Stores derived turbulence fields on the mesh database for further manipulation. More...

Inheritance diagram for turbulenceFields:

Collaboration diagram for turbulenceFields:

[legend]

Public Types
enum class	compressibleField { k , epsilon , omega , nut , nuEff , kappaEff , R }

enum class	incompressibleField { k , epsilon , omega , nut , nuEff , R }

Public Member Functions
	TypeName ("turbulenceFields")
	Runtime type information. More...

	turbulenceFields (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	turbulenceFields (const turbulenceFields &)=delete
	Disallow default bitwise copy construction. More...

virtual	~turbulenceFields ()
	Destructor. More...

virtual bool	read (const dictionary &)
	Read the controls. More...

virtual wordList	fields () const
	Return the list of fields required. More...

virtual bool	execute ()
	Calculate turbulence fields. More...

virtual bool	write ()
	Write the turbulence fields. More...

void	operator= (const turbulenceFields &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from fvMeshFunctionObject
	TypeName ("fvMeshFunctionObject")
	Runtime type information. More...

	fvMeshFunctionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	fvMeshFunctionObject (const word &name, const objectRegistry &obr)
	Construct from the region objectRegistry. More...

	fvMeshFunctionObject (const fvMeshFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~fvMeshFunctionObject ()
	Destructor. More...

const fvMesh &	mesh () const
	Return a reference to the mesh. More...

void	operator= (const fvMeshFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from regionFunctionObject
	TypeName ("regionFunctionObject")
	Runtime type information. More...

	regionFunctionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	regionFunctionObject (const word &name, const objectRegistry &obr)
	Construct from the region objectRegistry. More...

	regionFunctionObject (const regionFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~regionFunctionObject ()
	Destructor. More...

void	operator= (const regionFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from objectRegistryFunctionObject
	TypeName ("objectRegistryFunctionObject")
	Runtime type information. More...

	objectRegistryFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)
	Construct from an objectRegistry and dictionary. More...

	objectRegistryFunctionObject (const word &name, const objectRegistry &obr)
	Construct from an objectRegistry. More...

	objectRegistryFunctionObject (const objectRegistryFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~objectRegistryFunctionObject ()
	Destructor. More...

void	operator= (const objectRegistryFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from functionObject
	ClassName ("functionObject")

virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const Time &runTime)
	Construct from components. More...

	functionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from dictionary. More...

autoPtr< functionObject >	clone () const
	Return clone. More...

	functionObject (const functionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~functionObject ()
	Destructor. More...

const word &	name () const
	Return the name of this functionObject. More...

virtual bool	executeAtStart () const
	Return true if the functionObject should be executed at the start. More...

virtual bool	end ()
	Called when Time::run() determines that the time-loop exits. More...

virtual scalar	timeToNextAction ()
	Called by Time::adjustTimeStep(). Allows the functionObject to. More...

virtual scalar	maxDeltaT () const
	Return the maximum time-step for stable operation. More...

virtual void	movePoints (const polyMesh &mesh)
	Update topology using the given map. More...

virtual void	topoChange (const polyTopoChangeMap &map)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

void	operator= (const functionObject &)=delete
	Disallow default bitwise assignment. More...

Static Public Attributes
static const NamedEnum< compressibleField, 7 >	compressibleFieldNames_

static const NamedEnum< incompressibleField, 6 >	incompressibleFieldNames_

Static Public Attributes inherited from functionObject
static bool	postProcess
	Global post-processing mode switch. More...

Protected Member Functions
word	modelName ()

template<class Type >
void	processField (const word &fieldName, const tmp< VolField< Type >> &tvalue)
	Process the turbulence field. More...

Protected Member Functions inherited from objectRegistryFunctionObject
template<class ObjectType >
bool	foundObject (const word &fieldName) const
	Find field in the objectRegistry. More...

template<class ObjectType >
void	cannotFindObject (const word &fieldName)
	Prints a warning message that fieldName cannot be found. More...

void	cannotFindObject (const word &fieldName)
	Prints a warning message that fieldName cannot be found. More...

void	cannotFindObjects (const wordList &fieldNames)
	Prints a warning message that fieldNames cannot be found. More...

template<class ObjectType >
const ObjectType &	lookupObject (const word &fieldName) const
	Lookup object from the objectRegistry. More...

template<class ObjectType >
ObjectType &	lookupObjectRef (const word &fieldName)
	Lookup non-const object reference from the objectRegistry. More...

template<class ObjectType >
ObjectType &	store (const tmp< ObjectType > &tfield)
	Store the given field in the objectRegistry. More...

template<class ObjectType >
ObjectType &	store (const word &fieldName, const tmp< ObjectType > &tfield, bool cacheable=false)
	Store the given field in the objectRegistry under the given name. More...

bool	writeObject (const word &fieldName)
	Write field if present in objectRegistry. More...

bool	clearObject (const word &fieldName)
	Clear field from the objectRegistry if present. More...

Protected Attributes
wordHashSet	fieldSet_
	Fields to load. More...

word	prefix_
	Optional field prefix to avoid name clashes. More...

word	phaseName_
	Optional phase name. More...

Protected Attributes inherited from fvMeshFunctionObject
const fvMesh &	mesh_
	Reference to the fvMesh. More...

Protected Attributes inherited from objectRegistryFunctionObject
const objectRegistry &	obr_
	Reference to the objectRegistry. More...

Protected Attributes inherited from functionObject
const Time &	time_
	Reference to time. More...

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &, const dictionary &)
	Select from dictionary, based on its "type" entry. More...

Public Attributes inherited from functionObject
Switch	log
	Switch write log to Info. More...

Switch	executeAtStart_
	Switch execute at start time. More...

Detailed Description

Stores derived turbulence fields on the mesh database for further manipulation.

Usage

Property	Description	Required	Default value
`type`	Type name: processorField	yes
`fields`	Fields to store (see below)	yes
`prefix`	If true prefix fields	no	no
`phase`	phase name	no

Where fields can include:

k	:	turbulence kinetic energy
epsilon	:	turbulence kinetic energy dissipation rate
omega	:	turbulence specific dissipation rate
nut	:	turbulence viscosity (incompressible)
nuEff	:	effective turbulence viscosity (incompressible)
nut	:	turbulence viscosity (compressible)
nuEff	:	effective turbulence viscosity (compressible)
kappaEff	:	effective turbulence thermal diffusivity (compressible)
R	:	Reynolds stress tensor

If the optional prefix entry is set true the turbulence fields are stored with the prefix "momentumTransportModel:", e.g.:

    momentumTransportModel:R

Example of function object specification:

    turbulenceFields1
    {
        type        turbulenceFields;
        libs        ("libfieldFunctionObjects.so");
        ...
        fields
        (
            R
            devTau
        );
    }

See also: Foam::functionObjects::fvMeshFunctionObject Foam::functionObjects::timeControl

Source files

Definition at line 162 of file turbulenceFields.H.

Member Enumeration Documentation

◆ compressibleField

enum compressibleField

strong

Enumerator
k
epsilon
omega
nut
nuEff
kappaEff
R

Definition at line 168 of file turbulenceFields.H.

◆ incompressibleField

enum incompressibleField

strong

Enumerator
k
epsilon
omega
nut
nuEff
R

Definition at line 180 of file turbulenceFields.H.

Constructor & Destructor Documentation

◆ turbulenceFields() [1/2]

turbulenceFields	(	const word &	name,
		const Time &	runTime,
		const dictionary &	dict
	)

Construct from Time and dictionary.

Definition at line 80 of file turbulenceFields.C.

References dict, and turbulenceFields::read().

Here is the call graph for this function:

◆ turbulenceFields() [2/2]

turbulenceFields ( const turbulenceFields & )

delete

Disallow default bitwise copy construction.

◆ ~turbulenceFields()

~turbulenceFields ( )

virtual

Destructor.

Definition at line 97 of file turbulenceFields.C.

Member Function Documentation

◆ modelName()

word modelName ( )

protected

◆ processField()

void processField	(	const word &	fieldName,
		const tmp< VolField< Type >> &	tvalue
	)

protected

Process the turbulence field.

Definition at line 31 of file turbulenceFieldsTemplates.C.

