Momentum parcel class with rotational motion (as spherical particles only) and one/two-way coupling with the continuous phase. More...

Inheritance diagram for MomentumParcel< ParcelType >:

[legend]

Collaboration diagram for MomentumParcel< ParcelType >:

[legend]

Classes
class	constantProperties
	Class to hold momentum parcel constant properties. More...

class	trackingData

Public Member Functions
	AddToPropertyList (ParcelType, " moving"+" typeId"+" nParticle"+" d"+" dTarget "+" (Ux Uy Uz)"+" rho"+" age"+" tTurb"+" (UTurbx UTurby UTurbz)")
	String representation of properties. More...

	MomentumParcel (const polyMesh &mesh, const barycentric &coordinates, const label celli, const label tetFacei, const label tetPti, const label facei)
	Construct from mesh, coordinates and topology. More...

	MomentumParcel (const polyMesh &mesh, const vector &position, const label celli, label &nLocateBoundaryHits)
	Construct from a position and a cell, searching for the rest of the. More...

	MomentumParcel (Istream &is, bool readFields=true)
	Construct from Istream. More...

	MomentumParcel (const MomentumParcel &p)
	Construct as a copy. More...

virtual autoPtr< particle >	clone () const
	Construct and return a clone. More...

bool	moving () const
	Return const access to moving flag. More...

label	typeId () const
	Return const access to type id. More...

scalar	nParticle () const
	Return const access to number of particles. More...

scalar	d () const
	Return const access to diameter. More...

scalar	dTarget () const
	Return const access to target diameter. More...

const vector &	U () const
	Return const access to velocity. More...

scalar	rho () const
	Return const access to density. More...

scalar	age () const
	Return const access to the age. More...

scalar	tTurb () const
	Return const access to time spent in turbulent eddy. More...

const vector &	UTurb () const
	Return const access to turbulent velocity fluctuation. More...

bool &	moving ()
	Return const access to moving flag. More...

label &	typeId ()
	Return access to type id. More...

scalar &	nParticle ()
	Return access to number of particles. More...

scalar &	d ()
	Return access to diameter. More...

scalar &	dTarget ()
	Return access to target diameter. More...

vector &	U ()
	Return access to velocity. More...

scalar &	rho ()
	Return access to density. More...

scalar &	age ()
	Return access to the age. More...

scalar &	tTurb ()
	Return access to time spent in turbulent eddy. More...

vector &	UTurb ()
	Return access to turbulent velocity fluctuation. More...

scalar	massCell (const trackingData &td) const
	Cell owner mass. More...

scalar	mass () const
	Particle mass. More...

scalar	momentOfInertia () const
	Particle moment of inertia around diameter axis. More...

scalar	volume () const
	Particle volume. More...

scalar	areaP () const
	Particle projected area. More...

scalar	areaS () const
	Particle surface area. More...

scalar	Re (const trackingData &td) const
	Reynolds number. More...

scalar	We (const trackingData &td, const scalar sigma) const
	Weber number. More...

scalar	Eo (const trackingData &td, const scalar sigma) const
	Eotvos number. More...

template<class TrackCloudType >
bool	move (TrackCloudType &cloud, trackingData &td)
	Move the parcel. More...

virtual void	transformProperties (const transformer &)
	Transform the physical properties of the particle. More...

template<class TrackCloudType >
void	correctAfterParallelTransfer (TrackCloudType &, trackingData &)
	Make changes following a parallel transfer. More...

template<class TrackCloudType >
bool	hitPatch (TrackCloudType &cloud, trackingData &td)
	Overridable function to handle the particle hitting a patch. More...

template<class TrackCloudType >
void	hitWedgePatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a wedgePatch. More...

template<class TrackCloudType >
void	hitSymmetryPlanePatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a. More...

template<class TrackCloudType >
void	hitSymmetryPatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a. More...

template<class TrackCloudType >
void	hitCyclicPatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a. More...

template<class TrackCloudType >
bool	hitNonConformalCyclicPatch (const vector &displacement, const scalar fraction, const label patchi, TrackCloudType &cloud, trackingData &td)
	Overridable function to handle the particle hitting an. More...

