iterator set to the beginning of the HashTable More...

Public Member Functions inherited from HashTableCore
	HashTableCore ()
	Construct null. More...

	ClassName ("HashTable")
	Define template name and debug. More...

Public Member Functions inherited from primitiveMesh
	ClassName ("primitiveMesh")
	Runtime type information. More...

	primitiveMesh (const label nPoints, const label nInternalFaces, const label nFaces, const label nCells)
	Construct from components. More...

	primitiveMesh (primitiveMesh &&)=default
	Move constructor. More...

	primitiveMesh (const primitiveMesh &)=delete
	Disallow default bitwise copy construction. More...

virtual	~primitiveMesh ()
	Destructor. More...

void	reset (const label nPoints, const label nInternalFaces, const label nFaces, const label nCells)
	Reset this primitiveMesh given the primitive array sizes. More...

void	reset (const label nPoints, const label nInternalFaces, const label nFaces, const label nCells, cellList &cells)
	Reset this primitiveMesh given the primitive array sizes and cells. More...

void	reset (const label nPoints, const label nInternalFaces, const label nFaces, const label nCells, cellList &&cells)
	Reset this primitiveMesh given the primitive array sizes and cells. More...

label	nPoints () const

label	nEdges () const

label	nInternalFaces () const

label	nFaces () const

label	nCells () const

label	nInternalPoints () const
	Points not on boundary. More...

label	nInternal0Edges () const
	Internal edges (i.e. not on boundary face) using. More...

label	nInternal1Edges () const
	Internal edges using 0 or 1 boundary point. More...

label	nInternalEdges () const
	Internal edges using 0,1 or 2 boundary points. More...

const cellShapeList &	cellShapes () const
	Return cell shapes. More...

const edgeList &	edges () const
	Return mesh edges. Uses calcEdges. More...

const labelListList &	cellCells () const

const labelListList &	edgeCells () const

const labelListList &	pointCells () const

const cellList &	cells () const

const labelListList &	edgeFaces () const

const labelListList &	pointFaces () const

const labelListList &	cellEdges () const

const labelListList &	faceEdges () const

const labelListList &	pointEdges () const

const labelListList &	pointPoints () const

const labelListList &	cellPoints () const

const vectorField &	cellCentres () const

const vectorField &	faceCentres () const

const scalarField &	cellVolumes () const

const vectorField &	faceAreas () const

const scalarField &	magFaceAreas () const

tmp< scalarField >	movePoints (const pointField &p, const pointField &oldP)
	Move points, returns volumes swept by faces in motion. More...

bool	isInternalFace (const label faceIndex) const
	Return true if given face label is internal to the mesh. More...

bool	pointInCellBB (const point &p, label celli, scalar inflationFraction=0) const
	Return true if the point in the cell bounding box. More...

bool	pointInCell (const point &p, label celli) const
	Return true if the point is in the cell. More...

label	findNearestCell (const point &location) const
	Find the cell with the nearest cell centre to location. More...

label	findCell (const point &location) const
	Find cell enclosing this location (-1 if not in mesh) More...

void	printAllocated () const
	Print a list of all the currently allocated mesh data. More...

template<class Type >
bool	has (const Type &(primitiveMesh::*method)() const) const
	Return whether the result of the given method has been allocated. More...

const labelList &	cellCells (const label celli, DynamicList< label > &) const
	cellCells using cells. More...

const labelList &	cellCells (const label celli) const

const labelList &	cellPoints (const label celli, DynamicList< label > &) const
	cellPoints using cells More...

const labelList &	cellPoints (const label celli) const

const labelList &	pointCells (const label pointi, DynamicList< label > &) const
	pointCells using pointFaces More...

const labelList &	pointCells (const label pointi) const

const labelList &	pointPoints (const label pointi, DynamicList< label > &) const
	pointPoints using edges, pointEdges More...

const labelList &	pointPoints (const label pointi) const

const labelList &	faceEdges (const label facei, DynamicList< label > &) const
	faceEdges using pointFaces, edges, pointEdges More...

const labelList &	faceEdges (const label facei) const

const labelList &	edgeFaces (const label edgeI, DynamicList< label > &) const
	edgeFaces using pointFaces, edges, pointEdges More...

const labelList &	edgeFaces (const label edgeI) const

const labelList &	edgeCells (const label edgeI, DynamicList< label > &) const
	edgeCells using pointFaces, edges, pointEdges More...

const labelList &	edgeCells (const label edgeI) const

const labelList &	cellEdges (const label celli, DynamicList< label > &) const
	cellEdges using cells, pointFaces, edges, pointEdges More...

const labelList &	cellEdges (const label celli) const

void	clearGeom ()
	Clear geometry. More...

void	clearAddressing ()
	Clear topological data. More...

void	clearOut ()
	Clear all geometry and addressing unnecessary for CFD. More...

void	operator= (const primitiveMesh &)=delete
	Disallow default bitwise assignment. More...

Static Public Member Functions
static bool	found (const IOobject &io)
	Return whether the given IOobject relates to a mesh on disk. More...

Static Public Member Functions inherited from regIOobject
template<class Type >
static Type &	store (Type *)
	Transfer ownership of the given object pointer to its registry. More...

template<class Type >
static Type &	store (autoPtr< Type > &)
	Transfer ownership of the given object pointer to its registry. More...

Static Public Member Functions inherited from IOobject
static bool	fileNameComponents (const fileName &path, fileName &instance, fileName &local, word &name)
	Split path into instance, local, name components. More...

template<class Name >
static word	groupName (Name name, const word &group)

static word	group (const word &name)
	Return group (extension part of name) More...

static word	member (const word &name)
	Return member (name without the extension) More...

template<class Stream >
static Stream &	writeBanner (Stream &os, bool noHint=false)
	Write the standard OpenFOAM file/dictionary banner. More...

template<class Stream >
static Stream &	writeDivider (Stream &os)
	Write the standard file section divider. More...

template<class Stream >
static Stream &	writeEndDivider (Stream &os)
	Write the standard end file divider. More...

Static Public Member Functions inherited from HashTableCore
static label	canonicalSize (const label)
	Return a canonical (power-of-two) size. More...

static iteratorEnd	cend ()
	iteratorEnd set to beyond the end of any HashTable More...

static iteratorEnd	end ()
	iteratorEnd set to beyond the end of any HashTable More...

Static Public Member Functions inherited from primitiveMesh
static void	calcCells (cellList &, const labelUList &own, const labelUList &nei, const label nCells=-1)
	Helper function to calculate cell-face addressing from. More...

static bool	calcPointOrder (label &nInternalPoints, labelList &pointMap, const faceList &, const label nInternalFaces, const label nPoints)
	Helper function to calculate point ordering. Returns true. More...

Static Public Attributes
static word	defaultRegion = "region0"
	Return the default region name. More...

static word	meshSubDir = "polyMesh"
	Return the mesh sub-directory name (usually "polyMesh") More...

Static Public Attributes inherited from regIOobject
static float	fileModificationSkew

Static Public Attributes inherited from IOobject
static constexpr const char *	foamFile = "FoamFile"
	Keyword for the FoamFile header sub-dictionary. More...

static const NamedEnum< fileCheckTypes, 4 >	fileCheckTypesNames

static fileCheckTypes	fileModificationChecking
	Type of file modification checking. More...

Static Public Attributes inherited from HashTableCore
static const label	maxTableSize
	Maximum allowable table size. More...

Static Public Attributes inherited from primitiveMesh
static const unsigned	cellsPerEdge_ = 4
	Estimated number of cells per edge. More...

static const unsigned	cellsPerPoint_ = 8
	Estimated number of cells per point. More...

static const unsigned	facesPerCell_ = 6
	Estimated number of faces per cell. More...

static const unsigned	facesPerEdge_ = 4
	Estimated number of faces per edge. More...

static const unsigned	facesPerPoint_ = 12
	Estimated number of faces per point. More...

static const unsigned	edgesPerCell_ = 12
	Estimated number of edges per cell. More...

static const unsigned	edgesPerFace_ = 4
	Estimated number of edges per cell. More...

static const unsigned	edgesPerPoint_ = 6
	Estimated number of edges per point. More...

static const unsigned	pointsPerCell_ = 8
	Estimated number of points per cell. More...

static const unsigned	pointsPerFace_ = 4
	Estimated number of points per face. More...

Protected Attributes
bool	moving_
	Member data pending transfer to fvMesh. More...

bool	topoChanged_
	Has the mesh topology changed. More...

Additional Inherited Members
Protected Member Functions inherited from regIOobject
bool	readHeaderOk (const IOstream::streamFormat defaultFormat, const word &typeName)
	Read header, check readOpt flags and read data if necessary. More...

Protected Member Functions inherited from IOobject
template<class Type >
bool	typeHeaderOk (const bool checkType)
	Read header using typeGlobalFile to find file. More...

Protected Member Functions inherited from primitiveMesh
	primitiveMesh ()
	Construct null. More...

Static Protected Member Functions inherited from primitiveMesh
template<class Class , class Type >
static bool	isMethod (const Type &(Class::method)() const, const Type &(Class::otherMethod)() const)
	Test if the supplied methods are the same. Same type overload. More...

template<class Class , class Type , class OtherType >
static bool	isMethod (const Type &(Class::method)() const, const OtherType &(Class::otherMethod)() const)
	Test if the supplied methods are the same. Different type. More...

Detailed Description

Mesh consisting of general polyhedral cells.

Source files

Definition at line 76 of file polyMesh.H.

Member Typedef Documentation

◆ Mesh

typedef polyMesh Mesh

Definition at line 259 of file polyMesh.H.

◆ BoundaryMesh

typedef polyBoundaryMesh BoundaryMesh

Definition at line 260 of file polyMesh.H.

Member Enumeration Documentation

◆ readUpdateState

enum readUpdateState

Enumeration defining the state of the mesh after a read update.

Used for post-processing applications, where the mesh needs to update based on the files written in time directories.

Enumerator
UNCHANGED
POINTS_MOVED
TOPO_CHANGE
TOPO_PATCH_CHANGE

Definition at line 89 of file polyMesh.H.

◆ cellDecomposition

enum cellDecomposition

Enumeration defining the decomposition of the cell for.

inside/outside test

Enumerator
FACE_PLANES
FACE_CENTRE_TRIS
FACE_DIAG_TRIS
CELL_TETS

Definition at line 99 of file polyMesh.H.

Constructor & Destructor Documentation

◆ polyMesh() [1/7]

polyMesh ( const IOobject & io )

explicit

Construct from IOobject.

Definition at line 176 of file polyMesh.C.

References Foam::complete, Foam::endl(), IOobject::headerClassName(), IOobject::instance(), polyMesh::meshSubDir, IOobject::MUST_READ, primitiveMesh::nCells(), IOobject::NO_WRITE, primitiveMesh::nPoints(), UPstream::parRun(), TimePaths::processorCase(), ZoneList< ZoneType, ZonesType, MeshType >::readIfPresent(), Foam::returnReduce(), objectRegistry::time(), polyBoundaryMesh::topoChange(), WarningInFunction, and regIOobject::write().

Here is the call graph for this function:

◆ polyMesh() [2/7]

polyMesh	(	const IOobject &	io,
		pointField &&	points,
		faceList &&	faces,
		labelList &&	owner,
		labelList &&	neighbour,
		const bool	syncPar = `true`
	)

Move construct from IOobject or from components.

Boundary is added using addPatches() member function

Definition at line 368 of file polyMesh.C.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::max(), Foam::min(), and List< T >::size().

Here is the call graph for this function:

◆ polyMesh() [3/7]

polyMesh	(	const IOobject &	io,
		pointField &&	points,
		faceList &&	faces,
		cellList &&	cells,
		const bool	syncPar = `true`
	)

Move construct without boundary with cells rather than.

owner/neighbour. Boundary is added using addPatches() member function

Definition at line 519 of file polyMesh.C.

References Foam::abort(), primitiveMesh::cells(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::max(), Foam::min(), and List< T >::size().

Here is the call graph for this function:

◆ polyMesh() [4/7]

polyMesh	(	const IOobject &	io,
		pointField &&	points,
		const cellShapeList &	shapes,
		const faceListList &	boundaryFaces,
		const wordList &	boundaryPatchNames,
		const wordList &	boundaryPatchTypes,
		const word &	defaultBoundaryPatchName,
		const word &	defaultBoundaryPatchType,
		const wordList &	boundaryPatchPhysicalTypes,
		const bool	syncPar = `true`
	)

Move construct from cell shapes.

Definition at line 389 of file polyMeshFromShapeMesh.C.

References primitiveMesh::cells(), Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::findIndex(), forAll, Foam::Info, IOobject::instance(), IOobject::name(), polyPatch::New(), primitiveMesh::nFaces(), patchi, Foam::reduce(), polyMesh::removeFiles(), PtrList< T >::set(), PtrList< T >::setSize(), UPtrList< T >::size(), List< T >::size(), polyBoundaryMesh::topoChange(), and WarningInFunction.

Here is the call graph for this function:

◆ polyMesh() [5/7]

polyMesh	(	const IOobject &	io,
		pointField &&	points,
		const cellShapeList &	shapes,
		const faceListList &	boundaryFaces,
		const wordList &	boundaryPatchNames,
		const PtrList< dictionary > &	boundaryDicts,
		const word &	defaultBoundaryPatchName,
		const word &	defaultBoundaryPatchType,
		const bool	syncPar = `true`
	)

Move construct from cell shapes with patch information in dictionary.

format.

Definition at line 668 of file polyMeshFromShapeMesh.C.

References primitiveMesh::cells(), Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::findIndex(), forAll, Foam::Info, IOobject::instance(), IOobject::name(), polyPatch::New(), primitiveMesh::nFaces(), patchi, Foam::reduce(), polyMesh::removeFiles(), PtrList< T >::set(), PtrList< T >::setSize(), UPtrList< T >::size(), List< T >::size(), polyBoundaryMesh::topoChange(), Foam::type(), and WarningInFunction.

Here is the call graph for this function:

◆ polyMesh() [6/7]

polyMesh ( polyMesh && mesh )

Move constructor.

Definition at line 686 of file polyMesh.C.

◆ polyMesh() [7/7]

polyMesh ( const polyMesh & )

delete

Disallow default bitwise copy construction.

◆ ~polyMesh()

~polyMesh ( )

virtual

Destructor.

Definition at line 950 of file polyMesh.C.

Member Function Documentation

◆ TypeName()

TypeName ( "polyMesh" )

Runtime type information.

◆ found()

bool found ( const IOobject & io )

static

Return whether the given IOobject relates to a mesh on disk.

Definition at line 959 of file polyMesh.C.

References polyMesh::defaultRegion, Foam::fileHandler(), fileOperation::findInstance(), fileOperation::isDir(), IOobject::local(), IOobject::name(), dimensioned< Type >::name(), IOobject::NO_READ, word::null, IOobject::time(), and dimensioned< Type >::value().

Here is the call graph for this function:

◆ meshDir()

Foam::fileName meshDir ( ) const

Return the local mesh directory (dbDir()/meshSubDir)

Definition at line 982 of file polyMesh.C.

◆ pointsInstance()

const Foam::fileName & pointsInstance ( ) const

Return the current instance directory for points.

Used in the construction of geometric mesh data dependent on points

Definition at line 988 of file polyMesh.C.

Referenced by Foam::meshCheck::checkGeometry(), Foam::meshCheck::checkMeshOutputDir(), timeVaryingMappedFixedValuePointPatchField< Type >::checkTable(), Foam::meshCheck::checkTopology(), and if().

Here is the caller graph for this function:

◆ facesInstance()

const Foam::fileName & facesInstance ( ) const

Return the current instance directory for faces.

Definition at line 994 of file polyMesh.C.

Referenced by refinementHistoryConstraint::add(), refinementHistoryConstraint::apply(), timeVaryingMappedFixedValuePointPatchField< Type >::checkTable(), manual::decompose(), topoSet::localPath(), manualRenumber::renumber(), and hexRef8Data::topoChange().

Here is the caller graph for this function:

◆ pointsWriteOpt()

Foam::IOobject::writeOption pointsWriteOpt ( ) const

Return the points write option.

Definition at line 1000 of file polyMesh.C.

◆ facesWriteOpt()

Foam::IOobject::writeOption facesWriteOpt ( ) const

Return the points write option.

Definition at line 1006 of file polyMesh.C.

◆ setPointsInstance()

void setPointsInstance ( const fileName & inst )

Set the instance for the points files.

Definition at line 71 of file polyMeshIO.C.

References IOobject::AUTO_WRITE, Foam::endl(), and InfoInFunction.

Here is the call graph for this function:

◆ setInstance()

void setInstance ( const fileName & inst )

Set the instance for mesh files.

Definition at line 91 of file polyMeshIO.C.

References IOobject::AUTO_WRITE, Foam::endl(), and InfoInFunction.

Referenced by snappyLayerDriver::addLayers(), meshRefinement::mergePatchFacesUndo(), Foam::polyMeshZipUpCells(), and polyMesh::swap().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ points()

const Foam::pointField & points ( ) const

virtual

Return raw points.

