Foam::saturationModels Namespace Reference

Namespace containing common functionality for saturationPressureModel and saturationTemperatureModel. More...

Classes
class	Antoine
	Antoine equation for the vapour pressure. More...
class	AntoineExtended
	Extended Antoine equation for the vapour pressure. More...
class	ArdenBuck
	ArdenBuck equation for the vapour pressure of moist air. More...
class	constantPressure
	Constant saturation pressure model. More...
class	constantTemperature
	Constant saturation temperature model. More...
class	function1Temperature
	Saturation vapour temperature in terms of the vapour pressure (in Pa). The saturation temperature in Kelvins is specified as a Foam::Function1 type, to enable use of, e.g. constant, polynomial, table values. More...
class	polynomialTemperature
	Polynomial equation for the saturation vapour temperature in terms of the vapour pressure (in Pa). More...
struct	coefficient
	Structure to store a dimensioned coefficient of the saturation model. More...

Functions
	defineTypeNameAndDebug (Antoine, 0)
	addToRunTimeSelectionTable (saturationPressureModel, Antoine, dictionary)
	addToRunTimeSelectionTable (saturationTemperatureModel, Antoine, dictionary)
	defineTypeNameAndDebug (AntoineExtended, 0)
	addToRunTimeSelectionTable (saturationPressureModel, AntoineExtended, dictionary)
	defineTypeNameAndDebug (ArdenBuck, 0)
	addToRunTimeSelectionTable (saturationPressureModel, ArdenBuck, dictionary)
	defineTypeNameAndDebug (constantPressure, 0)
	addToRunTimeSelectionTable (saturationPressureModel, constantPressure, dictionary)
static const dimensionedScalar	zeroPbyT (dimPressure/dimTemperature, 0)
	defineTypeNameAndDebug (constantTemperature, 0)
	addToRunTimeSelectionTable (saturationTemperatureModel, constantTemperature, dictionary)
static const dimensionedScalar	zeroTbyP (dimTemperature/dimPressure, 0)
	defineTypeNameAndDebug (function1Temperature, 0)
	addToRunTimeSelectionTable (saturationTemperatureModel, function1Temperature, dictionary)
	defineTypeNameAndDebug (polynomialTemperature, 0)
	addToRunTimeSelectionTable (saturationTemperatureModel, polynomialTemperature, dictionary)
tmp< scalarField >	evaluate (const scalarField &argument, const word &name, const dimensionedScalar &value)
	Construct a scalar field from a uniform value. More...
template<class FieldType >
tmp< FieldType >	evaluate (const FieldType &argument, const word &name, const dimensionedScalar &value)
	Construct a volScalarField::Internal or a volScalarField field from a. More...
template<class Model >
tmp< volScalarField::Internal >	evaluate (const volScalarField::Internal &p, const word &name, const dimensionSet &dimensions, const Model &model, tmp< scalarField >(Model::*method)(const scalarField &) const)
	Use a model's scalarField method to construct a volScalarField::Internal. More...
template<class Model >
tmp< volScalarField >	evaluate (const volScalarField &p, const word &name, const dimensionSet &dimensions, const Model &model, tmp< scalarField >(Model::*method)(const scalarField &) const)
	Use a model's scalarField method to construct a volScalarField. More...

Variables
static const coefficient	oneP (dimPressure, 1)
static const coefficient	oneT (dimTemperature, 1)
static const coefficient	zeroC ("zeroC", dimTemperature, 273.15)
static const coefficient	A ("A", dimPressure, 611.21)
static const coefficient	B ("B", dimless, 18.678)
static const coefficient	C ("C", dimTemperature, 234.5)
static const coefficient	D ("D", dimTemperature, 257.14)
static const dimensionedScalar	oneP (dimPressure, 1)

Detailed Description

Namespace containing common functionality for saturationPressureModel and saturationTemperatureModel.