template<class TrackCloudType >
void	hitWallPatch (TrackCloudType &cloud, trackingData &td)
	Overridable function to handle the particle hitting a wallPatch. More...

template<class TrackCloudType >
void	hitBasicPatch (TrackCloudType &cloud, trackingData &td)
	Overridable function to handle the particle hitting a basic. More...

template<class TrackCloudType >
const Foam::vector	calcVelocity (TrackCloudType &cloud, trackingData &td, const scalar dt, const scalar Re, const scalar mu, const scalar mass, const vector &Su, vector &dUTrans, scalar &Spu) const

template<class CloudType >
void	readFields (CloudType &c)

template<class CloudType >
void	writeFields (const CloudType &c)

Static Public Member Functions
static autoPtr< MomentumParcel >	New (Istream &is)
	Construct from Istream and return. More...

static scalar	volume (const scalar d)
	Particle volume for a given diameter. More...

static scalar	areaP (const scalar d)
	Projected area for given diameter. More...

static scalar	areaS (const scalar d)
	Surface area for given diameter. More...

static scalar	Re (const scalar rhoc, const vector &U, const vector &Uc, const scalar d, const scalar muc)
	Reynolds number for given conditions. More...

static scalar	We (const scalar rhoc, const vector &U, const vector &Uc, const scalar d, const scalar sigma)
	Weber number for given conditions. More...

static scalar	Eo (const vector &g, const scalar rho, const scalar rhoc, const vector &U, const scalar d, const scalar sigma)
	Eotvos number for given conditions. More...

template<class TrackCloudType >
static void	readFields (TrackCloudType &c)
	Read. More...

template<class TrackCloudType >
static void	writeFields (const TrackCloudType &c)
	Write. More...

Protected Member Functions
template<class TrackCloudType >
void	setCellValues (TrackCloudType &cloud, trackingData &td)
	Set cell values. More...

template<class TrackCloudType >
void	calcDispersion (TrackCloudType &cloud, trackingData &td, const scalar dt)
	Apply dispersion to the carrier phase velocity and update. More...

template<class TrackCloudType >
void	cellValueSourceCorrection (TrackCloudType &cloud, trackingData &td, const scalar dt)
	Correct cell values using latest transfer information. More...

template<class TrackCloudType >
void	calc (TrackCloudType &cloud, trackingData &td, const scalar dt)
	Update parcel properties over the time interval. More...

template<class TrackCloudType >
const vector	calcVelocity (TrackCloudType &cloud, trackingData &td, const scalar dt, const scalar Re, const scalar mu, const scalar mass, const vector &Su, vector &dUTrans, scalar &Spu) const
	Calculate new particle velocity. More...

Protected Attributes
bool	moving_
	Moving flag - tracking stopped when moving = false. More...

label	typeId_
	Parcel type id. More...

scalar	nParticle_
	Number of particles in Parcel. More...

scalar	d_
	Diameter [m]. More...

scalar	dTarget_
	Target diameter [m]. More...

vector	U_
	Velocity of Parcel [m/s]. More...

scalar	rho_
	Density [kg/m^3]. More...

scalar	age_
	Age [s]. More...

scalar	tTurb_
	Time spent in turbulent eddy [s]. More...

vector	UTurb_
	Turbulent velocity fluctuation [m/s]. More...

Friends
Ostream &	operator (Ostream &, const MomentumParcel< ParcelType > &)

Detailed Description

template<class ParcelType>
class Foam::MomentumParcel< ParcelType >

Momentum parcel class with rotational motion (as spherical particles only) and one/two-way coupling with the continuous phase.

Sub-models include:

drag
turbulent dispersion
wall interactions

Source files

Definition at line 79 of file MomentumParcel.H.

Constructor & Destructor Documentation

◆ MomentumParcel() [1/4]

MomentumParcel	(	const polyMesh &	mesh,
		const barycentric &	coordinates,
		const label	celli,
		const label	tetFacei,
		const label	tetPti,
		const label	facei
	)

inline

Construct from mesh, coordinates and topology.

Other properties initialised as null

Definition at line 74 of file MomentumParcelI.H.

Referenced by MomentumParcel< ParcelType >::clone(), and MomentumParcel< ParcelType >::New().

