Patch injection, by using patch flow rate to determine concentration and velocity. More...

Inheritance diagram for PatchFlowRateInjection< CloudType >:

Collaboration diagram for PatchFlowRateInjection< CloudType >:

Public Member Functions
	TypeName ("patchFlowRateInjection")
	Runtime type information. More...

	PatchFlowRateInjection (const dictionary &dict, CloudType &owner, const word &modelName)
	Construct from dictionary. More...

	PatchFlowRateInjection (const PatchFlowRateInjection< CloudType > &im)
	Construct copy. More...

virtual autoPtr< InjectionModel< CloudType > >	clone () const
	Construct and return a clone. More...

virtual	~PatchFlowRateInjection ()
	Destructor. More...

virtual void	topoChange ()
	Set injector locations when mesh is updated. More...

virtual scalar	timeEnd () const
	Return the end-of-injection time. More...

scalar	flowRate () const
	Return the total volumetric flow rate across the patch [m^3/s]. More...

virtual label	nParcelsToInject (const scalar time0, const scalar time1)
	Number of parcels to introduce relative to SOI. More...

virtual scalar	massToInject (const scalar time0, const scalar time1)
	Parcel mass to introduce relative to SOI. More...

virtual void	setPositionAndCell (const label parcelI, const label nParcels, const scalar time, barycentric &coordinates, label &celli, label &tetFacei, label &tetPti, label &facei)
	Set the injection position and owner cell, tetFace and tetPt. More...

virtual void	setProperties (const label parcelI, const label nParcels, const scalar time, typename CloudType::parcelType &parcel)
	Set the parcel properties. More...

virtual bool	fullyDescribed () const
	Flag to identify whether model fully describes the parcel. More...

virtual void	topoChange (const polyMesh &mesh)
	Inherit topoChange from patchInjectionBase. More...

virtual void	setPositionAndCell (const fvMesh &mesh, Random &rnd, barycentric &coordinates, label &celli, label &tetFacei, label &tetPti, label &facei)
	Inherit setPositionAndCell from patchInjectionBase. More...

Public Member Functions inherited from InjectionModel< CloudType >
	TypeName ("injectionModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, InjectionModel, dictionary,(const dictionary &dict, CloudType &owner, const word &modelType),(dict, owner, modelType))
	Declare runtime constructor selection table. More...

	InjectionModel (CloudType &owner)
	Construct null from owner. More...

	InjectionModel (const dictionary &dict, CloudType &owner, const word &modelName, const word &modelType)
	Construct from dictionary. More...

	InjectionModel (const InjectionModel< CloudType > &im)
	Construct copy. More...

virtual	~InjectionModel ()
	Destructor. More...

scalar	timeStart () const
	Return the start-of-injection time. More...

scalar	massInjected () const
	Return mass of particles injected (cumulative) More...

scalar	averageParcelMass ()
	Return the average injected parcel mass. More...

label	nInjections () const
	Return the number of injections. More...

label	parcelsAddedTotal () const
	Return the total number parcels added. More...

template<class TrackCloudType >
void	inject (TrackCloudType &cloud, typename CloudType::parcelType::trackingData &td)
	Main injection loop. More...

template<class TrackCloudType >
void	injectSteadyState (TrackCloudType &cloud, typename CloudType::parcelType::trackingData &td)
	Main injection loop - steady-state. More...

virtual void	info (Ostream &os)
	Write injection info to stream. More...

Public Member Functions inherited from CloudSubModelBase< CloudType >
	CloudSubModelBase (CloudType &owner)
	Construct null from owner cloud. More...

	CloudSubModelBase (CloudType &owner, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")
	Construct from owner cloud without name. More...

	CloudSubModelBase (const word &modelName, CloudType &owner, const dictionary &dict, const word &baseName, const word &modelType)
	Construct from owner cloud with name. More...

	CloudSubModelBase (const CloudSubModelBase< CloudType > &smb)
	Copy constructor. More...

virtual	~CloudSubModelBase ()
	Destructor. More...

const CloudType &	owner () const
	Return const access to the owner cloud. More...

virtual bool	writeTime () const
	Flag to indicate when to write a property. More...

CloudType &	owner ()
	Return non-const access to the owner cloud for manipulation. More...

virtual void	write (Ostream &os) const
	Write. More...

