Template class for non-intrusive linked lists. More...

Inheritance diagram for LList< LListBase, T >:

[legend]

Collaboration diagram for LList< LListBase, T >:

Classes
class	const_iterator
	An STL-conforming const_iterator. More...

class	iterator
	An STL-conforming iterator. More...

struct	link
	Link structure. More...

Public Types
typedef T	value_type
	Type of values the LList contains. More...

typedef T &	reference
	Type that can be used for storing into value_type. More...

typedef const T &	const_reference
	Type that can be used for storing into constant. More...

typedef label	size_type
	The type that can represent the size of a LList. More...

typedef LListBase::iterator	LListBase_iterator

typedef LListBase::const_iterator	LListBase_const_iterator

Public Member Functions
	LList ()
	Null construct. More...

	LList (T a)
	Construct given initial T. More...

	LList (Istream &)
	Construct from Istream. More...

	LList (const LList< LListBase, T > &)
	Copy constructor. More...

	LList (LList< LListBase, T > &&)
	Move constructor. More...

	LList (std::initializer_list< T >)
	Construct from an initialiser list. More...

	~LList ()
	Destructor. More...

T &	first ()
	Return the first entry added. More...

const T &	first () const
	Return const access to the first entry added. More...

T &	last ()
	Return the last entry added. More...

const T &	last () const
	Return const access to the last entry added. More...

void	insert (const T &a)
	Add at head of list. More...

void	append (const T &a)
	Add at tail of list. More...

T	removeHead ()
	Remove and return head. More...

T	remove (link *l)
	Remove and return element. More...

T	remove (iterator &it)
	Remove and return element specified by iterator. More...

void	clear ()
	Delete contents of list. More...

void	transfer (LList< LListBase, T > &)
	Transfer the contents of the argument into this List. More...

void	operator= (const LList< LListBase, T > &)
	Assignment operator. More...

void	operator= (LList< LListBase, T > &&)
	Move assignment operator. More...

void	operator= (std::initializer_list< T >)
	Assignment to an initialiser list. More...

iterator	begin ()

const iterator &	end ()

const_iterator	cbegin () const

const const_iterator &	cend () const

const_iterator	begin () const

const const_iterator &	end () const

Friends
class	iterator

class	const_iterator

Istream &	operator>> (Istream &, LList< LListBase, T > &)

Ostream &	operator (Ostream &, const LList< LListBase, T > &)

Detailed Description

template<class LListBase, class T>
class Foam::LList< LListBase, T >

Template class for non-intrusive linked lists.

Source files

Definition at line 73 of file LList.H.

Member Typedef Documentation

◆ value_type

typedef T value_type

Type of values the LList contains.

Definition at line 227 of file LList.H.

◆ reference

typedef T& reference

Type that can be used for storing into value_type.

objects.

Definition at line 231 of file LList.H.

◆ const_reference

typedef const T& const_reference

Type that can be used for storing into constant.

LList::value_type objects.

Definition at line 235 of file LList.H.

◆ size_type

typedef label size_type

The type that can represent the size of a LList.

Definition at line 238 of file LList.H.

◆ LListBase_iterator

typedef LListBase::iterator LListBase_iterator

Definition at line 243 of file LList.H.

◆ LListBase_const_iterator

typedef LListBase::const_iterator LListBase_const_iterator

Definition at line 294 of file LList.H.

Constructor & Destructor Documentation

◆ LList() [1/6]

LList ( )

inline

Null construct.

Definition at line 108 of file LList.H.

◆ LList() [2/6]

LList ( T a )

inline

Construct given initial T.

Definition at line 112 of file LList.H.

◆ LList() [3/6]

LList ( Istream & is )

Construct from Istream.

Definition at line 33 of file LListIO.C.

References Foam::functionObjects::fieldValues::operator>>().

Here is the call graph for this function:

◆ LList() [4/6]

LList ( const LList< LListBase, T > & lst )

Copy constructor.

Definition at line 31 of file LList.C.

References LList< LListBase, T >::append(), and Foam::T().

Here is the call graph for this function:

◆ LList() [5/6]

LList ( LList< LListBase, T > && lst )

Move constructor.

Definition at line 43 of file LList.C.

References LList< LListBase, T >::transfer().

Here is the call graph for this function:

◆ LList() [6/6]

LList ( std::initializer_list< T > lst )

Construct from an initialiser list.

Definition at line 52 of file LList.C.

References LList< LListBase, T >::append(), and Foam::T().

Here is the call graph for this function:

◆ ~LList()

~LList

Destructor.

Definition at line 64 of file LList.C.

References clear().

Here is the call graph for this function:

Member Function Documentation

◆ first() [1/2]

T& first ( )

inline

Return the first entry added.

Definition at line 139 of file LList.H.

References Foam::first().

