Run-time selectable general function of one variable. More...
Public Types | |
typedef Type | returnType |
Public Member Functions | |
TypeName ("Function1") | |
Runtime type information. More... | |
declareRunTimeSelectionTable (autoPtr, Function1, dictionary,(const word &name, const dictionary &dict),(name, dict)) | |
Declare runtime constructor selection table. More... | |
Function1 (const word &name) | |
Construct from name. More... | |
Function1 (const Function1< Type > &f1) | |
Copy constructor. More... | |
virtual tmp< Function1< Type > > | clone () const =0 |
Construct and return a clone. More... | |
virtual | ~Function1 () |
Destructor. More... | |
const word & | name () const |
Return the name of the entry. More... | |
virtual Type | value (const scalar x) const =0 |
Return value as a function of scalar x. More... | |
virtual tmp< Field< Type > > | value (const scalarField &x) const =0 |
Return value as a function of a scalar field x. More... | |
virtual Type | integral (const scalar x1, const scalar x2) const =0 |
Integrate between two scalars. More... | |
virtual tmp< Field< Type > > | integral (const scalarField &x1, const scalarField &x2) const =0 |
Integrate between two scalar fields. More... | |
virtual void | write (Ostream &os) const =0 |
Write data to dictionary stream. More... | |
void | operator= (const Function1< Type > &) |
Assignment. More... | |
Public Member Functions inherited from refCount | |
int | count () const |
Return the current reference count. More... | |
bool | unique () const |
Return true if the reference count is zero. More... | |
void | operator++ () |
Increment the reference count. More... | |
void | operator++ (int) |
Increment the reference count. More... | |
void | operator-- () |
Decrement the reference count. More... | |
void | operator-- (int) |
Decrement the reference count. More... | |
Static Public Member Functions | |
static autoPtr< Function1< Type > > | New (const word &name, const dictionary &dict) |
Selector. More... | |
Protected Attributes | |
const word | name_ |
Name of entry. More... | |
Friends | |
Ostream & | operator (Ostream &os, const Function1< Type > &func) |
Ostream Operator. More... | |
Additional Inherited Members | |
Protected Member Functions inherited from refCount | |
refCount () | |
Construct null initialising count to 0. More... | |
Run-time selectable general function of one variable.
with many options provided from simple constant values to complex functions, interpolated tabulated data etc. etc.
Definition at line 61 of file Function1.H.
typedef Type returnType |
Definition at line 76 of file Function1.H.
Construct from name.
Definition at line 32 of file Function1.C.
Copy constructor.
Definition at line 39 of file Function1.C.
|
virtual |
Destructor.
Definition at line 70 of file Function1.C.
TypeName | ( | "Function1< Type >" | ) |
Runtime type information.
declareRunTimeSelectionTable | ( | autoPtr | , |
Function1< Type > | , | ||
dictionary | , | ||
(const word &name, const dictionary &dict) | , | ||
(name, dict) | |||
) |
Declare runtime constructor selection table.
Construct and return a clone.
Implemented in NSRDS7, NSRDS6, NSRDS5, NSRDS4, NSRDS3, NSRDS2, NSRDS14, NSRDS1, NSRDS0, FieldFunction1< Type, Function1Type >, FieldFunction1< Type, Scale< Type > >, FieldFunction1< scalar, NSRDS2 >, FieldFunction1< Type, Constant< Type > >, FieldFunction1< Type, UniformTable< Type > >, FieldFunction1< scalar, NSRDS3 >, FieldFunction1< Type, Table< Type > >, FieldFunction1< Type, NonUniformTable< Type > >, FieldFunction1< scalar, NSRDS0 >, FieldFunction1< scalar, Function1Type >, FieldFunction1< Type, None< Type > >, FieldFunction1< scalar, NSRDS1 >, FieldFunction1< Type, OneConstant< Type > >, FieldFunction1< Type, Square< Type > >, FieldFunction1< scalar, laminarBL >, FieldFunction1< Type, Polynomial< Type > >, FieldFunction1< scalar, squarePulse >, FieldFunction1< scalar, NSRDS6 >, FieldFunction1< scalar, turbulentBL >, FieldFunction1< Type, ZeroConstant< Type > >, FieldFunction1< scalar, NSRDS7 >, FieldFunction1< scalar, NSRDS4 >, FieldFunction1< scalar, NSRDS14 >, FieldFunction1< Type, Sine< Type > >, FieldFunction1< scalar, NSRDS5 >, Constant< Type >, and Coded< Type >.
|
static |
Selector.
Definition at line 31 of file Function1New.C.
References dict, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::Info, IOWarningInFunction, token::isWord(), dictionary::lookup(), Foam::name(), Foam::nl, Istream::putBack(), and token::wordToken().
