Solid-body motion of the mesh specified by a run-time selectable motion function. More...

Inheritance diagram for multiSolidBodyMotionSolver:

Collaboration diagram for multiSolidBodyMotionSolver:

Public Member Functions
	TypeName ("multiSolidBodyMotionSolver")
	Runtime type information. More...

	multiSolidBodyMotionSolver (const word &name, const polyMesh &, const dictionary &)
	Construct from mesh and dictionary. More...

	multiSolidBodyMotionSolver (const multiSolidBodyMotionSolver &)=delete
	Disallow default bitwise copy construction. More...

	~multiSolidBodyMotionSolver ()
	Destructor. More...

virtual tmp< pointField >	curPoints () const
	Return point location obtained from the current motion field. More...

virtual bool	solidBody () const
	This is a solid body motion. More...

virtual void	solve ()
	Solve for motion. More...

void	operator= (const multiSolidBodyMotionSolver &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from points0MotionSolver
	TypeName ("points0MotionSolver")
	Runtime type information. More...

	points0MotionSolver (const word &name, const polyMesh &, const dictionary &, const word &type)
	Construct from mesh and dictionary. More...

	points0MotionSolver (const points0MotionSolver &)=delete
	Disallow default bitwise copy construction. More...

virtual	~points0MotionSolver ()
	Destructor. More...

pointField &	points0 ()
	Return reference to the reference field. More...

const pointField &	points0 () const
	Return reference to the reference field. More...

virtual void	movePoints (const pointField &)
	Update local data for geometry changes. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update local data for topology changes. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Update corresponding to the given distribution map. More...

virtual bool	write () const
	Write points0 if the mesh topology changed. More...

void	operator= (const points0MotionSolver &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from motionSolver
	TypeName ("motionSolver")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, motionSolver, dictionary,(const word &name, const polyMesh &mesh, const dictionary &dict),(name, mesh, dict))

	motionSolver (const word &name, const polyMesh &mesh, const word &type)
	Construct from polyMesh and dictionary and type. More...

virtual autoPtr< motionSolver >	clone () const
	Clone function. More...

virtual	~motionSolver ()
	Destructor. More...

const word &	name () const
	Return name. More...

const word &	keyword () const
	Return keyword. More...

const polyMesh &	mesh () const
	Return reference to mesh. More...

virtual tmp< pointField >	newPoints ()
	Provide new points for motion. Solves for motion. More...

virtual void	twoDCorrectPoints (pointField &) const
	Correct point field for reduced-dimensionality cases. More...

Additional Inherited Members
Static Public Member Functions inherited from points0MotionSolver
static pointVectorField	readPoints0 (const polyMesh &mesh)

Static Public Member Functions inherited from motionSolver
static autoPtr< motionSolver >	New (const word &name, const polyMesh &, const dictionary &)
	Select constructed from polyMesh and dictionary. More...

Protected Attributes inherited from points0MotionSolver
pointVectorField	points0_
	Starting points. More...

Detailed Description

Solid-body motion of the mesh specified by a run-time selectable motion function.

Source files

Definition at line 50 of file multiSolidBodyMotionSolver.H.

Constructor & Destructor Documentation

◆ multiSolidBodyMotionSolver() [1/2]

multiSolidBodyMotionSolver	(	const word &	name,
		const polyMesh &	mesh,
		const dictionary &	dict
	)

Construct from mesh and dictionary.

Definition at line 49 of file multiSolidBodyMotionSolver.C.

References DynamicList< T, SizeInc, SizeMult, SizeDiv >::append(), Foam::constant::universal::c, primitiveMesh::cells(), polyMesh::cellZones(), dict, Foam::endl(), Foam::exit(), f(), polyMesh::faces(), Foam::FatalIOError, FatalIOErrorInFunction, PtrListDictionary< T >::findIndex(), forAll, forAllConstIter, Foam::Info, k, motionSolver::keyword(), motionSolver::mesh(), solidBodyMotionFunction::New(), primitiveMesh::nPoints(), List< T >::setSize(), List< T >::size(), syncTools::syncPointList(), objectRegistry::time(), DictionaryBase< IDLListType, T >::toc(), and List< T >::transfer().

Here is the call graph for this function:

◆ multiSolidBodyMotionSolver() [2/2]

multiSolidBodyMotionSolver ( const multiSolidBodyMotionSolver & )

delete

Disallow default bitwise copy construction.

◆ ~multiSolidBodyMotionSolver()

~multiSolidBodyMotionSolver ( )

Destructor.

Definition at line 136 of file multiSolidBodyMotionSolver.C.

Member Function Documentation

◆ TypeName()

TypeName ( "multiSolidBodyMotionSolver" )

Runtime type information.

◆ curPoints()

Foam::tmp< Foam::pointField > curPoints ( ) const

virtual

Return point location obtained from the current motion field.

Implements motionSolver.

Definition at line 142 of file multiSolidBodyMotionSolver.C.

References forAll, mesh, points, tmp< T >::ref(), and Foam::transformPoints().

Here is the call graph for this function:

◆ solidBody()

virtual bool solidBody ( ) const

inlinevirtual

This is a solid body motion.

Reimplemented from motionSolver.

Definition at line 96 of file multiSolidBodyMotionSolver.H.

◆ solve()

virtual void solve ( )

inlinevirtual

Solve for motion.

Implements motionSolver.

Definition at line 102 of file multiSolidBodyMotionSolver.H.

◆ operator=()

void operator= ( const multiSolidBodyMotionSolver & )
