Interpolating motion solver for extruded/layered meshes. More...

Inheritance diagram for displacementLayeredMotionSolver:

Collaboration diagram for displacementLayeredMotionSolver:

Public Member Functions
	TypeName ("displacementLayered")
	Runtime type information. More...

	displacementLayeredMotionSolver (const word &name, const polyMesh &, const dictionary &)
	Construct from polyMesh and dictionary. More...

	displacementLayeredMotionSolver (const displacementLayeredMotionSolver &)=delete
	Disallow default bitwise copy construction. More...

	~displacementLayeredMotionSolver ()
	Destructor. More...

virtual tmp< pointField >	curPoints () const
	Return point location obtained from the current motion field. More...

virtual void	solve ()
	Solve for motion. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update topology (not implemented) More...

void	operator= (const displacementLayeredMotionSolver &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from displacementMotionSolver
	TypeName ("displacementMotionSolver")
	Runtime type information. More...

	displacementMotionSolver (const word &name, const polyMesh &, const dictionary &, const word &type)
	Construct from mesh and dictionary. More...

	displacementMotionSolver (const displacementMotionSolver &)=delete
	Disallow default bitwise copy construction. More...

virtual	~displacementMotionSolver ()
	Destructor. More...

pointVectorField &	pointDisplacement ()
	Return reference to the point motion displacement field. More...

const pointVectorField &	pointDisplacement () const
	Return const reference to the point motion displacement field. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

void	operator= (const displacementMotionSolver &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from points0MotionSolver
	TypeName ("points0MotionSolver")
	Runtime type information. More...

	points0MotionSolver (const word &name, const polyMesh &, const dictionary &, const word &type)
	Construct from mesh and dictionary. More...

	points0MotionSolver (const points0MotionSolver &)=delete
	Disallow default bitwise copy construction. More...

virtual	~points0MotionSolver ()
	Destructor. More...

pointField &	points0 ()
	Return reference to the reference field. More...

const pointField &	points0 () const
	Return reference to the reference field. More...

virtual void	movePoints (const pointField &)
	Update local data for geometry changes. More...

virtual void	distribute (const polyDistributionMap &)
	Update corresponding to the given distribution map. More...

virtual bool	write () const
	Write points0 if the mesh topology changed. More...

void	operator= (const points0MotionSolver &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from motionSolver
	TypeName ("motionSolver")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, motionSolver, dictionary,(const word &name, const polyMesh &mesh, const dictionary &dict),(name, mesh, dict))

	motionSolver (const word &name, const polyMesh &mesh, const word &type)
	Construct from polyMesh and dictionary and type. More...

virtual autoPtr< motionSolver >	clone () const
	Clone function. More...

virtual	~motionSolver ()
	Destructor. More...

const word &	name () const
	Return name. More...

const word &	keyword () const
	Return keyword. More...

const polyMesh &	mesh () const
	Return reference to mesh. More...

virtual tmp< pointField >	newPoints ()
	Provide new points for motion. Solves for motion. More...

virtual void	twoDCorrectPoints (pointField &) const
	Correct point field for reduced-dimensionality cases. More...

virtual bool	solidBody () const
	Is the motion solid body? I.e., are the volumes and area magnitudes. More...

Additional Inherited Members
Static Public Member Functions inherited from points0MotionSolver
static pointVectorField	readPoints0 (const polyMesh &mesh)

Static Public Member Functions inherited from motionSolver
static autoPtr< motionSolver >	New (const word &name, const polyMesh &, const dictionary &)
	Select constructed from polyMesh and dictionary. More...

Protected Attributes inherited from displacementMotionSolver
pointVectorField	pointDisplacement_
	Point motion field. More...

Protected Attributes inherited from points0MotionSolver
pointVectorField	points0_
	Starting points. More...

Detailed Description

Interpolating motion solver for extruded/layered meshes.

Uses a topological walk from points along edges to points from one patch to the opposite, accumulating distance and propagating displacement and then again in the return direction and uses the distances from each point to the two opposite patches to linearly interpolate the displacements of these two patches to the each point.

This motion solver is very simple to configure, only the two opposite patches between which the mesh is layered need be specified as a pair of patch names following the oppositePatches keyword, e.g.

    mover
    {
        type            motionSolver;

        libs            ("libfvMotionSolvers.so");

        motionSolver    displacementLayered;

        oppositePatches (top bottom);
    }

Source files

Definition at line 71 of file displacementLayeredMotionSolver.H.
