Public Member Functions | Static Public Member Functions | List of all members
motionSolver Class Referenceabstract

Virtual base class for mesh motion solver. More...

Inheritance diagram for motionSolver:
Inheritance graph
[legend]

Public Member Functions

 TypeName ("motionSolver")
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, motionSolver, dictionary,(const word &name, const polyMesh &mesh, const dictionary &dict),(name, mesh, dict))

 motionSolver (const word &name, const polyMesh &mesh, const word &type)
 Construct from polyMesh and dictionary and type. More...

virtual autoPtr< motionSolver > clone () const
 Clone function. More...

virtual ~motionSolver ()
 Destructor. More...

const word & name () const
 Return name. More...

const word & keyword () const
 Return keyword. More...

const polyMesh & mesh () const
 Return reference to mesh. More...

virtual tmp< pointField > newPoints ()
 Provide new points for motion. Solves for motion. More...

virtual tmp< pointField > curPoints () const =0
 Provide current points for motion. Uses current motion field. More...

virtual void twoDCorrectPoints (pointField &) const
 Correct point field for reduced-dimensionality cases. More...

virtual bool solidBody () const
 Is the motion solid body? I.e., are the volumes and area magnitudes. More...

virtual void solve ()=0
 Solve for motion. More...

virtual void movePoints (const pointField &)=0
 Update local data for geometry changes. More...

virtual void topoChange (const polyTopoChangeMap &)=0
 Update local data for topology changes. More...

virtual void distribute (const polyDistributionMap &)=0
 Update corresponding to the given distribution map. More...

virtual void mapMesh (const polyMeshMap &)=0
 Update from another mesh using the given map. More...

virtual bool write () const
 Optionally write motion state information for restart. More...


Static Public Member Functions

static autoPtr< motionSolver > New (const word &name, const polyMesh &, const dictionary &)
 Select constructed from polyMesh and dictionary. More...


Detailed Description

Virtual base class for mesh motion solver.

Source files

Definition at line 56 of file motionSolver.H.

Constructor & Destructor Documentation

◆ motionSolver()

motionSolver ( const word &  name,
const polyMesh &  mesh,
const word &  type
)

Construct from polyMesh and dictionary and type.

Definition at line 42 of file motionSolver.C.

◆ ~motionSolver()

~motionSolver ( )
virtual

Destructor.

Definition at line 115 of file motionSolver.C.

Member Function Documentation

◆ TypeName()

TypeName ( "motionSolver"  )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable ( autoPtr  ,
motionSolver  ,
dictionary  ,
(const word &name, const polyMesh &mesh, const dictionary &dict)  ,
(name, mesh, dict)
)

◆ New()

Foam::autoPtr< Foam::motionSolver > New ( const word &  name,
const polyMesh &  mesh,
const dictionary &  solverDict
)
static

Select constructed from polyMesh and dictionary.

Definition at line 63 of file motionSolver.C.

References Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, Foam::Info, Foam::libs, dictionary::lookup(), mesh, Foam::name(), Foam::nl, dlLibraryTable::open(), and dictionary::optionalSubDict().

Referenced by motionSolverList::motionSolverList().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ clone()

Foam::autoPtr< Foam::motionSolver > clone ( ) const
virtual

Clone function.

Definition at line 54 of file motionSolver.C.

References NotImplemented.

◆ name()

const word& name ( ) const
inline

Return name.

Definition at line 121 of file motionSolver.H.

Referenced by motionSolver::keyword(), and motionSolverList::motionSolverList().

Here is the caller graph for this function:

◆ keyword()

const word& keyword ( ) const
inline

Return keyword.

Definition at line 127 of file motionSolver.H.

References motionSolver::name().

Referenced by multiSolidBodyMotionSolver::multiSolidBodyMotionSolver(), rigidBodyMeshMotion::rigidBodyMeshMotion(), and rigidBodyMeshMotionSolver::rigidBodyMeshMotionSolver().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ mesh()

const polyMesh& mesh ( ) const
inline

Return reference to mesh.

Definition at line 133 of file motionSolver.H.

Referenced by componentDisplacementMotionSolver::componentDisplacementMotionSolver(), motionSolverList::motionSolverList(), multiSolidBodyMotionSolver::multiSolidBodyMotionSolver(), points0MotionSolver::points0MotionSolver(), points0MotionSolver::readPoints0(), propellerDiskForce::restrain(), rigidBodyMeshMotion::rigidBodyMeshMotion(), rigidBodyMeshMotionSolver::rigidBodyMeshMotionSolver(), and sixDoFRigidBodyMotionSolver::sixDoFRigidBodyMotionSolver().

Here is the caller graph for this function:

◆ newPoints()

Foam::tmp< Foam::pointField > newPoints ( )
virtual

Provide new points for motion. Solves for motion.

