Abstract base class for turbulence models (RAS, LES and laminar). More...

Inheritance diagram for momentumTransportModel:

[legend]

Collaboration diagram for momentumTransportModel:

[legend]

Public Member Functions
	TypeName ("momentumTransport")
	Runtime type information. More...

	momentumTransportModel (const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

	momentumTransportModel (const momentumTransportModel &)=delete
	Disallow default bitwise copy construction. More...

virtual	~momentumTransportModel ()
	Destructor. More...

virtual bool	read ()=0
	Read model coefficients if they have changed. More...

const Time &	time () const

const fvMesh &	mesh () const

word	groupName (const word &name) const

word	GName () const
	Helper function to return the name of the turbulence G field. More...

const volVectorField &	U () const
	Access function to velocity field. More...

const surfaceScalarField &	alphaRhoPhi () const
	Access function to phase flux field. More...

virtual tmp< surfaceScalarField >	phi () const
	Return the volumetric flux field. More...

const class Foam::viscosity &	properties () const
	Access function to fluid properties. More...

const volScalarField &	y () const
	Return the wall distance. More...

const volScalarField::Boundary &	yb () const
	Return the near wall distance. More...

virtual tmp< volScalarField >	nu () const
	Return the laminar viscosity. More...

virtual tmp< scalarField >	nu (const label patchi) const
	Return the laminar viscosity on patchi. More...

virtual tmp< volScalarField >	nut () const =0
	Return the turbulence viscosity. More...

virtual tmp< scalarField >	nut (const label patchi) const =0
	Return the turbulence viscosity on patch. More...

virtual tmp< volScalarField >	nuEff () const =0
	Return the effective viscosity. More...

virtual tmp< scalarField >	nuEff (const label patchi) const =0
	Return the effective viscosity on patch. More...

virtual tmp< volSymmTensorField >	R () const =0
	Return the Reynolds stress tensor [m^2/s^2]. More...

virtual tmp< volScalarField >	k () const =0
	Return the turbulence kinetic energy. More...

virtual tmp< volScalarField >	epsilon () const =0
	Return the turbulence kinetic energy dissipation rate. More...

virtual tmp< volScalarField >	omega () const =0
	Return the turbulence specific dissipation rate. More...

virtual tmp< surfaceVectorField >	devTau () const =0
	Return the effective surface stress. More...

virtual tmp< fvVectorMatrix >	divDevTauCorr (const tmp< surfaceVectorField > &devTauCorr, volVectorField &U) const
	Return the explicit stress correction matrix. More...

virtual tmp< fvVectorMatrix >	divDevTau (volVectorField &U) const =0
	Return the stress matrix for the momentum equation. More...

virtual void	validate ()
	Validate the fields after construction. More...

virtual void	predict ()=0
	Predict the momentum transport coefficients if possible. More...

virtual void	correct ()=0
	Solve the momentum transport model equations. More...

void	operator= (const momentumTransportModel &)=delete
	Disallow default bitwise assignment. More...

template<class MomentumTransportModel >
Foam::autoPtr< MomentumTransportModel >	New (const typename MomentumTransportModel::alphaField &alpha, const typename MomentumTransportModel::rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)

Public Member Functions inherited from IOdictionary
	TypeName ("dictionary")

	IOdictionary (const IOobject &)
	Construct given an IOobject. More...

	IOdictionary (const IOobject &, const dictionary &)
	Construct given an IOobject and dictionary. More...

	IOdictionary (const IOobject &, Istream &)
	Construct given an IOobject and Istream. More...

	IOdictionary (const IOdictionary &)
	Copy constructor. More...

	IOdictionary (IOdictionary &&)
	Move constructor. More...

virtual	~IOdictionary ()
	Destructor. More...

virtual bool	global () const
	Return true as object is global, i.e. same for all processors. More...

virtual bool	readData (Istream &)
	ReadData function required for regIOobject read operation. More...

virtual bool	writeData (Ostream &) const
	WriteData function required for regIOobject write operation. More...

void	operator= (const IOdictionary &)
	Assignment of dictionary entries only. More...

void	operator= (IOdictionary &&)
	Move assignment of dictionary entries only. More...

Public Member Functions inherited from regIOobject
	TypeName ("regIOobject")
	Runtime type information. More...

	regIOobject (const IOobject &, const bool isTime=false)
	Construct from IOobject. Optional flag for if IOobject is the. More...

	regIOobject (const regIOobject &)
	Copy constructor. More...

	regIOobject (regIOobject &&)
	Move constructor. More...

	regIOobject (const regIOobject &, bool registerCopy)
	Copy constructor, transferring registry registration to copy. More...

	regIOobject (const word &newName, const regIOobject &, bool registerCopy)
	Copy constructor with new name, transferring registry registration. More...

	regIOobject (const IOobject &, const regIOobject &)
	Copy constructor with new IO parameters. More...

virtual	~regIOobject ()
	Destructor. More...

virtual bool	globalFile () const
	Return true if object is global, i.e. same for all processors. More...

const fileName &	caseName () const

fileName	path () const
	Return complete path. More...

fileName	objectPath () const
	Return complete path + object name. More...

fileName	filePath () const
	Return complete path + object name if the file exists. More...