Referenced by FIFOStack< T >::bottom(), ULPtrList< LListBase, T >::first(), Foam::polyMeshZipUpCells(), and LIFOStack< T >::top().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ first() [2/2]

const T& first ( ) const

inline

Return const access to the first entry added.

Definition at line 145 of file LList.H.

References Foam::first().

Here is the call graph for this function:

◆ last() [1/2]

T& last ( )

inline

Return the last entry added.

Definition at line 151 of file LList.H.

Referenced by LIFOStack< T >::bottom(), ULPtrList< LListBase, T >::last(), Foam::polyMeshZipUpCells(), and FIFOStack< T >::top().

Here is the caller graph for this function:

◆ last() [2/2]

const T& last ( ) const

inline

Return const access to the last entry added.

Definition at line 157 of file LList.H.

◆ insert()

void insert ( const T & a )

inline

Add at head of list.

Definition at line 166 of file LList.H.

References Foam::vtkWriteOps::insert().

Referenced by Foam::polyMeshZipUpCells(), and LIFOStack< T >::push().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ append()

void append ( const T & a )

inline

Add at tail of list.

Definition at line 172 of file LList.H.

Referenced by Foam::bandCompression(), LList< LListBase, T >::LList(), Foam::polyMeshZipUpCells(), FIFOStack< T >::push(), and Foam::blockMeshTools::read().

Here is the caller graph for this function:

◆ removeHead()

T removeHead ( )

inline

Remove and return head.

Definition at line 178 of file LList.H.

References LList< LListBase, T >::link::obj_, and Foam::T().

Referenced by Foam::bandCompression(), Foam::polyMeshZipUpCells(), FIFOStack< T >::pop(), and LIFOStack< T >::pop().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ remove() [1/2]

T remove ( link * l )

inline

Remove and return element.

Definition at line 187 of file LList.H.

References LList< LListBase, T >::link::obj_, and Foam::T().

Here is the call graph for this function:

◆ remove() [2/2]

T remove ( iterator & it )

inline

Remove and return element specified by iterator.

Definition at line 196 of file LList.H.

References LList< LListBase, T >::link::obj_, and Foam::T().

Here is the call graph for this function:

◆ clear()

void clear

Delete contents of list.

Definition at line 73 of file LList.C.

References clear().

Here is the call graph for this function:

◆ transfer()

void transfer ( LList< LListBase, T > & lst )

Transfer the contents of the argument into this List.

and annul the argument list.

Definition at line 86 of file LList.C.

References clear().

Referenced by LList< LListBase, T >::LList().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator=() [1/3]

void operator= ( const LList< LListBase, T > & lst )

Assignment operator.

Definition at line 96 of file LList.C.

References clear(), and Foam::T().

Here is the call graph for this function:

◆ operator=() [2/3]

void operator= ( LList< LListBase, T > && lst )

Move assignment operator.

Definition at line 108 of file LList.C.

◆ operator=() [3/3]

void operator= ( std::initializer_list< T > lst )

Assignment to an initialiser list.

Definition at line 115 of file LList.C.

References clear(), and Foam::T().

Here is the call graph for this function:

◆ begin() [1/2]

iterator begin ( )

inline

Definition at line 281 of file LList.H.

Referenced by FixedList< T, Size >::FixedList(), LPtrList< LListBase, T >::operator=(), and List< T >::operator=().

Here is the caller graph for this function:

◆ end() [1/2]

const iterator& end ( )

inline

Definition at line 286 of file LList.H.

Referenced by LPtrList< LListBase, T >::operator=(), and List< T >::operator=().

Here is the caller graph for this function:

◆ cbegin()

const_iterator cbegin ( ) const

inline

Definition at line 339 of file LList.H.

◆ cend()

const const_iterator& cend ( ) const

inline

Definition at line 344 of file LList.H.

◆ begin() [2/2]

const_iterator begin ( ) const

inline

Definition at line 349 of file LList.H.

◆ end() [2/2]

const const_iterator& end ( ) const

inline

Definition at line 354 of file LList.H.

Friends And Related Function Documentation

◆ iterator

friend class iterator

friend

Definition at line 83 of file LList.H.

◆ const_iterator

friend class const_iterator

friend

Definition at line 86 of file LList.H.

◆ operator>>

Istream& operator>>	(	Istream &	,
		LList< LListBase, T > &
	)

friend

◆ operator

Ostream& operator	(	Ostream &	,
		const LList< LListBase, T > &
	)

friend

The documentation for this class was generated from the following files:

src/OpenFOAM/containers/LinkedLists/accessTypes/LList/LList.H
src/OpenFOAM/containers/LinkedLists/accessTypes/LList/LList.C
src/OpenFOAM/containers/LinkedLists/accessTypes/LList/LListIO.C
