Base particle class. More...

Inheritance diagram for particle:

[legend]

Collaboration diagram for particle:

Classes
class	trackingData

Public Member Functions
	TypeName ("particle")
	Runtime type information. More...

	particle (const polyMesh &mesh, const barycentric &coordinates, const label celli, const label tetFacei, const label tetPti, const label facei)
	Construct from components. More...

	particle (const polyMesh &mesh, const vector &position, const label celli, label &nLocateBoundaryHits)
	Construct from a position and a cell, searching for the rest of the. More...

	particle (Istream &, bool readFields=true)
	Construct from Istream. More...

	particle (const particle &p)
	Construct as a copy. More...

virtual autoPtr< particle >	clone () const
	Construct and return a clone. More...

virtual	~particle ()
	Destructor. More...

label	getNewParticleIndex () const
	Get unique particle creation id. More...

const barycentric &	coordinates () const
	Return current particle coordinates. More...

label	cell () const
	Return current cell particle is in. More...

label	tetFace () const
	Return current tet face particle is in. More...

label	tetPt () const
	Return current tet face particle is in. More...

label	face () const
	Return current face particle is on otherwise -1. More...

label &	face ()
	Return current face particle is on otherwise -1. More...

scalar	stepFraction () const
	Return the fraction of time-step completed. More...

scalar &	stepFraction ()
	Return the fraction of time-step completed. More...

label	origProc () const
	Return the originating processor ID. More...

label &	origProc ()
	Return the originating processor ID. More...

label	origId () const
	Return the particle ID on the originating processor. More...

label &	origId ()
	Return the particle ID on the originating processor. More...

tetIndices	currentTetIndices (const polyMesh &mesh) const
	Return the indices of the current tet that the. More...

vector	normal (const polyMesh &mesh) const
	Return the normal of the tri on tetFacei_ for the. More...

bool	onFace () const
	Is the particle on a face? More...

bool	onInternalFace (const polyMesh &mesh) const
	Is the particle on an internal face? More...

bool	onBoundaryFace (const polyMesh &mesh) const
	Is the particle on a boundary face? More...

label	patch (const polyMesh &mesh) const
	Return the index of patch that the particle is on. More...

vector	position (const polyMesh &mesh) const
	Return current particle position. More...

void	reset (const scalar stepFraction)
	Set the step fraction and clear the behind data in preparation. More...

bool	locate (const polyMesh &mesh, const vector &position, label celli)
	Locate the particle at the given position. More...

scalar	track (const polyMesh &mesh, const vector &displacement, const scalar fraction)
	Track along the displacement for a given fraction of the overall. More...

scalar	trackToCell (const polyMesh &mesh, const vector &displacement, const scalar fraction)
	As particle::track, but stops when a new cell is reached. More...

scalar	trackToFace (const polyMesh &mesh, const vector &displacement, const scalar fraction)
	As particle::track, but stops when a face is hit. More...

template<class TrackCloudType >
void	hitFace (const vector &displacement, const scalar fraction, TrackCloudType &cloud, trackingData &td)
	Hit the current face. If the current face is internal than this. More...

template<class TrackCloudType >
scalar	trackToAndHitFace (const vector &displacement, const scalar fraction, TrackCloudType &cloud, trackingData &td)
	Convenience function. Combines trackToFace and hitFace. More...

vector	deviationFromMeshCentre (const polyMesh &mesh) const
	Get the displacement from the mesh centre. Used to correct the. More...

void	patchData (const polyMesh &mesh, vector &normal, vector &displacement) const
	Get the normal and displacement of the current patch location. More...

virtual void	transformProperties (const transformer &)
	Transform the physical properties of the particle. More...

template<class TrackCloudType >
void	prepareForParallelTransfer (TrackCloudType &, trackingData &)
	Make changes prior to a parallel transfer. Runs either. More...