Implements primitiveMesh.

Definition at line 1331 of file polyMesh.C.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ faces()

const Foam::faceList & faces ( ) const

virtual

Return raw faces.

Implements primitiveMesh.

Definition at line 1344 of file polyMesh.C.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

Here is the caller graph for this function:

◆ faceOwner()

const Foam::labelList & faceOwner ( ) const

virtual

Return face owner.

Implements primitiveMesh.

Definition at line 1357 of file polyMesh.C.

Here is the caller graph for this function:

◆ faceNeighbour()

const Foam::labelList & faceNeighbour ( ) const

virtual

Return face neighbour.

Implements primitiveMesh.

Definition at line 1363 of file polyMesh.C.

Here is the caller graph for this function:

◆ oldPoints()

const Foam::pointField & oldPoints ( ) const

virtual

Return old points for mesh motion.

Implements primitiveMesh.

Definition at line 1369 of file polyMesh.C.

References Foam::exit(), Foam::FatalError, and FatalErrorInFunction.

Referenced by volumeInjection::modify(), mappedPatchBaseBase::moving(), Foam::tracking::movingTetGeometry(), nonConformalCyclicPolyPatch::ray(), nonConformalCyclicPolyPatch::rays(), movingMappedWallVelocityFvPatchVectorField::updateCoeffs(), and movingWallVelocityFvPatchVectorField::updateCoeffs().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ oldCellCentres()

const Foam::pointField & oldCellCentres ( ) const

virtual

Return old cell centres for mesh motion.

Definition at line 1387 of file polyMesh.C.

References Foam::exit(), Foam::FatalError, and FatalErrorInFunction.

Referenced by Cloud< ParticleType >::Cloud(), LagrangianMesh::LagrangianMesh(), volumeInjection::modify(), and Foam::tracking::movingTetGeometry().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ boundaryMesh()

const polyBoundaryMesh& boundaryMesh ( ) const

inline

Return boundary mesh.

Definition at line 401 of file polyMesh.H.

Here is the caller graph for this function:

◆ bounds()

const boundBox& bounds ( ) const

inline

Return mesh bounding box.

Definition at line 407 of file polyMesh.H.

Referenced by Foam::meshCheck::checkGeometry(), Foam::meshCheck::checkMesh(), Foam::meshTools::constrainToMeshCentre(), Foam::tracking::crossWedge(), refinementParameters::findCells(), Kmesh::Kmesh(), cellsToCells::maskCells(), and streamlinesParticle::move().

Here is the caller graph for this function:

◆ geometricD()

const Foam::Vector< Foam::label > & geometricD ( ) const

Return the vector of geometric directions in mesh.

Defined according to the presence of empty and wedge patches. 1 indicates unconstrained direction and -1 a constrained direction.

Definition at line 1012 of file polyMesh.C.

Referenced by Foam::meshCheck::checkCellDeterminant(), Foam::meshCheck::checkGeometry(), Foam::meshTools::constrainToMeshCentre(), particle::deviationFromMeshCentre(), FitData< FitDataType, ExtendedStencil, Polynomial >::findFaceDirs(), and radiativeIntensityRay::radiativeIntensityRay().

Here is the caller graph for this function:

◆ nGeometricD()

Foam::label nGeometricD ( ) const

Return the number of valid geometric dimensions in the mesh.

Definition at line 1023 of file polyMesh.C.

References Foam::cmptSum().

Referenced by Foam::fvc::average(), Foam::meshCheck::checkGeometry(), FitData< FitDataType, ExtendedStencil, Polynomial >::findFaceDirs(), if(), InjectionModel< CloudType >::InjectionModel(), main(), MomentumCloud< CloudType >::preEvolve(), Foam::fvc::reconstruct(), streamFunction::streamFunction(), zeroDimensionalFixedPressureConstraint::zeroDimensionalFixedPressureConstraint(), zeroDimensionalFixedPressureModel::zeroDimensionalFixedPressureModel(), and zeroDimensionalMassSourceBase::zeroDimensionalMassSourceBase().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ solutionD()

const Foam::Vector< Foam::label > & solutionD ( ) const

Return the vector of solved-for directions in mesh.

Differs from geometricD in that it includes for wedge cases the circumferential direction in case of swirl. 1 indicates valid direction and -1 an invalid direction.

Definition at line 1029 of file polyMesh.C.

Referenced by MomentumParcel< ParcelType >::calcVelocity(), Foam::meshCheck::checkGeometry(), InjectionModel< CloudType >::inject(), InjectionModel< CloudType >::injectSteadyState(), DSMCParcel< ParcelType >::move(), CloudFilmTransfer< CloudType >::splashInteraction(), GradientDispersionRAS< CloudType >::update(), StochasticDispersionRAS< CloudType >::update(), and fvMesh::validComponents().

Here is the caller graph for this function:

◆ nSolutionD()

Foam::label nSolutionD ( ) const

Return the number of valid solved-for dimensions in the mesh.

Definition at line 1040 of file polyMesh.C.

References Foam::cmptSum().

Referenced by Foam::meshCheck::checkGeometry(), and radiativeIntensityRay::radiativeIntensityRay().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ tetBasePtIs()

const Foam::labelIOList & tetBasePtIs ( ) const

Return the tetBasePtIs.

Definition at line 1046 of file polyMesh.C.

References Foam::endl(), polyMeshTetDecomposition::findFaceBasePts(), IOobject::NO_READ, IOobject::NO_WRITE, and WarningInFunction.

Referenced by Foam::tracking::changeFace(), Cloud< ParticleType >::Cloud(), tetIndices::faceTriIs(), refinementParameters::findCells(), patchProbes::findElements(), LagrangianMesh::LagrangianMesh(), meshSearch::meshSearch(), and mappedInternalPatchBase::samplePoints().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ cellTree()

const Foam::indexedOctree< Foam::treeDataCell > & cellTree ( ) const

Return the cell search tree.

