A keyword and a list of tokens is an 'entry'. More...

Inheritance diagram for entry:

[legend]

Collaboration diagram for entry:

Public Member Functions
	entry (const keyType &keyword, const label lineNumber=-1)
	Construct from keyword and optional line number. More...

	entry (const entry &)
	Copy constructor. More...

virtual autoPtr< entry >	clone (const dictionary &parentDict) const =0
	Construct on freestore as copy with reference to the. More...

virtual autoPtr< entry >	clone () const
	Construct on freestore as copy. More...

virtual	~entry ()
	Destructor. More...

const keyType &	keyword () const
	Return keyword. More...

keyType &	keyword ()
	Return non-const access to keyword. More...

virtual const fileName &	name () const =0
	Return the dictionary name. More...

virtual fileName &	name ()=0
	Return the dictionary name. More...

virtual label	startLineNumber () const
	Return line number of keyword of the entry. More...

virtual label &	startLineNumber ()
	Return non-const access to line number of keyword of the entry. More...

virtual label	endLineNumber () const =0
	Return line number of last token in dictionary. More...

virtual bool	isStream () const
	Return true if this entry is a stream. More...

virtual ITstream &	stream () const =0
	Return token stream if this entry is a primitive entry. More...

virtual bool	isDict () const
	Return true if this entry is a dictionary. More...

virtual const dictionary &	dict () const =0
	Return dictionary if this entry is a dictionary. More...

virtual dictionary &	dict ()=0
	Return non-const access to dictionary if this entry is a dictionary. More...

virtual void	write (Ostream &) const =0
	Write. More...

void	operator= (const entry &)

bool	operator== (const entry &) const

bool	operator!= (const entry &) const

Static Public Member Functions
static bool	New (dictionary &parentDict, Istream &)
	Construct from Istream and insert into dictionary. More...

static autoPtr< entry >	New (Istream &is)
	Construct on freestore from Istream and return. More...

Static Public Attributes
static int	disableFunctionEntries

Friends
Ostream &	operator<< (Ostream &, const entry &)

Detailed Description

A keyword and a list of tokens is an 'entry'.

An entry can be read, written and printed, and the types and values of its tokens analysed. An entry is a high-level building block for data description. It is a front-end for the token parser. A list of entries can be used as a set of keyword syntax elements, for example.

Source files

Definition at line 65 of file entry.H.

Constructor & Destructor Documentation

◆ entry() [1/2]

entry	(	const keyType &	keyword,
		const label	lineNumber = `-1`
	)

explicit

Construct from keyword and optional line number.

Definition at line 40 of file entry.C.

References Foam::link.

◆ entry() [2/2]

entry ( const entry & e )

Copy constructor.

Definition at line 48 of file entry.C.

References Foam::link.

◆ ~entry()

virtual ~entry ( )

inlinevirtual

Destructor.

Definition at line 129 of file entry.H.

Member Function Documentation

◆ clone() [1/2]

virtual autoPtr<entry> clone ( const dictionary & parentDict ) const

pure virtual

Construct on freestore as copy with reference to the.

dictionary the copy belongs to

Implemented in dictionaryListEntry, dictionaryEntry, primitiveEntry, and functionEntry.

Referenced by Foam::addEntry().

Here is the caller graph for this function:

◆ clone() [2/2]

Foam::autoPtr< Foam::entry > clone ( ) const

virtual

Construct on freestore as copy.

Note: the parent directory is set to dictionary::null

Definition at line 56 of file entry.C.

References Foam::clone(), and dictionary::null.

Here is the call graph for this function:

◆ New() [1/2]

bool New	(	dictionary &	parentDict,
		Istream &	is
	)

static

Construct from Istream and insert into dictionary.

Definition at line 103 of file entryIO.C.

References dictionary::add(), token::BEGIN_BLOCK, token::BEGIN_LIST, dictionary::clear(), entry::dict(), token::END_BLOCK, Foam::endl(), IOstream::eof(), inputModeEntry::error(), functionEntry::execute(), Foam::exit(), IOstream::fatalCheck(), Foam::FatalIOError, FatalIOErrorInFunction, forAllConstIter, Foam::stringOps::inplaceExpandEntry(), entry::isDict(), keyType::isFunctionName(), token::isLabel(), token::isPunctuation(), entry::isStream(), keyType::isVariable(), dictionary::lookupEntryPtr(), dictionary::lookupScopedEntryPtr(), inputModeEntry::merge(), IOstream::name(), Foam::nl, inputModeEntry::overwrite(), inputModeEntry::protect(), token::pToken(), Istream::putBack(), s(), entry::stream(), success, and Foam::blendedInterfacialModel::valid().

Referenced by Foam::addArgEntry(), dictionaryListEntry::dictionaryListEntry(), and dictionary::read().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ New() [2/2]

Foam::autoPtr< Foam::entry > New ( Istream & is )

static

Construct on freestore from Istream and return.

Definition at line 369 of file entryIO.C.

References token::BEGIN_BLOCK, IOstream::fatalCheck(), dictionary::null, and Istream::putBack().

Here is the call graph for this function:

◆ keyword() [1/2]

const keyType& keyword ( ) const

inline

Return keyword.

Definition at line 136 of file entry.H.