Here is the caller graph for this function:

◆ MomentumParcel() [2/4]

MomentumParcel	(	const polyMesh &	mesh,
		const vector &	position,
		const label	celli,
		label &	nLocateBoundaryHits
	)

inline

Construct from a position and a cell, searching for the rest of the.

required topology. Other properties are initialised as null.

Definition at line 99 of file MomentumParcelI.H.

◆ MomentumParcel() [3/4]

MomentumParcel	(	Istream &	is,
		bool	readFields = `true`
	)

Construct from Istream.

Definition at line 48 of file MomentumParcelIO.C.

Here is the call graph for this function:

◆ MomentumParcel() [4/4]

MomentumParcel ( const MomentumParcel< ParcelType > & p )

Construct as a copy.

Member Function Documentation

◆ setCellValues()

void setCellValues	(	TrackCloudType &	cloud,
		trackingData &	td
	)

protected

Set cell values.

Definition at line 41 of file MomentumParcel.C.

References Foam::tracking::coordinates(), Foam::endl(), MomentumParcel< ParcelType >::trackingData::muc(), MomentumParcel< ParcelType >::trackingData::muInterp(), Foam::nl, MomentumParcel< ParcelType >::trackingData::rhoc(), MomentumParcel< ParcelType >::trackingData::rhoInterp(), MomentumParcel< ParcelType >::trackingData::Uc(), MomentumParcel< ParcelType >::trackingData::UInterp(), and WarningInFunction.

Here is the call graph for this function:

◆ calcDispersion()

void calcDispersion	(	TrackCloudType &	cloud,
		trackingData &	td,
		const scalar	dt
	)

protected

Apply dispersion to the carrier phase velocity and update.

parcel turbulence parameters

Definition at line 71 of file MomentumParcel.C.

References MomentumParcel< ParcelType >::trackingData::Uc().

Here is the call graph for this function:

◆ cellValueSourceCorrection()

void cellValueSourceCorrection	(	TrackCloudType &	cloud,
		trackingData &	td,
		const scalar	dt
	)

protected

Correct cell values using latest transfer information.

Definition at line 92 of file MomentumParcel.C.

References MomentumParcel< ParcelType >::trackingData::Uc().

Here is the call graph for this function:

◆ calc()

void calc	(	TrackCloudType &	cloud,
		trackingData &	td,
		const scalar	dt
	)

protected

Update parcel properties over the time interval.

Definition at line 105 of file MomentumParcel.C.

References MomentumParcel< ParcelType >::trackingData::muc(), Foam::Re(), Foam::fvc::Su(), and Foam::Zero.

Here is the call graph for this function:

◆ calcVelocity() [1/2]

const vector calcVelocity	(	TrackCloudType &	cloud,
		trackingData &	td,
		const scalar	dt,
		const scalar	Re,
		const scalar	mu,
		const scalar	mass,
		const vector &	Su,
		vector &	dUTrans,
		scalar &	Spu
	)		const

protected

Calculate new particle velocity.

◆ AddToPropertyList()

AddToPropertyList	(	ParcelType	,
		" moving"+" typeId"+" nParticle"+" d"+" dTarget "+" (Ux Uy Uz)"+" rho"+" age"+" tTurb"+" (UTurbx UTurby UTurbz)"
	)

String representation of properties.

◆ clone()

virtual autoPtr<particle> clone ( ) const

inlinevirtual

Construct and return a clone.

Definition at line 400 of file MomentumParcel.H.

References MomentumParcel< ParcelType >::MomentumParcel().

Here is the call graph for this function:

◆ New()

static autoPtr<MomentumParcel> New ( Istream & is )

inlinestatic

Construct from Istream and return.

Definition at line 406 of file MomentumParcel.H.

References MomentumParcel< ParcelType >::MomentumParcel().

Here is the call graph for this function:

◆ moving() [1/2]

bool moving

inline

Return const access to moving flag.

Definition at line 166 of file MomentumParcelI.H.

◆ typeId() [1/2]

Foam::label typeId

inline

Return const access to type id.

Definition at line 173 of file MomentumParcelI.H.

◆ nParticle() [1/2]

Foam::scalar nParticle

inline

Return const access to number of particles.

Definition at line 180 of file MomentumParcelI.H.

◆ d() [1/2]

Foam::scalar d

inline

Return const access to diameter.

Definition at line 187 of file MomentumParcelI.H.

◆ dTarget() [1/2]

Foam::scalar dTarget

inline

Return const access to target diameter.

Definition at line 194 of file MomentumParcelI.H.

◆ U() [1/2]

const Foam::vector & U

inline

Return const access to velocity.

Definition at line 201 of file MomentumParcelI.H.

◆ rho() [1/2]

Foam::scalar rho

inline

Return const access to density.

Definition at line 208 of file MomentumParcelI.H.

◆ age() [1/2]

Foam::scalar age

inline

Return const access to the age.

Definition at line 215 of file MomentumParcelI.H.

◆ tTurb() [1/2]

Foam::scalar tTurb

inline

Return const access to time spent in turbulent eddy.

Definition at line 222 of file MomentumParcelI.H.

◆ UTurb() [1/2]

const Foam::vector & UTurb

inline

Return const access to turbulent velocity fluctuation.

Definition at line 229 of file MomentumParcelI.H.

◆ moving() [2/2]

bool & moving

inline

Return const access to moving flag.

Definition at line 236 of file MomentumParcelI.H.

◆ typeId() [2/2]

Foam::label & typeId

inline

Return access to type id.

Definition at line 243 of file MomentumParcelI.H.

◆ nParticle() [2/2]

Foam::scalar & nParticle

inline

Return access to number of particles.

Definition at line 250 of file MomentumParcelI.H.

◆ d() [2/2]

Foam::scalar & d

inline

Return access to diameter.

Definition at line 257 of file MomentumParcelI.H.

◆ dTarget() [2/2]

Foam::scalar & dTarget

inline

Return access to target diameter.

Definition at line 264 of file MomentumParcelI.H.

◆ U() [2/2]

Foam::vector & U

inline

Return access to velocity.

Definition at line 271 of file MomentumParcelI.H.

◆ rho() [2/2]

Foam::scalar & rho

inline

Return access to density.

Definition at line 278 of file MomentumParcelI.H.

◆ age() [2/2]

Foam::scalar & age

inline

Return access to the age.

Definition at line 285 of file MomentumParcelI.H.

◆ tTurb() [2/2]

Foam::scalar & tTurb

inline

Return access to time spent in turbulent eddy.

Definition at line 292 of file MomentumParcelI.H.

◆ UTurb() [2/2]

Foam::vector & UTurb

inline

Return access to turbulent velocity fluctuation.

Definition at line 299 of file MomentumParcelI.H.

◆ massCell()

Foam::scalar massCell ( const trackingData & td ) const

inline

Cell owner mass.

Definition at line 306 of file MomentumParcelI.H.

References MomentumParcel< ParcelType >::trackingData::rhoc().

Here is the call graph for this function:

◆ mass()

Foam::scalar mass

inline

Particle mass.

Definition at line 316 of file MomentumParcelI.H.

◆ momentOfInertia()

Foam::scalar momentOfInertia

inline

Particle moment of inertia around diameter axis.

Definition at line 323 of file MomentumParcelI.H.

References Foam::sqr().

Here is the call graph for this function:

◆ volume() [1/2]

Foam::scalar volume

inline

Particle volume.

Definition at line 330 of file MomentumParcelI.H.

◆ volume() [2/2]

Foam::scalar volume ( const scalar d )

inlinestatic

Particle volume for a given diameter.

Definition at line 337 of file MomentumParcelI.H.

References Foam::constant::mathematical::pi(), and Foam::pow3().

Here is the call graph for this function:

◆ areaP() [1/2]

Foam::scalar areaP

inline

Particle projected area.

Definition at line 344 of file MomentumParcelI.H.

◆ areaP() [2/2]

Foam::scalar areaP ( const scalar d )

inlinestatic

Projected area for given diameter.

Definition at line 351 of file MomentumParcelI.H.

◆ areaS() [1/2]

Foam::scalar areaS

inline

Particle surface area.

Definition at line 358 of file MomentumParcelI.H.

◆ areaS() [2/2]

Foam::scalar areaS ( const scalar d )

inlinestatic

Surface area for given diameter.

