Creates a size distribution via interrogating a continuous phase fraction field. More...

Inheritance diagram for regionSizeDistribution:

Collaboration diagram for regionSizeDistribution:

Public Member Functions
	TypeName ("regionSizeDistribution")
	Runtime type information. More...

	regionSizeDistribution (const word &name, const Time &runTime, const dictionary &)
	Construct for given objectRegistry and dictionary. More...

	regionSizeDistribution (const regionSizeDistribution &)=delete
	Disallow default bitwise copy construction. More...

virtual	~regionSizeDistribution ()

virtual bool	read (const dictionary &)
	Read the regionSizeDistribution data. More...

virtual wordList	fields () const
	Return the list of fields required. More...

virtual bool	execute ()
	Do nothing. More...

virtual bool	write ()
	Calculate the regionSizeDistribution and write. More...

void	operator= (const regionSizeDistribution &)=delete
	Disallow default bitwise assignment. More...

template<class Type >
Foam::tmp< Foam::Field< Type > >	divide (const Field< Type > &num, const scalarField &denom)

template<class Type >
Foam::Map< Type >	regionSum (const regionSplit &regions, const Field< Type > &fld) const

template<class Type >
Foam::List< Type >	extractData (const UList< label > &keys, const Map< Type > &regionData) const

Public Member Functions inherited from fvMeshFunctionObject
	TypeName ("fvMeshFunctionObject")
	Runtime type information. More...

	fvMeshFunctionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	fvMeshFunctionObject (const word &name, const objectRegistry &obr)
	Construct from the region objectRegistry. More...

	fvMeshFunctionObject (const fvMeshFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~fvMeshFunctionObject ()
	Destructor. More...

const fvMesh &	mesh () const
	Return a reference to the mesh. More...

void	operator= (const fvMeshFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from regionFunctionObject
	TypeName ("regionFunctionObject")
	Runtime type information. More...

	regionFunctionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	regionFunctionObject (const word &name, const objectRegistry &obr)
	Construct from the region objectRegistry. More...

	regionFunctionObject (const regionFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~regionFunctionObject ()
	Destructor. More...

void	operator= (const regionFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from objectRegistryFunctionObject
	TypeName ("objectRegistryFunctionObject")
	Runtime type information. More...

	objectRegistryFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)
	Construct from an objectRegistry and dictionary. More...

	objectRegistryFunctionObject (const word &name, const objectRegistry &obr)
	Construct from an objectRegistry. More...

	objectRegistryFunctionObject (const objectRegistryFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~objectRegistryFunctionObject ()
	Destructor. More...

void	operator= (const objectRegistryFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from functionObject
	ClassName ("functionObject")

virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const Time &runTime)
	Construct from components. More...

	functionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from dictionary. More...

autoPtr< functionObject >	clone () const
	Return clone. More...

	functionObject (const functionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~functionObject ()
	Destructor. More...

const word &	name () const
	Return the name of this functionObject. More...

virtual bool	executeAtStart () const
	Return true if the functionObject should be executed at the start. More...

virtual bool	end ()
	Called when Time::run() determines that the time-loop exits. More...

virtual scalar	timeToNextAction ()
	Called by Time::adjustTimeStep(). Allows the functionObject to. More...

virtual scalar	maxDeltaT () const
	Return the maximum time-step for stable operation. More...

virtual void	movePoints (const polyMesh &mesh)
	Update topology using the given map. More...

virtual void	topoChange (const polyTopoChangeMap &map)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

void	operator= (const functionObject &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &, const dictionary &)
	Select from dictionary, based on its "type" entry. More...

Public Attributes inherited from functionObject
Switch	log
	Switch write log to Info. More...

Switch	executeAtStart_
	Switch execute at start time. More...

Static Public Attributes inherited from functionObject
static bool	postProcess
	Global post-processing mode switch. More...

