Evolves a passive scalar transport equation. More...

Inheritance diagram for scalarTransport:

Collaboration diagram for scalarTransport:

Public Types
enum class	diffusivityType { none , constant , viscosity }
	Enumeration defining the type of the diffusivity. More...

Public Member Functions
	TypeName ("scalarTransport")
	Runtime type information. More...

	scalarTransport (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	scalarTransport (const scalarTransport &)=delete
	Disallow default bitwise copy construction. More...

virtual	~scalarTransport ()
	Destructor. More...

virtual bool	read (const dictionary &)
	Read the scalarTransport data. More...

virtual wordList	fields () const
	Return the list of fields required. More...

virtual bool	executeAtStart () const
	Do not execute at the start of the run. More...

virtual bool	execute ()
	Calculate the scalarTransport. More...

virtual bool	write ()
	Write the updated scalar field. More...

void	operator= (const scalarTransport &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from fvMeshFunctionObject
	TypeName ("fvMeshFunctionObject")
	Runtime type information. More...

	fvMeshFunctionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	fvMeshFunctionObject (const word &name, const objectRegistry &obr)
	Construct from the region objectRegistry. More...

	fvMeshFunctionObject (const fvMeshFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~fvMeshFunctionObject ()
	Destructor. More...

const fvMesh &	mesh () const
	Return a reference to the mesh. More...

void	operator= (const fvMeshFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from regionFunctionObject
	TypeName ("regionFunctionObject")
	Runtime type information. More...

	regionFunctionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	regionFunctionObject (const word &name, const objectRegistry &obr)
	Construct from the region objectRegistry. More...

	regionFunctionObject (const regionFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~regionFunctionObject ()
	Destructor. More...

void	operator= (const regionFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from objectRegistryFunctionObject
	TypeName ("objectRegistryFunctionObject")
	Runtime type information. More...

	objectRegistryFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)
	Construct from an objectRegistry and dictionary. More...

	objectRegistryFunctionObject (const word &name, const objectRegistry &obr)
	Construct from an objectRegistry. More...

	objectRegistryFunctionObject (const objectRegistryFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~objectRegistryFunctionObject ()
	Destructor. More...

void	operator= (const objectRegistryFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from functionObject
	ClassName ("functionObject")

virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const Time &runTime)
	Construct from components. More...

	functionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from dictionary. More...

autoPtr< functionObject >	clone () const
	Return clone. More...

	functionObject (const functionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~functionObject ()
	Destructor. More...

const word &	name () const
	Return the name of this functionObject. More...

virtual bool	end ()
	Called when Time::run() determines that the time-loop exits. More...

virtual scalar	timeToNextAction ()
	Called by Time::adjustTimeStep(). Allows the functionObject to. More...

virtual scalar	maxDeltaT () const
	Return the maximum time-step for stable operation. More...

virtual void	movePoints (const polyMesh &mesh)
	Update topology using the given map. More...

virtual void	topoChange (const polyTopoChangeMap &map)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

void	operator= (const functionObject &)=delete
	Disallow default bitwise assignment. More...

Static Public Attributes
static const NamedEnum< diffusivityType, 3 >	diffusivityTypeNames_
	Diffusivity type names. More...

Static Public Attributes inherited from functionObject
static bool	postProcess
	Global post-processing mode switch. More...

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &, const dictionary &)
	Select from dictionary, based on its "type" entry. More...

Public Attributes inherited from functionObject
Switch	log
	Switch write log to Info. More...

Switch	executeAtStart_
	Switch execute at start time. More...

Protected Member Functions inherited from objectRegistryFunctionObject
template<class ObjectType >
bool	foundObject (const word &fieldName) const
	Find field in the objectRegistry. More...

template<class ObjectType >
void	cannotFindObject (const word &fieldName)
	Prints a warning message that fieldName cannot be found. More...

void	cannotFindObject (const word &fieldName)
	Prints a warning message that fieldName cannot be found. More...

void	cannotFindObjects (const wordList &fieldNames)
	Prints a warning message that fieldNames cannot be found. More...

template<class ObjectType >
const ObjectType &	lookupObject (const word &fieldName) const
	Lookup object from the objectRegistry. More...

template<class ObjectType >
ObjectType &	lookupObjectRef (const word &fieldName)
	Lookup non-const object reference from the objectRegistry. More...

template<class ObjectType >
ObjectType &	store (const tmp< ObjectType > &tfield)
	Store the given field in the objectRegistry. More...

template<class ObjectType >
ObjectType &	store (const word &fieldName, const tmp< ObjectType > &tfield, bool cacheable=false)
	Store the given field in the objectRegistry under the given name. More...

bool	writeObject (const word &fieldName)
	Write field if present in objectRegistry. More...

bool	clearObject (const word &fieldName)
	Clear field from the objectRegistry if present. More...

Protected Attributes inherited from fvMeshFunctionObject
const fvMesh &	mesh_
	Reference to the fvMesh. More...

Protected Attributes inherited from objectRegistryFunctionObject
const objectRegistry &	obr_
	Reference to the objectRegistry. More...

Protected Attributes inherited from functionObject
const Time &	time_
	Reference to time. More...

Detailed Description

Evolves a passive scalar transport equation.