Public Member Functions inherited from subModelBase
	subModelBase (dictionary &properties)
	Construct null. More...

	subModelBase (dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType, const word &dictExt="Coeffs")
	Construct from components without name. More...

	subModelBase (const word &modelName, dictionary &properties, const dictionary &dict, const word &baseName, const word &modelType)
	Construct from components with name. More...

	subModelBase (const subModelBase &smb)
	Copy constructor. More...

virtual	~subModelBase ()
	Destructor. More...

const word &	modelName () const
	Return const access to the name of the sub-model. More...

const dictionary &	dict () const
	Return const access to the cloud dictionary. More...

const word &	baseName () const
	Return const access to the base name of the sub-model. More...

const word &	modelType () const
	Return const access to the sub-model type. More...

const dictionary &	coeffDict () const
	Return const access to the coefficients dictionary. More...

const dictionary &	properties () const
	Return const access to the properties dictionary. More...

virtual bool	defaultCoeffs (const bool printMsg) const
	Returns true if defaultCoeffs is true and outputs on printMsg. More...

virtual void	cacheFields (const bool store)
	Cache dependent sub-model fields. More...

template<class Type >
Type	getBaseProperty (const word &entryName, const Type &defaultValue=pTraits< Type >::zero) const
	Retrieve generic property from the base model. More...

template<class Type >
void	getBaseProperty (const word &entryName, Type &value) const
	Retrieve generic property from the base model. More...

template<class Type >
void	setBaseProperty (const word &entryName, const Type &value)
	Add generic property to the base model. More...

template<class Type >
void	getModelProperty (const word &entryName, Type &value) const
	Retrieve generic property from the sub-model. More...

template<class Type >
Type	getModelProperty (const word &entryName, const Type &defaultValue=pTraits< Type >::zero) const
	Retrieve generic property from the sub-model. More...

template<class Type >
void	setModelProperty (const word &entryName, const Type &value)
	Add generic property to the sub-model. More...

void	operator= (const subModelBase &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from patchInjectionBase
	patchInjectionBase (const polyMesh &mesh, const word &patchName)
	Construct from mesh and patch name. More...

	patchInjectionBase (const patchInjectionBase &pib)
	Copy constructor. More...

virtual	~patchInjectionBase ()
	Destructor. More...

virtual void	topoChange (const polyMesh &mesh)
	Update patch geometry and derived info for injection locations. More...

virtual void	setPositionAndCell (const fvMesh &mesh, Random &rnd, barycentric &coordinates, label &celli, label &tetFacei, label &tetPti, label &facei)
	Set the injection position and owner cell, tetFace and tetPt. More...

Additional Inherited Members
Public Types inherited from InjectionModel< CloudType >
typedef CloudType::parcelType	parcelType
	Convenience typedef for parcelType. More...

Public Types inherited from injectionModel
enum class	uniformParcelSize { nParticle , surfaceArea , volume }
	Enumeration for the parcels' uniform size. More...

Public Types inherited from CloudSubModelBase< CloudType >
typedef CloudType	cloudType
	Type of cloud this model was instantiated for. More...

Static Public Member Functions inherited from InjectionModel< CloudType >
static autoPtr< InjectionModel< CloudType > >	New (const dictionary &dict, CloudType &owner)
	Selector with lookup from dictionary. More...

static autoPtr< InjectionModel< CloudType > >	New (const dictionary &dict, const word &modelName, const word &modelType, CloudType &owner)
	Selector with name and type. More...

Static Public Attributes inherited from injectionModel
static const NamedEnum< uniformParcelSize, 3 >	uniformParcelSizeNames_
	Names of the parcels' uniform size. More...

Protected Member Functions inherited from InjectionModel< CloudType >
scalar	readMassTotal (const dictionary &dict, CloudType &owner)
	Read the total mass value for instantaneous injections. More...

scalar	readDuration (const dictionary &dict, CloudType &owner)
	Read the duration for continuous injections. More...

TimeFunction1< scalar >	readMassFlowRate (const dictionary &dict, CloudType &owner, const scalar duration)
	Read the mass flow rate function for continuous injections. More...