template<class TrackCloudType >
void	correctAfterParallelTransfer (TrackCloudType &, trackingData &)
	Make changes following a parallel transfer. Runs either. More...

void	prepareForProcessorTransfer (trackingData &td)
	Make changes prior to a transfer across a processor boundary. More...

void	correctAfterProcessorTransfer (trackingData &td)
	Make changes following a transfer across a processor boundary. More...

void	prepareForNonConformalCyclicTransfer (const polyMesh &mesh, const label sendToPatch, const label sendToPatchFace, const vector &sendToPosition)
	Make changes prior to a transfer across a non conformal cyclic. More...

void	correctAfterNonConformalCyclicTransfer (const polyMesh &mesh, const label sendToPatch, labelList &patchNLocateBoundaryHits)
	Make changes following a transfer across a non conformal cyclic. More...

template<class TrackCloudType >
bool	hitPatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a patch. More...

template<class TrackCloudType >
void	hitWedgePatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a wedgePatch. More...

template<class TrackCloudType >
void	hitSymmetryPlanePatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a. More...

template<class TrackCloudType >
void	hitSymmetryPatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a. More...

template<class TrackCloudType >
void	hitCyclicPatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a. More...

template<class TrackCloudType >
bool	hitNonConformalCyclicPatch (const vector &displacement, const scalar fraction, const label patchi, TrackCloudType &cloud, trackingData &td)
	Overridable function to handle the particle hitting an. More...

template<class TrackCloudType >
void	hitProcessorPatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a. More...

template<class TrackCloudType >
void	hitWallPatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a wallPatch. More...

template<class TrackCloudType >
void	hitBasicPatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a basic. More...

void	prepareForInteractionListReferral (const polyMesh &mesh, const transformer &transform)
	Break the topology and store the cartesian position so that the. More...

void	correctAfterInteractionListReferral (const polyMesh &mesh, const label celli)
	Correct the topology after referral. Locates the particle. More...

label	procTetPt (const polyMesh &mesh, const polyMesh &procMesh, const label procCell, const label procTetFace) const
	Return the tet point appropriate for decomposition or. More...

void	writePosition (Ostream &) const
	Write the particle position and cell. More...

template<class TrackCloudType >
Foam::scalar	trackToAndHitFace (const vector &displacement, const scalar fraction, TrackCloudType &cloud, trackingData &td)

Static Public Member Functions
static string	propertyList ()

static autoPtr< particle >	New (Istream &is)
	Construct from Istream and return. More...

template<class TrackCloudType >
static void	readFields (TrackCloudType &c)
	Read the fields associated with the owner cloud. More...

template<class TrackCloudType >
static void	writeFields (const TrackCloudType &c)
	Write the fields associated with the owner cloud. More...

Static Public Attributes
static string	propertyList_ = Foam::particle::propertyList()
	String representation of properties. More...

static label	particleCount = 0
	Cumulative particle counter - used to provide unique ID. More...

static const bool	instantaneous = false
	Particles are not instantaneous by default. More...

Friends
Ostream &	operator<< (Ostream &, const particle &)

bool	operator== (const particle &pA, const particle &pB)

bool	operator!= (const particle &pA, const particle &pB)

Detailed Description

Base particle class.

Definition at line 80 of file particle.H.

Constructor & Destructor Documentation

◆ particle() [1/4]

particle	(	const polyMesh &	mesh,
		const barycentric &	coordinates,
		const label	celli,
		const label	tetFacei,
		const label	tetPti,
		const label	facei
	)

Construct from components.

Definition at line 46 of file particle.C.

Referenced by particle::clone(), and particle::New().

Here is the caller graph for this function:

◆ particle() [2/4]

particle	(	const polyMesh &	mesh,
		const vector &	position,
		const label	celli,
		label &	nLocateBoundaryHits
	)

Construct from a position and a cell, searching for the rest of the.

required topology

Definition at line 69 of file particle.C.

References particle::locate(), mesh, and particle::position().

