Solid-body motion of the mesh specified by a run-time selectable motion function. Applies SLERP interpolation of movement as function of distance to the object surface to move the mesh points. More...
Public Member Functions | |
| TypeName ("interpolatingSolidBody") | |
| Runtime type information. More... | |
| interpolatingSolidBodyMotionSolver (const word &name, const polyMesh &, const dictionary &dict) | |
| Construct from polyMesh and dictionary. More... | |
| interpolatingSolidBodyMotionSolver (const interpolatingSolidBodyMotionSolver &)=delete | |
| Disallow default bitwise copy construction. More... | |
| ~interpolatingSolidBodyMotionSolver () | |
| Destructor. More... | |
| virtual tmp< pointField > | curPoints () const |
| Return point location obtained from the current motion field. More... | |
| virtual void | solve () |
| Solve for motion. More... | |
| virtual void | topoChange (const polyTopoChangeMap &) |
| Update local data for topology changes. More... | |
| virtual void | mapMesh (const polyMeshMap &) |
| Update from another mesh using the given map. More... | |
| void | operator= (const interpolatingSolidBodyMotionSolver &)=delete |
| Disallow default bitwise assignment. More... | |
 Public Member Functions inherited from points0MotionSolver | |
| TypeName ("points0MotionSolver") | |
| Runtime type information. More... | |
| points0MotionSolver (const word &name, const polyMesh &, const dictionary &, const word &type) | |
| Construct from mesh and dictionary. More... | |
| points0MotionSolver (const points0MotionSolver &)=delete | |
| Disallow default bitwise copy construction. More... | |
| virtual | ~points0MotionSolver () |
| Destructor. More... | |
| pointField & | points0 () |
| Return reference to the reference field. More... | |
| const pointField & | points0 () const |
| Return reference to the reference field. More... | |
| virtual void | movePoints (const pointField &) |
| Update local data for geometry changes. More... | |
| virtual void | distribute (const polyDistributionMap &) |
| Update corresponding to the given distribution map. More... | |
| virtual bool | write () const |
| Write points0 if the mesh topology changed. More... | |
| void | operator= (const points0MotionSolver &)=delete |
| Disallow default bitwise assignment. More... | |
| Public Member Functions inherited from motionSolver | |
| TypeName ("motionSolver") | |
| Runtime type information. More... | |
| declareRunTimeSelectionTable (autoPtr, motionSolver, dictionary,(const word &name, const polyMesh &mesh, const dictionary &dict),(name, mesh, dict)) | |
| motionSolver (const word &name, const polyMesh &mesh, const word &type) | |
| Construct from polyMesh and dictionary and type. More... | |
| virtual autoPtr< motionSolver > | clone () const |
| Clone function. More... | |
| virtual | ~motionSolver () |
| Destructor. More... | |
| const word & | name () const |
| Return name. More... | |
| const word & | keyword () const |
| Return keyword. More... | |
| const polyMesh & | mesh () const |
| Return reference to mesh. More... | |
| virtual tmp< pointField > | newPoints () |
| Provide new points for motion. Solves for motion. More... | |
| virtual void | twoDCorrectPoints (pointField &) const |
| Correct point field for reduced-dimensionality cases. More... | |
| virtual bool | solidBody () const |
| Is the motion solid body? I.e., are the volumes and area magnitudes. More... | |
Additional Inherited Members | |
| Static Public Member Functions inherited from points0MotionSolver | |
| static pointVectorField | readPoints0 (const polyMesh &mesh) |
| Static Public Member Functions inherited from motionSolver | |
| static autoPtr< motionSolver > | New (const word &name, const polyMesh &, const dictionary &) |
| Select constructed from polyMesh and dictionary. More... | |
| Protected Attributes inherited from points0MotionSolver | |
| pointVectorField | points0_ |
| Starting points. More... | |
Solid-body motion of the mesh specified by a run-time selectable motion function. Applies SLERP interpolation of movement as function of distance to the object surface to move the mesh points.
Definition at line 51 of file interpolatingSolidBodyMotionSolver.H.
| interpolatingSolidBodyMotionSolver | ( | const word & | name, |
| const polyMesh & | mesh, | ||
| const dictionary & | dict | ||
| ) |
Construct from polyMesh and dictionary.
Definition at line 88 of file interpolatingSolidBodyMotionSolver.C.
|
delete |
Disallow default bitwise copy construction.
Destructor.
Definition at line 123 of file interpolatingSolidBodyMotionSolver.C.
| TypeName | ( | "interpolatingSolidBody" | ) |
Runtime type information.
|
virtual |
Return point location obtained from the current motion field.
Implements motionSolver.
Definition at line 130 of file interpolatingSolidBodyMotionSolver.C.
References forAll, septernion::I, points, tmp< T >::ref(), s(), Foam::slerp(), and septernion::transformPoint().
|
inlinevirtual |
Solve for motion.
Implements motionSolver.
Definition at line 113 of file interpolatingSolidBodyMotionSolver.H.
|
virtual |
Update local data for topology changes.
Reimplemented from points0MotionSolver.
Definition at line 164 of file interpolatingSolidBodyMotionSolver.C.
References NotImplemented.
|
virtual |
Update from another mesh using the given map.
Reimplemented from points0MotionSolver.
Definition at line 174 of file interpolatingSolidBodyMotionSolver.C.
References points0MotionSolver::mapMesh(), and Foam::Zero.
|
delete |
Disallow default bitwise assignment.
