Templated injection model class. More...

Inheritance diagram for InjectionModel< CloudType >:

[legend]

Collaboration diagram for InjectionModel< CloudType >:

Public Types
typedef CloudType::parcelType	parcelType
	Convenience typedef for parcelType. More...

Public Types inherited from injectionModel
enum class	uniformParcelSize { nParticle , surfaceArea , volume }
	Enumeration for the parcels' uniform size. More...

Public Types inherited from CloudSubModelBase< CloudType >
typedef CloudType	cloudType
	Type of cloud this model was instantiated for. More...

Public Member Functions
	TypeName ("injectionModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, InjectionModel, dictionary,(const dictionary &dict, CloudType &owner, const word &modelType),(dict, owner, modelType))
	Declare runtime constructor selection table. More...

	InjectionModel (CloudType &owner)
	Construct null from owner. More...

	InjectionModel (const dictionary &dict, CloudType &owner, const word &modelName, const word &modelType)
	Construct from dictionary. More...

	InjectionModel (const InjectionModel< CloudType > &im)
	Construct copy. More...

virtual autoPtr< InjectionModel< CloudType > >	clone () const =0
	Construct and return a clone. More...

virtual	~InjectionModel ()
	Destructor. More...

virtual void	topoChange ()
	Update mesh. More...

scalar	timeStart () const
	Return the start-of-injection time. More...

scalar	massInjected () const
	Return mass of particles injected (cumulative) More...

virtual scalar	timeEnd () const =0
	Return the end-of-injection time. More...

virtual label	nParcelsToInject (const scalar time0, const scalar time1)=0
	Number of parcels to introduce relative to SOI. More...

virtual scalar	massToInject (const scalar time0, const scalar time1)=0
	Parcel mass to introduce relative to SOI. More...

scalar	averageParcelMass ()
	Return the average injected parcel mass. More...

label	nInjections () const
	Return the number of injections. More...

label	parcelsAddedTotal () const
	Return the total number parcels added. More...

template<class TrackCloudType >
void	inject (TrackCloudType &cloud, typename CloudType::parcelType::trackingData &td)
	Main injection loop. More...

template<class TrackCloudType >
void	injectSteadyState (TrackCloudType &cloud, typename CloudType::parcelType::trackingData &td)
	Main injection loop - steady-state. More...

virtual void	setPositionAndCell (const label parcelI, const label nParcels, const scalar time, barycentric &coordinates, label &celli, label &tetFacei, label &tetPti, label &facei)=0
	Set the injection position and owner cell, tetFace and tetPt. More...

virtual void	setProperties (const label parcelI, const label nParcels, const scalar time, parcelType &parcel)=0
	Set the parcel properties. More...

virtual bool	fullyDescribed () const =0
	Flag to identify whether model fully describes the parcel. More...

virtual void	info (Ostream &os)
	Write injection info to stream. More...

Public Member Functions inherited from CloudSubModelBase< CloudType >
	CloudSubModelBase (CloudType &owner)
	Construct null from owner cloud. More...

	CloudSubModelBase (CloudType &owner, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")
	Construct from owner cloud without name. More...

	CloudSubModelBase (const word &modelName, CloudType &owner, const dictionary &dict, const word &baseName, const word &modelType)
	Construct from owner cloud with name. More...

	CloudSubModelBase (const CloudSubModelBase< CloudType > &smb)
	Copy constructor. More...

virtual	~CloudSubModelBase ()
	Destructor. More...

const CloudType &	owner () const
	Return const access to the owner cloud. More...

virtual bool	writeTime () const
	Flag to indicate when to write a property. More...

CloudType &	owner ()
	Return non-const access to the owner cloud for manipulation. More...

virtual void	write (Ostream &os) const
	Write. More...