Here is the call graph for this function:

◆ particle() [3/4]

particle	(	Istream &	is,
		bool	readFields = `true`
	)

Construct from Istream.

Definition at line 46 of file particleIO.C.

References IOstream::ASCII, IOstream::check(), IOstream::format(), Istream::read(), and particle::readFields().

Here is the call graph for this function:

◆ particle() [4/4]

particle ( const particle & p )

Construct as a copy.

Definition at line 95 of file particle.C.

◆ ~particle()

virtual ~particle ( )

inlinevirtual

Destructor.

Definition at line 255 of file particle.H.

Member Function Documentation

◆ TypeName()

TypeName ( "particle" )

Runtime type information.

◆ propertyList()

static string propertyList ( )

inlinestatic

Definition at line 203 of file particle.H.

◆ clone()

virtual autoPtr<particle> clone ( ) const

inlinevirtual

Construct and return a clone.

Reimplemented in sampledSetParticle, trackedParticle, solidParticle, molecule, passiveParticle, streamlinesParticle, and findCellParticle.

Definition at line 242 of file particle.H.

References particle::particle().

Here is the call graph for this function:

◆ New()

static autoPtr<particle> New ( Istream & is )

inlinestatic

Construct from Istream and return.

Definition at line 248 of file particle.H.

References particle::particle().

Here is the call graph for this function:

◆ getNewParticleIndex()

Foam::label getNewParticleIndex ( ) const

inline

Get unique particle creation id.

Definition at line 33 of file particleI.H.

References Foam::endl(), Foam::labelMax, particle::particleCount, and WarningInFunction.

Here is the call graph for this function:

◆ coordinates()

const Foam::barycentric & coordinates ( ) const

inline

Return current particle coordinates.

Definition at line 48 of file particleI.H.

Referenced by solidParticle::move().

Here is the caller graph for this function:

◆ cell()

Foam::label cell ( ) const

inline

Return current cell particle is in.

Definition at line 54 of file particleI.H.

◆ tetFace()

Foam::label tetFace ( ) const

inline

Return current tet face particle is in.

Definition at line 60 of file particleI.H.

◆ tetPt()

Foam::label tetPt ( ) const

inline

Return current tet face particle is in.

Definition at line 66 of file particleI.H.

◆ face() [1/2]

Foam::label face ( ) const

inline

Return current face particle is on otherwise -1.

Definition at line 72 of file particleI.H.

◆ face() [2/2]

Foam::label & face ( )

inline

Return current face particle is on otherwise -1.

Definition at line 78 of file particleI.H.

◆ stepFraction() [1/2]

Foam::scalar stepFraction ( ) const

inline

Return the fraction of time-step completed.

Definition at line 84 of file particleI.H.

Referenced by solidParticle::move().

Here is the caller graph for this function:

◆ stepFraction() [2/2]

Foam::scalar & stepFraction ( )

inline

Return the fraction of time-step completed.

Definition at line 90 of file particleI.H.

◆ origProc() [1/2]

Foam::label origProc ( ) const

inline

Return the originating processor ID.

Definition at line 96 of file particleI.H.

Referenced by Foam::operator==().

Here is the caller graph for this function:

◆ origProc() [2/2]

Foam::label & origProc ( )

inline

Return the originating processor ID.

Definition at line 102 of file particleI.H.

◆ origId() [1/2]

Foam::label origId ( ) const

inline

Return the particle ID on the originating processor.

Definition at line 108 of file particleI.H.

Referenced by Foam::operator==(), and particle::readFields().

Here is the caller graph for this function:

◆ origId() [2/2]

Foam::label & origId ( )

inline

Return the particle ID on the originating processor.

Definition at line 114 of file particleI.H.

◆ currentTetIndices()

Foam::tetIndices currentTetIndices ( const polyMesh & mesh ) const

inline

Return the indices of the current tet that the.

particle occupies.

Definition at line 120 of file particleI.H.

