Particle for generating line-type sampled sets. More...

Inheritance diagram for sampledSetParticle:

Collaboration diagram for sampledSetParticle:

Classes
class	trackingData
	Tracking data class. More...

Public Member Functions
	sampledSetParticle (const polyMesh &mesh, const point &position, const label celli, label &nLocateBoundaryHits, const label seti, const scalar setF, const scalar distance)
	Construct from components. More...

	sampledSetParticle (Istream &is, bool readFields=true)
	Construct from Istream. More...

	sampledSetParticle (const sampledSetParticle &)
	Copy constructor. More...

autoPtr< particle >	clone () const
	Construct and return a clone. More...

void	store (sampledSetCloud &, trackingData &)
	Store a point. More...

void	storeFace (sampledSetCloud &, trackingData &)
	Store a point on a face. More...

void	storeCell (sampledSetCloud &, trackingData &)
	Store a point in a cell. More...

bool	move (sampledSetCloud &, trackingData &)
	Track all particles to their end point. More...

void	hitWedgePatch (sampledSetCloud &, trackingData &)
	Hit a wedge patch. Ends the track. More...

void	hitSymmetryPlanePatch (sampledSetCloud &, trackingData &)
	Hit a symmetry patch. Ends the track. More...

void	hitSymmetryPatch (sampledSetCloud &, trackingData &)
	Hit a symmetry plane patch. Ends the track. More...

void	hitCyclicPatch (sampledSetCloud &, trackingData &)
	Hit a cyclic patch. Ends the track. More...

void	hitProcessorPatch (sampledSetCloud &, trackingData &)
	Hit a processor patch. Transfers the particle if there is no. More...

void	hitWallPatch (sampledSetCloud &, trackingData &)
	Hit a wall patch. Ends the track. More...

void	correctAfterParallelTransfer (sampledSetCloud &, trackingData &)
	Do corrections to the particle and tracking data following a. More...

Public Member Functions inherited from particle
	TypeName ("particle")
	Runtime type information. More...

	particle (const polyMesh &mesh, const barycentric &coordinates, const label celli, const label tetFacei, const label tetPti, const label facei)
	Construct from components. More...

	particle (const polyMesh &mesh, const vector &position, const label celli, label &nLocateBoundaryHits)
	Construct from a position and a cell, searching for the rest of the. More...

	particle (Istream &, bool readFields=true)
	Construct from Istream. More...

	particle (const particle &p)
	Construct as a copy. More...

virtual	~particle ()
	Destructor. More...

label	getNewParticleIndex () const
	Get unique particle creation id. More...

const barycentric &	coordinates () const
	Return current particle coordinates. More...

label	cell () const
	Return current cell particle is in. More...

label	tetFace () const
	Return current tet face particle is in. More...

label	tetPt () const
	Return current tet face particle is in. More...

label	face () const
	Return current face particle is on otherwise -1. More...

label &	face ()
	Return current face particle is on otherwise -1. More...

scalar	stepFraction () const
	Return the fraction of time-step completed. More...

scalar &	stepFraction ()
	Return the fraction of time-step completed. More...

label	origProc () const
	Return the originating processor ID. More...

label &	origProc ()
	Return the originating processor ID. More...

label	origId () const
	Return the particle ID on the originating processor. More...

label &	origId ()
	Return the particle ID on the originating processor. More...

tetIndices	currentTetIndices (const polyMesh &mesh) const
	Return the indices of the current tet that the. More...

vector	normal (const polyMesh &mesh) const
	Return the normal of the tri on tetFacei_ for the. More...

bool	onFace () const
	Is the particle on a face? More...

bool	onInternalFace (const polyMesh &mesh) const
	Is the particle on an internal face? More...

bool	onBoundaryFace (const polyMesh &mesh) const
	Is the particle on a boundary face? More...

label	patch (const polyMesh &mesh) const
	Return the index of patch that the particle is on. More...

vector	position (const polyMesh &mesh) const
	Return current particle position. More...

void	reset (const scalar stepFraction)
	Set the step fraction and clear the behind data in preparation. More...

bool	locate (const polyMesh &mesh, const vector &position, label celli)
	Locate the particle at the given position. More...

scalar	track (const polyMesh &mesh, const vector &displacement, const scalar fraction)
	Track along the displacement for a given fraction of the overall. More...

scalar	trackToCell (const polyMesh &mesh, const vector &displacement, const scalar fraction)
	As particle::track, but stops when a new cell is reached. More...

scalar	trackToFace (const polyMesh &mesh, const vector &displacement, const scalar fraction)
	As particle::track, but stops when a face is hit. More...

