Allows specification of different writing frequency of objects registered to the database. More...

Inheritance diagram for writeObjects:

Collaboration diagram for writeObjects:

[legend]

Public Types
enum class	writeOption { AUTO_WRITE , NO_WRITE , ANY_WRITE }
	Re-enumeration defining the write options, based on the original. More...

Public Member Functions
	TypeName ("writeObjects")
	Runtime type information. More...

	writeObjects (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	writeObjects (const writeObjects &)=delete
	Disallow default bitwise copy construction. More...

virtual	~writeObjects ()
	Destructor. More...

virtual bool	read (const dictionary &)
	Read the writeObjects data. More...

virtual wordList	fields () const
	Return the list of fields required. More...

virtual bool	execute ()
	Do nothing. More...

virtual bool	write ()
	Write the registered objects. More...

void	operator= (const writeObjects &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from functionObject
	ClassName ("functionObject")

virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const Time &runTime)
	Construct from components. More...

	functionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from dictionary. More...

autoPtr< functionObject >	clone () const
	Return clone. More...

	functionObject (const functionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~functionObject ()
	Destructor. More...

const word &	name () const
	Return the name of this functionObject. More...

virtual bool	executeAtStart () const
	Return true if the functionObject should be executed at the start. More...

virtual bool	end ()
	Called when Time::run() determines that the time-loop exits. More...

virtual scalar	timeToNextAction ()
	Called by Time::adjustTimeStep(). Allows the functionObject to. More...

virtual scalar	maxDeltaT () const
	Return the maximum time-step for stable operation. More...

virtual void	movePoints (const polyMesh &mesh)
	Update topology using the given map. More...

virtual void	topoChange (const polyTopoChangeMap &map)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

void	operator= (const functionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from writeObjectsBase
	writeObjectsBase (const objectRegistry &obr, const Switch &logRef=logFalse)
	Construct from objectRegistry and inheriting function object. More...

	writeObjectsBase (const writeObjectsBase &)=delete
	Disallow default bitwise copy construction. More...

virtual	~writeObjectsBase ()
	Destructor. More...

const wordReList &	writeObjectNames () const
	Return const access to the object names requested to be written. More...

void	operator= (const writeObjectsBase &)=delete
	Disallow default bitwise assignment. More...

Static Public Attributes
static const NamedEnum< writeOption, 3 >	writeOptionNames_

Static Public Attributes inherited from functionObject
static bool	postProcess
	Global post-processing mode switch. More...

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &, const dictionary &)
	Select from dictionary, based on its "type" entry. More...

Public Attributes inherited from functionObject
Switch	log
	Switch write log to Info. More...

Switch	executeAtStart_
	Switch execute at start time. More...

Protected Member Functions inherited from writeObjectsBase
void	resetWriteObjectName (const wordRe &name)
	Reset the list of object names to be written to a single regular. More...

void	resetWriteObjectNames (const wordReList &names)
	Reset the list of object names to be written. More...

virtual wordList	objectNames ()
	Get the list of field names to be written. More...

Protected Attributes inherited from functionObject
const Time &	time_
	Reference to time. More...

Protected Attributes inherited from writeObjectsBase
const objectRegistry &	writeObr_
	Reference to the region objectRegistry. More...

const Switch &	log_
	Reference to the inheriting function object's log variable. More...

Switch	regExp_
	Optional switch for regular expression support. More...

wordReList	writeObjectNames_
	Object names requested by the user to be written. More...

Static Protected Attributes inherited from writeObjectsBase
static const Switch	logFalse
	False switch to which log_ defaults. More...

Detailed Description

Allows specification of different writing frequency of objects registered to the database.

It has similar functionality as the main time database through the writeControl setting:

timeStep
writeTime
adjustableRunTime
runTime
clockTime
cpuTime

It also has the ability to write the selected objects that were defined with the respective write mode for the requested writeOption, namely:

	=	objects set to write at output time
	=	objects set to not write by default
	=	any option of the previous two

Example of function object specification:

    writeObjects1
    {
        type            writeObjects;

        libs            ("libutilityFunctionObjects.so");

        objects         (obj1 obj2);
        writeOption     anyWrite;
    }

Usage

Property	Description	Required	Default value
`type`	type name: writeObjects	yes
`objects`, fields or field	objects to write	yes
`writeOption`	only those with this write option	no	anyWrite

The objects to be written can either be specified by the objects, fields or field entry, the latter two for backwards compatibility and to provide a more logical, obvious and readable interface when writing fields. Regular expressions can also be used when specifying multiple objects or fields.

See also: Foam::functionObject Foam::functionObjects::writeObjectsBase Foam::functionObjects::timeControl

Source files

Definition at line 135 of file writeObjects.H.

Member Enumeration Documentation

◆ writeOption

enum writeOption

strong

Re-enumeration defining the write options, based on the original.

ones at IOobject::writeOption

Enumerator
AUTO_WRITE
NO_WRITE
ANY_WRITE

Definition at line 146 of file writeObjects.H.

Constructor & Destructor Documentation

◆ writeObjects() [1/2]

writeObjects	(	const word &	name,
		const Time &	runTime,
		const dictionary &	dict
	)

Construct from Time and dictionary.

Definition at line 122 of file writeObjects.C.

References dict, and writeObjects::read().

Here is the call graph for this function:

◆ writeObjects() [2/2]

writeObjects ( const writeObjects & )

delete

Disallow default bitwise copy construction.

◆ ~writeObjects()

~writeObjects ( )

virtual

Destructor.

Definition at line 146 of file writeObjects.C.

Member Function Documentation

◆ TypeName()

TypeName ( "writeObjects" )

Runtime type information.

◆ read()

bool read ( const dictionary & dict )

virtual

Read the writeObjects data.

Reimplemented from functionObject.

Definition at line 152 of file writeObjects.C.

References dict, functionObject::read(), and writeObjectsBase::read().

Referenced by writeObjects::writeObjects().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ fields()

virtual wordList fields ( ) const

inlinevirtual

Return the list of fields required.

Implements functionObject.

Definition at line 200 of file writeObjects.H.

References List< word >::null().

Here is the call graph for this function:

◆ execute()

bool execute ( )

virtual

Do nothing.

Implements functionObject.

Definition at line 183 of file writeObjects.C.

◆ write()

bool write ( )

virtual

Write the registered objects.

Implements functionObject.

Definition at line 189 of file writeObjects.C.

References Foam::endl(), Log, Foam::name(), Foam::nl, Foam::type(), and writeObjectsBase::write().

Here is the call graph for this function:

◆ operator=()

void operator= ( const writeObjects & )

delete

Disallow default bitwise assignment.

Member Data Documentation

◆ writeOptionNames_

const Foam::NamedEnum< Foam::functionObjects::writeObjects::writeOption, 3 > writeOptionNames_

static

Initial value:

{
    "autoWrite",
    "noWrite",
    "anyWrite"
}

Definition at line 153 of file writeObjects.H.

The documentation for this class was generated from the following files:

src/functionObjects/utilities/writeObjects/writeObjects.H
src/functionObjects/utilities/writeObjects/writeObjects.C
