Evolves a passive scalar transport equation within one phase of a multiphase simulation. The scalar is considered to be a phase-intensive property; i.e., its value represents an amount per-unit of the phase. In addition to the scalar, the function also writes out the product of the volume fraction and the scalar, as this provides a phase-extensive field which is often more convenient to post-process. More...

Inheritance diagram for phaseScalarTransport:

[legend]

Collaboration diagram for phaseScalarTransport:

[legend]

Public Member Functions
	TypeName ("phaseScalarTransport")
	Runtime type information. More...

	phaseScalarTransport (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

virtual	~phaseScalarTransport ()
	Destructor. More...

virtual bool	read (const dictionary &)
	Read the settings from the given dictionary. More...

virtual wordList	fields () const
	Return the list of fields required. More...

virtual bool	executeAtStart () const
	Do not execute at the start of the run. More...

virtual bool	execute ()
	Solve for the evolution of the field. More...

virtual bool	write ()
	Do nothing. The field is registered and written automatically. More...

Public Member Functions inherited from fvMeshFunctionObject
	TypeName ("fvMeshFunctionObject")
	Runtime type information. More...

	fvMeshFunctionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	fvMeshFunctionObject (const word &name, const objectRegistry &obr)
	Construct from the region objectRegistry. More...

	fvMeshFunctionObject (const fvMeshFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~fvMeshFunctionObject ()
	Destructor. More...

const fvMesh &	mesh () const
	Return a reference to the mesh. More...

void	operator= (const fvMeshFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from regionFunctionObject
	TypeName ("regionFunctionObject")
	Runtime type information. More...

	regionFunctionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	regionFunctionObject (const word &name, const objectRegistry &obr)
	Construct from the region objectRegistry. More...

	regionFunctionObject (const regionFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~regionFunctionObject ()
	Destructor. More...

void	operator= (const regionFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from objectRegistryFunctionObject
	TypeName ("objectRegistryFunctionObject")
	Runtime type information. More...

	objectRegistryFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)
	Construct from an objectRegistry and dictionary. More...

	objectRegistryFunctionObject (const word &name, const objectRegistry &obr)
	Construct from an objectRegistry. More...

	objectRegistryFunctionObject (const objectRegistryFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~objectRegistryFunctionObject ()
	Destructor. More...

void	operator= (const objectRegistryFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from functionObject
	ClassName ("functionObject")

virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const Time &runTime)
	Construct from components. More...

	functionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from dictionary. More...

autoPtr< functionObject >	clone () const
	Return clone. More...

	functionObject (const functionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~functionObject ()
	Destructor. More...

const word &	name () const
	Return the name of this functionObject. More...

virtual bool	end ()
	Called when Time::run() determines that the time-loop exits. More...

virtual scalar	timeToNextAction ()
	Called by Time::adjustTimeStep(). Allows the functionObject to. More...

virtual scalar	maxDeltaT () const
	Return the maximum time-step for stable operation. More...

virtual void	movePoints (const polyMesh &mesh)
	Update topology using the given map. More...

virtual void	topoChange (const polyTopoChangeMap &map)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

void	operator= (const functionObject &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &, const dictionary &)
	Select from dictionary, based on its "type" entry. More...

Public Attributes inherited from functionObject
Switch	log
	Switch write log to Info. More...

Switch	executeAtStart_
	Switch execute at start time. More...

Static Public Attributes inherited from functionObject
static bool	postProcess
	Global post-processing mode switch. More...

Protected Member Functions inherited from objectRegistryFunctionObject
template<class ObjectType >
bool	foundObject (const word &fieldName) const
	Find field in the objectRegistry. More...

template<class ObjectType >
void	cannotFindObject (const word &fieldName)
	Prints a warning message that fieldName cannot be found. More...

void	cannotFindObject (const word &fieldName)
	Prints a warning message that fieldName cannot be found. More...

void	cannotFindObjects (const wordList &fieldNames)
	Prints a warning message that fieldNames cannot be found. More...

template<class ObjectType >
const ObjectType &	lookupObject (const word &fieldName) const
	Lookup object from the objectRegistry. More...

template<class ObjectType >
ObjectType &	lookupObjectRef (const word &fieldName)
	Lookup non-const object reference from the objectRegistry. More...

template<class ObjectType >
ObjectType &	store (const tmp< ObjectType > &tfield)
	Store the given field in the objectRegistry. More...

template<class ObjectType >
ObjectType &	store (const word &fieldName, const tmp< ObjectType > &tfield, bool cacheable=false)
	Store the given field in the objectRegistry under the given name. More...

bool	writeObject (const word &fieldName)
	Write field if present in objectRegistry. More...

bool	clearObject (const word &fieldName)
	Clear field from the objectRegistry if present. More...

Protected Attributes inherited from fvMeshFunctionObject
const fvMesh &	mesh_
	Reference to the fvMesh. More...

Protected Attributes inherited from objectRegistryFunctionObject
const objectRegistry &	obr_
	Reference to the objectRegistry. More...

Protected Attributes inherited from functionObject
const Time &	time_
	Reference to time. More...

Detailed Description

Evolves a passive scalar transport equation within one phase of a multiphase simulation. The scalar is considered to be a phase-intensive property; i.e., its value represents an amount per-unit of the phase. In addition to the scalar, the function also writes out the product of the volume fraction and the scalar, as this provides a phase-extensive field which is often more convenient to post-process.

Most entries are the same as for the scalarTransport function. Refer to its documentation for details. Entries specific to this function are detailed below. Note that the phase-name will be determined by stripping the extension from the supplied field name.

If the solver does not provide an alphaPhi flux, or that flux is for some reason unreliable, then the solveAlphaPhi switch can be used to make this function solve a pressure-like equation from which alphaPhi is recovered.

Usage

Property	Description	Req'd?	Default
`alpha`	Name of the volume-fraction field	no	alpha.<phase-name>
`alphaPhi`	Name of the phase-flux field	no	alphaPhi.<phase-name>
`solveAlphaPhi`	Solve for the alphaPhi flux, rather than looking it up	no	false
`p`	Name of the pressure field	no	p
`residualAlpha`	Small volume fraction used to stabilise the solution	no	rootSmall
`writeAlphaField`	Also write out alpha multiplied by the field	no	true

Example specification for incompressibleVoF:

    phaseScalarTransport1
    {
        type            phaseScalarTransport;
        libs            ("libsolverFunctionObjects.so");

        field           s.water;
    }

Example specification for multiphaseEuler:

    phaseScalarTransport1
    {
        type            phaseScalarTransport;
        libs            ("libsolverFunctionObjects.so");

        field           s.water;
        alphaPhi        alphaRhoPhi.water;
        rho             rho.water;
    }