Definition at line 365 of file MomentumParcelI.H.

References Foam::constant::mathematical::pi().

Here is the call graph for this function:

◆ Re() [1/2]

Foam::scalar Re ( const trackingData & td ) const

inline

Reynolds number.

Definition at line 372 of file MomentumParcelI.H.

References MomentumParcel< ParcelType >::trackingData::muc(), Foam::Re(), MomentumParcel< ParcelType >::trackingData::rhoc(), and MomentumParcel< ParcelType >::trackingData::Uc().

Here is the call graph for this function:

◆ Re() [2/2]

Foam::scalar Re	(	const scalar	rhoc,
		const vector &	U,
		const vector &	Uc,
		const scalar	d,
		const scalar	muc
	)

inlinestatic

Reynolds number for given conditions.

Definition at line 382 of file MomentumParcelI.H.

References Foam::mag(), Foam::max(), and U.

Here is the call graph for this function:

◆ We() [1/2]

Foam::scalar We	(	const trackingData &	td,
		const scalar	sigma
	)		const

inline

Weber number.

Definition at line 396 of file MomentumParcelI.H.

References MomentumParcel< ParcelType >::trackingData::rhoc(), Foam::constant::physicoChemical::sigma, and MomentumParcel< ParcelType >::trackingData::Uc().

Here is the call graph for this function:

◆ We() [2/2]

Foam::scalar We	(	const scalar	rhoc,
		const vector &	U,
		const vector &	Uc,
		const scalar	d,
		const scalar	sigma
	)

inlinestatic

Weber number for given conditions.

Definition at line 407 of file MomentumParcelI.H.

References Foam::magSqr(), Foam::max(), Foam::constant::physicoChemical::sigma, and U.

Here is the call graph for this function:

◆ Eo() [1/2]

Foam::scalar Eo	(	const trackingData &	td,
		const scalar	sigma
	)		const

inline

Eotvos number.

Definition at line 421 of file MomentumParcelI.H.

References MomentumParcel< ParcelType >::trackingData::g(), MomentumParcel< ParcelType >::trackingData::rhoc(), and Foam::constant::physicoChemical::sigma.

Here is the call graph for this function:

◆ Eo() [2/2]

Foam::scalar Eo	(	const vector &	g,
		const scalar	rho,
		const scalar	rhoc,
		const vector &	U,
		const scalar	d,
		const scalar	sigma
	)

inlinestatic

Eotvos number for given conditions.

Definition at line 432 of file MomentumParcelI.H.

References Foam::mag(), Foam::max(), rho, Foam::constant::physicoChemical::sigma, Foam::sqr(), and U.

Here is the call graph for this function:

◆ move()

bool move	(	TrackCloudType &	cloud,
		trackingData &	td
	)

Move the parcel.

Definition at line 257 of file MomentumParcel.C.

References f(), Foam::mag(), Foam::max(), maxCo, Foam::min(), p, and s().

Here is the call graph for this function:

◆ transformProperties()

void transformProperties ( const transformer & transform )

virtual

Transform the physical properties of the particle.

according to the given transformation

Definition at line 355 of file MomentumParcel.C.

References Foam::transform(), and dimensionSet::transform.

Here is the call graph for this function:

◆ correctAfterParallelTransfer()

void correctAfterParallelTransfer	(	TrackCloudType &	cloud,
		trackingData &	td
	)

Make changes following a parallel transfer.

Definition at line 368 of file MomentumParcel.C.

References p.

◆ hitPatch()

bool hitPatch	(	TrackCloudType &	cloud,
		trackingData &	td
	)

Overridable function to handle the particle hitting a patch.

Executed before other patch-hitting functions

Definition at line 387 of file MomentumParcel.C.

References p.

◆ hitWedgePatch()

void hitWedgePatch	(	TrackCloudType &	cloud,
		trackingData &	td
	)

Overridable function to handle the particle hitting a wedgePatch.

Definition at line 418 of file MomentumParcel.C.

References p.

◆ hitSymmetryPlanePatch()

void hitSymmetryPlanePatch	(	TrackCloudType &	cloud,
		trackingData &	td
	)

Overridable function to handle the particle hitting a.

symmetryPlanePatch

Definition at line 437 of file MomentumParcel.C.

References p.

◆ hitSymmetryPatch()

void hitSymmetryPatch	(	TrackCloudType &	cloud,
		trackingData &	td
	)

Overridable function to handle the particle hitting a.

symmetryPatch

Definition at line 456 of file MomentumParcel.C.

References p.

◆ hitCyclicPatch()

void hitCyclicPatch	(	TrackCloudType &	cloud,
		trackingData &	td
	)

Overridable function to handle the particle hitting a.

cyclicPatch

Definition at line 475 of file MomentumParcel.C.

References p.

◆ hitNonConformalCyclicPatch()

bool hitNonConformalCyclicPatch	(	const vector &	displacement,
		const scalar	fraction,
		const label	patchi,
		TrackCloudType &	cloud,
		trackingData &	td
	)

Overridable function to handle the particle hitting an.

nonConformalCyclicPolyPatch

Definition at line 494 of file MomentumParcel.C.

References p, and patchi.

◆ hitWallPatch()

void hitWallPatch	(	TrackCloudType &	cloud,
		trackingData &	td
	)

Overridable function to handle the particle hitting a wallPatch.

Definition at line 529 of file MomentumParcel.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, patchIdentifier::name(), and Foam::tracking::position().

Here is the call graph for this function:

◆ hitBasicPatch()

void hitBasicPatch	(	TrackCloudType &	cloud,
		trackingData &	td
	)

Overridable function to handle the particle hitting a basic.

patch. Fall-through for the above.

Definition at line 547 of file MomentumParcel.C.

References p.

◆ readFields() [1/2]

static void readFields ( TrackCloudType & c )

static

Read.

Referenced by MomentumParcel< ParcelType >::MomentumParcel().

Here is the caller graph for this function:

◆ writeFields() [1/2]

static void writeFields ( const TrackCloudType & c )

static

Write.

◆ calcVelocity() [2/2]

const Foam::vector calcVelocity	(	TrackCloudType &	cloud,
		trackingData &	td,
		const scalar	dt,
		const scalar	Re,
		const scalar	mu,
		const scalar	mass,
		const vector &	Su,
		vector &	dUTrans,
		scalar &	Spu
	)		const

Definition at line 157 of file MomentumParcel.C.

References Foam::meshTools::constrainDirection(), mesh, Foam::constant::physicoChemical::mu, p, Foam::Re(), polyMesh::solutionD(), forceSuSp::Sp(), forceSuSp::Su(), Foam::fvc::Su(), and MomentumParcel< ParcelType >::trackingData::Uc().

Here is the call graph for this function:

◆ readFields() [2/2]

void readFields ( CloudType & c )

Definition at line 94 of file MomentumParcelIO.C.

References Foam::constant::universal::c, forAllIter, IOobject::MUST_READ, p, Foam::readFields(), rho, U, and Foam::vtkWriteOps::write().

Here is the call graph for this function:

◆ writeFields() [2/2]

void writeFields ( const CloudType & c )

Definition at line 194 of file MomentumParcelIO.C.

References Foam::constant::universal::c, forAllConstIter, IOobject::NO_READ, p, rho, U, regIOobject::write(), and Foam::vtkWriteOps::write().

Here is the call graph for this function:

Friends And Related Function Documentation

◆ operator

Ostream& operator	(	Ostream &	,
		const MomentumParcel< ParcelType > &
	)

friend

Member Data Documentation

◆ moving_

bool moving_

protected

Moving flag - tracking stopped when moving = false.

Definition at line 268 of file MomentumParcel.H.

Referenced by MomentumParcel< ParcelType >::MomentumParcel().

◆ typeId_

label typeId_

protected

Parcel type id.

Definition at line 271 of file MomentumParcel.H.

Referenced by MomentumParcel< ParcelType >::MomentumParcel().

◆ nParticle_

scalar nParticle_

protected

Number of particles in Parcel.

Definition at line 274 of file MomentumParcel.H.

Referenced by MomentumParcel< ParcelType >::MomentumParcel().

◆ d_

scalar d_

protected

Diameter [m].

Definition at line 277 of file MomentumParcel.H.