TimeFunction1< scalar >	readParcelsPerSecond (const dictionary &dict, CloudType &owner)
	Read the number of parcels injected per second for continuous. More...

label	index () const
	Get the index of this injector. More...

bool	findCellAtPosition (const point &position, barycentric &coordinates, label &celli, label &tetFacei, label &tetPti, bool errorOnNotFound=true)
	Find the cell that contains the supplied position. More...

void	constrainPosition (typename CloudType::parcelType::trackingData &td, typename CloudType::parcelType &parcel)
	Constrain a parcel's position appropriately to the geometric. More...

label	sizeSampleQ () const
	Return the sampling moment to be used by the size distribution. More...

void	setNumberOfParticles (PtrList< parcelType > &parcelPtrs, const scalar mass) const
	Set number of particles to inject given parcel properties. More...

void	postInjectCheck (const label parcelsAdded, const scalar massAdded)
	Post injection checks. More...

Protected Member Functions inherited from subModelBase
bool	inLine () const
	Flag to indicate whether data is/was read in-line. More...

Protected Attributes inherited from InjectionModel< CloudType >
scalar	SOI_
	Start of injection [s]. More...

scalar	massInjected_
	Total mass injected to date [kg]. More...

label	nInjections_
	Number of injections counter. More...

label	parcelsAddedTotal_
	Running counter of total number of parcels added. More...

scalar	nParticleFixed_
	Fixed nParticle to assign to parcels. Only valid if. More...

uniformParcelSize	uniformParcelSize_
	Size uniform to all parcels. More...

scalar	time0_
	Continuous phase time at start of injection time step [s]. More...

scalar	timeStep0_
	Time at start of injection time step [s]. More...

Protected Attributes inherited from CloudSubModelBase< CloudType >
CloudType &	owner_
	Reference to the cloud. More...

Protected Attributes inherited from subModelBase
const word	modelName_
	Name of the sub-model. More...

dictionary &	properties_
	Reference to properties dictionary e.g. for restart. More...

const dictionary	dict_
	Copy of dictionary used during construction. More...

const word	baseName_
	Name of the sub-model base class. More...

const word	modelType_
	Type of the sub-model. More...

const dictionary	coeffDict_
	Coefficients dictionary. More...

Protected Attributes inherited from patchInjectionBase
const word	patchName_
	Patch name. More...

const label	patchId_
	Patch ID. More...

scalarList	sumProcArea_
	Cumulative sum of the total patch areas in each process. More...

scalarList	sumFaceArea_
	Cumulative sum of the face areas in the patch. More...

scalarListList	sumFaceTriArea_
	Cumulative sum of the triangle areas in each patch face. More...

Detailed Description

template<class CloudType>
class Foam::PatchFlowRateInjection< CloudType >

Patch injection, by using patch flow rate to determine concentration and velocity.

User specifies:

Name of patch
Injection duration
Injection target concentration/carrier volume flow rate

Properties:

Initial parcel velocity given by local flow velocity
Parcel diameters obtained by distribution model
Parcels injected randomly across the patch

Source files

Definition at line 64 of file PatchFlowRateInjection.H.

Constructor & Destructor Documentation

◆ PatchFlowRateInjection() [1/2]

PatchFlowRateInjection	(	const dictionary &	dict,
		CloudType &	owner,
		const word &	modelName
	)

Construct from dictionary.

Definition at line 35 of file PatchFlowRateInjection.C.

◆ PatchFlowRateInjection() [2/2]

PatchFlowRateInjection ( const PatchFlowRateInjection< CloudType > & im )

Construct copy.

Definition at line 73 of file PatchFlowRateInjection.C.

◆ ~PatchFlowRateInjection()

~PatchFlowRateInjection

virtual

Destructor.

Definition at line 92 of file PatchFlowRateInjection.C.

Member Function Documentation

◆ TypeName()

TypeName ( "patchFlowRateInjection" )

Runtime type information.

◆ clone()

virtual autoPtr<InjectionModel<CloudType> > clone ( ) const

inlinevirtual

Construct and return a clone.

Implements InjectionModel< CloudType >.

Definition at line 110 of file PatchFlowRateInjection.H.

◆ topoChange() [1/2]

void topoChange

virtual

Set injector locations when mesh is updated.

Reimplemented from InjectionModel< CloudType >.