Protected Member Functions inherited from objectRegistryFunctionObject
template<class ObjectType >
bool	foundObject (const word &fieldName) const
	Find field in the objectRegistry. More...

template<class ObjectType >
void	cannotFindObject (const word &fieldName)
	Prints a warning message that fieldName cannot be found. More...

void	cannotFindObject (const word &fieldName)
	Prints a warning message that fieldName cannot be found. More...

void	cannotFindObjects (const wordList &fieldNames)
	Prints a warning message that fieldNames cannot be found. More...

template<class ObjectType >
const ObjectType &	lookupObject (const word &fieldName) const
	Lookup object from the objectRegistry. More...

template<class ObjectType >
ObjectType &	lookupObjectRef (const word &fieldName)
	Lookup non-const object reference from the objectRegistry. More...

template<class ObjectType >
ObjectType &	store (const tmp< ObjectType > &tfield)
	Store the given field in the objectRegistry. More...

template<class ObjectType >
ObjectType &	store (const word &fieldName, const tmp< ObjectType > &tfield, bool cacheable=false)
	Store the given field in the objectRegistry under the given name. More...

bool	writeObject (const word &fieldName)
	Write field if present in objectRegistry. More...

bool	clearObject (const word &fieldName)
	Clear field from the objectRegistry if present. More...

Protected Attributes inherited from fvMeshFunctionObject
const fvMesh &	mesh_
	Reference to the fvMesh. More...

Protected Attributes inherited from objectRegistryFunctionObject
const objectRegistry &	obr_
	Reference to the objectRegistry. More...

Protected Attributes inherited from functionObject
const Time &	time_
	Reference to time. More...

Detailed Description

Creates a size distribution via interrogating a continuous phase fraction field.

Looks up a phase-fraction (alpha) field and splits the mesh into regions based on where the field is below the threshold value. These regions ("droplets") can now be analysed.

Regions:

print the regions connected to a user-defined set of patches. (in spray calculation these form the liquid core)
print the regions with too large volume. These are the 'background' regions.
(debug) write regions as a volScalarField
(debug) print for all regions the sum of volume and alpha*volume

Output (volume scalar) fields include:

alpha_liquidCore : alpha with outside liquid core set to 0
alpha_background : alpha with outside background set to 0.

Histogram:

determine histogram of diameter (given minDiameter, maxDiameter, nBins)
write graph of number of droplets per bin
write graph of sum, average and deviation of droplet volume per bin
write graph of sum, average and deviation of user-defined fields. For volVectorFields these are those of the 3 components and the magnitude.

Example of function object specification:

regionSizeDistribution1
{
    type            regionSizeDistribution;
    libs            ("libfieldFunctionObjects.so");
    ...
    alpha           alpha;
    patches         (inlet);
    threshold       0.4;
    fields          (p U);
    nBins           100;
    maxDiameter     0.5e-4;
    minDiameter     0;
    setFormat       gnuplot;
}

Usage

Property	Description	Required	Default value
`type`	type name: regionSizeDistribution	yes
`alpha`	phase field to interrogate	yes
`patches`	patches from which the liquid core is identified	yes
`threshold`	phase fraction applied to delimit regions	yes
`fields`	fields to sample	yes
`nBins`	number of bins for histogram	yes
`maxDiameter`	maximum region equivalent diameter	yes
`minDiameter`	minimum region equivalent diameter	no	0
`setFormat`	writing format	yes

See also: Foam::functionObject Foam::functionObjects::fvMeshFunctionObject Foam::functionObjects::writeFile

Source files

Definition at line 171 of file regionSizeDistribution.H.

Constructor & Destructor Documentation

◆ regionSizeDistribution() [1/2]

regionSizeDistribution	(	const word &	name,
		const Time &	runTime,
		const dictionary &	dict
	)

Construct for given objectRegistry and dictionary.

Allow the possibility to load fields from files

Definition at line 339 of file regionSizeDistribution.C.

References dict, and regionSizeDistribution::read().

Here is the call graph for this function:

◆ regionSizeDistribution() [2/2]

regionSizeDistribution ( const regionSizeDistribution & )

delete

Disallow default bitwise copy construction.

◆ ~regionSizeDistribution()

~regionSizeDistribution ( )

virtual

Definition at line 357 of file regionSizeDistribution.C.

Member Function Documentation

◆ TypeName()

TypeName ( "regionSizeDistribution" )

Runtime type information.

◆ read()

bool read ( const dictionary & dict )

virtual

Read the regionSizeDistribution data.

Reimplemented from objectRegistryFunctionObject.

Definition at line 363 of file regionSizeDistribution.C.

References dict, and setWriter::New().

Referenced by regionSizeDistribution::regionSizeDistribution().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ fields()

Foam::wordList fields ( ) const

virtual

Return the list of fields required.

Implements functionObject.

Definition at line 380 of file regionSizeDistribution.C.

References fields.

◆ execute()

bool execute ( )

virtual

Do nothing.

Implements functionObject.

Definition at line 388 of file regionSizeDistribution.C.

◆ write()

bool write ( )

virtual

Calculate the regionSizeDistribution and write.

Implements functionObject.

Definition at line 394 of file regionSizeDistribution.C.

References alpha(), List< T >::append(), HashTable< T, Key, Hash >::begin(), Foam::cbrt(), GeometricField< Type, GeoMesh, PrimitiveField >::correctBoundaryConditions(), fvPatchField< Type >::coupled(), DeclareTypeFields, delta, Foam::dimless, Foam::fvc::domainIntegrate(), HashTableCore::end(), Foam::endl(), HashTable< T, Key, Hash >::erase(), fieldNames, Foam::FOR_ALL_FIELD_TYPES(), forAll, forAllConstIter, forAllIter, found, HashTable< T, Key, Hash >::found(), GenerateTypeFields, Foam::gSum(), Foam::Info, IOobject::MUST_READ, IOobject::name(), Foam::name(), Foam::nl, IOobject::NO_READ, IOobject::NO_WRITE, regionSplit::nRegions(), fvPatchField< Type >::patch(), fvPatch::patch(), patchi, fvPatchField< Type >::patchInternalField(), fvPatchField< Type >::patchNeighbourField(), Foam::constant::mathematical::pi(), Foam::pow(), autoPtr< T >::reset(), HashTable< T, Key, Hash >::size(), List< T >::size(), HashTable< T, Key, Hash >::sortedToc(), polyPatch::start(), Foam::tab, Foam::type(), TypeFieldsExpand, TypeFieldsParameter, autoPtr< T >::valid(), regIOobject::write(), and x.

Here is the call graph for this function:

◆ operator=()

void operator= ( const regionSizeDistribution & )

delete

Disallow default bitwise assignment.

◆ divide()

Foam::tmp<Foam::Field<Type> > divide	(	const Field< Type > &	num,
		const scalarField &	denom
	)

Definition at line 198 of file regionSizeDistribution.C.

References forAll, tmp< T >::ref(), List< T >::size(), and Foam::Zero.

Here is the call graph for this function:

◆ regionSum()

Foam::Map<Type> regionSum	(	const regionSplit &	regions,
		const Field< Type > &	fld
	)		const

Definition at line 33 of file regionSizeDistributionTemplates.C.

References HashTableCore::end(), HashTable< T, Key, Hash >::find(), fld(), forAll, HashTable< T, Key, Hash >::insert(), Pstream::mapCombineGather(), Pstream::mapCombineScatter(), UPstream::nProcs(), and regionSplit::nRegions().

Here is the call graph for this function:

◆ extractData()

Foam::List<Type> extractData	(	const UList< label > &	keys,
		const Map< Type > &	regionData
	)		const

Definition at line 64 of file regionSizeDistributionTemplates.C.

References forAll, and UList< T >::size().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/functionObjects/field/regionSizeDistribution/regionSizeDistribution.H
src/functionObjects/field/regionSizeDistribution/regionSizeDistribution.C
src/functionObjects/field/regionSizeDistribution/regionSizeDistributionTemplates.C

Public Member Functions

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ regionSizeDistribution() [1/2]

◆ regionSizeDistribution() [2/2]

◆ ~regionSizeDistribution()

Member Function Documentation

◆ TypeName()

◆ read()

◆ fields()

◆ execute()

◆ write()

◆ operator=()

◆ divide()

◆ regionSum()

◆ extractData()