Public Member Functions inherited from subModelBase
	subModelBase (dictionary &properties)
	Construct null. More...

	subModelBase (dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")
	Construct from components without name. More...

	subModelBase (const word &modelName, dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType)
	Construct from components with name. More...

	subModelBase (const subModelBase &smb)
	Copy constructor. More...

virtual	~subModelBase ()
	Destructor. More...

const word &	modelName () const
	Return const access to the name of the sub-model. More...

const dictionary &	dict () const
	Return const access to the cloud dictionary. More...

const word &	baseName () const
	Return const access to the base name of the sub-model. More...

const word &	modelType () const
	Return const access to the sub-model type. More...

const dictionary &	coeffDict () const
	Return const access to the coefficients dictionary. More...

const dictionary &	properties () const
	Return const access to the properties dictionary. More...

virtual bool	defaultCoeffs (const bool printMsg) const
	Returns true if defaultCoeffs is true and outputs on printMsg. More...

virtual void	cacheFields (const bool store)
	Cache dependent sub-model fields. More...

template<class Type >
Type	getBaseProperty (const word &entryName, const Type &defaultValue=pTraits< Type >::zero) const
	Retrieve generic property from the base model. More...

template<class Type >
void	getBaseProperty (const word &entryName, Type &value) const
	Retrieve generic property from the base model. More...

template<class Type >
void	setBaseProperty (const word &entryName, const Type &value)
	Add generic property to the base model. More...

template<class Type >
void	getModelProperty (const word &entryName, Type &value) const
	Retrieve generic property from the sub-model. More...

template<class Type >
Type	getModelProperty (const word &entryName, const Type &defaultValue=pTraits< Type >::zero) const
	Retrieve generic property from the sub-model. More...

template<class Type >
void	setModelProperty (const word &entryName, const Type &value)
	Add generic property to the sub-model. More...

void	operator= (const subModelBase &)=delete
	Disallow default bitwise assignment. More...

Static Public Member Functions
static autoPtr< InjectionModel< CloudType > >	New (const dictionary &dict, CloudType &owner)
	Selector with lookup from dictionary. More...

static autoPtr< InjectionModel< CloudType > >	New (const dictionary &dict, const word &modelName, const word &modelType, CloudType &owner)
	Selector with name and type. More...

Protected Member Functions
scalar	readMassTotal (const dictionary &dict, CloudType &owner)
	Read the total mass value for instantaneous injections. More...

scalar	readDuration (const dictionary &dict, CloudType &owner)
	Read the duration for continuous injections. More...

TimeFunction1< scalar >	readMassFlowRate (const dictionary &dict, CloudType &owner, const scalar duration)
	Read the mass flow rate function for continuous injections. More...

TimeFunction1< scalar >	readParcelsPerSecond (const dictionary &dict, CloudType &owner)
	Read the number of parcels injected per second for continuous. More...

label	index () const
	Get the index of this injector. More...

bool	findCellAtPosition (const point &position, barycentric &coordinates, label &celli, label &tetFacei, label &tetPti, bool errorOnNotFound=true)
	Find the cell that contains the supplied position. More...

void	constrainPosition (typename CloudType::parcelType::trackingData &td, typename CloudType::parcelType &parcel)
	Constrain a parcel's position appropriately to the geometric. More...

label	sizeSampleQ () const
	Return the sampling moment to be used by the size distribution. More...

void	setNumberOfParticles (PtrList< parcelType > &parcelPtrs, const scalar mass) const
	Set number of particles to inject given parcel properties. More...

void	postInjectCheck (const label parcelsAdded, const scalar massAdded)
	Post injection checks. More...

Protected Member Functions inherited from subModelBase
bool	inLine () const
	Flag to indicate whether data is/was read in-line. More...

Protected Attributes
scalar	SOI_
	Start of injection [s]. More...

scalar	massInjected_
	Total mass injected to date [kg]. More...

label	nInjections_
	Number of injections counter. More...

label	parcelsAddedTotal_
	Running counter of total number of parcels added. More...

scalar	nParticleFixed_
	Fixed nParticle to assign to parcels. Only valid if. More...

uniformParcelSize	uniformParcelSize_
	Size uniform to all parcels. More...

scalar	time0_
	Continuous phase time at start of injection time step [s]. More...

scalar	timeStep0_
	Time at start of injection time step [s]. More...

Protected Attributes inherited from CloudSubModelBase< CloudType >
CloudType &	owner_
	Reference to the cloud. More...

Protected Attributes inherited from subModelBase
const word	modelName_
	Name of the sub-model. More...

dictionary &	properties_
	Reference to properties dictionary e.g. for restart. More...

const dictionary	dict_
	Copy of dictionary used during construction. More...

const word	baseName_
	Name of the sub-model base class. More...

const word	modelType_
	Type of the sub-model. More...

const dictionary	coeffDict_
	Coefficients dictionary. More...