Function Documentation

defineTypeNameAndDebug() [1/7]

Foam::saturationModels::defineTypeNameAndDebug	(	Antoine	,
		0
	)

addToRunTimeSelectionTable() [1/8]

Foam::saturationModels::addToRunTimeSelectionTable	(	saturationPressureModel	,
		Antoine	,
		dictionary
	)

addToRunTimeSelectionTable() [2/8]

Foam::saturationModels::addToRunTimeSelectionTable	(	saturationTemperatureModel	,
		Antoine	,
		dictionary
	)

defineTypeNameAndDebug() [2/7]

Foam::saturationModels::defineTypeNameAndDebug	(	AntoineExtended	,
		0
	)

addToRunTimeSelectionTable() [3/8]

Foam::saturationModels::addToRunTimeSelectionTable	(	saturationPressureModel	,
		AntoineExtended	,
		dictionary
	)

defineTypeNameAndDebug() [3/7]

Foam::saturationModels::defineTypeNameAndDebug	(	ArdenBuck	,
		0
	)

addToRunTimeSelectionTable() [4/8]

Foam::saturationModels::addToRunTimeSelectionTable	(	saturationPressureModel	,
		ArdenBuck	,
		dictionary
	)

defineTypeNameAndDebug() [4/7]

Foam::saturationModels::defineTypeNameAndDebug	(	constantPressure	,
		0
	)

addToRunTimeSelectionTable() [5/8]

Foam::saturationModels::addToRunTimeSelectionTable	(	saturationPressureModel	,
		constantPressure	,
		dictionary
	)

zeroPbyT()

static const dimensionedScalar Foam::saturationModels::zeroPbyT ( dimPressure/  dimTemperature, 0    )

static

Referenced by constantPressure::pSatPrime().

Here is the caller graph for this function:

defineTypeNameAndDebug() [5/7]

Foam::saturationModels::defineTypeNameAndDebug	(	constantTemperature	,
		0
	)

addToRunTimeSelectionTable() [6/8]

Foam::saturationModels::addToRunTimeSelectionTable	(	saturationTemperatureModel	,
		constantTemperature	,
		dictionary
	)

zeroTbyP()

static const dimensionedScalar Foam::saturationModels::zeroTbyP ( dimTemperature/  dimPressure, 0    )

static

Referenced by constantTemperature::TsatPrime().

Here is the caller graph for this function:

defineTypeNameAndDebug() [6/7]

Foam::saturationModels::defineTypeNameAndDebug	(	function1Temperature	,
		0
	)

addToRunTimeSelectionTable() [7/8]

Foam::saturationModels::addToRunTimeSelectionTable	(	saturationTemperatureModel	,
		function1Temperature	,
		dictionary
	)

defineTypeNameAndDebug() [7/7]

Foam::saturationModels::defineTypeNameAndDebug	(	polynomialTemperature	,
		0
	)

addToRunTimeSelectionTable() [8/8]

Foam::saturationModels::addToRunTimeSelectionTable	(	saturationTemperatureModel	,
		polynomialTemperature	,
		dictionary
	)

evaluate() [1/4]

tmp<scalarField> Foam::saturationModels::evaluate ( const scalarField &  argument, const word &  name, const dimensionedScalar &  value  )

inline

Construct a scalar field from a uniform value.

Definition at line 63 of file saturationModels.H.

References List< T >::size(), and dimensioned< Type >::value().

Referenced by constantPressure::lnPSat(), saturationPressureModel::lnPSat(), constantPressure::pSat(), saturationPressureModel::pSat(), constantPressure::pSatPrime(), saturationPressureModel::pSatPrime(), constantTemperature::Tsat(), saturationTemperatureModel::Tsat(), constantTemperature::TsatPrime(), and saturationTemperatureModel::TsatPrime().

Here is the call graph for this function:

Here is the caller graph for this function:

evaluate() [2/4]

tmp<FieldType> Foam::saturationModels::evaluate ( const FieldType &  argument, const word &  name, const dimensionedScalar &  value  )

inline

Construct a volScalarField::Internal or a volScalarField field from a.

uniform value

Definition at line 76 of file saturationModels.H.

References Foam::name(), and Foam::compressible::New().

Here is the call graph for this function:

evaluate() [3/4]

tmp<volScalarField::Internal> Foam::saturationModels::evaluate ( const volScalarField::Internal &  p, const word &  name, const dimensionSet &  dimensions, const Model &  model, tmp< scalarField >(Model::*)(const scalarField &) const  method  )

inline

Use a model's scalarField method to construct a volScalarField::Internal.

Definition at line 88 of file saturationModels.H.