Referenced by solidParticle::move().

Here is the caller graph for this function:

◆ normal()

Foam::vector normal ( const polyMesh & mesh ) const

inline

Return the normal of the tri on tetFacei_ for the.

current tet.

Definition at line 129 of file particleI.H.

References mesh.

◆ onFace()

bool onFace ( ) const

inline

Is the particle on a face?

Definition at line 135 of file particleI.H.

Referenced by lineFace::calcSamples().

Here is the caller graph for this function:

◆ onInternalFace()

bool onInternalFace ( const polyMesh & mesh ) const

inline

Is the particle on an internal face?

Definition at line 141 of file particleI.H.

References primitiveMesh::isInternalFace(), and mesh.

Here is the call graph for this function:

◆ onBoundaryFace()

bool onBoundaryFace ( const polyMesh & mesh ) const

inline

Is the particle on a boundary face?

Definition at line 147 of file particleI.H.

References primitiveMesh::isInternalFace(), and mesh.

Here is the call graph for this function:

◆ patch()

Foam::label patch ( const polyMesh & mesh ) const

inline

Return the index of patch that the particle is on.

Definition at line 153 of file particleI.H.

References polyMesh::boundaryMesh(), mesh, and polyBoundaryMesh::whichPatch().

Here is the call graph for this function:

◆ position()

Foam::vector position ( const polyMesh & mesh ) const

inline

Return current particle position.

Definition at line 159 of file particleI.H.

References mesh, and Foam::tracking::position().

Referenced by nearWallFields::calcAddressing(), lineFace::calcSamples(), and particle::particle().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ reset()

void reset ( const scalar stepFraction )

inline

Set the step fraction and clear the behind data in preparation.

for a new track

Definition at line 174 of file particleI.H.

◆ locate()

bool locate	(	const polyMesh &	mesh,
		const vector &	position,
		label	celli
	)

Locate the particle at the given position.

Definition at line 112 of file particle.C.

References Foam::tracking::locate(), mesh, Foam::name(), and Foam::tracking::position().

Referenced by particle::particle().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ track()

Foam::scalar track	(	const polyMesh &	mesh,
		const vector &	displacement,
		const scalar	fraction
	)

Track along the displacement for a given fraction of the overall.

step. End when the track is complete, or when a boundary is hit. On exit, stepFraction_ will have been incremented to the current position, and facei_ will be set to the index of the boundary face that was hit, or -1 if the track completed within a cell. The proportion of the displacement still to be completed is returned.

Definition at line 133 of file particle.C.

References Tuple2< Type1, Type2 >::first(), mesh, Foam::name(), Tuple2< Type1, Type2 >::second(), and Foam::tracking::toBoundary().

Here is the call graph for this function:

◆ trackToCell()

Foam::scalar trackToCell	(	const polyMesh &	mesh,
		const vector &	displacement,
		const scalar	fraction
	)

As particle::track, but stops when a new cell is reached.

Definition at line 157 of file particle.C.

References Tuple2< Type1, Type2 >::first(), mesh, Foam::name(), Tuple2< Type1, Type2 >::second(), and Foam::tracking::toCell().

Here is the call graph for this function:

◆ trackToFace()

Foam::scalar trackToFace	(	const polyMesh &	mesh,
		const vector &	displacement,
		const scalar	fraction
	)

As particle::track, but stops when a face is hit.

Definition at line 181 of file particle.C.

References Tuple2< Type1, Type2 >::first(), mesh, Foam::name(), Tuple2< Type1, Type2 >::second(), and Foam::tracking::toFace().

Referenced by lineFace::calcSamples(), and streamlinesParticle::move().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ hitFace()

void hitFace	(	const vector &	displacement,
		const scalar	fraction,
		TrackCloudType &	cloud,
		trackingData &	td
	)

Hit the current face. If the current face is internal than this.

crosses into the next cell. If it is a boundary face then this will interact the particle with the relevant patch.