Additional Inherited Members
Static Public Attributes inherited from injectionModel
static const NamedEnum< uniformParcelSize, 3 >	uniformParcelSizeNames_
	Names of the parcels' uniform size. More...

Detailed Description

template<class CloudType>
class Foam::InjectionModel< CloudType >

Templated injection model class.

The injection model nominally describes the parcel:

position
diameter
velocity In this case, the fullyDescribed() flag should be set to 0 (false). When the parcel is then added to the cloud, the remaining properties are populated using values supplied in the constant properties.

If, however, all of a parcel's properties are described in the model, the fullDescribed() flag should be set to 1 (true).

Source files

Definition at line 66 of file InjectionModel.H.

Member Typedef Documentation

◆ parcelType

typedef CloudType::parcelType parcelType

Convenience typedef for parcelType.

Definition at line 74 of file InjectionModel.H.

Constructor & Destructor Documentation

◆ InjectionModel() [1/3]

InjectionModel ( CloudType & owner )

Construct null from owner.

Definition at line 446 of file InjectionModel.C.

◆ InjectionModel() [2/3]

InjectionModel	(	const dictionary &	dict,
		CloudType &	owner,
		const word &	modelName,
		const word &	modelType
	)

Construct from dictionary.

Definition at line 464 of file InjectionModel.C.

References subModelBase::coeffDict(), IOobject::db(), subModelBase::dict(), Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, Foam::Info, DSMCCloud< ParcelType >::mesh(), polyMesh::nGeometricD(), injectionModel::nParticle, InjectionModel< CloudType >::nParticleFixed_, CloudSubModelBase< CloudType >::owner(), InjectionModel< CloudType >::SOI_, objectRegistry::time(), InjectionModel< CloudType >::uniformParcelSize_, injectionModel::uniformParcelSizeNames_, and Time::userTimeToTime().

Here is the call graph for this function:

◆ InjectionModel() [3/3]

InjectionModel ( const InjectionModel< CloudType > & im )

Construct copy.

Definition at line 527 of file InjectionModel.C.

◆ ~InjectionModel()

~InjectionModel

virtual

Destructor.

Definition at line 547 of file InjectionModel.C.

Member Function Documentation

◆ readMassTotal()

Foam::scalar readMassTotal	(	const dictionary &	dict,
		CloudType &	owner
	)

protected

Read the total mass value for instantaneous injections.

Definition at line 37 of file InjectionModel.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, IOWarningInFunction, Foam::patchToPatchTools::NaN(), and Foam::type().

Here is the call graph for this function:

◆ readDuration()

Foam::scalar readDuration	(	const dictionary &	dict,
		CloudType &	owner
	)

protected

Read the duration for continuous injections.

Definition at line 70 of file InjectionModel.C.

References DSMCCloud< ParcelType >::mesh(), fvMesh::time(), and Time::userTimeToTime().

Here is the call graph for this function:

◆ readMassFlowRate()

Foam::TimeFunction1< Foam::scalar > readMassFlowRate	(	const dictionary &	dict,
		CloudType &	owner,
		const scalar	duration
	)

protected

Read the mass flow rate function for continuous injections.

Definition at line 93 of file InjectionModel.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, IOWarningInFunction, DSMCCloud< ParcelType >::mesh(), Foam::patchToPatchTools::NaN(), Function1< Type >::New(), and fvMesh::time().

Here is the call graph for this function:

◆ readParcelsPerSecond()

Foam::TimeFunction1< Foam::scalar > readParcelsPerSecond	(	const dictionary &	dict,
		CloudType &	owner
	)

protected

Read the number of parcels injected per second for continuous.

injections

Definition at line 175 of file InjectionModel.C.

References dict, DSMCCloud< ParcelType >::mesh(), and fvMesh::time().

Here is the call graph for this function:

◆ index()

Foam::label index

protected

Get the index of this injector.

Definition at line 188 of file InjectionModel.C.

References forAll.

◆ findCellAtPosition()

bool findCellAtPosition	(	const point &	position,
		barycentric &	coordinates,
		label &	celli,
		label &	tetFacei,
		label &	tetPti,
		bool	errorOnNotFound = `true`
	)

protected

Find the cell that contains the supplied position.

Will modify position slightly towards the owner cell centroid to ensure that it lies in a cell and not edge/face

Definition at line 203 of file InjectionModel.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, Pair< Type >::first(), UPstream::myProcNo(), Foam::nl, p, Foam::pos(), Foam::reduce(), and Pair< Type >::second().