Referenced by dictionary::add(), cellModel::cellModel(), dictionary::lookupBackwardsCompatible(), dictionary::lookupEntryPtrBackwardsCompatible(), dictionary::lookupOrDefaultBackwardsCompatible(), Foam::mergeDictionaries(), Foam::operator>>(), phaseProperties::phaseProperties(), primitiveEntry::primitiveEntry(), refinementRegions::refinementRegions(), refinementSurfaces::refinementSurfaces(), and dictionary::set().

Here is the caller graph for this function:

◆ keyword() [2/2]

keyType& keyword ( )

inline

Return non-const access to keyword.

Definition at line 142 of file entry.H.

◆ name() [1/2]

virtual const fileName& name ( ) const

pure virtual

Return the dictionary name.

Implemented in primitiveEntry, and dictionaryEntry.

Referenced by dictionary::add().

Here is the caller graph for this function:

◆ name() [2/2]

virtual fileName& name ( )

pure virtual

Return the dictionary name.

Implemented in primitiveEntry, and dictionaryEntry.

◆ startLineNumber() [1/2]

virtual label startLineNumber ( ) const

inlinevirtual

Return line number of keyword of the entry.

Reimplemented in dictionaryEntry.

Definition at line 154 of file entry.H.

Referenced by primitiveEntry::primitiveEntry(), and dictionaryEntry::startLineNumber().

Here is the caller graph for this function:

◆ startLineNumber() [2/2]

virtual label& startLineNumber ( )

inlinevirtual

Return non-const access to line number of keyword of the entry.

Definition at line 160 of file entry.H.

◆ endLineNumber()

virtual label endLineNumber ( ) const

pure virtual

Return line number of last token in dictionary.

Implemented in primitiveEntry, and dictionaryEntry.

◆ isStream()

virtual bool isStream ( ) const

inlinevirtual

Return true if this entry is a stream.

Reimplemented in primitiveEntry.

Definition at line 169 of file entry.H.

Referenced by entry::New().

Here is the caller graph for this function:

◆ stream()

virtual ITstream& stream ( ) const

pure virtual

Return token stream if this entry is a primitive entry.

Implemented in primitiveEntry, and dictionaryEntry.

Referenced by dictionary::lookup(), dictionary::lookupBackwardsCompatible(), dictionary::lookupCompoundScoped(), dictionary::lookupOrAddDefault(), dictionary::lookupOrDefault(), dictionary::lookupOrDefaultBackwardsCompatible(), dictionary::lookupScoped(), coordinateSystem::New(), entry::New(), dynamicCodeContext::read(), Foam::blockMeshTools::read(), dimensioned< Type >::readIfPresent(), dictionary::readIfPresent(), unitConversions::readIfPresent(), unitConversion::readIfPresent(), and solution::upgradeSolverDict().

Here is the caller graph for this function:

◆ isDict()

virtual bool isDict ( ) const

inlinevirtual

Return true if this entry is a dictionary.

Reimplemented in dictionaryEntry.

Definition at line 178 of file entry.H.

Referenced by dictionary::add(), Foam::addEntry(), Foam::stringOps::inplaceExpandCodeString(), dictionary::isDict(), coordinateSystem::New(), entry::New(), dictionary::scopedDict(), dictionary::set(), Foam::debug::switchSet(), and solution::upgradeSolverDict().

Here is the caller graph for this function:

◆ dict() [1/2]

virtual const dictionary& dict ( ) const

pure virtual

Return dictionary if this entry is a dictionary.

Implemented in primitiveEntry, and dictionaryEntry.

Referenced by dictionary::add(), Foam::addEntry(), Foam::stringOps::inplaceExpandCodeString(), entry::New(), dictionary::optionalSubDict(), refinementRegions::refinementRegions(), refinementSurfaces::refinementSurfaces(), dictionary::scopedDict(), dictionary::set(), dictionary::subDict(), dictionary::subDictBackwardsCompatible(), dictionary::subDictPtr(), dictionary::subOrEmptyDict(), dictionary::substituteKeyword(), and Foam::debug::switchSet().

Here is the caller graph for this function:

◆ dict() [2/2]

virtual dictionary& dict ( )

pure virtual

Return non-const access to dictionary if this entry is a dictionary.

Implemented in primitiveEntry, and dictionaryEntry.

◆ write()

virtual void write ( Ostream & ) const

pure virtual

Write.

Implemented in primitiveEntry, functionEntry, dictionaryListEntry, and dictionaryEntry.

◆ operator=()

void operator= ( const entry & e )

Definition at line 64 of file entry.C.

References Foam::abort(), Foam::e, Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

◆ operator==()

bool operator== ( const entry & e ) const

Definition at line 78 of file entry.C.

References Foam::e, and OStringStream::str().

Here is the call graph for this function:

◆ operator!=()

bool operator!= ( const entry & e ) const

Definition at line 97 of file entry.C.

References Foam::e, and Foam::operator==().

Here is the call graph for this function:

Friends And Related Function Documentation

◆ operator<<

Ostream& operator<<	(	Ostream &	,
		const entry &
	)

friend

Member Data Documentation

◆ disableFunctionEntries

int disableFunctionEntries

static

Definition at line 102 of file entry.H.

Referenced by dictionary::add(), and Foam::readConfigFile().

The documentation for this class was generated from the following files:

src/OpenFOAM/db/dictionary/entry/entry.H
src/OpenFOAM/db/dictionary/entry/entry.C
src/OpenFOAM/db/dictionary/entry/entryIO.C