template<class TrackCloudType >
void	hitFace (const vector &displacement, const scalar fraction, TrackCloudType &cloud, trackingData &td)
	Hit the current face. If the current face is internal than this. More...

template<class TrackCloudType >
scalar	trackToAndHitFace (const vector &displacement, const scalar fraction, TrackCloudType &cloud, trackingData &td)
	Convenience function. Combines trackToFace and hitFace. More...

vector	deviationFromMeshCentre (const polyMesh &mesh) const
	Get the displacement from the mesh centre. Used to correct the. More...

void	patchData (const polyMesh &mesh, vector &normal, vector &displacement) const
	Get the normal and displacement of the current patch location. More...

virtual void	transformProperties (const transformer &)
	Transform the physical properties of the particle. More...

template<class TrackCloudType >
void	prepareForParallelTransfer (TrackCloudType &, trackingData &)
	Make changes prior to a parallel transfer. Runs either. More...

template<class TrackCloudType >
void	correctAfterParallelTransfer (TrackCloudType &, trackingData &)
	Make changes following a parallel transfer. Runs either. More...

void	prepareForProcessorTransfer (trackingData &td)
	Make changes prior to a transfer across a processor boundary. More...

void	correctAfterProcessorTransfer (trackingData &td)
	Make changes following a transfer across a processor boundary. More...

void	prepareForNonConformalCyclicTransfer (const polyMesh &mesh, const label sendToPatch, const label sendToPatchFace, const vector &sendToPosition)
	Make changes prior to a transfer across a non conformal cyclic. More...

void	correctAfterNonConformalCyclicTransfer (const polyMesh &mesh, const label sendToPatch, labelList &patchNLocateBoundaryHits)
	Make changes following a transfer across a non conformal cyclic. More...

template<class TrackCloudType >
bool	hitPatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a patch. More...

template<class TrackCloudType >
void	hitWedgePatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a wedgePatch. More...

template<class TrackCloudType >
void	hitSymmetryPlanePatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a. More...

template<class TrackCloudType >
void	hitSymmetryPatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a. More...

template<class TrackCloudType >
void	hitCyclicPatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a. More...

template<class TrackCloudType >
bool	hitNonConformalCyclicPatch (const vector &displacement, const scalar fraction, const label patchi, TrackCloudType &cloud, trackingData &td)
	Overridable function to handle the particle hitting an. More...

template<class TrackCloudType >
void	hitProcessorPatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a. More...

template<class TrackCloudType >
void	hitWallPatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a wallPatch. More...

template<class TrackCloudType >
void	hitBasicPatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a basic. More...

void	prepareForInteractionListReferral (const polyMesh &mesh, const transformer &transform)
	Break the topology and store the cartesian position so that the. More...

void	correctAfterInteractionListReferral (const polyMesh &mesh, const label celli)
	Correct the topology after referral. Locates the particle. More...

label	procTetPt (const polyMesh &mesh, const polyMesh &procMesh, const label procCell, const label procTetFace) const
	Return the tet point appropriate for decomposition or. More...

void	writePosition (Ostream &) const
	Write the particle position and cell. More...

template<class TrackCloudType >
Foam::scalar	trackToAndHitFace (const vector &displacement, const scalar fraction, TrackCloudType &cloud, trackingData &td)

Static Public Member Functions
static autoPtr< sampledSetParticle >	New (Istream &is)
	Construct from Istream and return. More...

Static Public Member Functions inherited from particle
static string	propertyList ()

static autoPtr< particle >	New (Istream &is)
	Construct from Istream and return. More...

template<class TrackCloudType >
static void	readFields (TrackCloudType &c)
	Read the fields associated with the owner cloud. More...

template<class TrackCloudType >
static void	writeFields (const TrackCloudType &c)
	Write the fields associated with the owner cloud. More...

Static Public Attributes
static const bool	instantaneous = true
	Sample sets are computed at an instant. More...

Static Public Attributes inherited from particle
static string	propertyList_ = Foam::particle::propertyList()
	String representation of properties. More...

static label	particleCount = 0
	Cumulative particle counter - used to provide unique ID. More...

static const bool	instantaneous = false
	Particles are not instantaneous by default. More...

Friends
Ostream &	operator<< (Ostream &, const sampledSetParticle &)

Detailed Description

Particle for generating line-type sampled sets.

Source files

Definition at line 57 of file sampledSetParticle.H.

Constructor & Destructor Documentation

◆ sampledSetParticle() [1/3]

sampledSetParticle	(	const polyMesh &	mesh,
		const point &	position,
		const label	celli,
		label &	nLocateBoundaryHits,
		const label	seti,
		const scalar	setF,
		const scalar	distance
	)