References Foam::endl(), HashTable< T, Key, Hash >::found(), objectRegistry::foundObject(), IOobject::groupName(), objectRegistry::lookupObjectRef(), dimensioned< Type >::name(), Foam::nl, IOobject::NO_WRITE, objectRegistryFunctionObject::obr_, turbulenceFields::phaseName_, turbulenceFields::prefix_, IOobject::READ_IF_PRESENT, regIOobject::store(), functionObject::time_, and WarningInFunction.

Here is the call graph for this function:

◆ TypeName()

TypeName ( "turbulenceFields" )

Runtime type information.

◆ read()

bool read ( const dictionary & dict )

virtual

Read the controls.

Reimplemented from objectRegistryFunctionObject.

Definition at line 103 of file turbulenceFields.C.

References dict, Foam::endl(), forAllConstIter, IOobject::groupName(), Foam::Info, Foam::name(), Foam::nl, word::null, and Foam::type().

Referenced by turbulenceFields::turbulenceFields().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ fields()

virtual wordList fields ( ) const

inlinevirtual

Return the list of fields required.

Implements functionObject.

Definition at line 250 of file turbulenceFields.H.

References List< word >::null().

Here is the call graph for this function:

◆ execute()

bool execute ( )

virtual

Calculate turbulence fields.

Implements functionObject.

Definition at line 143 of file turbulenceFields.C.

References epsilon, momentumTransportModel::epsilon(), Foam::exit(), f(), Foam::FatalError, FatalErrorInFunction, forAllConstIter, k, momentumTransportModel::k(), thermophysicalTransportModel::kappaEff(), fluidThermophysicalTransportModel::momentumTransport(), nuEff, momentumTransportModel::nuEff(), nut, momentumTransportModel::nut(), omega, momentumTransportModel::omega(), momentumTransportModel::R(), and R().

Here is the call graph for this function:

◆ write()

bool write ( )

virtual

Write the turbulence fields.

Implements functionObject.

Definition at line 311 of file turbulenceFields.C.

References forAllConstIter, and IOobject::groupName().

Here is the call graph for this function:

◆ operator=()

void operator= ( const turbulenceFields & )

delete

Disallow default bitwise assignment.

Member Data Documentation

◆ compressibleFieldNames_

const Foam::NamedEnum< Foam::functionObjects::turbulenceFields::compressibleField, 7 > compressibleFieldNames_

static

Initial value:

{
    "k",
    "epsilon",
    "omega",
    "nut",
    "nuEff",
    "kappaEff",
    "R"
}

Definition at line 178 of file turbulenceFields.H.

◆ incompressibleFieldNames_

const Foam::NamedEnum< Foam::functionObjects::turbulenceFields::incompressibleField, 6 > incompressibleFieldNames_

static

Initial value:

{
    "k",
    "epsilon",
    "omega",
    "nut",
    "nuEff",
    "R"
}

Definition at line 189 of file turbulenceFields.H.

◆ fieldSet_

wordHashSet fieldSet_

protected

Fields to load.

Definition at line 197 of file turbulenceFields.H.

◆ prefix_

word prefix_

protected

Optional field prefix to avoid name clashes.

Defaults to null

Definition at line 201 of file turbulenceFields.H.

Referenced by turbulenceFields::processField().

◆ phaseName_

word phaseName_

protected

Optional phase name.

Definition at line 204 of file turbulenceFields.H.

Referenced by turbulenceFields::processField().

The documentation for this class was generated from the following files:

src/functionObjects/field/turbulenceFields/turbulenceFields.H
src/functionObjects/field/turbulenceFields/turbulenceFields.C
src/functionObjects/field/turbulenceFields/turbulenceFieldsTemplates.C

Public Types

Public Member Functions

Static Public Attributes

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Member Enumeration Documentation

◆ compressibleField

◆ incompressibleField

Constructor & Destructor Documentation

◆ turbulenceFields() [1/2]

◆ turbulenceFields() [2/2]

◆ ~turbulenceFields()

Member Function Documentation

◆ modelName()

◆ processField()

◆ TypeName()

◆ read()

◆ fields()

◆ execute()

◆ write()

◆ operator=()

Member Data Documentation

◆ compressibleFieldNames_

◆ incompressibleFieldNames_

◆ fieldSet_

◆ prefix_

◆ phaseName_