Definition at line 162 of file particleTemplates.C.

References polyMesh::boundaryMesh(), Foam::tracking::crossInternalFace(), forAll, particle::trackingData::mesh, Foam::onInternalFace, and p.

Here is the call graph for this function:

◆ trackToAndHitFace() [1/2]

scalar trackToAndHitFace	(	const vector &	displacement,
		const scalar	fraction,
		TrackCloudType &	cloud,
		trackingData &	td
	)

Convenience function. Combines trackToFace and hitFace.

Referenced by solidParticle::move().

Here is the caller graph for this function:

◆ deviationFromMeshCentre()

Foam::vector deviationFromMeshCentre ( const polyMesh & mesh ) const

Get the displacement from the mesh centre. Used to correct the.

particle position in cases with reduced dimensionality. Returns a zero vector for three-dimensional cases.

Definition at line 205 of file particle.C.

References Foam::cmptMin(), Foam::meshTools::constrainToMeshCentre(), polyMesh::geometricD(), mesh, Foam::pos(), Foam::tracking::position(), and VectorSpace< Form, Cmpt, Ncmpts >::zero.

Here is the call graph for this function:

◆ patchData()

void patchData	(	const polyMesh &	mesh,
		vector &	normal,
		vector &	displacement
	)		const

inline

Get the normal and displacement of the current patch location.

Definition at line 182 of file particleI.H.

References Foam::exit(), Foam::tracking::faceNormalAndDisplacement(), Foam::FatalError, FatalErrorInFunction, Pair< Type >::first(), mesh, and Pair< Type >::second().

Here is the call graph for this function:

◆ transformProperties()

void transformProperties ( const transformer & )

virtual

Transform the physical properties of the particle.

according to the given transformation tensor

Reimplemented in solidParticle, molecule, and streamlinesParticle.

Definition at line 223 of file particle.C.

Referenced by molecule::transformProperties(), and solidParticle::transformProperties().

Here is the caller graph for this function:

◆ prepareForParallelTransfer()

void prepareForParallelTransfer	(	TrackCloudType &	cloud,
		trackingData &	td
	)

Make changes prior to a parallel transfer. Runs either.

processor or nonConformalCyclic variant below.

Definition at line 107 of file particleTemplates.C.

References particle::trackingData::mesh, particle::trackingData::sendFromPatch, particle::trackingData::sendToPatchFace, and particle::trackingData::sendToPosition.

◆ correctAfterParallelTransfer()

void correctAfterParallelTransfer	(	TrackCloudType &	cloud,
		trackingData &	td
	)

Make changes following a parallel transfer. Runs either.

processor or nonConformalCyclic variant below.

Definition at line 131 of file particleTemplates.C.

References polyMesh::boundaryMesh(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, particle::trackingData::mesh, particle::trackingData::patchNLocateBoundaryHits, and particle::trackingData::sendToPatch.

Referenced by trackedParticle::correctAfterParallelTransfer(), and sampledSetParticle::correctAfterParallelTransfer().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ prepareForProcessorTransfer()

void prepareForProcessorTransfer ( trackingData & td )

Make changes prior to a transfer across a processor boundary.

Stores the local patch face index (in facei_) so that the mesh face index can be determined on the other side.

Definition at line 227 of file particle.C.

References polyMesh::boundaryMesh(), Foam::tracking::inProcessor(), particle::trackingData::mesh, and particle::trackingData::sendFromPatch.

Here is the call graph for this function:

◆ correctAfterProcessorTransfer()

void correctAfterProcessorTransfer ( trackingData & td )

Make changes following a transfer across a processor boundary.

Converts the stored patch index to a mesh index. Accounts for the receiving face being reversed relative to the sending face.

Definition at line 239 of file particle.C.

References polyMesh::boundaryMesh(), particle::trackingData::mesh, Foam::tracking::outProcessor(), particle::trackingData::sendToPatch, processorPolyPatch::transform(), and transformer::transformsPosition().