bool	checkIn ()
	Add object to registry. More...

bool	checkOut ()
	Remove object from registry. More...

void	addWatch ()
	Add file watch on object (if registered and READ_IF_MODIFIED) More...

bool	registered () const
	Is this object registered with the registry? More...

bool	ownedByRegistry () const
	Is this object owned by the registry? More...

void	store ()
	Transfer ownership of this object to its registry. More...

void	release ()
	Release ownership of this object from its registry. More...

label	eventNo () const
	Event number at last update. More...

label &	eventNo ()
	Event number at last update. More...

bool	upToDate (const regIOobject &) const
	Return true if up-to-date with respect to given object. More...

bool	upToDate (const regIOobject &, const regIOobject &) const
	Return true if up-to-date with respect to given objects. More...

bool	upToDate (const regIOobject &, const regIOobject &, const regIOobject &) const
	Return true if up-to-date with respect to given objects. More...

bool	upToDate (const regIOobject &, const regIOobject &, const regIOobject &, const regIOobject &) const
	Return true if up-to-date with respect to given objects. More...

void	setUpToDate ()
	Set up to date (obviously) More...

virtual void	rename (const word &newName)
	Rename. More...

bool	headerOk ()
	Read and check header info. More...

Istream &	readStream (const word &, const bool read=true)
	Return Istream and check object type against that given. More...

void	close ()
	Close Istream. More...

const labelList &	watchIndices () const
	Return file-monitoring handles. More...

labelList &	watchIndices ()
	Return file-monitoring handles. More...

virtual bool	modified () const
	Return true if the object's file (or files for objectRegistry) More...

virtual bool	dependenciesModified () const
	Return true if the object's dependencies have been modified. More...

virtual bool	readIfModified ()
	Read object if modified (as set by call to modified) More...

virtual bool	writeObject (IOstream::streamFormat, IOstream::versionNumber, IOstream::compressionType, const bool write) const
	Write using given format, version and compression. More...

virtual bool	write (const bool write=true) const
	Write using setting from DB. More...

void	operator= (const IOobject &)=delete
	Assign to IOobject. More...

void	operator= (const regIOobject &)=delete
	Disallow default assignment. More...

const fileName &	caseName (const bool global) const

fileName	path (const bool global) const
	Return complete path including the processor sub-directory. More...

fileName	objectPath (const bool global) const
	Return complete path + object name including the processor. More...

fileName	filePath (const bool global) const
	Return complete path + object name if the file exists. More...

Public Member Functions inherited from IOobject
	TypeName ("IOobject")
	Runtime type information. More...

	IOobject (const word &name, const fileName &instance, const objectRegistry &registry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true)
	Construct from name, instance, registry, io options. More...

	IOobject (const word &name, const fileName &instance, const fileName &local, const objectRegistry &registry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true)
	Construct from name, instance, local, registry, io options. More...

	IOobject (const fileName &path, const objectRegistry &registry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true)
	Construct from path, registry, io options. More...

	IOobject (const IOobject &io, const objectRegistry &registry)
	Construct from copy resetting registry. More...

	IOobject (const IOobject &io, const word &name)
	Construct from copy resetting name. More...

	IOobject (const IOobject &io)=default
	Copy constructor. More...

autoPtr< IOobject >	clone () const
	Clone. More...

autoPtr< IOobject >	clone (const objectRegistry &registry) const
	Clone resetting registry. More...

virtual	~IOobject ()
	Destructor. More...

const Time &	time () const
	Return time. More...

const objectRegistry &	db () const
	Return the local objectRegistry. More...

const word &	name () const
	Return name. More...

const word &	headerClassName () const
	Return name of the class name read from header. More...

word &	headerClassName ()
	Return name of the class name read from header. More...

string &	note ()
	Return non-constant access to the optional note. More...

const string &	note () const
	Return the optional note. More...

bool &	registerObject ()
	Register object created from this IOobject with registry if true. More...

bool	registerObject () const
	Register object created from this IOobject with registry if true. More...

readOption	readOpt () const

readOption &	readOpt ()

writeOption	writeOpt () const

writeOption &	writeOpt ()

word	group () const
	Return group (extension part of name) More...

word	member () const
	Return member (name without the extension) More...

const fileName &	rootPath () const

const fileName &	caseName (const bool global) const

fileName &	instance () const
	Return the instance directory, constant, system, <time> etc. More...

void	updateInstance () const
	If the instance is a time directory update to the current time. More...

void	updateTimeInstance () const
	Update instance to the current time. More...

const fileName &	local () const

fileName	path (const bool global) const
	Return complete path including the processor sub-directory. More...

fileName	objectPath (const bool global) const
	Return complete path + object name including the processor. More...

fileName	relativePath () const
	Return the path relative to the case directory. More...

fileName	relativeObjectPath () const
	Return complete relativePath + object name. More...

fileName	filePath (const bool global) const
	Return complete path + object name if the file exists. More...

bool	readHeader (Istream &)
	Read header. More...

bool	headerOk ()
	Read header of local object without type-checking. More...

template<class Type >
void	warnNoRereading () const
	Helper: warn that type does not support re-reading. More...

bool	writeHeader (Ostream &) const
	Write header. More...