Here is the call graph for this function:

◆ constrainPosition()

void constrainPosition	(	typename CloudType::parcelType::trackingData &	td,
		typename CloudType::parcelType &	parcel
	)

protected

Constrain a parcel's position appropriately to the geometric.

dimensions of the mesh

Definition at line 276 of file InjectionModel.C.

References VectorSpace< Form, Cmpt, Ncmpts >::zero.

◆ sizeSampleQ()

Foam::label sizeSampleQ

protected

Return the sampling moment to be used by the size distribution.

Definition at line 315 of file InjectionModel.C.

References Foam::labelMax.

◆ setNumberOfParticles()

void setNumberOfParticles	(	PtrList< parcelType > &	parcelPtrs,
		const scalar	mass
	)		const

protected

Set number of particles to inject given parcel properties.

Definition at line 332 of file InjectionModel.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::mag(), Foam::max(), Foam::min(), Foam::patchToPatchTools::NaN(), p, Foam::reduce(), and PtrList< T >::set().

Here is the call graph for this function:

◆ postInjectCheck()

void postInjectCheck	(	const label	parcelsAdded,
		const scalar	massAdded
	)

protected

Post injection checks.

Definition at line 413 of file InjectionModel.C.

References Foam::endl(), Foam::Info, Foam::nl, and Foam::returnReduce().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "injectionModel" )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		InjectionModel< CloudType >	,
		dictionary	,
		(const dictionary &dict, CloudType &owner, const word &modelType)	,
		(dict, owner, modelType)
	)

Declare runtime constructor selection table.

◆ clone()

virtual autoPtr<InjectionModel<CloudType> > clone ( ) const

pure virtual

Construct and return a clone.

Implemented in ThermoLookupTableInjection< CloudType >, ReactingMultiphaseLookupTableInjection< CloudType >, ReactingLookupTableInjection< CloudType >, PatchInjection< CloudType >, PatchFlowRateInjection< CloudType >, NoInjection< CloudType >, MomentumLookupTableInjection< CloudType >, ManualInjection< CloudType >, FieldActivatedInjection< CloudType >, ConeInjection< CloudType >, and CellZoneInjection< CloudType >.

◆ New() [1/2]

Foam::autoPtr< Foam::InjectionModel< CloudType > > New	(	const dictionary &	dict,
		CloudType &	owner
	)

static

Selector with lookup from dictionary.

Definition at line 32 of file InjectionModelNew.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::Info, and Foam::nl.

Here is the call graph for this function:

◆ New() [2/2]

Foam::autoPtr< Foam::InjectionModel< CloudType > > New	(	const dictionary &	dict,
		const word &	modelName,
		const word &	modelType,
		CloudType &	owner
	)

static

Selector with name and type.

Definition at line 60 of file InjectionModelNew.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::Info, and Foam::nl.

Here is the call graph for this function:

◆ topoChange()

void topoChange

virtual

Update mesh.

Reimplemented in PatchInjection< CloudType >, PatchFlowRateInjection< CloudType >, ThermoLookupTableInjection< CloudType >, ReactingMultiphaseLookupTableInjection< CloudType >, ReactingLookupTableInjection< CloudType >, PatchInjection< CloudType >, PatchFlowRateInjection< CloudType >, MomentumLookupTableInjection< CloudType >, ManualInjection< CloudType >, FieldActivatedInjection< CloudType >, ConeInjection< CloudType >, and CellZoneInjection< CloudType >.

Definition at line 554 of file InjectionModel.C.

◆ timeStart()

Foam::scalar timeStart

inline

Return the start-of-injection time.

Definition at line 31 of file InjectionModelI.H.

◆ massInjected()

Foam::scalar massInjected

inline

Return mass of particles injected (cumulative)

Definition at line 38 of file InjectionModelI.H.

◆ timeEnd()

virtual scalar timeEnd ( ) const

pure virtual

Return the end-of-injection time.

Implemented in ThermoLookupTableInjection< CloudType >, ReactingMultiphaseLookupTableInjection< CloudType >, ReactingLookupTableInjection< CloudType >, PatchInjection< CloudType >, PatchFlowRateInjection< CloudType >, NoInjection< CloudType >, MomentumLookupTableInjection< CloudType >, ManualInjection< CloudType >, FieldActivatedInjection< CloudType >, ConeInjection< CloudType >, and CellZoneInjection< CloudType >.