Here is the call graph for this function:

◆ prepareForNonConformalCyclicTransfer()

void prepareForNonConformalCyclicTransfer	(	const polyMesh &	mesh,
		const label	sendToPatch,
		const label	sendToPatchFace,
		const vector &	sendToPosition
	)

Make changes prior to a transfer across a non conformal cyclic.

boundary. Stores the receiving patch face (in facei_). Breaks the topology and stores the cartesian position.

Definition at line 260 of file particle.C.

References polyMesh::boundaryMesh(), Foam::cmptSum(), mesh, nonConformalCyclicPolyPatch::nbrPatch(), nonConformalCyclicPolyPatch::transform(), transformer::transformsPosition(), Vector< Cmpt >::x(), Vector< Cmpt >::y(), and Vector< Cmpt >::z().

Here is the call graph for this function:

◆ correctAfterNonConformalCyclicTransfer()

void correctAfterNonConformalCyclicTransfer	(	const polyMesh &	mesh,
		const label	sendToPatch,
		labelList &	patchNLocateBoundaryHits
	)

Make changes following a transfer across a non conformal cyclic.

boundary. Locates the particle using the stored face index and cartesian position.

Definition at line 300 of file particle.C.

References polyMesh::boundaryMesh(), polyMesh::faceOwner(), Foam::tracking::locate(), mesh, nonConformalPolyPatch::origPatch(), and polyPatch::start().

Here is the call graph for this function:

◆ hitPatch()

bool hitPatch	(	TrackCloudType &	,
		trackingData &
	)

Overridable function to handle the particle hitting a patch.

Executed before other patch-hitting functions.

Definition at line 265 of file particleTemplates.C.

◆ hitWedgePatch()

void hitWedgePatch	(	TrackCloudType &	cloud,
		trackingData &	td
	)

Overridable function to handle the particle hitting a wedgePatch.

Definition at line 272 of file particleTemplates.C.

References Foam::abort(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

◆ hitSymmetryPlanePatch()

void hitSymmetryPlanePatch	(	TrackCloudType &	cloud,
		trackingData &	td
	)

Overridable function to handle the particle hitting a.

symmetryPlanePatch

Definition at line 283 of file particleTemplates.C.

◆ hitSymmetryPatch()

void hitSymmetryPatch	(	TrackCloudType &	,
		trackingData &	td
	)

Overridable function to handle the particle hitting a.

symmetryPatch

Definition at line 294 of file particleTemplates.C.

References Foam::I, particle::trackingData::mesh, and transformer::rotation().

Here is the call graph for this function:

◆ hitCyclicPatch()

void hitCyclicPatch	(	TrackCloudType &	,
		trackingData &	td
	)

Overridable function to handle the particle hitting a.

cyclicPatch

Definition at line 302 of file particleTemplates.C.

References polyMesh::boundaryMesh(), Foam::tracking::crossCyclic(), particle::trackingData::mesh, cyclicPolyPatch::nbrPatch(), cyclicPolyPatch::transform(), and transformer::transformsPosition().

Referenced by streamlinesParticle::hitCyclicPatch().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ hitNonConformalCyclicPatch()

bool hitNonConformalCyclicPatch	(	const vector &	displacement,
		const scalar	fraction,
		const label	patchi,
		TrackCloudType &	cloud,
		trackingData &	td
	)

Overridable function to handle the particle hitting an.

nonConformalCyclicPolyPatch

Definition at line 325 of file particleTemplates.C.

References polyMesh::boundaryMesh(), remote::elementi, patchIdentifier::index(), particle::trackingData::mesh, UPstream::myProcNo(), cyclicPolyPatch::nbrPatchIndex(), nonConformalPolyPatch::origPatch(), patchi, particle::trackingData::patchNLocateBoundaryHits, Foam::tracking::position(), remote::proci, nonConformalCyclicPolyPatch::ray(), particle::trackingData::sendFromPatch, particle::trackingData::sendToPatch, particle::trackingData::sendToPatchFace, particle::trackingData::sendToPosition, particle::trackingData::sendToProc, and polyPatch::whichFace().