Definition at line 99 of file PatchFlowRateInjection.C.

References patchInjectionBase::topoChange().

Here is the call graph for this function:

◆ timeEnd()

Foam::scalar timeEnd

virtual

Return the end-of-injection time.

Implements InjectionModel< CloudType >.

Definition at line 106 of file PatchFlowRateInjection.C.

◆ flowRate()

Foam::scalar flowRate

Return the total volumetric flow rate across the patch [m^3/s].

Definition at line 113 of file PatchFlowRateInjection.C.

References GeometricField< Type, PatchField, GeoMesh >::boundaryField(), DimensionedField< Type, GeoMesh >::dimensions(), Foam::dimFlux, objectRegistry::lookupObject(), Foam::max(), Foam::reduce(), rho, and Foam::sum().

Here is the call graph for this function:

◆ nParcelsToInject()

Foam::label nParcelsToInject	(	const scalar	time0,
		const scalar	time1
	)

virtual

Number of parcels to introduce relative to SOI.

Implements InjectionModel< CloudType >.

Definition at line 143 of file PatchFlowRateInjection.C.

References Foam::constant::universal::c, Random::globalScalar01(), and dimensioned< Type >::value().

Here is the call graph for this function:

◆ massToInject()

Foam::scalar massToInject	(	const scalar	time0,
		const scalar	time1
	)

virtual

Parcel mass to introduce relative to SOI.

Implements InjectionModel< CloudType >.

Definition at line 182 of file PatchFlowRateInjection.C.

References Foam::constant::universal::c, and dimensioned< Type >::value().

Here is the call graph for this function:

◆ setPositionAndCell() [1/2]

void setPositionAndCell	(	const label	parcelI,
		const label	nParcels,
		const scalar	time,
		barycentric &	coordinates,
		label &	celli,
		label &	tetFacei,
		label &	tetPti,
		label &	facei
	)

virtual

Set the injection position and owner cell, tetFace and tetPt.

Implements InjectionModel< CloudType >.

Definition at line 202 of file PatchFlowRateInjection.C.

References rndGen(), and patchInjectionBase::setPositionAndCell().

Here is the call graph for this function:

◆ setProperties()

void setProperties	(	const label	parcelI,
		const label	nParcels,
		const scalar	time,
		typename CloudType::parcelType &	parcel
	)

virtual

Set the parcel properties.

Implements InjectionModel< CloudType >.

Definition at line 228 of file PatchFlowRateInjection.C.

◆ fullyDescribed()

bool fullyDescribed

virtual

Flag to identify whether model fully describes the parcel.

Implements InjectionModel< CloudType >.

Definition at line 245 of file PatchFlowRateInjection.C.

◆ topoChange() [2/2]

void topoChange

virtual

Inherit topoChange from patchInjectionBase.

Reimplemented from InjectionModel< CloudType >.

Definition at line 104 of file patchInjectionBase.C.

◆ setPositionAndCell() [2/2]

void setPositionAndCell

Inherit setPositionAndCell from patchInjectionBase.

Definition at line 107 of file patchInjectionBase.C.

References tetIndices::faceTri(), and triangle< Point, PointRef >::mag().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/lagrangian/parcel/submodels/Momentum/InjectionModel/PatchFlowRateInjection/PatchFlowRateInjection.H
src/lagrangian/parcel/submodels/Momentum/InjectionModel/PatchFlowRateInjection/PatchFlowRateInjection.C

Public Member Functions

Additional Inherited Members

Detailed Description

template<class CloudType> class Foam::PatchFlowRateInjection< CloudType >

Constructor & Destructor Documentation

◆ PatchFlowRateInjection() [1/2]

◆ PatchFlowRateInjection() [2/2]

◆ ~PatchFlowRateInjection()

Member Function Documentation

◆ TypeName()

◆ clone()

◆ topoChange() [1/2]

◆ timeEnd()

◆ flowRate()

◆ nParcelsToInject()

◆ massToInject()

◆ setPositionAndCell() [1/2]

◆ setProperties()

◆ fullyDescribed()

◆ topoChange() [2/2]

◆ setPositionAndCell() [2/2]

template<class CloudType>
class Foam::PatchFlowRateInjection< CloudType >