References Foam::dimensions(), Foam::name(), DimensionedField< Type, GeoMesh, PrimitiveField >::New(), p, DimensionedField< Type, GeoMesh, PrimitiveField >::primitiveFieldRef(), and tmp< T >::ref().

Here is the call graph for this function:

evaluate() [4/4]

tmp<volScalarField> Foam::saturationModels::evaluate ( const volScalarField &  p, const word &  name, const dimensionSet &  dimensions, const Model &  model, tmp< scalarField >(Model::*)(const scalarField &) const  method  )

inline

Use a model's scalarField method to construct a volScalarField.

Definition at line 111 of file saturationModels.H.

References GeometricField< Type, GeoMesh, PrimitiveField >::boundaryField(), GeometricField< Type, GeoMesh, PrimitiveField >::boundaryFieldRef(), Foam::dimensions(), forAll, Foam::name(), GeometricField< Type, GeoMesh, PrimitiveField >::New(), p, patchi, GeometricField< Type, GeoMesh, PrimitiveField >::primitiveFieldRef(), and tmp< T >::ref().

Here is the call graph for this function:

Variable Documentation

oneP [1/2]

const coefficient oneP(dimPressure, 1) ( dimPressure  , 1    )

static

Referenced by constantPressure::lnPSat(), Antoine::pSat(), Antoine::Tsat(), and Antoine::TsatPrime().

oneT

const coefficient oneT(dimTemperature, 1) ( dimTemperature  , 1    )

static

Referenced by AntoineExtended::lnPSat().

zeroC

const coefficient zeroC("zeroC", dimTemperature, 273.15) ( "zeroC"  , dimTemperature  , 273.  15  )

static

Referenced by ArdenBuck::lnPSat(), ArdenBuck::pSat(), and ArdenBuck::pSatPrime().

A

const coefficient A("A", dimPressure, 611.21) ( "A"  , dimPressure  , 611.  21  )

static

Referenced by Barycentric< Cmpt >::a(), Barycentric2D< Cmpt >::a(), ISAT::add(), solidThermalEquilibrium::addSup(), Barycentric< Cmpt >::Barycentric(), Barycentric2D< Cmpt >::Barycentric2D(), PlessisMasliyahDragForce< CloudType >::calcCoupled(), COxidationHurtMitchell< CloudType >::calculate(), LiquidEvaporationBoil< CloudType >::calculate(), SyamlalOBrien::CdRe(), ODESystem::check(), chemPointISAT::checkSolution(), twoDPointCorrector::correctDisplacement(), twoDPointCorrector::correctPoints(), PengRobinsonGas< Specie >::Cp(), PengRobinsonGas< Specie >::CpMCv(), cyclicTransform::cyclicTransform(), Foam::diff(), eigendecomposition::eigendecomposition(), Foam::eigenVector(), binaryTree::insertNewLeaf(), twoPhaseMixture::interfaceFraction(), lduMatrix::lduMatrix(), ArdenBuck::lnPSat(), Saito::mDotcvAlphal(), Saito::mDotcvP(), Foam::tracking::movingTetReverseTransform(), Foam::multiply(), Foam::operator+(), lduMatrix::operator+=(), LduMatrix< Type, DType, LUType >::operator+=(), Foam::operator-(), lduMatrix::operator-=(), LduMatrix< Type, DType, LUType >::operator-=(), lduMatrix::operator=(), LduMatrix< Type, DType, LUType >::operator=(), BSpline::position(), CatmullRomSpline::position(), ArdenBuck::pSat(), ArdenBuck::pSatPrime(), EFA< ThermoType >::reduceMechanism(), PFA< ThermoType >::reduceMechanism(), ConeInjection< CloudType >::setProperties(), Foam::triIntersect::solveProjectionGivenT(), Foam::triIntersect::srcEdgeTgtEdgeIntersection(), Foam::triIntersect::srcEdgeTgtPointOffset(), Foam::triIntersect::srcPointTgtEdgeOffset(), Foam::triIntersect::srcPointTgtTriIntersection(), Foam::triIntersect::srcTriTgtPointIntersection(), Foam::tracking::stationaryTetReverseTransform(), SVD::SVD(), Foam::SVDinv(), Matrix< Form, Type >::T(), solitary::velocity(), and PengRobinsonGas< Specie >::Z().

