Public Member Functions | Protected Attributes | List of all members
velocityMotionSolver Class Reference

Virtual base class for velocity motion solver. More...

Inheritance diagram for velocityMotionSolver:
Inheritance graph
[legend]
Collaboration diagram for velocityMotionSolver:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("velocityMotionSolver")
 Runtime type information. More...

 velocityMotionSolver (const word &name, const polyMesh &, const dictionary &, const word &type)
 Construct from mesh and dictionary. More...

 velocityMotionSolver (const velocityMotionSolver &)=delete
 Disallow default bitwise copy construction. More...

virtual ~velocityMotionSolver ()
 Destructor. More...

pointVectorField & pointMotionU ()
 Return reference to the point motion velocity field. More...

const pointVectorField & pointMotionU () const
 Return const reference to the point motion velocity field. More...

virtual void movePoints (const pointField &)
 Update local data for geometry changes. More...

virtual void topoChange (const polyTopoChangeMap &)
 Update corresponding to the given map. More...

virtual void mapMesh (const polyMeshMap &)
 Update from another mesh using the given map. More...

virtual void distribute (const polyDistributionMap &)
 Update corresponding to the given distribution map. More...

void operator= (const velocityMotionSolver &)=delete
 Disallow default bitwise assignment. More...

- Public Member Functions inherited from motionSolver
 TypeName ("motionSolver")
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, motionSolver, dictionary,(const word &name, const polyMesh &mesh, const dictionary &dict),(name, mesh, dict))

 motionSolver (const word &name, const polyMesh &mesh, const word &type)
 Construct from polyMesh and dictionary and type. More...

virtual autoPtr< motionSolver > clone () const
 Clone function. More...

virtual ~motionSolver ()
 Destructor. More...

const word & name () const
 Return name. More...

const word & keyword () const
 Return keyword. More...

const polyMesh & mesh () const
 Return reference to mesh. More...

virtual tmp< pointField > newPoints ()
 Provide new points for motion. Solves for motion. More...

virtual tmp< pointField > curPoints () const =0
 Provide current points for motion. Uses current motion field. More...

virtual void twoDCorrectPoints (pointField &) const
 Correct point field for reduced-dimensionality cases. More...

virtual bool solidBody () const
 Is the motion solid body? I.e., are the volumes and area magnitudes. More...

virtual void solve ()=0
 Solve for motion. More...

virtual bool write () const
 Optionally write motion state information for restart. More...


Protected Attributes

pointVectorField pointMotionU_
 Point motion field. More...


Additional Inherited Members

- Static Public Member Functions inherited from motionSolver
static autoPtr< motionSolver > New (const word &name, const polyMesh &, const dictionary &)
 Select constructed from polyMesh and dictionary. More...


Detailed Description

Virtual base class for velocity motion solver.

The boundary displacement is set as a boundary condition on the pointMotionU pointVectorField.

Source files

Definition at line 54 of file velocityMotionSolver.H.

Constructor & Destructor Documentation

◆ velocityMotionSolver() [1/2]

velocityMotionSolver ( const word &  name,
const polyMesh &  mesh,
const dictionary &  dict,
const word &  type
)

Construct from mesh and dictionary.

Definition at line 39 of file velocityMotionSolver.C.

◆ velocityMotionSolver() [2/2]

velocityMotionSolver ( const velocityMotionSolver &  )
delete

Disallow default bitwise copy construction.

◆ ~velocityMotionSolver()

~velocityMotionSolver ( )
virtual

Destructor.

Definition at line 65 of file velocityMotionSolver.C.

Member Function Documentation

◆ TypeName()

TypeName ( "velocityMotionSolver"  )

Runtime type information.

◆ pointMotionU() [1/2]

pointVectorField& pointMotionU ( )
inline

Return reference to the point motion velocity field.

Definition at line 94 of file velocityMotionSolver.H.

References velocityMotionSolver::pointMotionU_.

◆ pointMotionU() [2/2]

const pointVectorField& pointMotionU ( ) const
inline

Return const reference to the point motion velocity field.

Definition at line 100 of file velocityMotionSolver.H.

References velocityMotionSolver::pointMotionU_.

◆ movePoints()

void movePoints ( const pointField &  p)
virtual

Update local data for geometry changes.

Implements motionSolver.

Definition at line 71 of file velocityMotionSolver.C.

◆ topoChange()

void topoChange ( const polyTopoChangeMap &  map)
virtual

Update corresponding to the given map.

Implements motionSolver.

Reimplemented in velocityLaplacianFvMotionSolver.

Definition at line 77 of file velocityMotionSolver.C.

Referenced by velocityLaplacianFvMotionSolver::topoChange().

Here is the caller graph for this function:

◆ mapMesh()

void mapMesh ( const polyMeshMap &  map)
virtual

Update from another mesh using the given map.

Implements motionSolver.

Reimplemented in velocityLaplacianFvMotionSolver.

Definition at line 83 of file velocityMotionSolver.C.

References Foam::Zero.

Referenced by velocityLaplacianFvMotionSolver::mapMesh().

Here is the caller graph for this function:

◆ distribute()

void distribute ( const polyDistributionMap &  )
virtual

Update corresponding to the given distribution map.

Implements motionSolver.

Definition at line 90 of file velocityMotionSolver.C.

◆ operator=()

void operator= ( const velocityMotionSolver &  )
delete

Disallow default bitwise assignment.

Member Data Documentation

◆ pointMotionU_

pointVectorField pointMotionU_
mutableprotected

Point motion field.

Definition at line 63 of file velocityMotionSolver.H.

Referenced by velocityMotionSolver::pointMotionU().

The documentation for this class was generated from the following files:
