Tuple2< Type1, Type2 > Class Template Reference

A 2-tuple for storing two objects of different types. More...

Inheritance diagram for Tuple2< Type1, Type2 >:

Classes
class	Hash
	Hashing function class. More...

Public Member Functions
	Tuple2 ()
	Null constructor for lists. More...
	Tuple2 (const Type1 &f, const Type2 &s)
	Construct from components. More...
	Tuple2 (Istream &is)
	Construct from Istream. More...
const Type1 &	first () const
	Return first. More...
Type1 &	first ()
	Return first. More...
const Type2 &	second () const
	Return second. More...
Type2 &	second ()
	Return second. More...
const char *const	typeName ("Tuple2<scalar," "vector2D" ">")
const char *const	typeName ("Tuple2<word,scalar>")

Static Public Attributes
static const char *const	typeName

Friends
Istream &	operator>> (Istream &is, Tuple2< Type1, Type2 > &t2)
	Read Tuple2 from Istream, discarding contents of existing Tuple2. More...
Ostream &	operator (Ostream &os, const Tuple2< Type1, Type2 > &t2)

Detailed Description

template<class Type1, class Type2>
class Foam::Tuple2< Type1, Type2 >

A 2-tuple for storing two objects of different types.

See also

Foam::Pair for storing two objects of identical types.

Definition at line 65 of file Tuple2.H.

Constructor & Destructor Documentation

Tuple2() [1/3]

Tuple2 ( )

inline

Null constructor for lists.

Definition at line 99 of file Tuple2.H.

Tuple2() [2/3]

Tuple2 ( const Type1 &  f, const Type2 &  s  )

inline

Construct from components.

Definition at line 103 of file Tuple2.H.

Tuple2() [3/3]

Tuple2 ( Istream &  is )

inline

Construct from Istream.

Definition at line 110 of file Tuple2.H.

Member Function Documentation

first() [1/2]

const Type1& first ( ) const

inline

Return first.

Definition at line 119 of file Tuple2.H.

Referenced by faceFsData::cache(), pointConstraint::combine(), Foam::dictArgList(), fieldAverageItem::fieldAverageItem(), coordSet::gather(), Foam::tracking::locate(), forceSuSp::operator+=(), forceSuSp::operator-=(), Foam::operator<<(), Foam::operator==(), Foam::operator>>(), argList::parse(), intersection::part::part(), nonConformalCyclicLagrangianPatch::partition(), Foam::readConfigFile(), Foam::reverse(), Newmark::solve(), symplectic::solve(), LagrangianMesh::track(), particle::track(), particle::trackToCell(), particle::trackToFace(), Foam::transform(), and Foam::Function2s::valueName().

Here is the caller graph for this function:

first() [2/2]

Type1& first ( )

inline

Return first.

Definition at line 125 of file Tuple2.H.

second() [1/2]

const Type2& second ( ) const

inline

Return second.

Definition at line 131 of file Tuple2.H.

Referenced by face::areaAndCentreStabilised(), faceFsData::cache(), pointConstraint::combine(), Foam::dictArgList(), fieldAverageItem::fieldAverageItem(), coordSet::gather(), Foam::isValidBoundSphere(), Foam::tracking::locate(), forceSuSp::operator+=(), forceSuSp::operator-=(), Foam::operator<<(), Foam::operator==(), Foam::operator>>(), argList::parse(), intersection::part::part(), nonConformalCyclicLagrangianPatch::partition(), Foam::readConfigFile(), Foam::reverse(), symplectic::solve(), LagrangianMesh::track(), particle::track(), particle::trackToCell(), particle::trackToFace(), and Foam::transform().

Here is the caller graph for this function:

second() [2/2]

Type2& second ( )

inline

Return second.

Definition at line 137 of file Tuple2.H.

typeName() [1/2]

const char *const typeName

(

"Tuple2<scalar," "vector2D" ">"

)

typeName() [2/2]

const char *const typeName

(

"Tuple2<word,scalar>"

)

Friends And Related Function Documentation

operator>>

Istream& operator>> ( Istream &  is, Tuple2< Type1, Type2 > &  t2  )

friend

Read Tuple2 from Istream, discarding contents of existing Tuple2.

Definition at line 208 of file Tuple2.H.

operator

Ostream& operator ( Ostream &  os, const Tuple2< Type1, Type2 > &  t2  )

friend

Member Data Documentation

typeName

const char* const typeName

static

Definition at line 93 of file Tuple2.H.

---

The documentation for this class was generated from the following files:

• src/OpenFOAM/containers/HashTables/HashTable/HashTable.H
• src/OpenFOAM/primitives/Tuple2/Tuple2.H