B

const coefficient B("B", dimless, 18.678) ( "B"  , dimless  , 18.  678  )

static

Referenced by solidThermalEquilibrium::addSup(), Barycentric< Cmpt >::b(), Barycentric2D< Cmpt >::b(), Barycentric< Cmpt >::Barycentric(), Barycentric2D< Cmpt >::Barycentric2D(), PlessisMasliyahDragForce< CloudType >::calcCoupled(), CentredFitSnGradData< Polynomial >::calcFit(), LiquidEvaporationBoil< CloudType >::calculate(), SyamlalOBrien::CdRe(), PengRobinsonGas< Specie >::Cp(), PengRobinsonGas< Specie >::CpMCv(), PengRobinsonGas< Specie >::Cv(), Barycentric< scalar >::d(), Foam::diff(), PengRobinsonGas< Specie >::e(), PengRobinsonGas< Specie >::h(), Foam::invIncGammaRatio_P(), main(), Foam::multiply(), Foam::operator+(), Foam::operator-(), BSpline::position(), CatmullRomSpline::position(), EFA< ThermoType >::reduceMechanism(), PFA< ThermoType >::reduceMechanism(), inhomogeneousEGRMixture< ThermoType >::reset(), Foam::triIntersect::solveProjectionGivenT(), PengRobinsonGas< Specie >::sp(), homogeneousMixture< ThermoType >::thermoMixture(), leanInhomogeneousMixture< ThermoType >::thermoMixture(), homogeneousMixture< ThermoType >::transportMixture(), leanInhomogeneousMixture< ThermoType >::transportMixture(), XiEqModel::writeFields(), ArdenBuck::xByTC(), and PengRobinsonGas< Specie >::Z().

C

const coefficient C("C", dimTemperature, 234.5) ( "C"  , dimTemperature  , 234.  5  )

static

Referenced by Barycentric< scalar >::Barycentric(), Barycentric< Cmpt >::Barycentric(), Barycentric2D< Cmpt >::Barycentric2D(), Barycentric< Cmpt >::c(), Barycentric2D< Cmpt >::c(), viewFactor::calculate(), Reaction< ThermoType >::ddNdtByVdcTp(), fvMesh::delta(), makeFvGradScheme(), nonConformalProcessorCyclicFvPatch::makeWeights(), processorFvPatch::makeWeights(), Foam::multiply(), Reaction< ThermoType >::omega(), inverseFaceDistanceDiffusivity::operator()(), plane::planeCoeffs(), ArdenBuck::pSatPrime(), forcing::regionLength(), and writeCellCentres::write().

D

const coefficient D("D", dimTemperature, 257.14) ( "D"  , dimTemperature  , 257.  14  )

static

Referenced by fvMatrix< Type >::A(), momentumTransferSystem::alphaDByAf(), Barycentric< Cmpt >::Barycentric(), COxidationMurphyShaddix< CloudType >::calculate(), dynamicKEqn< BasicMomentumTransportModel >::Ce(), chemPointISAT::chemPointISAT(), dynamicKEqn< BasicMomentumTransportModel >::Ck(), kineticTheoryModel::correct(), DeardorffDiffStress< BasicMomentumTransportModel >::correct(), dynamicKEqn< BasicMomentumTransportModel >::correct(), LaunderSharmaKE< BasicMomentumTransportModel >::correct(), dynamicKEqn< BasicMomentumTransportModel >::correctNut(), Barycentric< Cmpt >::d(), iC3H8O::D(), nC3H8O::D(), phaseForces::execute(), phaseScalarTransport::execute(), scalarTransport::execute(), momentumTransferSystem::Ffs(), momentumTransferSystem::Fs(), Foam::invIncGammaRatio_P(), Smagorinsky< BasicMomentumTransportModel >::k(), makeMomentumTransportModelTypes(), JohnsonJacksonSchaeffer::nu(), Schaeffer::nu(), motionDirectionalDiffusivity::operator()(), BSpline::position(), CatmullRomSpline::position(), solidDisplacement::pressureCorrector(), ArdenBuck::pSatPrime(), fvMatrix< Type >::relax(), ArdenBuck::xByTC(), and PengRobinsonGas< Specie >::Z().

oneP [2/2]

const dimensionedScalar oneP(dimPressure, 1) ( dimPressure  , 1    )

static