Definition at line 121 of file motionSolver.C.

References Foam::solve().

Here is the call graph for this function:

◆ curPoints()

virtual tmp<pointField> curPoints ( ) const
pure virtual

Provide current points for motion. Uses current motion field.

Implemented in sixDoFRigidBodyMotionSolver, rigidBodyMeshMotionSolver, rigidBodyMeshMotion, motionSolverList, solidBodyMotionSolver, multiSolidBodyMotionSolver, interpolatingSolidBodyMotionSolver, displacementLinearMotionSolver, displacementLayeredMotionSolver, displacementMeshMoverMotionSolver, velocityLaplacianFvMotionSolver, displacementSBRStressFvMotionSolver, displacementLaplacianFvMotionSolver, velocityComponentLaplacianFvMotionSolver, and displacementComponentLaplacianFvMotionSolver.

◆ twoDCorrectPoints()

void twoDCorrectPoints ( pointField &  p) const
virtual

Correct point field for reduced-dimensionality cases.

Definition at line 128 of file motionSolver.C.

References twoDPointCorrector::correctPoints(), DemandDrivenMeshObject< polyMesh, TopoChangeableMeshObject, twoDPointCorrector >::New(), and p.

Here is the call graph for this function:

◆ solidBody()

virtual bool solidBody ( ) const
inlinevirtual

Is the motion solid body? I.e., are the volumes and area magnitudes.

unchanged? Defaults to false. Set to true by motionSolvers::solidBody.

Reimplemented in solidBodyMotionSolver, and multiSolidBodyMotionSolver.

Definition at line 150 of file motionSolver.H.

◆ solve()

virtual void solve ( )
pure virtual

Solve for motion.

Implemented in sixDoFRigidBodyMotionSolver, rigidBodyMeshMotionSolver, rigidBodyMeshMotion, motionSolverList, solidBodyMotionSolver, multiSolidBodyMotionSolver, interpolatingSolidBodyMotionSolver, displacementLinearMotionSolver, displacementLayeredMotionSolver, displacementMeshMoverMotionSolver, velocityLaplacianFvMotionSolver, displacementSBRStressFvMotionSolver, displacementLaplacianFvMotionSolver, velocityComponentLaplacianFvMotionSolver, and displacementComponentLaplacianFvMotionSolver.

◆ movePoints()

virtual void movePoints ( const pointField &  )
pure virtual

Update local data for geometry changes.

Implemented in rigidBodyMeshMotionSolver, velocityMotionSolver, motionSolverList, points0MotionSolver, componentVelocityMotionSolver, componentDisplacementMotionSolver, and displacementMeshMoverMotionSolver.

◆ topoChange()

virtual void topoChange ( const polyTopoChangeMap &  )
pure virtual

Update local data for topology changes.

Implemented in rigidBodyMeshMotionSolver, rigidBodyMeshMotion, velocityMotionSolver, motionSolverList, solidBodyMotionSolver, interpolatingSolidBodyMotionSolver, points0MotionSolver, displacementLayeredMotionSolver, componentVelocityMotionSolver, componentDisplacementMotionSolver, displacementMeshMoverMotionSolver, velocityLaplacianFvMotionSolver, displacementSBRStressFvMotionSolver, displacementLaplacianFvMotionSolver, velocityComponentLaplacianFvMotionSolver, and displacementComponentLaplacianFvMotionSolver.

◆ distribute()

virtual void distribute ( const polyDistributionMap &  )
pure virtual

Update corresponding to the given distribution map.

Implemented in rigidBodyMeshMotionSolver, velocityMotionSolver, motionSolverList, solidBodyMotionSolver, points0MotionSolver, componentVelocityMotionSolver, and componentDisplacementMotionSolver.

◆ mapMesh()

virtual void mapMesh ( const polyMeshMap &  )
pure virtual

Update from another mesh using the given map.

Implemented in rigidBodyMeshMotionSolver, velocityMotionSolver, motionSolverList, solidBodyMotionSolver, interpolatingSolidBodyMotionSolver, points0MotionSolver, displacementMotionSolver, componentVelocityMotionSolver, componentDisplacementMotionSolver, velocityLaplacianFvMotionSolver, displacementSBRStressFvMotionSolver, displacementLaplacianFvMotionSolver, velocityComponentLaplacianFvMotionSolver, and displacementComponentLaplacianFvMotionSolver.

◆ write()

bool write ( ) const
virtual

Optionally write motion state information for restart.

Reimplemented in sixDoFRigidBodyMotionSolver, rigidBodyMeshMotionSolver, rigidBodyMeshMotion, and points0MotionSolver.

Definition at line 134 of file motionSolver.C.

Referenced by points0MotionSolver::write(), and rigidBodyMeshMotionSolver::write().

Here is the caller graph for this function:
The documentation for this class was generated from the following files:
