Helper class which maintains intersections of (changing) mesh with (static) surfaces. More...

Collaboration diagram for meshRefinement:

[legend]

Public Types
enum	IOdebugType { IOMESH , IOOBJINTERSECTIONS , IOFEATURESEEDS , IOATTRACTION , IOLAYERINFO }
	Enumeration for what to debug. More...

enum	debugType { MESH = 1<<IOMESH , OBJINTERSECTIONS = 1<<IOOBJINTERSECTIONS , FEATURESEEDS = 1<<IOFEATURESEEDS , ATTRACTION = 1<< IOATTRACTION , LAYERINFO = 1<<IOLAYERINFO }

enum	IOoutputType { IOOUTPUTLAYERINFO }
	Enumeration for what to output. More...

enum	outputType { OUTPUTLAYERINFO = 1<<IOOUTPUTLAYERINFO }

enum	IOwriteType { IOWRITEMESH , IONOWRITEREFINEMENT , IOWRITELEVELS , IOWRITELAYERSETS , IOWRITELAYERFIELDS }
	Enumeration for what to write. More...

enum	writeType { WRITEMESH = 1<<IOWRITEMESH , NOWRITEREFINEMENT = 1<<IONOWRITEREFINEMENT , WRITELEVELS = 1<<IOWRITELEVELS , WRITELAYERSETS = 1<<IOWRITELAYERSETS , WRITELAYERFIELDS = 1<<IOWRITELAYERFIELDS }

enum	mapType { MASTERONLY = 1 , KEEPALL = 2 , REMOVE = 4 }
	Enumeration for how the userdata is to be mapped upon refinement. More...

Public Member Functions
	ClassName ("meshRefinement")
	Runtime type information. More...

	meshRefinement (fvMesh &mesh, const dictionary &refineDict, const scalar mergeDistance, const bool overwrite, refinementSurfaces &, const refinementFeatures &, const refinementRegions &)
	Construct from components. More...

	meshRefinement (const meshRefinement &)=delete
	Disallow default bitwise copy construction. More...

const fvMesh &	mesh () const
	Reference to mesh. More...

fvMesh &	mesh ()

scalar	mergeDistance () const

bool	overwrite () const
	Overwrite the mesh? More...

const word &	oldInstance () const
	(points)instance of mesh upon construction More...

const refinementSurfaces &	surfaces () const
	Reference to surface search engines. More...

const refinementFeatures &	features () const
	Reference to feature edge mesh. More...

const refinementRegions &	shells () const
	Reference to refinement shells (regions) More...

const hexRef8 &	meshCutter () const
	Reference to meshcutting engine. More...

const labelList &	surfaceIndex () const
	Per start-end edge the index of the surface hit. More...

labelList &	surfaceIndex ()

const List< Tuple2< mapType, labelList > > &	userFaceData () const
	Additional face data that is maintained across. More...

List< Tuple2< mapType, labelList > > &	userFaceData ()

label	countHits () const
	Count number of intersections (local) More...

autoPtr< polyDistributionMap >	balance (const bool keepZoneFaces, const bool keepBaffles, const scalarField &cellWeights, decompositionMethod &decomposer, fvMeshDistribute &distributor)
	Redecompose according to cell count. More...

labelList	intersectedFaces () const
	Get faces with intersection. More...

labelList	intersectedPoints () const
	Get points on surfaces with intersection and boundary faces. More...

bool	isGap (const scalar, const vector &, const vector &, const vector &, const vector &) const
	Is local topology a small gap? More...

bool	isNormalGap (const scalar, const vector &, const vector &, const vector &, const vector &) const
	Is local topology a small gap normal to the test vector. More...

labelList	refineCandidates (const List< point > &insidePoints, const scalar curvature, const scalar planarAngle, const bool featureRefinement, const bool featureDistanceRefinement, const bool internalRefinement, const bool surfaceRefinement, const bool curvatureRefinement, const bool gapRefinement, const label maxGlobalCells, const label maxLocalCells) const
	Calculate list of cells to refine. More...

autoPtr< polyTopoChangeMap >	refine (const labelList &cellsToRefine)
	Refine some cells. More...

autoPtr< polyDistributionMap >	refineAndBalance (const string &msg, decompositionMethod &decomposer, fvMeshDistribute &distributor, const labelList &cellsToRefine, const scalar maxLoadUnbalance)
	Refine some cells and rebalance. More...

autoPtr< polyDistributionMap >	balanceAndRefine (const string &msg, decompositionMethod &decomposer, fvMeshDistribute &distributor, const labelList &cellsToRefine, const scalar maxLoadUnbalance)
	Balance before refining some cells. More...

void	baffleAndSplitMesh (const bool handleSnapProblems, const snapParameters &snapParams, const bool useTopologicalSnapDetection, const bool removeEdgeConnectedCells, const scalarField &perpendicularAngle, const bool mergeFreeStanding, const scalar freeStandingAngle, const dictionary &motionDict, Time &runTime, const labelList &globalToMasterPatch, const labelList &globalToSlavePatch, const refinementParameters::cellSelectionPoints &selectionPoints)
	Split off unreachable areas of mesh. More...

autoPtr< polyTopoChangeMap >	splitMesh (const label nBufferLayers, const labelList &globalToMasterPatch, const labelList &globalToSlavePatch, const refinementParameters::cellSelectionPoints &selectionPoints)
	Split off (with optional buffer layers) unreachable areas. More...

autoPtr< polyTopoChangeMap >	dupNonManifoldPoints (const localPointRegion &)
	Find boundary points that connect to more than one cell. More...

autoPtr< polyTopoChangeMap >	dupNonManifoldPoints ()
	Find boundary points that connect to more than one cell. More...

autoPtr< polyTopoChangeMap >	createBaffles (const labelList &ownPatch, const labelList &nbrPatch)
	Create baffle for every internal face where ownPatch != -1. More...

void	checkZoneFaces () const
	Debug helper: check faceZones are not on processor patches. More...

autoPtr< polyTopoChangeMap >	createZoneBaffles (const labelList &globalToMasterPatch, const labelList &globalToSlavePatch, List< labelPair > &)
	Create baffles for faces straddling zoned surfaces. Return. More...

autoPtr< polyTopoChangeMap >	mergeBaffles (const List< labelPair > &)
	Merge baffles. Gets pairs of faces. More...

autoPtr< polyTopoChangeMap >	zonify (const List< point > &insidePoints, const bool allowFreeStandingZoneFaces)
	Put faces/cells into zones according to surface specification. More...

label	addMeshedPatch (const word &name, const dictionary &)
	Add patch originating from meshing. Update meshedPatches_. More...

labelList	meshedPatches () const
	Get patchIDs for patches added in addMeshedPatch. More...

void	selectSeparatedCoupledFaces (boolList &) const
	Select coupled faces that are not collocated. More...

autoPtr< polyTopoChangeMap >	splitMeshRegions (const labelList &globalToMasterPatch, const labelList &globalToSlavePatch, const refinementParameters::cellSelectionPoints &selectionPoints)
	Split mesh according to selectionPoints. More...

autoPtr< polyTopoChangeMap >	splitFaces (const labelList &splitFaces, const labelPairList &splits)
	Split faces into two. More...

void	distribute (const polyDistributionMap &)
	Update local numbering for mesh redistribution. More...

void	topoChange (const polyTopoChangeMap &, const labelList &changedFaces)
	Update for external change to mesh. changedFaces are in new mesh. More...

void	storeData (const labelList &pointsToStore, const labelList &facesToStore, const labelList &cellsToStore)
	Signal points/face/cells for which to store data. More...

void	topoChange (const polyTopoChangeMap &, const labelList &changedFaces, const Map< label > &pointsToRestore, const Map< label > &facesToRestore, const Map< label > &cellsToRestore)
	Update local numbering + undo. More...