Referenced by streamlinesParticle::hitNonConformalCyclicPatch().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ hitProcessorPatch()

void hitProcessorPatch	(	TrackCloudType &	cloud,
		trackingData &	td
	)

Overridable function to handle the particle hitting a.

processorPatch

Definition at line 394 of file particleTemplates.C.

References polyMesh::boundaryMesh(), particle::trackingData::mesh, particle::trackingData::sendFromPatch, particle::trackingData::sendToPatch, particle::trackingData::sendToPatchFace, and particle::trackingData::sendToProc.

Referenced by findCellParticle::hitProcessorPatch(), sampledSetParticle::hitProcessorPatch(), and streamlinesParticle::hitProcessorPatch().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ hitWallPatch()

void hitWallPatch	(	TrackCloudType &	,
		trackingData &
	)

Overridable function to handle the particle hitting a wallPatch.

Definition at line 405 of file particleTemplates.C.

◆ hitBasicPatch()

void hitBasicPatch	(	TrackCloudType &	,
		trackingData &	td
	)

Overridable function to handle the particle hitting a basic.

patch. Fall-through for the above.

Definition at line 410 of file particleTemplates.C.

References particle::trackingData::keepParticle.

◆ prepareForInteractionListReferral()

void prepareForInteractionListReferral	(	const polyMesh &	mesh,
		const transformer &	transform
	)

Break the topology and store the cartesian position so that the.

particle can be referred.

Definition at line 334 of file particle.C.

References Foam::cmptSum(), Foam::inv(), mesh, Foam::pos(), Foam::tracking::position(), and Foam::transform().

Here is the call graph for this function:

◆ correctAfterInteractionListReferral()

void correctAfterInteractionListReferral	(	const polyMesh &	mesh,
		const label	celli
	)

Correct the topology after referral. Locates the particle.

relative to a nearby cell/tet. The particle may end up outside this cell/tet and cannot therefore be tracked.

Definition at line 359 of file particle.C.

References primitiveMesh::cells(), Foam::tracking::coordinates(), mesh, and Foam::pos().

Here is the call graph for this function:

◆ procTetPt()

Foam::label procTetPt	(	const polyMesh &	mesh,
		const polyMesh &	procMesh,
		const label	procCell,
		const label	procTetFace
	)		const

Return the tet point appropriate for decomposition or.

reconstruction to or from the given mesh.

Definition at line 388 of file particle.C.

References polyMesh::faceOwner(), polyMesh::faces(), mesh, and List< T >::size().

Here is the call graph for this function:

◆ readFields()

void readFields ( TrackCloudType & c )

static

Read the fields associated with the owner cloud.

Definition at line 42 of file particleTemplates.C.

References Foam::constant::universal::c, forAllIter, typeIOobject< Type >::headerOk(), IOobject::MUST_READ, particle::origId(), p, and Foam::blendedInterfacialModel::valid().

Referenced by findCellParticle::findCellParticle(), particle::particle(), passiveParticleCloud::passiveParticleCloud(), molecule::readFields(), solidParticle::readFields(), streamlinesParticle::readFields(), sampledSetCloud::sampledSetCloud(), sampledSetParticle::sampledSetParticle(), and trackedParticle::trackedParticle().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ writeFields()

void writeFields ( const TrackCloudType & c )

static

Write the fields associated with the owner cloud.

Definition at line 75 of file particleTemplates.C.

References Foam::constant::universal::c, forAllConstIter, IOobject::NO_READ, IOPosition< CloudType >::write(), and regIOobject::write().

Referenced by molecule::writeFields(), solidParticle::writeFields(), and streamlinesParticle::writeFields().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ writePosition()

void writePosition ( Ostream & os ) const

Write the particle position and cell.