To specify the field name set the field entry
To employ the same numerical schemes as another field set the schemesField entry,
The diffusivity entry can be set to none, constant, viscosity
A constant diffusivity is specified with the D entry,
If a momentum transport model is available and the viscosity diffusivity option specified an effective diffusivity may be constructed from the laminar and turbulent viscosities using the diffusivity coefficients alphal and alphat:
```
      D = alphal*nu + alphat*nut
```

Example:

    #includeFunc scalarTransport(T, alphal=1, alphat=1)

For incompressible flow the passive scalar may optionally be solved with the MULES limiter and sub-cycling or semi-implicit in order to maintain boundedness, particularly if a compressive, PLIC or MPLIC convection scheme is used.

Example:

    #includeFunc scalarTransport(tracer, diffusivity=none)

with scheme specification:
    div(phi,tracer)     Gauss interfaceCompression vanLeer 1;

and solver specification:
    tracer
    {
        nCorr      1;
        nSubCycles 3;

        MULESCorr       no;
        nLimiterIter    5;
        applyPrevCorr   yes;

        solver          smoothSolver;
        smoother        symGaussSeidel;
        tolerance       1e-8;
        relTol          0;

        diffusivity
        {
            solver          smoothSolver;
            smoother        symGaussSeidel;
            tolerance       1e-8;
            relTol          0;
        }
    }

See also: Foam::functionObjects::fvMeshFunctionObject

Source files

Definition at line 109 of file scalarTransport.H.

Member Enumeration Documentation

◆ diffusivityType

enum diffusivityType

strong

Enumeration defining the type of the diffusivity.

Enumerator
none
constant
viscosity

Definition at line 116 of file scalarTransport.H.

Constructor & Destructor Documentation

◆ scalarTransport() [1/2]

scalarTransport	(	const word &	name,
		const Time &	runTime,
		const dictionary &	dict
	)

Construct from Time and dictionary.

Definition at line 111 of file scalarTransport.C.

References dict, dictionary::found(), dictionary::lookupOrDefault(), fvMeshFunctionObject::mesh_, scalarTransport::read(), fvMesh::schemes(), fvSchemes::setFluxRequired(), fvMesh::solution(), solution::solverDict(), and solution::solversDict().

Here is the call graph for this function:

◆ scalarTransport() [2/2]

scalarTransport ( const scalarTransport & )

delete

Disallow default bitwise copy construction.

◆ ~scalarTransport()

~scalarTransport ( )

virtual

Destructor.

Definition at line 164 of file scalarTransport.C.

Member Function Documentation

◆ TypeName()

TypeName ( "scalarTransport" )

Runtime type information.

◆ read()

bool read ( const dictionary & dict )

virtual

Read the scalarTransport data.

Reimplemented from objectRegistryFunctionObject.

Definition at line 170 of file scalarTransport.C.

References dict, objectRegistryFunctionObject::read(), and viscosity().

Referenced by scalarTransport::scalarTransport().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ fields()

Foam::wordList fields ( ) const

virtual

Return the list of fields required.

Implements functionObject.

Definition at line 205 of file scalarTransport.C.

◆ executeAtStart()

virtual bool executeAtStart ( ) const

inlinevirtual

Do not execute at the start of the run.

Reimplemented from functionObject.

Definition at line 214 of file scalarTransport.H.

◆ execute()

bool execute ( )

virtual

Calculate the scalarTransport.

Implements functionObject.

Definition at line 211 of file scalarTransport.C.

References fvConstraints::constrain(), Foam::saturationModels::D, Foam::fvm::ddt(), DimensionedField< Type, GeoMesh, PrimitiveField >::dimensions(), Foam::dimMass, Foam::dimTime, Foam::dimVolume, Foam::fvm::div(), Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, fvConstraints(), fvModels(), Foam::Info, Foam::fvm::laplacian(), dictionary::New(), Foam::nl, fvMatrix< Type >::relax(), rho, fvMatrix< Type >::solve(), fvModels::source(), and Foam::type().

Here is the call graph for this function:

◆ write()

bool write ( )

virtual

Write the updated scalar field.

Implements functionObject.

Definition at line 639 of file scalarTransport.C.

◆ operator=()

void operator= ( const scalarTransport & )

delete

Disallow default bitwise assignment.

Member Data Documentation

◆ diffusivityTypeNames_

const Foam::NamedEnum< Foam::functionObjects::scalarTransport::diffusivityType, 3 > diffusivityTypeNames_

static

Initial value:

{
    "none",
    "constant",
    "viscosity"
}

Diffusivity type names.

Definition at line 124 of file scalarTransport.H.

Referenced by phaseScalarTransport::read().

The documentation for this class was generated from the following files:

src/functionObjects/solvers/scalarTransport/scalarTransport.H
src/functionObjects/solvers/scalarTransport/scalarTransport.C

Public Types

Public Member Functions

Static Public Attributes

Additional Inherited Members

Detailed Description

Member Enumeration Documentation

◆ diffusivityType

Constructor & Destructor Documentation

◆ scalarTransport() [1/2]

◆ scalarTransport() [2/2]

◆ ~scalarTransport()

Member Function Documentation

◆ TypeName()

◆ read()

◆ fields()

◆ executeAtStart()

◆ execute()

◆ write()

◆ operator=()

Member Data Documentation

◆ diffusivityTypeNames_
