Mesh motion solver for an fvMesh. Based on solving the cell-centre Laplacian for the given component of the motion displacement. More...

Inheritance diagram for displacementComponentLaplacianFvMotionSolver:

[legend]

Collaboration diagram for displacementComponentLaplacianFvMotionSolver:

[legend]

Public Member Functions
	TypeName ("displacementComponentLaplacian")
	Runtime type information. More...

	displacementComponentLaplacianFvMotionSolver (const word &name, const polyMesh &, const dictionary &)
	Construct from polyMesh and dictionary. More...

	displacementComponentLaplacianFvMotionSolver (const displacementComponentLaplacianFvMotionSolver &)=delete
	Disallow default bitwise copy construction. More...

	~displacementComponentLaplacianFvMotionSolver ()
	Destructor. More...

volScalarField &	cellDisplacement ()
	Non-const access to the cellDisplacement in order to allow. More...

virtual tmp< pointField >	curPoints () const
	Return point location obtained from the current motion field. More...

virtual void	solve ()
	Solve for motion. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update corresponding to the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

void	operator= (const displacementComponentLaplacianFvMotionSolver &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from componentDisplacementMotionSolver
	TypeName ("componentDisplacementMotionSolver")
	Runtime type information. More...

	componentDisplacementMotionSolver (const word &name, const polyMesh &, const dictionary &, const word &type)
	Construct from polyMesh and dictionary and type. More...

	componentDisplacementMotionSolver (const componentDisplacementMotionSolver &)=delete
	Disallow default bitwise copy construction. More...

virtual	~componentDisplacementMotionSolver ()
	Destructor. More...

scalarField &	points0 ()
	Return reference to the reference field. More...

const scalarField &	points0 () const
	Return reference to the reference field. More...

virtual void	movePoints (const pointField &)
	Update local data for geometry changes. More...

virtual void	distribute (const polyDistributionMap &)
	Update corresponding to the given distribution map. More...

void	operator= (const componentDisplacementMotionSolver &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from motionSolver
	TypeName ("motionSolver")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, motionSolver, dictionary,(const word &name, const polyMesh &mesh, const dictionary &dict),(name, mesh, dict))

	motionSolver (const word &name, const polyMesh &mesh, const word &type)
	Construct from polyMesh and dictionary and type. More...

virtual autoPtr< motionSolver >	clone () const
	Clone function. More...

virtual	~motionSolver ()
	Destructor. More...

const word &	name () const
	Return name. More...

const word &	keyword () const
	Return keyword. More...

const polyMesh &	mesh () const
	Return reference to mesh. More...

virtual tmp< pointField >	newPoints ()
	Provide new points for motion. Solves for motion. More...

virtual void	twoDCorrectPoints (pointField &) const
	Correct point field for reduced-dimensionality cases. More...

virtual bool	solidBody () const
	Is the motion solid body? I.e., are the volumes and area magnitudes. More...

virtual bool	write () const
	Optionally write motion state information for restart. More...

Public Member Functions inherited from fvMotionSolver
	ClassName ("displacementMotionSolver")
	Runtime type information. More...

	fvMotionSolver (const polyMesh &)
	Construct from polyMesh. More...

const fvMesh &	mesh () const
	Return reference to the fvMesh to be moved. More...

template<class Type >
Foam::wordList	cellMotionBoundaryTypes (const typename PointField< Type >::Boundary &pmUbf) const

Additional Inherited Members
Static Public Member Functions inherited from motionSolver
static autoPtr< motionSolver >	New (const word &name, const polyMesh &, const dictionary &)
	Select constructed from polyMesh and dictionary. More...

Protected Member Functions inherited from fvMotionSolver
template<class Type >
wordList	cellMotionBoundaryTypes (const typename PointField< Type >::Boundary &pmUbf) const
	Create the corresponding patch types for cellMotion from those. More...

Protected Attributes inherited from componentDisplacementMotionSolver
word	cmptName_
	The component name to solve for. More...

direction	cmpt_
	The component to solve for. More...

scalarField	points0_
	Reference point field for this component. More...

pointScalarField	pointDisplacement_
	Point motion field. More...

