Mesh motion solver for an fvMesh. Based on solving the cell-centre Laplacian for the motion velocity. More...

Inheritance diagram for velocityLaplacianFvMotionSolver:

Collaboration diagram for velocityLaplacianFvMotionSolver:

Public Member Functions
	TypeName ("velocityLaplacian")
	Runtime type information. More...

	velocityLaplacianFvMotionSolver (const word &name, const polyMesh &, const dictionary &)
	Construct from polyMesh and dictionary. More...

	velocityLaplacianFvMotionSolver (const velocityLaplacianFvMotionSolver &)=delete
	Disallow default bitwise copy construction. More...

	~velocityLaplacianFvMotionSolver ()
	Destructor. More...

volVectorField &	cellMotionU ()
	Return reference to the cell motion velocity field. More...

const volVectorField &	cellMotionU () const
	Return const reference to the cell motion velocity field. More...

virtual tmp< pointField >	curPoints () const
	Return point location obtained from the current motion field. More...

virtual void	solve ()
	Solve for motion. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update corresponding to the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

void	operator= (const velocityLaplacianFvMotionSolver &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from velocityMotionSolver
	TypeName ("velocityMotionSolver")
	Runtime type information. More...

	velocityMotionSolver (const word &name, const polyMesh &, const dictionary &, const word &type)
	Construct from mesh and dictionary. More...

	velocityMotionSolver (const velocityMotionSolver &)=delete
	Disallow default bitwise copy construction. More...

virtual	~velocityMotionSolver ()
	Destructor. More...

pointVectorField &	pointMotionU ()
	Return reference to the point motion velocity field. More...

const pointVectorField &	pointMotionU () const
	Return const reference to the point motion velocity field. More...

virtual void	movePoints (const pointField &)
	Update local data for geometry changes. More...

virtual void	distribute (const polyDistributionMap &)
	Update corresponding to the given distribution map. More...

void	operator= (const velocityMotionSolver &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from motionSolver
	TypeName ("motionSolver")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, motionSolver, dictionary,(const word &name, const polyMesh &mesh, const dictionary &dict),(name, mesh, dict))

	motionSolver (const word &name, const polyMesh &mesh, const word &type)
	Construct from polyMesh and dictionary and type. More...

virtual autoPtr< motionSolver >	clone () const
	Clone function. More...

virtual	~motionSolver ()
	Destructor. More...

const word &	name () const
	Return name. More...

const word &	keyword () const
	Return keyword. More...

const polyMesh &	mesh () const
	Return reference to mesh. More...

virtual tmp< pointField >	newPoints ()
	Provide new points for motion. Solves for motion. More...

virtual void	twoDCorrectPoints (pointField &) const
	Correct point field for reduced-dimensionality cases. More...

virtual bool	solidBody () const
	Is the motion solid body? I.e., are the volumes and area magnitudes. More...

virtual bool	write () const
	Optionally write motion state information for restart. More...

Public Member Functions inherited from fvMotionSolver
	ClassName ("displacementMotionSolver")
	Runtime type information. More...

	fvMotionSolver (const polyMesh &)
	Construct from polyMesh. More...

const fvMesh &	mesh () const
	Return reference to the fvMesh to be moved. More...

template<class Type >
Foam::wordList	cellMotionBoundaryTypes (const typename PointField< Type >::Boundary &pmUbf) const

Additional Inherited Members
Static Public Member Functions inherited from motionSolver
static autoPtr< motionSolver >	New (const word &name, const polyMesh &, const dictionary &)
	Select constructed from polyMesh and dictionary. More...

Protected Member Functions inherited from fvMotionSolver
template<class Type >
wordList	cellMotionBoundaryTypes (const typename PointField< Type >::Boundary &pmUbf) const
	Create the corresponding patch types for cellMotion from those. More...

Protected Attributes inherited from velocityMotionSolver
pointVectorField	pointMotionU_
	Point motion field. More...

Protected Attributes inherited from fvMotionSolver
const fvMesh &	fvMesh_
	The fvMesh to be moved. More...

Detailed Description

Mesh motion solver for an fvMesh. Based on solving the cell-centre Laplacian for the motion velocity.

Source files

Definition at line 53 of file velocityLaplacianFvMotionSolver.H.

Constructor & Destructor Documentation

◆ velocityLaplacianFvMotionSolver() [1/2]

velocityLaplacianFvMotionSolver	(	const word &	name,
		const polyMesh &	mesh,
		const dictionary &	dict
	)

Construct from polyMesh and dictionary.

Definition at line 49 of file velocityLaplacianFvMotionSolver.C.

◆ velocityLaplacianFvMotionSolver() [2/2]

velocityLaplacianFvMotionSolver ( const velocityLaplacianFvMotionSolver & )

delete

Disallow default bitwise copy construction.

◆ ~velocityLaplacianFvMotionSolver()

~velocityLaplacianFvMotionSolver ( )

Destructor.

Definition at line 87 of file velocityLaplacianFvMotionSolver.C.

Member Function Documentation

◆ TypeName()

TypeName ( "velocityLaplacian" )

Runtime type information.

◆ cellMotionU() [1/2]

volVectorField& cellMotionU ( )

inline

Return reference to the cell motion velocity field.

Definition at line 100 of file velocityLaplacianFvMotionSolver.H.

◆ cellMotionU() [2/2]

const volVectorField& cellMotionU ( ) const

inline

Return const reference to the cell motion velocity field.

Definition at line 106 of file velocityLaplacianFvMotionSolver.H.

◆ curPoints()

Foam::tmp< Foam::pointField > curPoints ( ) const

virtual

Return point location obtained from the current motion field.

Implements motionSolver.

Definition at line 94 of file velocityLaplacianFvMotionSolver.C.

References volPointInterpolation::interpolate(), DemandDrivenMeshObject< fvMesh, DeletableMeshObject, volPointInterpolation >::New(), and tmp< T >::ref().

Here is the call graph for this function:

◆ solve()

void solve ( )

virtual

Solve for motion.

Implements motionSolver.

Definition at line 114 of file velocityLaplacianFvMotionSolver.C.

References Foam::fvm::laplacian(), and Foam::solve().

Here is the call graph for this function:

◆ topoChange()

void topoChange ( const polyTopoChangeMap & map )

virtual

Update corresponding to the given map.

Reimplemented from velocityMotionSolver.

Definition at line 142 of file velocityLaplacianFvMotionSolver.C.

References motionDiffusivity::New(), and velocityMotionSolver::topoChange().

Here is the call graph for this function:

◆ mapMesh()

void mapMesh ( const polyMeshMap & map )

virtual

Update from another mesh using the given map.

Reimplemented from velocityMotionSolver.

Definition at line 161 of file velocityLaplacianFvMotionSolver.C.

References velocityMotionSolver::mapMesh(), and motionDiffusivity::New().

Here is the call graph for this function:

◆ operator=()

void operator= ( const velocityLaplacianFvMotionSolver & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

src/fvMotionSolver/fvMotionSolvers/velocity/laplacian/velocityLaplacianFvMotionSolver.H
src/fvMotionSolver/fvMotionSolvers/velocity/laplacian/velocityLaplacianFvMotionSolver.C
