Function to write the mass field for a cloud. More...

Inheritance diagram for cloudMass:

Collaboration diagram for cloudMass:

Public Member Functions
	TypeName ("cloudMass")
	Runtime type information. More...

	cloudMass (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	cloudMass (const cloudMass &)=delete
	Disallow default bitwise copy construction. More...

virtual	~cloudMass ()
	Destructor. More...

virtual wordList	fields () const
	Return the list of fields required. More...

virtual bool	execute ()
	Calculate and store the masses. More...

virtual void	calculate (const LagrangianSubScalarField &deltaT, const bool final)
	Update the masses. More...

virtual bool	write ()
	Write the masses. More...

virtual bool	clear ()
	Clear the masses. More...

void	operator= (const cloudMass &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from cloudLagrangianMeshFunctionObject
	TypeName ("cloudLagrangianMeshFunctionObject")
	Runtime type information. More...

	cloudLagrangianMeshFunctionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	cloudLagrangianMeshFunctionObject (const cloudLagrangianMeshFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~cloudLagrangianMeshFunctionObject ()
	Destructor. More...

void	operator= (const cloudLagrangianMeshFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from LagrangianMeshFunctionObject
	TypeName ("LagrangianMeshFunctionObject")
	Runtime type information. More...

	LagrangianMeshFunctionObject (const word &name, const Time &runTime, const dictionary &dict, const word &LagrangianKeyword="Lagrangian")
	Construct from Time and dictionary. More...

	LagrangianMeshFunctionObject (const LagrangianMeshFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~LagrangianMeshFunctionObject ()
	Destructor. More...

const LagrangianMesh &	mesh () const
	Access the mesh. More...

void	operator= (const LagrangianMeshFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from objectRegistryFunctionObject
	TypeName ("objectRegistryFunctionObject")
	Runtime type information. More...

	objectRegistryFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)
	Construct from an objectRegistry and dictionary. More...

	objectRegistryFunctionObject (const word &name, const objectRegistry &obr)
	Construct from an objectRegistry. More...

	objectRegistryFunctionObject (const objectRegistryFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~objectRegistryFunctionObject ()
	Destructor. More...

virtual bool	read (const dictionary &)
	Read optional controls. More...

void	operator= (const objectRegistryFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from functionObject
	ClassName ("functionObject")

virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const Time &runTime)
	Construct from components. More...

	functionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from dictionary. More...

autoPtr< functionObject >	clone () const
	Return clone. More...

	functionObject (const functionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~functionObject ()
	Destructor. More...

const word &	name () const
	Return the name of this functionObject. More...

virtual bool	executeAtStart () const
	Return true if the functionObject should be executed at the start. More...

virtual bool	end ()
	Called when Time::run() determines that the time-loop exits. More...

virtual scalar	timeToNextAction ()
	Called by Time::adjustTimeStep(). Allows the functionObject to. More...

virtual scalar	maxDeltaT () const
	Return the maximum time-step for stable operation. More...

virtual void	movePoints (const polyMesh &mesh)
	Update topology using the given map. More...

virtual void	topoChange (const polyTopoChangeMap &map)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

void	operator= (const functionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from cloudFunctionObject
	TypeName ("cloudFunctionObject")
	Runtime type information. More...

	cloudFunctionObject (const LagrangianMeshFunctionObject &)
	Construct from a Lagrangian mesh function object. More...

	cloudFunctionObject (const fvMeshFunctionObject &, const dictionary &dict)
	Construct from an fvMesh function object and a dictionary. More...

	cloudFunctionObject (const cloudFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~cloudFunctionObject ()
	Destructor. More...

const Foam::cloud &	cloud () const
	Return the cloud. More...

virtual void	preSolve ()
	Hook before solution steps. More...

virtual void	preCrossFaces (const LagrangianScalarInternalDynamicField &fraction)
	Hook before all face crossings. More...

virtual void	preCrossFaces (const LagrangianSubScalarSubField &fraction)
	Hook before face crossings of a specific sub-mesh. More...

virtual void	postCrossFaces (const LagrangianSubScalarSubField &fraction)
	Hook following face crossings of a specific sub-mesh. More...

virtual void	postCrossFaces (const LagrangianScalarInternalDynamicField &fraction)
	Hook after all face crossings. More...

virtual void	postSolve ()
	Hook following solution steps. More...

void	operator= (const cloudFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &, const dictionary &)
	Select from dictionary, based on its "type" entry. More...

Public Attributes inherited from functionObject
Switch	log
	Switch write log to Info. More...

Switch	executeAtStart_
	Switch execute at start time. More...

Static Public Attributes inherited from functionObject
static bool	postProcess
	Global post-processing mode switch. More...

Protected Member Functions inherited from objectRegistryFunctionObject
template<class ObjectType >
bool	foundObject (const word &fieldName) const
	Find field in the objectRegistry. More...

template<class ObjectType >
void	cannotFindObject (const word &fieldName)
	Prints a warning message that fieldName cannot be found. More...

void	cannotFindObject (const word &fieldName)
	Prints a warning message that fieldName cannot be found. More...

void	cannotFindObjects (const wordList &fieldNames)
	Prints a warning message that fieldNames cannot be found. More...

template<class ObjectType >
const ObjectType &	lookupObject (const word &fieldName) const
	Lookup object from the objectRegistry. More...

template<class ObjectType >
ObjectType &	lookupObjectRef (const word &fieldName)
	Lookup non-const object reference from the objectRegistry. More...

template<class ObjectType >
ObjectType &	store (const tmp< ObjectType > &tfield)
	Store the given field in the objectRegistry. More...

template<class ObjectType >
ObjectType &	store (const word &fieldName, const tmp< ObjectType > &tfield, bool cacheable=false)
	Store the given field in the objectRegistry under the given name. More...

bool	writeObject (const word &fieldName)
	Write field if present in objectRegistry. More...

bool	clearObject (const word &fieldName)
	Clear field from the objectRegistry if present. More...

Protected Member Functions inherited from cloudFunctionObject
template<class Cloud >
bool	isCloud () const
	Determine whether the cloud is of the given type. More...

template<class Cloud = Foam::cloud>
const Cloud &	cloud () const
	Get a reference to the cloud. More...

Protected Attributes inherited from objectRegistryFunctionObject
const objectRegistry &	obr_
	Reference to the objectRegistry. More...

Protected Attributes inherited from functionObject
const Time &	time_
	Reference to time. More...

Detailed Description

Function to write the mass field for a cloud.

Usage

Property	Description	Required?	Default
`cloud`	Name of the cloud	yes

Example specification:

    cloudMass1
    {
        type            cloudMass;
        libs            ("libLagrangianCloudFunctionObjects.so");
        cloud           cloud;
    }

Source files

Definition at line 76 of file cloudMass.H.

Constructor & Destructor Documentation

◆ cloudMass() [1/2]

cloudMass	(	const word &	name,
		const Time &	runTime,
		const dictionary &	dict
	)

Construct from Time and dictionary.

Definition at line 46 of file cloudMass.C.

◆ cloudMass() [2/2]

cloudMass ( const cloudMass & )

delete

Disallow default bitwise copy construction.

◆ ~cloudMass()

~cloudMass ( )

virtual

Destructor.

Definition at line 59 of file cloudMass.C.

Member Function Documentation

◆ TypeName()

TypeName ( "cloudMass" )

Runtime type information.

◆ fields()

Foam::wordList fields ( ) const

virtual

Return the list of fields required.

Implements functionObject.

Definition at line 65 of file cloudMass.C.

References List< word >::null().

Here is the call graph for this function:

◆ execute()

bool execute ( )

virtual

Calculate and store the masses.

Implements functionObject.

Definition at line 71 of file cloudMass.C.

References boundary(), mesh, massive::mName, GeometricField< Type, GeoMesh, PrimitiveField >::New(), and List< word >::null().

Here is the call graph for this function:

◆ calculate()

void calculate	(	const LagrangianSubScalarField &	deltaT,
		const bool	final
	)

virtual

Update the masses.

Reimplemented from cloudFunctionObject.

Definition at line 102 of file cloudMass.C.

References DimensionedField< Type, GeoMesh, PrimitiveField >::mesh(), massive::mName, and LagrangianSubMesh::sub().

Here is the call graph for this function:

◆ write()

bool write ( )

virtual

Write the masses.

Implements functionObject.

Definition at line 125 of file cloudMass.C.

References massive::mName.

◆ clear()

bool clear ( )

virtual

Clear the masses.

Definition at line 131 of file cloudMass.C.

References massive::mName.

◆ operator=()

void operator= ( const cloudMass & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

src/Lagrangian/cloudFunctionObjects/cloudMass/cloudMass.H
src/Lagrangian/cloudFunctionObjects/cloudMass/cloudMass.C