Referenced by CrankNicolsonDdtScheme< Type >::CrankNicolsonDdtScheme(), fanPressureJumpFvPatchScalarField::fanPressureJumpFvPatchScalarField(), flowRateInletVelocityFvPatchVectorField::flowRateInletVelocityFvPatchVectorField(), flowRateOutletVelocityFvPatchVectorField::flowRateOutletVelocityFvPatchVectorField(), pressureInletOutletVelocityFvPatchVectorField::pressureInletOutletVelocityFvPatchVectorField(), setTimeStepFunctionObject::read(), setWriteIntervalFunctionObject::read(), externalForce::read(), sixDoFMotion::read(), axialAngularSpring::read(), strainRateFunction::read(), forcing::readCoeffs(), temperatureDependent::readDict(), InjectionModel< CloudType >::readMassFlowRate(), rigidBodyMeshMotion::rigidBodyMeshMotion(), rigidBodyMeshMotionSolver::rigidBodyMeshMotionSolver(), timeVaryingMappedFixedValuePointPatchField< Type >::timeVaryingMappedFixedValuePointPatchField(), timeVaryingMappedFvPatchField< Type >::timeVaryingMappedFvPatchField(), and uniformJumpFvPatchField< Type >::uniformJumpFvPatchField().
const Foam::word & name |
Return the name of the entry.
Definition at line 82 of file Function1.C.
Referenced by Constant< Type >::Constant(), NonUniformTable< Type >::NonUniformTable(), Polynomial< Type >::Polynomial(), and Foam::writeEntry().
|
pure virtual |
Return value as a function of scalar x.
Implemented in UniformTable< Type >, NonUniformTable< Type >, NonUniformTable< scalar >, NSRDS7, NSRDS6, NSRDS5, NSRDS4, NSRDS3, NSRDS2, NSRDS14, NSRDS1, NSRDS0, ZeroConstant< Type >, OneConstant< Type >, Constant< Type >, FieldFunction1< Type, Scale< Type > >, FieldFunction1< scalar, NSRDS2 >, FieldFunction1< Type, Constant< Type > >, FieldFunction1< Type, UniformTable< Type > >, FieldFunction1< scalar, NSRDS3 >, FieldFunction1< Type, Table< Type > >, FieldFunction1< Type, NonUniformTable< Type > >, FieldFunction1< scalar, NSRDS0 >, FieldFunction1< scalar, Function1Type >, FieldFunction1< Type, None< Type > >, FieldFunction1< scalar, NSRDS1 >, FieldFunction1< Type, OneConstant< Type > >, FieldFunction1< Type, Square< Type > >, FieldFunction1< scalar, laminarBL >, FieldFunction1< Type, Polynomial< Type > >, FieldFunction1< scalar, squarePulse >, FieldFunction1< scalar, NSRDS6 >, FieldFunction1< scalar, turbulentBL >, FieldFunction1< Type, ZeroConstant< Type > >, FieldFunction1< scalar, NSRDS7 >, FieldFunction1< scalar, NSRDS4 >, FieldFunction1< scalar, NSRDS14 >, FieldFunction1< Type, Sine< Type > >, FieldFunction1< scalar, NSRDS5 >, FieldFunction1< Type, Function1Type >, Table< Type >, Table< scalar >, Square< Type >, Sine< Type >, Scale< Type >, Polynomial< Type >, None< Type >, Coded< Type >, Ramp< reverseRamp >, Ramp< quarterSineRamp >, Ramp< halfCosineRamp >, Ramp< quarterCosineRamp >, Ramp< exponentialSqrRamp >, Ramp< quadraticRamp >, Ramp< linearRamp >, Ramp< Function1Type >, squarePulse, reverseRamp, quarterSineRamp, quarterCosineRamp, quadraticRamp, linearRamp, halfCosineRamp, exponentialSqrRamp, turbulentBL, and laminarBL.
|
pure virtual |
Return value as a function of a scalar field x.
Implemented in FieldFunction1< Type, Function1Type >, FieldFunction1< Type, Scale< Type > >, FieldFunction1< scalar, NSRDS2 >, FieldFunction1< Type, Constant< Type > >, FieldFunction1< Type, UniformTable< Type > >, FieldFunction1< scalar, NSRDS3 >, FieldFunction1< Type, Table< Type > >, FieldFunction1< Type, NonUniformTable< Type > >, FieldFunction1< scalar, NSRDS0 >, FieldFunction1< scalar, Function1Type >, FieldFunction1< Type, None< Type > >, FieldFunction1< scalar, NSRDS1 >, FieldFunction1< Type, OneConstant< Type > >, FieldFunction1< Type, Square< Type > >, FieldFunction1< scalar, laminarBL >, FieldFunction1< Type, Polynomial< Type > >, FieldFunction1< scalar, squarePulse >, FieldFunction1< scalar, NSRDS6 >, FieldFunction1< scalar, turbulentBL >, FieldFunction1< Type, ZeroConstant< Type > >, FieldFunction1< scalar, NSRDS7 >, FieldFunction1< scalar, NSRDS4 >, FieldFunction1< scalar, NSRDS14 >, FieldFunction1< Type, Sine< Type > >, FieldFunction1< scalar, NSRDS5 >, and Coded< Type >.
|
pure virtual |
Integrate between two scalars.