label	mergePatchFacesUndo (const scalar minCos, const scalar concaveCos, const labelHashSet &patchIDs, const dictionary &motionDict, const labelList &preserveFaces)
	Merge coplanar faces. preserveFaces is != -1 for faces. More...

autoPtr< polyTopoChangeMap >	doRemovePoints (removePoints &pointRemover, const boolList &pointCanBeDeleted)

autoPtr< polyTopoChangeMap >	doRestorePoints (removePoints &pointRemover, const labelList &facesToRestore)

labelList	collectFaces (const labelList &candidateFaces, const labelHashSet &set) const

labelList	growFaceCellFace (const labelHashSet &set) const

label	mergeEdgesUndo (const scalar minCos, const dictionary &motionDict)
	Merge edges, maintain mesh quality. Return global number. More...

void	checkData ()
	Debugging: check that all faces still obey start()>end() More...

template<class T >
void	testSyncBoundaryFaceList (const scalar mergeDistance, const string &, const UList< T > &, const UList< T > &) const
	Compare two lists over all boundary faces. More...

void	printMeshInfo (const bool, const string &) const
	Print some mesh stats. More...

word	name () const
	Replacement for Time::name() : return oldInstance (if. More...

void	setInstance (const fileName &)
	Set instance of all local IOobjects. More...

bool	write () const
	Write mesh and all data. More...

void	dumpRefinementLevel () const
	Write refinement level as volScalarFields for postprocessing. More...

void	dumpIntersections (const fileName &prefix) const
	Debug: Write intersection information to OBJ format. More...

void	write (const debugType debugFlags, const writeType writeFlags, const fileName &) const
	Do any one of above IO functions. More...

void	operator= (const meshRefinement &)=delete
	Disallow default bitwise assignment. More...

Static Public Member Functions
static autoPtr< indirectPrimitivePatch >	makePatch (const polyMesh &, const labelList &)
	Create patch from set of patches. More...

static tmp< pointVectorField >	makeDisplacementField (const pointMesh &pMesh, const labelList &adaptPatchIDs)
	Helper function to make a pointVectorField with correct. More...

static void	checkCoupledFaceZones (const polyMesh &)
	Helper function: check that face zones are synced. More...

static void	calculateEdgeWeights (const polyMesh &mesh, const PackedBoolList &isMasterEdge, const labelList &meshPoints, const edgeList &edges, scalarField &edgeWeights, scalarField &invSumWeight)
	Helper: calculate edge weights (1/length) More...

template<class Type >
static void	weightedSum (const polyMesh &mesh, const PackedBoolList &isMasterEdge, const labelList &meshPoints, const edgeList &edges, const scalarField &edgeWeights, const Field< Type > &data, Field< Type > &sum)
	Helper: weighted sum (over all subset of mesh points) by. More...

static label	findRegion (const polyMesh &, const labelList &cellRegion, const vector &perturbVec, const point &location)
	Find region point is in. Uses optional perturbation to re-test. More...

static void	findRegions (const polyMesh &, labelList &cellRegion, const vector &perturbVec, const refinementParameters::cellSelectionPoints &selectionPoints)
	Find regions points are in and update cellRegion. More...

template<class T >
static void	updateList (const labelList &newToOld, const T &nullValue, List< T > &elems)
	Helper: reorder list according to map. More...

static void	testSyncPointList (const string &msg, const polyMesh &mesh, const List< scalar > &fld)

static void	testSyncPointList (const string &msg, const polyMesh &mesh, const List< point > &fld)

template<class T >
static void	collectAndPrint (const UList< point > &points, const UList< T > &data)
	Print list according to (collected and) sorted coordinate. More...

static PackedBoolList	getMasterPoints (const polyMesh &mesh, const labelList &meshPoints)
	Determine master point for subset of points. If coupled. More...

static PackedBoolList	getMasterEdges (const polyMesh &mesh, const labelList &meshEdges)
	Determine master edge for subset of edges. If coupled. More...

template<class T >
static T	gAverage (const PackedBoolList &isMasterElem, const UList< T > &values)
	Helper: calculate average. More...

static writeType	writeLevel ()
	Get/set write level. More...

static void	writeLevel (const writeType)

static outputType	outputLevel ()
	Get/set output level. More...

static void	outputLevel (const outputType)

template<class Enum >
static int	readFlags (const Enum &namedEnum, const wordList &)
	Helper: convert wordList into bit pattern using provided. More...

Static Public Attributes
static const NamedEnum< IOdebugType, 5 >	IOdebugTypeNames

static const NamedEnum< IOoutputType, 1 >	IOoutputTypeNames

static const NamedEnum< IOwriteType, 5 >	IOwriteTypeNames

Detailed Description

Helper class which maintains intersections of (changing) mesh with (static) surfaces.

Maintains

per face any intersections of the cc-cc segment with any of the surfaces

Source files

Definition at line 81 of file meshRefinement.H.

Member Enumeration Documentation

◆ IOdebugType

enum IOdebugType

Enumeration for what to debug.

Enumerator
IOMESH
IOOBJINTERSECTIONS
IOFEATURESEEDS
IOATTRACTION
IOLAYERINFO

Definition at line 89 of file meshRefinement.H.

◆ debugType

enum debugType

Enumerator
MESH
OBJINTERSECTIONS
FEATURESEEDS
ATTRACTION
LAYERINFO

Definition at line 99 of file meshRefinement.H.

◆ IOoutputType

enum IOoutputType

Enumeration for what to output.

Enumerator
IOOUTPUTLAYERINFO

Definition at line 109 of file meshRefinement.H.

◆ outputType

enum outputType

Enumerator
OUTPUTLAYERINFO

Definition at line 115 of file meshRefinement.H.

◆ IOwriteType

enum IOwriteType

Enumeration for what to write.

Enumerator
IOWRITEMESH
IONOWRITEREFINEMENT
IOWRITELEVELS
IOWRITELAYERSETS
IOWRITELAYERFIELDS

Definition at line 121 of file meshRefinement.H.

◆ writeType

enum writeType

Enumerator
WRITEMESH
NOWRITEREFINEMENT
WRITELEVELS
WRITELAYERSETS
WRITELAYERFIELDS

Definition at line 131 of file meshRefinement.H.

◆ mapType

enum mapType

Enumeration for how the userdata is to be mapped upon refinement.

Enumerator
MASTERONLY	maintain master only
KEEPALL	have slaves (upon refinement) from master
REMOVE	set value to -1 any face that was refined

Definition at line 141 of file meshRefinement.H.

Constructor & Destructor Documentation

◆ meshRefinement() [1/2]

meshRefinement	(	fvMesh &	mesh,
		const dictionary &	refineDict,
		const scalar	mergeDistance,
		const bool	overwrite,
		refinementSurfaces &	surfaces,
		const refinementFeatures &	features,
		const refinementRegions &	shells
	)

Construct from components.

Definition at line 1122 of file meshRefinement.C.

References Foam::identityMap(), hexRef8::level0EdgeLength(), dictionary::lookupOrDefault(), primitiveMesh::nFaces(), refinementSurfaces::setMinLevelFields(), and meshRefinement::surfaces().

Here is the call graph for this function:

◆ meshRefinement() [2/2]

meshRefinement ( const meshRefinement & )

delete

Disallow default bitwise copy construction.

Member Function Documentation

◆ ClassName()

ClassName ( "meshRefinement" )

Runtime type information.

◆ mesh() [1/2]

const fvMesh& mesh ( ) const

inline

Reference to mesh.

Definition at line 610 of file meshRefinement.H.

Referenced by snappySnapDriver::calcNearestSurface(), and snappySnapDriver::preSmoothPatch().

Here is the caller graph for this function:

◆ mesh() [2/2]

fvMesh& mesh ( )

inline

Definition at line 615 of file meshRefinement.H.

◆ mergeDistance()

scalar mergeDistance ( ) const

inline

Definition at line 620 of file meshRefinement.H.