bool	writeHeader (Ostream &, const word &objectType) const
	Write header. Allow override of type. More...

bool	good () const

bool	bad () const

InfoProxy< IOobject >	info () const
	Return info proxy. More...

void	operator= (const IOobject &)

template<class Name >
Foam::word	groupName (Name name, const word &group)

Public Member Functions inherited from dictionary
	ClassName ("dictionary")

	dictionary ()
	Construct top-level dictionary null. More...

	dictionary (const fileName &name)
	Construct top-level empty dictionary with given name. More...

	dictionary (const fileName &name, const dictionary &parentDict)
	Construct an empty sub-dictionary with given name and parent. More...

	dictionary (const fileName &name, const dictionary &parentDict, Istream &)
	Construct given the name, parent dictionary and Istream,. More...

	dictionary (Istream &, const bool keepHeader=false)
	Construct top-level dictionary from Istream,. More...

	dictionary (const dictionary &parentDict, const dictionary &)
	Construct as copy given the parent dictionary. More...

	dictionary (const dictionary &)
	Construct top-level dictionary as copy. More...

	dictionary (const dictionary *)
	Construct top-level dictionary as copy from pointer to dictionary. More...

template<class ... Entries>
	dictionary (const std::tuple< const Entries &... > &)
	Construct top-level dictionary with given entries. More...

template<class ... Entries>
	dictionary (const fileName &name, const std::tuple< const Entries &... > &)
	Construct top-level dictionary with given name and entries. More...

template<class ... Entries>
	dictionary (const fileName &name, const dictionary &parentDict, const std::tuple< const Entries &... > &)
	Construct dictionary with given name, parent and entries. More...

template<class ... Entries>
	dictionary (const dictionary &dict, const std::tuple< const Entries &... > &)
	Construct dictionary as copy and add a list of entries. More...

autoPtr< dictionary >	clone () const
	Construct and return clone. More...

virtual	~dictionary ()
	Destructor. More...

const dictionary &	parent () const
	Return the parent dictionary. More...

bool	isNull () const
	Return whether this dictionary is null. More...

const dictionary &	topDict () const
	Return the top of the tree. More...

word	topDictKeyword () const
	Return the scoped keyword with which this dictionary can be. More...

virtual label	startLineNumber () const
	Return line number of first token in dictionary. More...

virtual label	endLineNumber () const
	Return line number of last token in dictionary. More...

SHA1Digest	digest () const
	Return the SHA1 digest of the dictionary contents. More...

tokenList	tokens () const
	Return the dictionary as a list of tokens. More...

bool	found (const word &, bool recursive=false, bool patternMatch=true) const
	Search dictionary for given keyword. More...

const entry *	lookupEntryPtr (const word &, bool recursive, bool patternMatch) const
	Find and return an entry data stream pointer if present. More...

entry *	lookupEntryPtr (const word &, bool recursive, bool patternMatch)
	Find and return an entry data stream pointer for manipulation. More...

const entry *	lookupEntryPtrBackwardsCompatible (const wordList &, bool recursive, bool patternMatch) const
	Find and return an entry data stream if present, trying a list. More...

const entry &	lookupEntry (const word &, bool recursive, bool patternMatch) const
	Find and return an entry data stream if present otherwise error. More...

const entry &	lookupEntryBackwardsCompatible (const wordList &, bool recursive, bool patternMatch) const
	Find and return an entry data stream if present, trying a list. More...

ITstream &	lookup (const word &, bool recursive=false, bool patternMatch=true) const
	Find and return an entry data stream. More...

ITstream &	lookupBackwardsCompatible (const wordList &, bool recursive=false, bool patternMatch=true) const
	Find and return an entry data stream, trying a list of keywords. More...

template<class T >
T	lookup (const word &, bool recursive=false, bool patternMatch=true) const
	Find and return a T, if not found throw a fatal error. More...

template<class T >
T	lookup (const word &, const unitConversion &, bool recursive=false, bool patternMatch=true) const
	Find and return a T, with dimension checking and unit. More...

template<class T >
T	lookupBackwardsCompatible (const wordList &, bool recursive=false, bool patternMatch=true) const
	Find and return a T, trying a list of keywords in sequence,. More...

template<class T >
T	lookupBackwardsCompatible (const wordList &, const unitConversion &, bool recursive=false, bool patternMatch=true) const
	Find and return a T, with dimension checking and unit. More...

template<class T >
T	lookupOrDefault (const word &, const T &, const bool writeDefault=writeOptionalEntries > 0) const
	Find and return a T, if not found return the given default. More...

template<class T >
T	lookupOrDefault (const word &, const unitConversion &, const T &, const bool writeDefault=writeOptionalEntries > 0) const
	Find and return a T with dimension checking and unit. More...

template<class T >
T	lookupOrDefaultBackwardsCompatible (const wordList &, const T &) const
	Find and return a T, trying a list of keywords in sequence,. More...

template<class T >
T	lookupOrDefaultBackwardsCompatible (const wordList &, const unitConversion &, const T &) const
	Find and return a T, with dimension checking and unit. More...

template<class T >
T	lookupOrAddDefault (const word &, const T &)
	Find and return a T, if not found return the given. More...

template<class T >
bool	readIfPresent (const word &, T &, bool recursive=false, bool patternMatch=true) const
	Find an entry if present, and assign to T. More...

template<class T >
bool	readIfPresent (const word &, const unitConversion &, T &, bool recursive=false, bool patternMatch=true) const
	Find an entry if present, and assign to T, with dimension. More...

const entry *	lookupScopedEntryPtr (const word &, bool recursive, bool patternMatch) const
	Find and return an entry data stream pointer if present,. More...

template<class T >
T	lookupScoped (const word &, bool recursive=false, bool patternMatch=true) const
	Find and return a T,. More...

template<class T >
const T &	lookupCompoundScoped (const word &keyword, bool recursive, bool patternMatch) const
	Find return the reference to the compound T,. More...

bool	isDict (const word &) const
	Check if entry is a sub-dictionary. More...

const dictionary *	subDictPtr (const word &) const
	Find and return a sub-dictionary pointer if present. More...

dictionary *	subDictPtr (const word &)
	Find and return a sub-dictionary pointer if present. More...

const dictionary &	subDict (const word &) const
	Find and return a sub-dictionary. More...

dictionary &	subDict (const word &)
	Find and return a sub-dictionary for manipulation. More...

const dictionary &	subDictBackwardsCompatible (const wordList &) const
	Find and return a sub-dictionary, trying a list of keywords in. More...

const dictionary &	subOrEmptyDict (const word &, const bool mustRead=false) const
	Find and return a sub-dictionary. More...

const dictionary &	optionalSubDict (const word &) const
	Find and return a sub-dictionary if found. More...

const dictionary &	scopedDict (const word &) const
	Find and return a sub-dictionary by scoped lookup. More...

dictionary &	scopedDict (const word &)
	Find and return a sub-dictionary by scoped lookup. More...

wordList	toc () const
	Return the table of contents. More...

wordList	sortedToc () const
	Return the sorted table of contents. More...

List< keyType >	keys (bool patterns=false) const
	Return the list of available keys or patterns. More...

bool	substituteKeyword (const word &keyword)
	Substitute the given keyword prepended by '$' with the. More...

bool	add (entry *, bool mergeEntry=false)
	Add a new entry. More...

void	add (const entry &, bool mergeEntry=false)
	Add an entry. More...

void	add (const keyType &, const word &, bool overwrite=false)
	Add a word entry. More...

void	add (const keyType &, const string &, bool overwrite=false)
	Add a string entry. More...

void	add (const keyType &, const label, bool overwrite=false)
	Add a label entry. More...

void	add (const keyType &, const scalar, bool overwrite=false)
	Add a scalar entry. More...

void	add (const keyType &, const dictionary &, bool mergeEntry=false)
	Add a dictionary entry. More...

template<class T >
void	add (const keyType &, const T &, bool overwrite=false)
	Add a T entry. More...

void	set (entry *)
	Assign a new entry, overwrite any existing entry. More...

void	set (const entry &)
	Assign a new entry, overwrite any existing entry. More...

void	set (const keyType &, const dictionary &)
	Assign a dictionary entry, overwrite any existing entry. More...

template<class T >
void	set (const keyType &, const T &)
	Assign a T entry, overwrite any existing entry. More...

template<class ... Entries>
void	set (const entry &e, const Entries &...)
	Assign multiple entries, overwriting any existing entries. More...

template<class T , class ... Entries>
void	set (const keyType &, const T &, const Entries &...)
	Assign multiple T entries, overwriting any existing entries. More...

bool	remove (const word &)
	Remove an entry specified by keyword. More...

void	remove (const wordList &)
	Remove entries specified by keywords. More...

bool	changeKeyword (const keyType &oldKeyword, const keyType &newKeyword, bool forceOverwrite=false)
	Change the keyword for an entry,. More...

bool	merge (const dictionary &)
	Merge entries from the given dictionary. More...

void	clear ()
	Clear the dictionary. More...

void	transfer (dictionary &)
	Transfer the contents of the argument and annul the argument. More...

bool	read (Istream &, const bool keepHeader=false)
	Read dictionary from Istream, optionally keeping the header. More...

void	write (Ostream &, const bool subDict=true) const
	Write dictionary, normally with sub-dictionary formatting. More...

ITstream &	operator[] (const word &) const
	Find and return entry. More...

void	operator= (const dictionary &)

void	operator+= (const dictionary &)
	Include entries from the given dictionary. More...

void	operator\|= (const dictionary &)
	Conditionally include entries from the given dictionary. More...

void	operator<<= (const dictionary &)
	Unconditionally include entries from the given dictionary. More...

template<class ... Entries>
std::tuple< const Entries &... >	entries (const Entries &... entries)

template<class T >
T	lookupOrDefault (const word &keyword, const T &defaultValue, const bool writeDefault) const

template<class T >
T	lookupOrDefault (const word &keyword, const unitConversion &defaultUnits, const T &defaultValue, const bool writeDefault) const

template<class ... Entries>
void	set (const entry &e, const Entries &... entries)

template<class T , class ... Entries>
void	set (const keyType &k, const T &t, const Entries &... entries)

Public Member Functions inherited from dictionaryName
	dictionaryName ()
	Construct dictionaryName null. More...

	dictionaryName (const fileName &name)
	Construct dictionaryName as copy of the given fileName. More...

	dictionaryName (dictionaryName &&name)
	Move constructor. More...

const fileName &	name () const
	Return the dictionary name. More...

fileName &	name ()
	Return the dictionary name. More...

const word	dictName () const
	Return the local dictionary name (final part of scoped name) More...

void	operator= (const dictionaryName &name)

void	operator= (dictionaryName &&name)

Public Member Functions inherited from ILList< LListBase, T >
	ILList ()
	Null construct. More...

	ILList (T *a)
	Construct given initial T. More...

	ILList (Istream &)
	Construct from Istream. More...

	ILList (const ILList< LListBase, T > &)
	Copy constructor. More...

	ILList (ILList< LListBase, T > &&)
	Move constructor. More...

template<class CloneArg >
	ILList (const ILList< LListBase, T > &lst, const CloneArg &cloneArg)
	Copy constructor with additional argument for clone. More...

template<class INew >
	ILList (Istream &, const INew &)
	Construct from Istream using given Istream constructor class. More...

	~ILList ()
	Destructor. More...

bool	eraseHead ()
	Remove the head element specified from the list and delete it. More...

bool	erase (T *p)
	Remove the specified element from the list and delete it. More...

void	clear ()
	Clear the contents of the list. More...

void	transfer (ILList< LListBase, T > &)
	Transfer the contents of the argument into this List. More...

void	operator= (const ILList< LListBase, T > &)
	Assignment operator. More...

void	operator= (ILList< LListBase, T > &&)
	Move assignment operator. More...

Public Member Functions inherited from UILList< LListBase, T >
	UILList ()
	Null construct. More...

	UILList (T *a)
	Construct given initial T. More...

	UILList (const UILList< LListBase, T > &)
	Copy constructor. More...

	UILList (UILList< LListBase, T > &&)
	Move constructor. More...

T *	first ()
	Return the first entry. More...

const T *	first () const
	Return the first entry. More...

T *	last ()
	Return the last entry. More...

const T *	last () const
	Return the last entry. More...

T *	removeHead ()
	Remove and return head. More...

T *	remove (T *p)
	Remove and return element. More...

T *	remove (iterator &it)
	Remove and return specified by iterator. More...

void	operator= (const UILList< LListBase, T > &)
	Assignment operator. More...

void	operator= (UILList< LListBase, T > &&)
	Move assignment operator. More...

iterator	begin ()

const iterator &	end ()

const_iterator	cbegin () const

const const_iterator &	cend () const

const_iterator	begin () const

const const_iterator &	end () const

const_reverse_iterator	crbegin () const

const const_reverse_iterator &	crend () const

const_reverse_iterator	rbegin () const

const const_reverse_iterator &	rend () const

bool	operator== (const UILList< LListBase, T > &) const
	Equality operation on ULists of the same type. More...

bool	operator!= (const UILList< LListBase, T > &) const
	The opposite of the equality operation. Takes linear time. More...

Static Protected Member Functions
static typeIOobject< IOdictionary >	readModelDict (const objectRegistry &obr, const word &group, bool registerObject=false)

template<class MomentumTransportModel >
static autoPtr< MomentumTransportModel >	New (const typename MomentumTransportModel::alphaField &alpha, const typename MomentumTransportModel::rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)

Protected Attributes
const Time &	runTime_

const fvMesh &	mesh_

const volVectorField &	U_

const surfaceScalarField &	alphaRhoPhi_

const surfaceScalarField &	phi_

const viscosity &	viscosity_

Additional Inherited Members
Public Types inherited from IOobject
enum	objectState { GOOD , BAD }
	Enumeration defining the valid states of an IOobject. More...

enum	readOption { MUST_READ , MUST_READ_IF_MODIFIED , READ_IF_PRESENT , NO_READ }
	Enumeration defining the read options. More...

enum	writeOption { AUTO_WRITE = 0 , NO_WRITE = 1 }
	Enumeration defining the write options. More...

enum	fileCheckTypes { timeStamp , timeStampMaster , inotify , inotifyMaster }
	Enumeration defining the file checking options. More...

Public Types inherited from UILList< LListBase, T >
typedef T	value_type
	Type of values the DLList contains. More...

typedef T &	reference
	Type that can be used for storing into DLList::value_type. More...

typedef const T &	const_reference
	Type that can be used for storing into constant. More...

typedef label	size_type
	The type that can represent the size of a DLList. More...

typedef LListBase::iterator	LListBase_iterator

typedef LListBase::const_iterator	LListBase_const_iterator

Static Public Member Functions inherited from regIOobject
template<class Type >
static Type &	store (Type *)
	Transfer ownership of the given object pointer to its registry. More...

template<class Type >
static Type &	store (autoPtr< Type > &)
	Transfer ownership of the given object pointer to its registry. More...

Static Public Member Functions inherited from IOobject
static bool	fileNameComponents (const fileName &path, fileName &instance, fileName &local, word &name)
	Split path into instance, local, name components. More...

template<class Name >
static word	groupName (Name name, const word &group)

static word	group (const word &name)
	Return group (extension part of name) More...

static word	member (const word &name)
	Return member (name without the extension) More...

template<class Stream >
static Stream &	writeBanner (Stream &os, bool noHint=false)
	Write the standard OpenFOAM file/dictionary banner. More...

template<class Stream >
static Stream &	writeDivider (Stream &os)
	Write the standard file section divider. More...

template<class Stream >
static Stream &	writeEndDivider (Stream &os)
	Write the standard end file divider. More...

Static Public Member Functions inherited from dictionary
template<class ... Entries>
static std::tuple< const Entries &... >	entries (const Entries &...)
	Construct an entries tuple from which to make a dictionary. More...

static autoPtr< dictionary >	New (Istream &)
	Construct top-level dictionary on freestore from Istream. More...

Static Public Attributes inherited from IOdictionary
static bool	writeDictionaries

Static Public Attributes inherited from regIOobject
static float	fileModificationSkew

Static Public Attributes inherited from IOobject
static constexpr const char *	foamFile = "FoamFile"
	Keyword for the FoamFile header sub-dictionary. More...

static const NamedEnum< fileCheckTypes, 4 >	fileCheckTypesNames

static fileCheckTypes	fileModificationChecking
	Type of file modification checking. More...

Static Public Attributes inherited from dictionary
static const dictionary	null
	Null dictionary. More...

static int	writeOptionalEntries
	If true write optional keywords and values. More...

Protected Member Functions inherited from IOdictionary
	IOdictionary (const IOobject &io, const word &wantedType)
	Construct given an IOobject, supply wanted typeName. More...

Protected Member Functions inherited from regIOobject
bool	readHeaderOk (const IOstream::streamFormat defaultFormat, const word &typeName)
	Read header, check readOpt flags and read data if necessary. More...

Protected Member Functions inherited from IOobject
template<class Type >
bool	typeHeaderOk (const bool checkType)
	Read header using typeGlobalFile to find file. More...

Detailed Description

Abstract base class for turbulence models (RAS, LES and laminar).

Source files

Definition at line 57 of file momentumTransportModel.H.

Constructor & Destructor Documentation

◆ momentumTransportModel() [1/2]

momentumTransportModel	(	const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const viscosity &	viscosity
	)

Construct from components.

Definition at line 93 of file momentumTransportModel.C.

References momentumTransportModel::alphaRhoPhi(), IOobject::group(), IOobject::groupName(), and regIOobject::rename().

Here is the call graph for this function:

◆ momentumTransportModel() [2/2]

momentumTransportModel ( const momentumTransportModel & )

delete

Disallow default bitwise copy construction.

◆ ~momentumTransportModel()

virtual ~momentumTransportModel ( )

inlinevirtual

Destructor.

Definition at line 119 of file momentumTransportModel.H.

Member Function Documentation

◆ readModelDict()

Foam::typeIOobject< Foam::IOdictionary > readModelDict	(	const objectRegistry &	obr,
		const word &	group,
		bool	registerObject = `false`
	)

staticprotected

Definition at line 46 of file momentumTransportModel.C.

References TimePaths::constant(), IOobject::group(), IOobject::groupName(), typeIOobject< Type >::headerOk(), IOobject::MUST_READ_IF_MODIFIED, IOobject::NO_WRITE, IOobject::registerObject(), and objectRegistry::time().

Referenced by laminarModel< BasicMomentumTransportModel >::New(), LESModel< BasicMomentumTransportModel >::New(), RASModel< BasicMomentumTransportModel >::New(), and momentumTransportModel::New().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ New() [1/2]

static autoPtr<MomentumTransportModel> New	(	const typename MomentumTransportModel::alphaField &	alpha,
		const typename MomentumTransportModel::rhoField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const viscosity &	viscosity
	)

inlinestaticprotected

Referenced by filmCompressibleMomentumTransportModel::New(), phaseCompressibleMomentumTransportModel::New(), and phaseIncompressibleMomentumTransportModel::New().

Here is the caller graph for this function:

◆ TypeName()

TypeName ( "momentumTransport" )

Runtime type information.

◆ read()

bool read ( )

pure virtual

Read model coefficients if they have changed.

Reimplemented from regIOobject.

Definition at line 136 of file momentumTransportModel.C.

References regIOobject::read().

Here is the call graph for this function:

◆ time()

const Time& time ( ) const

inline

Definition at line 128 of file momentumTransportModel.H.

References momentumTransportModel::runTime_.

◆ mesh()

const fvMesh& mesh ( ) const

inline

Definition at line 133 of file momentumTransportModel.H.

References momentumTransportModel::mesh_.

Referenced by dispersedTurbulentDispersionModel::continuousTurbulence().

Here is the caller graph for this function:

◆ groupName()

word groupName ( const word & name ) const

inline

Definition at line 138 of file momentumTransportModel.H.

◆ GName()

word GName ( ) const

inline

Helper function to return the name of the turbulence G field.

Definition at line 144 of file momentumTransportModel.H.

References Foam::typedName().

Here is the call graph for this function:

◆ U()

const volVectorField& U ( ) const

inline

Access function to velocity field.

Definition at line 150 of file momentumTransportModel.H.

References momentumTransportModel::U_.

Referenced by viscousHeating::addSup(), NicenoKEqn< BasicMomentumTransportModel >::bubbleG(), LaheyKEpsilon< BasicMomentumTransportModel >::bubbleG(), nutUSpaldingWallFunctionFvPatchScalarField::calcUTau(), NicenoKEqn< BasicMomentumTransportModel >::correctNut(), SmagorinskyZhang< BasicMomentumTransportModel >::correctNut(), LaheyKEpsilon< BasicMomentumTransportModel >::correctNut(), power::execute(), turbulenceIntensity::execute(), momentumTransportModel::New(), nutURoughWallFunctionFvPatchScalarField::nut(), nutUSpaldingWallFunctionFvPatchScalarField::nut(), nutUWallFunctionFvPatchScalarField::nut(), nutLowReWallFunctionFvPatchScalarField::yPlus(), nutUSpaldingWallFunctionFvPatchScalarField::yPlus(), and nutUWallFunctionFvPatchScalarField::yPlus().

Here is the caller graph for this function:

◆ alphaRhoPhi()

const surfaceScalarField& alphaRhoPhi ( ) const

inline

Access function to phase flux field.

Definition at line 156 of file momentumTransportModel.H.

References momentumTransportModel::alphaRhoPhi_.

Referenced by specieFluxBase::calcPhiYif(), momentumTransportModel::momentumTransportModel(), and momentumTransportModel::New().

Here is the caller graph for this function:

◆ phi()

Foam::tmp< Foam::surfaceScalarField > phi ( ) const

virtual

Return the volumetric flux field.

Reimplemented in compressibleMomentumTransportModel.

Definition at line 118 of file momentumTransportModel.C.

Referenced by momentumTransportModel::New().

Here is the caller graph for this function:

◆ properties()

const class Foam::viscosity& properties ( ) const

inline

Access function to fluid properties.

Definition at line 165 of file momentumTransportModel.H.

References momentumTransportModel::viscosity_.

◆ y()

const Foam::volScalarField & y ( ) const

Return the wall distance.

Definition at line 124 of file momentumTransportModel.C.

References DemandDrivenMeshObject< fvMesh, DeletableMeshObject, wallDist >::New(), and wallDist::y().

Here is the call graph for this function:

◆ yb()

const Foam::volScalarField::Boundary & yb ( ) const

Return the near wall distance.

Definition at line 130 of file momentumTransportModel.C.

References DemandDrivenMeshObject< fvMesh, DeletableMeshObject, nearWallDist >::New(), and nearWallDist::y().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ nu() [1/2]

virtual tmp<volScalarField> nu ( ) const

inlinevirtual

Return the laminar viscosity.

Definition at line 177 of file momentumTransportModel.H.

References viscosity::nu().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ nu() [2/2]

virtual tmp<scalarField> nu ( const label patchi ) const

inlinevirtual

Return the laminar viscosity on patchi.

Definition at line 183 of file momentumTransportModel.H.

References viscosity::nu(), and patchi.

Here is the call graph for this function:

◆ nut() [1/2]

virtual tmp<volScalarField> nut ( ) const

pure virtual

Return the turbulence viscosity.

Referenced by continuousGasKEpsilon< BasicMomentumTransportModel >::correctNut(), turbulenceFields::execute(), kappaEff::htcByRhoCp(), nutWallFunctionFvPatchScalarField::nutw(), and compressibleMultiphaseVoF::thermophysicalPredictor().

Here is the caller graph for this function:

◆ nut() [2/2]

virtual tmp<scalarField> nut ( const label patchi ) const

pure virtual

Return the turbulence viscosity on patch.

◆ nuEff() [1/2]

virtual tmp<volScalarField> nuEff ( ) const

pure virtual

Return the effective viscosity.

Referenced by XiGModel::Db(), XiModel::Db(), turbulenceFields::execute(), and fixedShearStressFvPatchVectorField::updateCoeffs().

Here is the caller graph for this function:

◆ nuEff() [2/2]

virtual tmp<scalarField> nuEff ( const label patchi ) const

pure virtual

Return the effective viscosity on patch.

◆ R()

virtual tmp<volSymmTensorField> R ( ) const

pure virtual

Return the Reynolds stress tensor [m^2/s^2].

Referenced by turbulenceFields::execute().

Here is the caller graph for this function:

◆ k()

virtual tmp<volScalarField> k ( ) const

pure virtual

Return the turbulence kinetic energy.

Here is the caller graph for this function:

◆ epsilon()

virtual tmp<volScalarField> epsilon ( ) const

pure virtual

Return the turbulence kinetic energy dissipation rate.

Referenced by phaseTurbulenceStabilisation::addSup(), continuousGasKEpsilon< BasicMomentumTransportModel >::correctNut(), DispersionRASModel< CloudType >::epsilonModel(), continuousGasKEpsilon< BasicMomentumTransportModel >::epsilonSource(), LaheyKEpsilon< BasicMomentumTransportModel >::epsilonSource(), turbulenceFields::execute(), continuousGasKEpsilon< BasicMomentumTransportModel >::phaseTransferCoeff(), LaheyKEpsilon< BasicMomentumTransportModel >::phaseTransferCoeff(), and fWallFunctionFvPatchScalarField::updateCoeffs().

Here is the caller graph for this function:

◆ omega()

virtual tmp<volScalarField> omega ( ) const

pure virtual

Return the turbulence specific dissipation rate.

Referenced by phaseTurbulenceStabilisation::addSup(), and turbulenceFields::execute().

Here is the caller graph for this function:

◆ devTau()

virtual tmp<surfaceVectorField> devTau ( ) const

pure virtual

Return the effective surface stress.

Implemented in phaseIncompressibleMomentumTransportModel, phaseCompressibleMomentumTransportModel, and filmCompressibleMomentumTransportModel.

Referenced by power::execute().

Here is the caller graph for this function:

◆ divDevTauCorr()

Foam::tmp< Foam::fvVectorMatrix > divDevTauCorr	(	const tmp< surfaceVectorField > &	devTauCorr,
		volVectorField &	U
	)		const

virtual

Return the explicit stress correction matrix.

for the momentum equation. Combined with the implicit part by divDevTau Also creates and registers the devTauCorrFlux field which is cached in the matrix if fluxRequired.

Definition at line 143 of file momentumTransportModel.C.

References Foam::fvm::divc(), and U.

Here is the call graph for this function:

◆ divDevTau()

virtual tmp<fvVectorMatrix> divDevTau ( volVectorField & U ) const

pure virtual

Return the stress matrix for the momentum equation.

Implemented in phaseIncompressibleMomentumTransportModel, phaseCompressibleMomentumTransportModel, and filmCompressibleMomentumTransportModel.

Referenced by viscousHeating::addSup(), and compressibleMultiphaseVoF::divDevTau().

Here is the caller graph for this function:

◆ validate()

void validate ( )

virtual

Validate the fields after construction.

Update derived fields as required

Definition at line 164 of file momentumTransportModel.C.

◆ predict()

void predict ( )

pure virtual

Predict the momentum transport coefficients if possible.

without solving momentum transport model equations

Definition at line 168 of file momentumTransportModel.C.

◆ correct()

void correct ( )

pure virtual

Solve the momentum transport model equations.

and correct the momentum transport coefficients

Definition at line 172 of file momentumTransportModel.C.

◆ operator=()

void operator= ( const momentumTransportModel & )

delete

Disallow default bitwise assignment.

◆ New() [2/2]

Foam::autoPtr<MomentumTransportModel> New	(	const typename MomentumTransportModel::alphaField &	alpha,
		const typename MomentumTransportModel::rhoField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const viscosity &	viscosity
	)

inline

Definition at line 31 of file momentumTransportModelTemplates.C.

References alpha(), momentumTransportModel::alphaRhoPhi(), IOobject::db(), Foam::decrIndent(), UILList< LListBase, T >::end(), Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, IOobject::group(), Foam::incrIndent(), Foam::indent(), Foam::Info, dictionary::lookup(), Foam::nl, momentumTransportModel::phi(), momentumTransportModel::readModelDict(), rho, and momentumTransportModel::U().

Here is the call graph for this function:

Member Data Documentation

◆ runTime_

const Time& runTime_

protected

Definition at line 65 of file momentumTransportModel.H.

Referenced by momentumTransportModel::time().

◆ mesh_

const fvMesh& mesh_

protected

Definition at line 66 of file momentumTransportModel.H.

Referenced by momentumTransportModel::mesh().

◆ U_

const volVectorField& U_

protected

Definition at line 68 of file momentumTransportModel.H.

Referenced by momentumTransportModel::U().

◆ alphaRhoPhi_

const surfaceScalarField& alphaRhoPhi_

protected

Definition at line 69 of file momentumTransportModel.H.

Referenced by momentumTransportModel::alphaRhoPhi(), and phaseIncompressibleMomentumTransportModel::divDevTau().

◆ phi_

const surfaceScalarField& phi_

protected

Definition at line 70 of file momentumTransportModel.H.

◆ viscosity_

const viscosity& viscosity_

protected

Definition at line 72 of file momentumTransportModel.H.

Referenced by momentumTransportModel::properties().

The documentation for this class was generated from the following files:

src/MomentumTransportModels/momentumTransportModels/momentumTransportModel.H
src/MomentumTransportModels/momentumTransportModels/momentumTransportModel.C
src/MomentumTransportModels/momentumTransportModels/momentumTransportModelTemplates.C

Public Member Functions

Static Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ momentumTransportModel() [1/2]

◆ momentumTransportModel() [2/2]

◆ ~momentumTransportModel()

Member Function Documentation

◆ readModelDict()

◆ New() [1/2]

◆ TypeName()

◆ read()

◆ time()

◆ mesh()

◆ groupName()

◆ GName()

◆ U()

◆ alphaRhoPhi()

◆ phi()

◆ properties()

◆ y()

◆ yb()

◆ nu() [1/2]

◆ nu() [2/2]

◆ nut() [1/2]

◆ nut() [2/2]

◆ nuEff() [1/2]

◆ nuEff() [2/2]

◆ R()

◆ k()

◆ epsilon()

◆ omega()

◆ devTau()

◆ divDevTauCorr()

◆ divDevTau()

◆ validate()

◆ predict()

◆ correct()

◆ operator=()

◆ New() [2/2]

Member Data Documentation

◆ runTime_

◆ mesh_

◆ U_

◆ alphaRhoPhi_

◆ phi_

◆ viscosity_