Implemented in FieldFunction1< Type, Scale< Type > >, FieldFunction1< scalar, NSRDS2 >, FieldFunction1< Type, Constant< Type > >, FieldFunction1< Type, UniformTable< Type > >, FieldFunction1< scalar, NSRDS3 >, FieldFunction1< Type, Table< Type > >, FieldFunction1< Type, NonUniformTable< Type > >, FieldFunction1< scalar, NSRDS0 >, FieldFunction1< scalar, Function1Type >, FieldFunction1< Type, None< Type > >, FieldFunction1< scalar, NSRDS1 >, FieldFunction1< Type, OneConstant< Type > >, FieldFunction1< Type, Square< Type > >, FieldFunction1< scalar, laminarBL >, FieldFunction1< Type, Polynomial< Type > >, FieldFunction1< scalar, squarePulse >, FieldFunction1< scalar, NSRDS6 >, FieldFunction1< scalar, turbulentBL >, FieldFunction1< Type, ZeroConstant< Type > >, FieldFunction1< scalar, NSRDS7 >, FieldFunction1< scalar, NSRDS4 >, FieldFunction1< scalar, NSRDS14 >, FieldFunction1< Type, Sine< Type > >, FieldFunction1< scalar, NSRDS5 >, FieldFunction1< Type, Function1Type >, NSRDS7, NSRDS6, NSRDS5, NSRDS4, NSRDS3, NSRDS2, NSRDS14, NSRDS1, NSRDS0, ZeroConstant< Type >, UniformTable< Type >, Table< Type >, Table< scalar >, Square< Type >, Sine< Type >, Scale< Type >, Polynomial< Type >, OneConstant< Type >, NonUniformTable< Type >, NonUniformTable< scalar >, None< Type >, Constant< Type >, Coded< Type >, squarePulse, reverseRamp, quarterSineRamp, quarterCosineRamp, quadraticRamp, linearRamp, halfCosineRamp, exponentialSqrRamp, turbulentBL, and laminarBL.
|
pure virtual |
Integrate between two scalar fields.
Implemented in FieldFunction1< Type, Function1Type >, FieldFunction1< Type, Scale< Type > >, FieldFunction1< scalar, NSRDS2 >, FieldFunction1< Type, Constant< Type > >, FieldFunction1< Type, UniformTable< Type > >, FieldFunction1< scalar, NSRDS3 >, FieldFunction1< Type, Table< Type > >, FieldFunction1< Type, NonUniformTable< Type > >, FieldFunction1< scalar, NSRDS0 >, FieldFunction1< scalar, Function1Type >, FieldFunction1< Type, None< Type > >, FieldFunction1< scalar, NSRDS1 >, FieldFunction1< Type, OneConstant< Type > >, FieldFunction1< Type, Square< Type > >, FieldFunction1< scalar, laminarBL >, FieldFunction1< Type, Polynomial< Type > >, FieldFunction1< scalar, squarePulse >, FieldFunction1< scalar, NSRDS6 >, FieldFunction1< scalar, turbulentBL >, FieldFunction1< Type, ZeroConstant< Type > >, FieldFunction1< scalar, NSRDS7 >, FieldFunction1< scalar, NSRDS4 >, FieldFunction1< scalar, NSRDS14 >, FieldFunction1< Type, Sine< Type > >, FieldFunction1< scalar, NSRDS5 >, and Coded< Type >.
|
pure virtual |
Write data to dictionary stream.
Implemented in NSRDS7, NSRDS6, NSRDS5, NSRDS4, NSRDS3, NSRDS2, NSRDS14, NSRDS1, NSRDS0, integratedNonUniformTable, ZeroConstant< Type >, UniformTable< Type >, Table< Type >, Table< scalar >, squarePulse, Square< Type >, Sine< Type >, Scale< Type >, reverseRamp, Ramp< Function1Type >, Ramp< reverseRamp >, Ramp< quarterSineRamp >, Ramp< halfCosineRamp >, Ramp< quarterCosineRamp >, Ramp< exponentialSqrRamp >, Ramp< quadraticRamp >, Ramp< linearRamp >, Polynomial< Type >, OneConstant< Type >, NonUniformTable< Type >, NonUniformTable< scalar >, None< Type >, Constant< Type >, Coded< Type >, turbulentBL, and laminarBL.
Referenced by Foam::writeEntry().
Assignment.
Definition at line 130 of file Function1.C.
References Foam::abort(), f(), Foam::FatalError, and FatalErrorInFunction.
|
protected |
Name of entry.
Definition at line 71 of file Function1.H.
Referenced by Polynomial< Type >::Polynomial().