◆ overwrite()

bool overwrite ( ) const

inline

Overwrite the mesh?

Definition at line 626 of file meshRefinement.H.

◆ oldInstance()

const word& oldInstance ( ) const

inline

(points)instance of mesh upon construction

Definition at line 632 of file meshRefinement.H.

◆ surfaces()

const refinementSurfaces& surfaces ( ) const

inline

Reference to surface search engines.

Definition at line 638 of file meshRefinement.H.

Referenced by snappySnapDriver::calcNearestSurface(), and meshRefinement::meshRefinement().

Here is the caller graph for this function:

◆ features()

const refinementFeatures& features ( ) const

inline

Reference to feature edge mesh.

Definition at line 644 of file meshRefinement.H.

◆ shells()

const refinementRegions& shells ( ) const

inline

Reference to refinement shells (regions)

Definition at line 650 of file meshRefinement.H.

◆ meshCutter()

const hexRef8& meshCutter ( ) const

inline

Reference to meshcutting engine.

Definition at line 656 of file meshRefinement.H.

◆ surfaceIndex() [1/2]

const labelList& surfaceIndex ( ) const

inline

Per start-end edge the index of the surface hit.

Definition at line 662 of file meshRefinement.H.

◆ surfaceIndex() [2/2]

labelList& surfaceIndex ( )

inline

Definition at line 667 of file meshRefinement.H.

◆ userFaceData() [1/2]

const List<Tuple2<mapType, labelList> >& userFaceData ( ) const

inline

Additional face data that is maintained across.

topo changes. Every entry is a list over all faces. Bit of a hack. Additional flag to say whether to maintain master only (false) or increase set to account for face-from-face.

Definition at line 676 of file meshRefinement.H.

◆ userFaceData() [2/2]

List<Tuple2<mapType, labelList> >& userFaceData ( )

inline

Definition at line 681 of file meshRefinement.H.

◆ countHits()

Foam::label countHits ( ) const

Count number of intersections (local)

Definition at line 1175 of file meshRefinement.C.

References forAll, PackedList< nBits >::get(), and syncTools::getMasterFaces().

Here is the call graph for this function:

◆ balance()

Foam::autoPtr< Foam::polyDistributionMap > balance	(	const bool	keepZoneFaces,
		const bool	keepBaffles,
		const scalarField &	cellWeights,
		decompositionMethod &	decomposer,
		fvMeshDistribute &	distributor
	)

Redecompose according to cell count.

keepZoneFaces : find all faceZones from zoned surfaces and keep owner and neighbour together keepBaffles : find all baffles and keep them together

Definition at line 1337 of file meshRefinement.C.

References fvMeshDistribute::countCells(), decompositionMethod::decompose(), fvMeshDistribute::distribute(), Foam::endl(), localPointRegion::findDuplicateFacePairs(), Pair< Type >::first(), forAll, Foam::Info, Pstream::listCombineGather(), Pstream::listCombineScatter(), Foam::name(), UPstream::parRun(), Foam::Pout, Foam::reduce(), Foam::returnReduce(), Pair< Type >::second(), decompositionMethod::setConstraints(), List< T >::setSize(), List< T >::size(), syncTools::syncFaceList(), and polyBoundaryMesh::whichPatch().

Here is the call graph for this function:

◆ intersectedFaces()

Foam::labelList intersectedFaces ( ) const

Get faces with intersection.

Definition at line 1615 of file meshRefinement.C.

References forAll.

◆ intersectedPoints()

Foam::labelList intersectedPoints ( ) const

Get points on surfaces with intersection and boundary faces.

Definition at line 1641 of file meshRefinement.C.

References f(), forAll, PackedList< nBits >::get(), and PackedBoolList::set().

Here is the call graph for this function:

◆ makePatch()

Foam::autoPtr< Foam::indirectPrimitivePatch > makePatch	(	const polyMesh &	mesh,
		const labelList &	patchIDs
	)

static

Create patch from set of patches.

Definition at line 1708 of file meshRefinement.C.

References polyMesh::boundaryMesh(), polyMesh::faces(), forAll, patches, polyMesh::points(), UList< T >::size(), and polyPatch::start().

Referenced by snappyLayerDriver::addLayers(), snappySnapDriver::doSnap(), and snappySnapDriver::repatchToSurface().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ makeDisplacementField()

Foam::tmp< Foam::pointVectorField > makeDisplacementField	(	const pointMesh &	pMesh,
		const labelList &	adaptPatchIDs
	)

static

Helper function to make a pointVectorField with correct.

bcs for mesh movement:

adaptPatchIDs : fixedValue
processor : calculated (so free to move)
cyclic/wedge/symmetry : slip
other : slip

Definition at line 1753 of file meshRefinement.C.

References pointMesh::boundary(), Foam::dimLength, forAll, GeometricField< Type, pointPatchField, pointMesh >::New(), patchi, UPtrList< T >::size(), and Foam::Zero.

Referenced by snappySnapDriver::doSnap().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ checkCoupledFaceZones()

void checkCoupledFaceZones ( const polyMesh & mesh )

static

Helper function: check that face zones are synced.

Definition at line 1802 of file meshRefinement.C.

References Foam::abort(), Foam::exit(), polyMesh::faceZones(), Foam::FatalError, FatalErrorInFunction, forAll, Pstream::gatherList(), UPstream::myProcNo(), Zone< ZoneType, ZonesType >::name(), primitiveMesh::nFaces(), primitiveMesh::nInternalFaces(), Foam::nl, UPstream::nProcs(), Pstream::scatterList(), syncTools::swapBoundaryFaceList(), and DictionaryBase< IDLListType, T >::toc().

Here is the call graph for this function:

◆ calculateEdgeWeights()

void calculateEdgeWeights	(	const polyMesh &	mesh,
		const PackedBoolList &	isMasterEdge,
		const labelList &	meshPoints,
		const edgeList &	edges,
		scalarField &	edgeWeights,
		scalarField &	invSumWeight
	)

static

Helper: calculate edge weights (1/length)

Definition at line 1880 of file meshRefinement.C.

References Foam::e, forAll, Foam::mag(), Foam::max(), polyMesh::points(), List< T >::setSize(), PackedList< nBits >::size(), and List< T >::size().

Here is the call graph for this function:

◆ weightedSum()

void weightedSum	(	const polyMesh &	mesh,
		const PackedBoolList &	isMasterEdge,
		const labelList &	meshPoints,
		const edgeList &	edges,
		const scalarField &	edgeWeights,
		const Field< Type > &	data,
		Field< Type > &	sum
	)

static

Helper: weighted sum (over all subset of mesh points) by.

summing contribution from (master) edges

Definition at line 220 of file meshRefinementTemplates.C.

References Foam::abort(), Foam::e, Foam::FatalError, FatalErrorInFunction, forAll, PackedList< nBits >::size(), List< T >::size(), Foam::sum(), syncTools::syncPointList(), and Foam::Zero.

Here is the call graph for this function:

◆ isGap()

bool isGap	(	const scalar	planarCos,
		const vector &	point0,
		const vector &	normal0,
		const vector &	point1,
		const vector &	normal1
	)		const

Is local topology a small gap?

Hits differ and angles are oppositeish and

hits have a normal distance

Definition at line 1506 of file meshRefinementRefine.C.

References Foam::mag(), VectorSpace< Form, Cmpt, Ncmpts >::zero, and Foam::Zero.

Here is the call graph for this function:

◆ isNormalGap()

bool isNormalGap	(	const scalar	planarCos,
		const vector &	point0,
		const vector &	normal0,
		const vector &	point1,
		const vector &	normal1
	)		const

Is local topology a small gap normal to the test vector.

Hits differ and angles are oppositeish and

hits have a normal distance

Definition at line 1563 of file meshRefinementRefine.C.