Protected Attributes inherited from fvMotionSolver
const fvMesh &	fvMesh_
	The fvMesh to be moved. More...

Detailed Description

Mesh motion solver for an fvMesh. Based on solving the cell-centre Laplacian for the given component of the motion displacement.

Source files

Definition at line 53 of file displacementComponentLaplacianFvMotionSolver.H.

Constructor & Destructor Documentation

◆ displacementComponentLaplacianFvMotionSolver() [1/2]

displacementComponentLaplacianFvMotionSolver	(	const word &	name,
		const polyMesh &	mesh,
		const dictionary &	dict
	)

Construct from polyMesh and dictionary.

Definition at line 50 of file displacementComponentLaplacianFvMotionSolver.C.

References IOobject::AUTO_WRITE, Foam::endl(), fvMotionSolver::fvMesh_, typeIOobject< Type >::headerOk(), Foam::Info, IOobject::MUST_READ, dimensioned< Type >::name(), DemandDrivenMeshObject< polyMesh, RepatchableMeshObject, pointMesh >::New(), Foam::nl, and fvMesh::time().

Here is the call graph for this function:

◆ displacementComponentLaplacianFvMotionSolver() [2/2]

displacementComponentLaplacianFvMotionSolver ( const displacementComponentLaplacianFvMotionSolver & )

delete

Disallow default bitwise copy construction.

◆ ~displacementComponentLaplacianFvMotionSolver()

~displacementComponentLaplacianFvMotionSolver ( )

Destructor.

Definition at line 137 of file displacementComponentLaplacianFvMotionSolver.C.

Member Function Documentation

◆ TypeName()

TypeName ( "displacementComponentLaplacian" )

Runtime type information.

◆ cellDisplacement()

volScalarField& cellDisplacement ( )

inline

Non-const access to the cellDisplacement in order to allow.

changes to the boundary motion

Definition at line 115 of file displacementComponentLaplacianFvMotionSolver.H.

◆ curPoints()

Foam::tmp< Foam::pointField > curPoints ( ) const

virtual

Return point location obtained from the current motion field.

Implements motionSolver.

Definition at line 145 of file displacementComponentLaplacianFvMotionSolver.C.

References Foam::endl(), forAll, Foam::Info, volPointInterpolation::interpolate(), DemandDrivenMeshObject< fvMesh, DeletableMeshObject, volPointInterpolation >::New(), primitiveFieldRef(), tmp< T >::ref(), and Field< Type >::replace().

Here is the call graph for this function:

◆ solve()

void solve ( )

virtual

Solve for motion.

Implements motionSolver.

Definition at line 223 of file displacementComponentLaplacianFvMotionSolver.C.

References Foam::fvm::laplacian(), and Foam::solve().

Here is the call graph for this function:

◆ topoChange()

void topoChange ( const polyTopoChangeMap & map )

virtual

Update corresponding to the given map.

Reimplemented from componentDisplacementMotionSolver.

Definition at line 244 of file displacementComponentLaplacianFvMotionSolver.C.

References motionDiffusivity::New(), and componentDisplacementMotionSolver::topoChange().

Here is the call graph for this function:

◆ mapMesh()

void mapMesh ( const polyMeshMap & map )

virtual

Update from another mesh using the given map.

Reimplemented from componentDisplacementMotionSolver.

Definition at line 263 of file displacementComponentLaplacianFvMotionSolver.C.

References componentDisplacementMotionSolver::mapMesh(), and motionDiffusivity::New().

Here is the call graph for this function:

◆ operator=()

void operator= ( const displacementComponentLaplacianFvMotionSolver & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

src/fvMotionSolver/fvMotionSolvers/componentDisplacement/componentLaplacian/displacementComponentLaplacianFvMotionSolver.H
src/fvMotionSolver/fvMotionSolvers/componentDisplacement/componentLaplacian/displacementComponentLaplacianFvMotionSolver.C