Definition at line 86 of file particleIO.C.

References IOstream::ASCII, IOstream::check(), IOstream::format(), token::SPACE, and Ostream::write().

Here is the call graph for this function:

◆ trackToAndHitFace() [2/2]

Foam::scalar trackToAndHitFace	(	const vector &	displacement,
		const scalar	fraction,
		TrackCloudType &	cloud,
		trackingData &	td
	)

Definition at line 248 of file particleTemplates.C.

References f(), and particle::trackingData::mesh.

Here is the call graph for this function:

Friends And Related Function Documentation

◆ operator<<

Ostream& operator<<	(	Ostream &	,
		const particle &
	)

friend

◆ operator==

bool operator==	(	const particle &	pA,
		const particle &	pB
	)

friend

◆ operator!=

bool operator!=	(	const particle &	pA,
		const particle &	pB
	)

friend

Member Data Documentation

◆ propertyList_

Foam::string propertyList_ = Foam::particle::propertyList()

static

String representation of properties.

Definition at line 203 of file particle.H.

◆ particleCount

Foam::label particleCount = 0

static

Cumulative particle counter - used to provide unique ID.

Definition at line 206 of file particle.H.

Referenced by particle::getNewParticleIndex().

◆ instantaneous

const bool instantaneous = false

static

Particles are not instantaneous by default.

Definition at line 209 of file particle.H.

The documentation for this class was generated from the following files:

src/lagrangian/basic/particle/particle.H
src/lagrangian/basic/particle/particle.C
src/lagrangian/basic/particle/particleI.H
src/lagrangian/basic/particle/particleIO.C
src/lagrangian/basic/particle/particleTemplates.C

Classes

Public Member Functions

Static Public Member Functions

Static Public Attributes

Friends

Detailed Description

Constructor & Destructor Documentation

◆ particle() [1/4]

◆ particle() [2/4]

◆ particle() [3/4]

◆ particle() [4/4]

◆ ~particle()

Member Function Documentation

◆ TypeName()

◆ propertyList()

◆ clone()

◆ New()

◆ getNewParticleIndex()

◆ coordinates()

◆ cell()

◆ tetFace()

◆ tetPt()

◆ face() [1/2]

◆ face() [2/2]

◆ stepFraction() [1/2]

◆ stepFraction() [2/2]

◆ origProc() [1/2]

◆ origProc() [2/2]

◆ origId() [1/2]

◆ origId() [2/2]

◆ currentTetIndices()

◆ normal()

◆ onFace()

◆ onInternalFace()

◆ onBoundaryFace()

◆ patch()

◆ position()

◆ reset()

◆ locate()

◆ track()

◆ trackToCell()

◆ trackToFace()

◆ hitFace()

◆ trackToAndHitFace() [1/2]

◆ deviationFromMeshCentre()

◆ patchData()

◆ transformProperties()

◆ prepareForParallelTransfer()

◆ correctAfterParallelTransfer()

◆ prepareForProcessorTransfer()

◆ correctAfterProcessorTransfer()

◆ prepareForNonConformalCyclicTransfer()

◆ correctAfterNonConformalCyclicTransfer()

◆ hitPatch()

◆ hitWedgePatch()

◆ hitSymmetryPlanePatch()

◆ hitSymmetryPatch()

◆ hitCyclicPatch()

◆ hitNonConformalCyclicPatch()

◆ hitProcessorPatch()

◆ hitWallPatch()

◆ hitBasicPatch()

◆ prepareForInteractionListReferral()

◆ correctAfterInteractionListReferral()

◆ procTetPt()

◆ readFields()

◆ writeFields()

◆ writePosition()

◆ trackToAndHitFace() [2/2]

Friends And Related Function Documentation

◆ operator<<

◆ operator==

◆ operator!=

Member Data Documentation

◆ propertyList_

◆ particleCount

◆ instantaneous