Definition at line 1080 of file polyMesh.C.

References Foam::e, and points.

Referenced by mappedInternalPatchBase::calcMapping(), LagrangianMesh::locate(), Foam::tracking::locate(), and tetOverlapVolume::overlappingCells().

Here is the caller graph for this function:

◆ pointZones() [1/2]

const pointZoneList& pointZones ( ) const

inline

Return point zones.

Definition at line 437 of file polyMesh.H.

Referenced by polyMeshAdder::add(), Foam::meshCheck::checkTopology(), polyTopoChange::makeMesh(), pointZoneSet::pointZoneSet(), fvMeshDistribute::printMeshInfo(), Foam::meshCheck::printMeshStats(), addPatchCellLayer::setRefinement(), and addPatchCellLayer::updateZones().

Here is the caller graph for this function:

◆ faceZones() [1/2]

const faceZoneList& faceZones ( ) const

inline

◆ cellZones() [1/2]

const cellZoneList& cellZones ( ) const

inline

Return cell zones.

Definition at line 449 of file polyMesh.H.

Referenced by polyMeshAdder::add(), cellTable::addCellZones(), surfaceZonesInfo::addCellZonesToMesh(), cellZoneSet::cellZoneSet(), Foam::meshCheck::checkTopology(), cutPolyIsoSurface::cutPolyIsoSurface(), zoneCombustion::filter(), interRegionPorosityForce::interRegionPorosityForce(), polyTopoChange::makeMesh(), multiSolidBodyMotionSolver::multiSolidBodyMotionSolver(), cellTable::operator=(), porosityModel::porosityModel(), powerLawLopesdaCostaZone::powerLawLopesdaCostaZone(), fvMeshDistribute::printMeshInfo(), Foam::meshCheck::printMeshStats(), constSolidThermo::readProperty(), ensightParts::recalculate(), sampledIsoSurfaceSurface::sampledIsoSurfaceSurface(), addPatchCellLayer::setRefinement(), CellZoneInjection< CloudType >::topoChange(), addPatchCellLayer::updateZones(), and zeroDimensionalMassSourceBase::zone().

Here is the caller graph for this function:

◆ globalData()

const Foam::globalMeshData & globalData ( ) const

Return parallel info.

Definition at line 1521 of file polyMesh.C.

References Foam::endl(), and Foam::Pout.

Referenced by structured::decompose(), decompositionMethod::decompose(), Dual< Type >::Dual(), PatchTools::edgeNormals(), PatchTools::gatherAndMerge(), pistonBowlPoints::generate(), syncTools::getMasterEdges(), syncTools::getMasterPoints(), globalIndexAndTransform::globalIndexAndTransform(), pointBoundaryMesh::movePoints(), polyBoundaryMesh::movePoints(), PatchEdgeFaceWave< PrimitivePatchType, Type, TrackingData >::PatchEdgeFaceWave(), mappedExtrudedPatchBase::patchFaceAreas(), mappedExtrudedPatchBase::patchLocalPoints(), PatchTools::pointNormals(), structuredRenumber::renumber(), motionSmootherAlgo::setDisplacement(), Foam::fvc::smooth(), syncTools::syncEdgeList(), syncTools::syncEdgeMap(), syncTools::syncPointList(), syncTools::syncPointMap(), pointBoundaryMesh::topoChange(), polyBoundaryMesh::topoChange(), distributor::update(), loadBalancer::update(), cellsToCellsStabilisation::update(), and FacePostProcessing< CloudType >::write().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ comm() [1/2]

Foam::label comm ( ) const

Return communicator used for parallel communication.

Definition at line 1539 of file polyMesh.C.

Referenced by fvMesh::comm(), and processorPolyPatch::comm().

Here is the caller graph for this function:

◆ comm() [2/2]

Foam::label & comm ( )

Return communicator used for parallel communication.

Definition at line 1545 of file polyMesh.C.

◆ thisDb()

const objectRegistry& thisDb ( ) const

inline

Return the object registry.

Definition at line 464 of file polyMesh.H.

Referenced by fvMesh::thisDb().

Here is the caller graph for this function:

◆ moving()

bool moving ( ) const

inline

Is mesh moving.

Definition at line 473 of file polyMesh.H.

References polyMesh::moving_.

Referenced by backwardDdtScheme< Type >::backwardDdtScheme(), Foam::tracking::coordinates(), CrankNicolsonDdtScheme< Type >::CrankNicolsonDdtScheme(), Foam::MULES::explicitSolve(), Foam::tracking::faceNormalAndDisplacement(), EulerD2dt2Scheme< Type >::fvcD2dt2(), backwardDdtScheme< Type >::fvcDdt(), backwardDdtScheme< Type >::fvmDdt(), Foam::MULES::limit(), volumeInjection::modify(), mappedPatchBaseBase::moving(), Foam::tracking::position(), compressibleVoF::pressureCorrector(), isothermalFluid::pressureWork(), shockFluid::thermophysicalPredictor(), movingMappedWallVelocityFvPatchVectorField::updateCoeffs(), movingWallSlipVelocityFvPatchVectorField::updateCoeffs(), movingWallVelocityFvPatchVectorField::updateCoeffs(), and noSlipFvPatchVectorField::updateCoeffs().

Here is the caller graph for this function:

◆ topoChanged()

bool topoChanged ( ) const

inline

Has the mesh topology changed this time-step.

Definition at line 479 of file polyMesh.H.

References polyMesh::topoChanged_.

Referenced by incompressibleDenseParticleFluid::motionCorrector(), incompressibleFluid::motionCorrector(), isothermalFluid::motionCorrector(), multiphaseEuler::motionCorrector(), shockFluid::motionCorrector(), VoFSolver::motionCorrector(), multiphaseEuler::moveMesh(), and VoFSolver::moveMesh().

Here is the caller graph for this function:

◆ changing()

bool changing ( ) const

inline

Is mesh changing.

Moving or mesh topology changed this time-step)

Definition at line 486 of file polyMesh.H.

Referenced by Foam::correctUphiBCs(), waveAlphaFvPatchScalarField::faceCellSubset(), waveVelocityFvPatchVectorField::faceCellSubset(), incompressibleDenseParticleFluid::motionCorrector(), incompressibleFluid::motionCorrector(), isothermalFluid::motionCorrector(), multiphaseEuler::motionCorrector(), shockFluid::motionCorrector(), and VoFSolver::motionCorrector().

Here is the caller graph for this function:

◆ setPoints()

void setPoints ( const pointField & newPoints )

virtual

Reset the points.

without storing old points or returning swept volumes

Reimplemented in fvMesh.

Definition at line 1407 of file polyMesh.C.

References primitiveMesh::clearGeom(), Foam::endl(), InfoInFunction, Foam::name(), and Foam::Zero.

Referenced by fvMesh::setPoints().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ movePoints()

Foam::tmp< Foam::scalarField > movePoints ( const pointField & newPoints )

virtual

Move points, returns volumes swept by faces in motion.

Reimplemented in fvMesh.

Definition at line 1449 of file polyMesh.C.

References Foam::endl(), InfoInFunction, primitiveMesh::movePoints(), Foam::name(), timeIndex, and Foam::Zero.

Referenced by fvMesh::movePoints().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ resetMotion()

void resetMotion ( ) const

Reset motion.

Definition at line 1513 of file polyMesh.C.

Referenced by polyMeshAdder::add().

Here is the caller graph for this function:

◆ pointZones() [2/2]

pointZoneList& pointZones ( )

inline

Return non-const access to the pointZones.

Definition at line 505 of file polyMesh.H.

◆ faceZones() [2/2]

faceZoneList& faceZones ( )

inline

Return non-const access to the faceZones.

Definition at line 511 of file polyMesh.H.

◆ cellZones() [2/2]

cellZoneList& cellZones ( )

inline

Return non-const access to the cellZones.

Definition at line 517 of file polyMesh.H.

◆ addPatches()

void addPatches	(	const List< polyPatch * > &	p,
		const bool	validBoundary = `true`
	)

Add boundary patches.

Definition at line 1106 of file polyMesh.C.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, forAll, p, and Foam::Zero.

Referenced by meshReader::mesh(), and Foam::polyMeshUnMergeCyclics().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ addZones()

void addZones	(	const List< pointZone * > &	pz,
		const List< faceZone * > &	fz,
		const List< cellZone * > &	cz
	)

Add mesh zones.

Definition at line 1144 of file polyMesh.C.

References Foam::abort(), IOobject::AUTO_WRITE, Foam::FatalError, FatalErrorInFunction, forAll, Foam::name(), and List< T >::size().

Referenced by polyTopoChange::makeMesh().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ addPatch()

void addPatch	(	const label	insertPatchi,
		const polyPatch &	patch
	)

virtual

Add/insert single patch.

Reimplemented in fvMesh.

Definition at line 1245 of file polyMesh.C.

References meshObjects::clearUpto(), and polyPatch::clone().

Referenced by polyMeshAdder::add(), and fvMesh::addPatch().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ addedPatches()

void addedPatches ( )

Complete addition of single patches.

Definition at line 1319 of file polyMesh.C.

Referenced by fvMeshTools::addedPatches().

Here is the caller graph for this function:

◆ reorderPatches()

void reorderPatches	(	const labelUList &	newToOld,
		const bool	validBoundary
	)

virtual

Reorder and trim existing patches. If validBoundary the new.

situation is consistent across processors

Reimplemented in fvMesh.

Definition at line 1202 of file polyMesh.C.

References meshObjects::clearUpto(), and Foam::name().

Referenced by polyMeshAdder::add(), and fvMesh::reorderPatches().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readUpdate()

Foam::polyMesh::readUpdateState readUpdate ( )

Update the mesh based on the mesh files saved in.

time directories

Definition at line 124 of file polyMeshIO.C.

References cells, Foam::clone(), Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::Info, InfoInFunction, IOobject::MUST_READ, Foam::name(), polyBoundaryMesh::names(), Foam::nl, IOobject::NO_WRITE, regIOobject::objectPath(), patchi, polyMesh::POINTS_MOVED, IOobject::READ_IF_PRESENT, UPtrList< T >::size(), List< T >::size(), polyMesh::TOPO_CHANGE, polyMesh::TOPO_PATCH_CHANGE, Foam::type(), polyBoundaryMesh::types(), polyMesh::UNCHANGED, autoPtr< T >::valid(), and Foam::Zero.

Referenced by fvMesh::readUpdate().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ topoChangeZones()

void topoChangeZones ( const polyTopoChangeMap & map )

Update zones using the given map.

Definition at line 39 of file polyMeshUpdate.C.

References ZoneList< ZoneType, ZonesType, MeshType >::topoChange().

Here is the call graph for this function:

◆ topoChange()

void topoChange ( const polyTopoChangeMap & map )

virtual

Update topology using the given map.

Reimplemented in fvMesh.

Definition at line 47 of file polyMeshUpdate.C.

References polyTopoChangeMap::cellMap(), Foam::endl(), forAll, InfoInFunction, Field< Type >::map(), Foam::name(), newPointi, polyTopoChangeMap::pointMap(), List< T >::setSize(), and Foam::Zero.

Referenced by fvMesh::topoChange().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ mapMesh()

void mapMesh ( const polyMeshMap & map )

virtual

Update from another mesh using the given map.