Referenced by MomentumParcel< ParcelType >::MomentumParcel().

◆ dTarget_

scalar dTarget_

protected

Target diameter [m].

Definition at line 280 of file MomentumParcel.H.

Referenced by MomentumParcel< ParcelType >::MomentumParcel().

◆ U_

vector U_

protected

Velocity of Parcel [m/s].

Definition at line 283 of file MomentumParcel.H.

Referenced by MomentumParcel< ParcelType >::MomentumParcel().

◆ rho_

scalar rho_

protected

Density [kg/m^3].

Definition at line 286 of file MomentumParcel.H.

Referenced by MomentumParcel< ParcelType >::MomentumParcel().

◆ age_

scalar age_

protected

Age [s].

Definition at line 289 of file MomentumParcel.H.

Referenced by MomentumParcel< ParcelType >::MomentumParcel().

◆ tTurb_

scalar tTurb_

protected

Time spent in turbulent eddy [s].

Definition at line 292 of file MomentumParcel.H.

Referenced by MomentumParcel< ParcelType >::MomentumParcel().

◆ UTurb_

vector UTurb_

protected

Turbulent velocity fluctuation [m/s].

Definition at line 295 of file MomentumParcel.H.

Referenced by MomentumParcel< ParcelType >::MomentumParcel().

The documentation for this class was generated from the following files:

src/lagrangian/parcel/parcels/Templates/MomentumParcel/MomentumParcel.H
src/lagrangian/parcel/parcels/Templates/MomentumParcel/MomentumParcel.C
src/lagrangian/parcel/parcels/Templates/MomentumParcel/MomentumParcelI.H
src/lagrangian/parcel/parcels/Templates/MomentumParcel/MomentumParcelIO.C

Classes

Public Member Functions

Static Public Member Functions

Protected Member Functions

Protected Attributes

Friends

Detailed Description

template<class ParcelType> class Foam::MomentumParcel< ParcelType >

Constructor & Destructor Documentation

◆ MomentumParcel() [1/4]

◆ MomentumParcel() [2/4]

◆ MomentumParcel() [3/4]

◆ MomentumParcel() [4/4]

Member Function Documentation

◆ setCellValues()

◆ calcDispersion()

◆ cellValueSourceCorrection()

◆ calc()

◆ calcVelocity() [1/2]

◆ AddToPropertyList()

◆ clone()

◆ New()

◆ moving() [1/2]

◆ typeId() [1/2]

◆ nParticle() [1/2]

◆ d() [1/2]

◆ dTarget() [1/2]

◆ U() [1/2]

◆ rho() [1/2]

◆ age() [1/2]

◆ tTurb() [1/2]

◆ UTurb() [1/2]

◆ moving() [2/2]

◆ typeId() [2/2]

◆ nParticle() [2/2]

◆ d() [2/2]

◆ dTarget() [2/2]

◆ U() [2/2]

◆ rho() [2/2]

◆ age() [2/2]

◆ tTurb() [2/2]

◆ UTurb() [2/2]

◆ massCell()

◆ mass()

◆ momentOfInertia()

◆ volume() [1/2]

◆ volume() [2/2]

◆ areaP() [1/2]

◆ areaP() [2/2]

◆ areaS() [1/2]

◆ areaS() [2/2]

◆ Re() [1/2]

◆ Re() [2/2]

◆ We() [1/2]

◆ We() [2/2]

◆ Eo() [1/2]

◆ Eo() [2/2]

◆ move()

◆ transformProperties()

◆ correctAfterParallelTransfer()

◆ hitPatch()

◆ hitWedgePatch()

◆ hitSymmetryPlanePatch()

◆ hitSymmetryPatch()

◆ hitCyclicPatch()

◆ hitNonConformalCyclicPatch()

◆ hitWallPatch()

◆ hitBasicPatch()

◆ readFields() [1/2]

◆ writeFields() [1/2]

◆ calcVelocity() [2/2]

◆ readFields() [2/2]

◆ writeFields() [2/2]

Friends And Related Function Documentation

◆ operator

Member Data Documentation

◆ moving_

◆ typeId_

◆ nParticle_

◆ d_

template<class ParcelType>
class Foam::MomentumParcel< ParcelType >
