Abstract base class for stop conditions. More...

Inheritance diagram for stopAt:

[legend]

Collaboration diagram for stopAt:

Public Types
enum class	actionType { noWriteNow , writeNow , nextWrite }
	Enumeration defining the type of action. More...

Public Member Functions
	TypeName ("stopAt")
	Runtime type information. More...

	stopAt (const word &name, const Time &runTime, const dictionary &)
	Construct from Time and dictionary. More...

	stopAt (const stopAt &)=delete
	Disallow default bitwise copy construction. More...

virtual	~stopAt ()
	Destructor. More...

virtual bool	read (const dictionary &)
	Read the dictionary settings. More...

virtual wordList	fields () const
	Return the list of fields required. More...

virtual bool	execute ()
	Execute, check existence of stopAt file and take action. More...

virtual bool	write ()
	Execute, check existence of stopAt file and take action. More...

virtual bool	end ()
	Execute at the final time-loop, used for cleanup. More...

void	operator= (const stopAt &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from functionObject
	ClassName ("functionObject")

virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const Time &runTime)
	Construct from components. More...

	functionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from dictionary. More...

autoPtr< functionObject >	clone () const
	Return clone. More...

	functionObject (const functionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~functionObject ()
	Destructor. More...

const word &	name () const
	Return the name of this functionObject. More...

virtual bool	executeAtStart () const
	Return true if the functionObject should be executed at the start. More...

virtual scalar	timeToNextAction ()
	Called by Time::adjustTimeStep(). Allows the functionObject to. More...

virtual scalar	maxDeltaT () const
	Return the maximum time-step for stable operation. More...

virtual void	movePoints (const polyMesh &mesh)
	Update topology using the given map. More...

virtual void	topoChange (const polyTopoChangeMap &map)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

void	operator= (const functionObject &)=delete
	Disallow default bitwise assignment. More...

Protected Member Functions
virtual bool	condition () const =0
	Return true when the stop condition is achieved. More...

Protected Attributes
actionType	action_
	The type of action. More...

bool	stopped_
	Set true when the stop action has executed. More...

Protected Attributes inherited from functionObject
const Time &	time_
	Reference to time. More...

Static Protected Attributes
static const NamedEnum< actionType, 3 >	actionTypeNames_
	Action type names. More...

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &, const dictionary &)
	Select from dictionary, based on its "type" entry. More...

Public Attributes inherited from functionObject
Switch	log
	Switch write log to Info. More...

Switch	executeAtStart_
	Switch execute at start time. More...

Static Public Attributes inherited from functionObject
static bool	postProcess
	Global post-processing mode switch. More...

Detailed Description

Abstract base class for stop conditions.

Currently the following actions are supported:

noWriteNow
writeNow
nextWrite

Source files

Definition at line 56 of file stopAt.H.

Member Enumeration Documentation

◆ actionType

enum actionType

strong

Enumeration defining the type of action.

Enumerator
noWriteNow	stop immediately without writing data
writeNow	write data and stop immediately
nextWrite	stop the next time data are written

Definition at line 63 of file stopAt.H.

Constructor & Destructor Documentation

◆ stopAt() [1/2]

stopAt	(	const word &	name,
		const Time &	runTime,
		const dictionary &	dict
	)

Construct from Time and dictionary.

Definition at line 55 of file stopAt.C.

◆ stopAt() [2/2]

stopAt ( const stopAt & )

delete

Disallow default bitwise copy construction.

◆ ~stopAt()

~stopAt ( )

virtual

Destructor.

Definition at line 70 of file stopAt.C.

Member Function Documentation

◆ condition()

virtual bool condition ( ) const

protectedpure virtual

Return true when the stop condition is achieved.

◆ TypeName()

TypeName ( "stopAt" )

Runtime type information.

◆ read()

bool read ( const dictionary & dict )

virtual

Read the dictionary settings.

Reimplemented from functionObject.

Reimplemented in stopAtTimeStep, stopAtFile, and stopAtClockTime.

Definition at line 76 of file stopAt.C.

References dict.

Referenced by stopAtClockTime::read(), stopAtFile::read(), stopAtTimeStep::read(), and stopAtEmptyClouds::stopAtEmptyClouds().

Here is the caller graph for this function:

◆ fields()

virtual wordList fields ( ) const

inlinevirtual

Return the list of fields required.

Implements functionObject.

Definition at line 121 of file stopAt.H.

References List< word >::null().

Here is the call graph for this function:

◆ execute()

bool execute ( )

virtual

Execute, check existence of stopAt file and take action.

Implements functionObject.

Definition at line 87 of file stopAt.C.

References Foam::endl(), Foam::Info, Time::nextWrite, Time::noWriteNow, Foam::reduce(), Foam::type(), and Time::writeNow.

Here is the call graph for this function:

◆ write()

bool write ( )

virtual

Execute, check existence of stopAt file and take action.

Implements functionObject.

Definition at line 143 of file stopAt.C.

◆ end()

bool end ( )

virtual

Execute at the final time-loop, used for cleanup.

Reimplemented from functionObject.

Reimplemented in stopAtFile.

Definition at line 149 of file stopAt.C.

◆ operator=()

void operator= ( const stopAt & )

delete

Disallow default bitwise assignment.

Member Data Documentation

◆ actionTypeNames_

const Foam::NamedEnum< Foam::functionObjects::stopAt::actionType, 3 > actionTypeNames_

staticprotected

Initial value:

{
    "noWriteNow",
    "writeNow",
    "nextWrite"
}

Action type names.

Definition at line 76 of file stopAt.H.

◆ action_

actionType action_

protected

The type of action.

Definition at line 79 of file stopAt.H.

Referenced by stopAtTimeStep::stopAtTimeStep().

◆ stopped_

bool stopped_

protected

Set true when the stop action has executed.

Definition at line 82 of file stopAt.H.

The documentation for this class was generated from the following files:

src/functionObjects/utilities/stopAt/stopAt.H
src/functionObjects/utilities/stopAt/stopAt.C