◆ nParcelsToInject()

virtual label nParcelsToInject	(	const scalar	time0,
		const scalar	time1
	)

pure virtual

Number of parcels to introduce relative to SOI.

Implemented in ThermoLookupTableInjection< CloudType >, ReactingMultiphaseLookupTableInjection< CloudType >, ReactingLookupTableInjection< CloudType >, PatchInjection< CloudType >, PatchFlowRateInjection< CloudType >, NoInjection< CloudType >, MomentumLookupTableInjection< CloudType >, ManualInjection< CloudType >, FieldActivatedInjection< CloudType >, ConeInjection< CloudType >, and CellZoneInjection< CloudType >.

◆ massToInject()

virtual scalar massToInject	(	const scalar	time0,
		const scalar	time1
	)

pure virtual

Parcel mass to introduce relative to SOI.

Implemented in ThermoLookupTableInjection< CloudType >, ReactingMultiphaseLookupTableInjection< CloudType >, ReactingLookupTableInjection< CloudType >, PatchInjection< CloudType >, PatchFlowRateInjection< CloudType >, NoInjection< CloudType >, MomentumLookupTableInjection< CloudType >, ManualInjection< CloudType >, FieldActivatedInjection< CloudType >, ConeInjection< CloudType >, and CellZoneInjection< CloudType >.

◆ averageParcelMass()

Foam::scalar averageParcelMass

Return the average injected parcel mass.

Definition at line 559 of file InjectionModel.C.

◆ nInjections()

Foam::label nInjections

inline

Return the number of injections.

Definition at line 45 of file InjectionModelI.H.

◆ parcelsAddedTotal()

Foam::label parcelsAddedTotal

inline

Return the total number parcels added.

Definition at line 52 of file InjectionModelI.H.

◆ inject()

void inject	(	TrackCloudType &	cloud,
		typename CloudType::parcelType::trackingData &	td
	)

Main injection loop.

Definition at line 570 of file InjectionModel.C.

References Foam::meshTools::constrainDirection(), IOobject::db(), forAll, Foam::max(), Foam::min(), Foam::patchToPatchTools::NaN(), p, PtrList< T >::set(), polyMesh::solutionD(), objectRegistry::time(), VectorSpace< Form, Cmpt, Ncmpts >::uniform(), and dimensioned< Type >::value().

Here is the call graph for this function:

◆ injectSteadyState()

void injectSteadyState	(	TrackCloudType &	cloud,
		typename CloudType::parcelType::trackingData &	td
	)

Main injection loop - steady-state.

Definition at line 747 of file InjectionModel.C.

References Foam::meshTools::constrainDirection(), forAll, Foam::patchToPatchTools::NaN(), p, PtrList< T >::set(), polyMesh::solutionD(), and VectorSpace< Form, Cmpt, Ncmpts >::uniform().

Here is the call graph for this function:

◆ setPositionAndCell()

virtual void setPositionAndCell	(	const label	parcelI,
		const label	nParcels,
		const scalar	time,
		barycentric &	coordinates,
		label &	celli,
		label &	tetFacei,
		label &	tetPti,
		label &	facei
	)

pure virtual

Set the injection position and owner cell, tetFace and tetPt.

Implemented in ThermoLookupTableInjection< CloudType >, ReactingMultiphaseLookupTableInjection< CloudType >, ReactingLookupTableInjection< CloudType >, PatchInjection< CloudType >, PatchFlowRateInjection< CloudType >, NoInjection< CloudType >, MomentumLookupTableInjection< CloudType >, ManualInjection< CloudType >, FieldActivatedInjection< CloudType >, ConeInjection< CloudType >, and CellZoneInjection< CloudType >.

◆ setProperties()

virtual void setProperties	(	const label	parcelI,
		const label	nParcels,
		const scalar	time,
		parcelType &	parcel
	)

pure virtual

Set the parcel properties.

Implemented in ThermoLookupTableInjection< CloudType >, ReactingMultiphaseLookupTableInjection< CloudType >, ReactingLookupTableInjection< CloudType >, PatchInjection< CloudType >, PatchFlowRateInjection< CloudType >, NoInjection< CloudType >, MomentumLookupTableInjection< CloudType >, ManualInjection< CloudType >, FieldActivatedInjection< CloudType >, ConeInjection< CloudType >, and CellZoneInjection< CloudType >.

◆ fullyDescribed()

virtual bool fullyDescribed ( ) const

pure virtual

Flag to identify whether model fully describes the parcel.

Implemented in ThermoLookupTableInjection< CloudType >, ReactingMultiphaseLookupTableInjection< CloudType >, ReactingLookupTableInjection< CloudType >, PatchInjection< CloudType >, PatchFlowRateInjection< CloudType >, NoInjection< CloudType >, MomentumLookupTableInjection< CloudType >, ManualInjection< CloudType >, FieldActivatedInjection< CloudType >, ConeInjection< CloudType >, and CellZoneInjection< CloudType >.

◆ info()

void info ( Ostream & os )

virtual

Write injection info to stream.

Definition at line 852 of file InjectionModel.C.

References Foam::nl.

Member Data Documentation

◆ SOI_

scalar SOI_

protected

Start of injection [s].

Definition at line 84 of file InjectionModel.H.

Referenced by InjectionModel< CloudType >::InjectionModel().

◆ massInjected_

scalar massInjected_

protected

Total mass injected to date [kg].

Definition at line 87 of file InjectionModel.H.

◆ nInjections_

label nInjections_

protected

Number of injections counter.

Definition at line 93 of file InjectionModel.H.

◆ parcelsAddedTotal_

label parcelsAddedTotal_

protected

Running counter of total number of parcels added.

Definition at line 96 of file InjectionModel.H.

◆ nParticleFixed_

scalar nParticleFixed_

protected

Fixed nParticle to assign to parcels. Only valid if.

uniformParcelSize is nParticle.

Definition at line 103 of file InjectionModel.H.

Referenced by InjectionModel< CloudType >::InjectionModel().

◆ uniformParcelSize_

uniformParcelSize uniformParcelSize_

protected

Size uniform to all parcels.

Definition at line 106 of file InjectionModel.H.

Referenced by InjectionModel< CloudType >::InjectionModel().

◆ time0_

scalar time0_

protected

Continuous phase time at start of injection time step [s].

Definition at line 109 of file InjectionModel.H.

◆ timeStep0_

scalar timeStep0_

protected

Time at start of injection time step [s].

Definition at line 112 of file InjectionModel.H.

The documentation for this class was generated from the following files:

src/lagrangian/parcel/clouds/Templates/ThermoCloud/ThermoCloud.H
src/lagrangian/parcel/submodels/Momentum/InjectionModel/InjectionModel/InjectionModel.H
src/lagrangian/parcel/submodels/Momentum/InjectionModel/InjectionModel/InjectionModel.C
src/lagrangian/parcel/submodels/Momentum/InjectionModel/InjectionModel/InjectionModelI.H
src/lagrangian/parcel/submodels/Momentum/InjectionModel/InjectionModel/InjectionModelNew.C

Public Types

Public Member Functions

Static Public Member Functions

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

template<class CloudType> class Foam::InjectionModel< CloudType >

Member Typedef Documentation

◆ parcelType

Constructor & Destructor Documentation

◆ InjectionModel() [1/3]

◆ InjectionModel() [2/3]

◆ InjectionModel() [3/3]

◆ ~InjectionModel()

Member Function Documentation

◆ readMassTotal()

◆ readDuration()

◆ readMassFlowRate()

◆ readParcelsPerSecond()

◆ index()

◆ findCellAtPosition()

◆ constrainPosition()

◆ sizeSampleQ()

◆ setNumberOfParticles()

◆ postInjectCheck()

◆ TypeName()

◆ declareRunTimeSelectionTable()

◆ clone()

◆ New() [1/2]

◆ New() [2/2]

◆ topoChange()

◆ timeStart()

◆ massInjected()

◆ timeEnd()

◆ nParcelsToInject()

◆ massToInject()

◆ averageParcelMass()

◆ nInjections()

◆ parcelsAddedTotal()

◆ inject()

◆ injectSteadyState()

◆ setPositionAndCell()

◆ setProperties()

◆ fullyDescribed()

◆ info()

Member Data Documentation

◆ SOI_

◆ massInjected_

◆ nInjections_

◆ parcelsAddedTotal_

◆ nParticleFixed_

◆ uniformParcelSize_

◆ time0_

◆ timeStep0_

template<class CloudType>
class Foam::InjectionModel< CloudType >