Reimplemented in fvMesh.

Definition at line 134 of file polyMeshUpdate.C.

Referenced by fvMesh::mapMesh().

Here is the caller graph for this function:

◆ distribute()

void distribute ( const polyDistributionMap & map )

virtual

Redistribute or update using the given distribution map.

Reimplemented in fvMesh.

Definition at line 146 of file polyMeshUpdate.C.

Referenced by fvMesh::distribute().

Here is the caller graph for this function:

◆ removeBoundary()

void removeBoundary ( )

Remove boundary patches.

Definition at line 36 of file polyMeshClear.C.

References PtrList< T >::clear(), polyMesh::clearOut(), Foam::endl(), InfoInFunction, and PtrList< T >::setSize().

Referenced by Foam::polyMeshUnMergeCyclics(), and fvMesh::removeFvBoundary().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ resetPrimitives()

void resetPrimitives	(	pointField &&	points,
		faceList &&	faces,
		labelList &&	owner,
		labelList &&	neighbour,
		const labelList &	patchSizes,
		const labelList &	patchStarts,
		const bool	validBoundary = `true`
	)

Reset mesh primitive data. Assumes all patch info correct.

(so does e.g. parallel communication). If not use validBoundary=false

Definition at line 715 of file polyMesh.C.

References Foam::abort(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::max(), Foam::min(), Foam::name(), Foam::notNull(), nPoints, patchi, points, Foam::returnReduce(), and List< T >::size().

Referenced by polyMeshAdder::add(), polyTopoChange::changeMesh(), and Foam::polyMeshZipUpCells().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ swap()

void swap ( polyMesh & otherMesh )

Swap mesh.

For run-time mesh replacement and mesh to mesh mapping

Definition at line 817 of file polyMesh.C.

References Foam::abort(), polyBoundaryMesh::clearAddressing(), polyMesh::clearAddressing(), polyBoundaryMesh::clearGeom(), Foam::clone(), Foam::FatalError, FatalErrorInFunction, forAll, objectRegistry::foundObject(), Foam::max(), mesh, Foam::min(), Foam::name(), DemandDrivenMeshObject< polyMesh, RepatchableMeshObject, pointMesh >::New(), patches, pointMesh::reset(), polyMesh::setInstance(), HashTable< T, Key, Hash >::size(), UPtrList< T >::size(), and polyBoundaryMesh::topoChange().

Referenced by fvMesh::swap().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ printAllocated()

void printAllocated ( ) const

Print a list of all the currently allocated mesh data.

Definition at line 53 of file polyMeshClear.C.

References Foam::endl(), Foam::Pout, and primitiveMesh::printAllocated().

Referenced by fvMesh::printAllocated().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ clearGeom()

void clearGeom ( )

Clear geometry.

Definition at line 71 of file polyMeshClear.C.

References primitiveMesh::clearGeom(), Foam::endl(), InfoInFunction, and Foam::Zero.

Referenced by fvMesh::clearGeom().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ clearAddressing()

void clearAddressing ( const bool isMeshUpdate = false )

Clear addressing.

Definition at line 95 of file polyMeshClear.C.

References primitiveMesh::clearAddressing(), meshObjects::clearUpto(), Foam::endl(), InfoInFunction, and Foam::Zero.

Referenced by polyMesh::swap().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ clearOut()

void clearOut ( )

Clear all geometry and addressing unnecessary for CFD.

Definition at line 168 of file polyMeshClear.C.

Referenced by fvMesh::clearOut(), and polyMesh::removeBoundary().

Here is the caller graph for this function:

◆ clearPrimitives()

void clearPrimitives ( )

Clear primitive data (points, faces and cells)

Definition at line 155 of file polyMeshClear.C.

◆ clearTetBasePtIs()

void clearTetBasePtIs ( )

Clear tet base points.

Definition at line 175 of file polyMeshClear.C.

References Foam::endl(), and InfoInFunction.

Here is the call graph for this function:

◆ clearCellTree()

void clearCellTree ( )

Clear cell tree data.

Definition at line 186 of file polyMeshClear.C.

References Foam::endl(), and InfoInFunction.

Here is the call graph for this function:

◆ removeFiles() [1/2]

void removeFiles ( const fileName & instanceDir ) const

Remove all files from mesh instance.

Definition at line 1551 of file polyMesh.C.

References Foam::isDir(), fileName::path(), Foam::rm(), and Foam::rmDir().

Referenced by meshReader::writeMesh().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ removeFiles() [2/2]

void removeFiles ( ) const

Remove all files from mesh instance()

Definition at line 1575 of file polyMesh.C.

Referenced by polyMesh::polyMesh().

Here is the caller graph for this function:

◆ findCellFacePt()

void findCellFacePt	(	const point &	p,
		label &	celli,
		label &	tetFacei,
		label &	tetPti
	)		const

Find the cell, tetFacei and tetPti for point p.

Definition at line 1581 of file polyMesh.C.

References indexedOctree< Type >::findInside(), and p.

Here is the call graph for this function:

◆ findTetFacePt()

void findTetFacePt	(	const label	celli,
		const point &	p,
		label &	tetFacei,
		label &	tetPti
	)		const

Find the tetFacei and tetPti for point p in celli.

tetFacei and tetPtI are set to -1 if not found

Definition at line 1606 of file polyMesh.C.

References tetIndices::face(), polyMeshTetDecomposition::findTet(), mesh, p, and tetIndices::tetPt().

Here is the call graph for this function:

◆ pointInCell()

bool pointInCell	(	const point &	p,
		label	celli,
		const cellDecomposition	decompMode = `CELL_TETS`
	)		const

Test if point p is in the celli.

Definition at line 1622 of file polyMesh.C.

References triangle< Point, PointRef >::area(), cells, triangle< Point, PointRef >::centre(), f(), tetIndices::faceTri(), forAll, p, primitiveMesh::pointInCell(), points, and List< T >::size().

Referenced by treeDataCell::contains(), and cellsToCells::srcToTgtPoint().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ findCell()

Foam::label findCell	(	const point &	p,
		const cellDecomposition	decompMode = `CELL_TETS`
	)		const

Find cell enclosing this location and return index.

If not found -1 is returned

Definition at line 1732 of file polyMesh.C.

References p, and UPstream::parRun().

Referenced by refinementParameters::findCells(), probes::findElements(), and meshRefinement::findRegion().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ writeObject()

bool writeObject	(	IOstream::streamFormat	fmt,
		IOstream::versionNumber	ver,
		IOstream::compressionType	cmp,
		const bool	write = `true`
	)		const

virtual

Write the underlying polyMesh.

Reimplemented from objectRegistry.

Reimplemented in fvMesh.

Definition at line 525 of file polyMeshIO.C.

References Foam::fileHandler(), IOobject::filePath(), Foam::name(), IOobject::NO_WRITE, UPstream::parRun(), fileOperation::rm(), Foam::vtkWriteOps::write(), and objectRegistry::writeObject().

Referenced by fvMesh::writeObject().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator=()

void operator= ( const polyMesh & )

delete

Disallow default bitwise assignment.

Member Data Documentation

◆ moving_

bool moving_

protected

Member data pending transfer to fvMesh.

Is the mesh moving

Definition at line 249 of file polyMesh.H.

Referenced by polyMesh::moving().

◆ topoChanged_

bool topoChanged_

protected

Has the mesh topology changed.

Definition at line 252 of file polyMesh.H.

Referenced by polyMesh::topoChanged(), and list::update().

◆ defaultRegion

Foam::word defaultRegion = "region0"

static

Return the default region name.

Definition at line 270 of file polyMesh.H.

Referenced by writeFile::baseFileDir(), regIOobject::checkIn(), polyMesh::found(), nonConformalCyclicPolyPatch::intersection(), meshReader::mesh(), probes::prepare(), nonConformalCyclicPolyPatch::rays(), Foam::regionName(), layerAverage::write(), and streamlines::write().

◆ meshSubDir

Foam::word meshSubDir = "polyMesh"

static

Return the mesh sub-directory name (usually "polyMesh")

Definition at line 273 of file polyMesh.H.

Referenced by refinementHistoryConstraint::add(), refinementHistoryConstraint::apply(), timeVaryingMappedFixedValuePointPatchField< Type >::checkTable(), componentDisplacementMotionSolver::componentDisplacementMotionSolver(), topoSet::localPath(), solidBodyMotionDisplacementPointPatchVectorField::localPoints0(), fileOperation::nProcs(), points0MotionSolver::points0MotionSolver(), polyMesh::polyMesh(), domainDecomposition::readDecompose(), points0MotionSolver::readPoints0(), domainDecomposition::readReconstruct(), domainDecomposition::writeComplete(), and domainDecomposition::writeProcs().

The documentation for this class was generated from the following files:

src/OpenFOAM/meshes/polyMesh/polyMesh.H
src/OpenFOAM/meshes/polyMesh/polyMesh.C
src/OpenFOAM/meshes/polyMesh/polyMeshClear.C
src/OpenFOAM/meshes/polyMesh/polyMeshFromShapeMesh.C
src/OpenFOAM/meshes/polyMesh/polyMeshInitMesh.C
src/OpenFOAM/meshes/polyMesh/polyMeshIO.C
src/OpenFOAM/meshes/polyMesh/polyMeshUpdate.C

Public Types

Public Member Functions

Static Public Member Functions

Static Public Attributes

Protected Attributes

Additional Inherited Members

Detailed Description

Member Typedef Documentation

◆ Mesh

◆ BoundaryMesh

Member Enumeration Documentation

◆ readUpdateState

◆ cellDecomposition

Constructor & Destructor Documentation

◆ polyMesh() [1/7]

◆ polyMesh() [2/7]

◆ polyMesh() [3/7]

◆ polyMesh() [4/7]

◆ polyMesh() [5/7]

◆ polyMesh() [6/7]

◆ polyMesh() [7/7]

◆ ~polyMesh()

Member Function Documentation

◆ TypeName()

◆ found()

◆ meshDir()

◆ pointsInstance()

◆ facesInstance()

◆ pointsWriteOpt()

◆ facesWriteOpt()

◆ setPointsInstance()

◆ setInstance()

◆ points()

◆ faces()

◆ faceOwner()

◆ faceNeighbour()

◆ oldPoints()

◆ oldCellCentres()

◆ boundaryMesh()

◆ bounds()

◆ geometricD()

◆ nGeometricD()

◆ solutionD()

◆ nSolutionD()

◆ tetBasePtIs()

◆ cellTree()

◆ pointZones() [1/2]

◆ faceZones() [1/2]

◆ cellZones() [1/2]

◆ globalData()

◆ comm() [1/2]

◆ comm() [2/2]

◆ thisDb()

◆ moving()

◆ topoChanged()

◆ changing()

◆ setPoints()

◆ movePoints()

◆ resetMotion()

◆ pointZones() [2/2]

◆ faceZones() [2/2]

◆ cellZones() [2/2]

◆ addPatches()

◆ addZones()

◆ addPatch()

◆ addedPatches()

◆ reorderPatches()

◆ readUpdate()

◆ topoChangeZones()

◆ topoChange()

◆ mapMesh()

◆ distribute()

◆ removeBoundary()

◆ resetPrimitives()

◆ swap()

◆ printAllocated()

◆ clearGeom()

◆ clearAddressing()

◆ clearOut()

◆ clearPrimitives()