References Foam::cos(), Foam::degToRad(), Foam::mag(), VectorSpace< Form, Cmpt, Ncmpts >::zero, and Foam::Zero.

Here is the call graph for this function:

◆ refineCandidates()

Foam::labelList refineCandidates	(	const List< point > &	insidePoints,
		const scalar	curvature,
		const scalar	planarAngle,
		const bool	featureRefinement,
		const bool	featureDistanceRefinement,
		const bool	internalRefinement,
		const bool	surfaceRefinement,
		const bool	curvatureRefinement,
		const bool	gapRefinement,
		const label	maxGlobalCells,
		const label	maxLocalCells
	)		const

Calculate list of cells to refine.

Disable refinement shortcut. nAllowRefine is per processor limit.

Definition at line 2029 of file meshRefinementRefine.C.

References Foam::cos(), Foam::endl(), forAll, Foam::Info, insidePoints(), Foam::labelMax, Foam::max(), UPstream::nProcs(), Foam::radToDeg(), and List< T >::setSize().

Here is the call graph for this function:

◆ refine()

Foam::autoPtr< Foam::polyTopoChangeMap > refine ( const labelList & cellsToRefine )

Refine some cells.

Definition at line 2232 of file meshRefinementRefine.C.

References polyTopoChange::changeMesh(), Foam::patchDistWave::getChangedFaces(), and Foam::name().

Here is the call graph for this function:

◆ refineAndBalance()

Foam::autoPtr< Foam::polyDistributionMap > refineAndBalance	(	const string &	msg,
		decompositionMethod &	decomposer,
		fvMeshDistribute &	distributor,
		const labelList &	cellsToRefine,
		const scalar	maxLoadUnbalance
	)

Refine some cells and rebalance.

Definition at line 2261 of file meshRefinementRefine.C.

References Foam::endl(), Foam::Info, Foam::mag(), meshRefinement::MESH, Foam::name(), UPstream::nProcs(), Foam::Pout, Foam::returnReduce(), and Foam::vtkWriteOps::write().

Here is the call graph for this function:

◆ balanceAndRefine()

Foam::autoPtr< Foam::polyDistributionMap > balanceAndRefine	(	const string &	msg,
		decompositionMethod &	decomposer,
		fvMeshDistribute &	distributor,
		const labelList &	cellsToRefine,
		const scalar	maxLoadUnbalance
	)

Balance before refining some cells.

Definition at line 2362 of file meshRefinementRefine.C.

References Foam::endl(), forAll, Foam::Info, Foam::mag(), meshRefinement::MESH, Foam::name(), UPstream::nProcs(), Foam::Pout, Foam::returnReduce(), List< T >::size(), and Foam::vtkWriteOps::write().

Here is the call graph for this function:

◆ baffleAndSplitMesh()

void baffleAndSplitMesh	(	const bool	handleSnapProblems,
		const snapParameters &	snapParams,
		const bool	useTopologicalSnapDetection,
		const bool	removeEdgeConnectedCells,
		const scalarField &	perpendicularAngle,
		const bool	mergeFreeStanding,
		const scalar	freeStandingAngle,
		const dictionary &	motionDict,
		Time &	runTime,
		const labelList &	globalToMasterPatch,
		const labelList &	globalToSlavePatch,
		const refinementParameters::cellSelectionPoints &	selectionPoints
	)

Split off unreachable areas of mesh.

Definition at line 2130 of file meshRefinementBaffles.C.

References cpuTime::cpuTimeIncrement(), Foam::endl(), localPointRegion::findDuplicateFacePairs(), Foam::Info, Foam::name(), Foam::nl, Time::path(), Foam::Pout, Foam::reduce(), Foam::returnReduce(), List< T >::size(), and Foam::vtkWriteOps::write().

Here is the call graph for this function:

◆ splitMesh()

Foam::autoPtr< Foam::polyTopoChangeMap > splitMesh	(	const label	nBufferLayers,
		const labelList &	globalToMasterPatch,
		const labelList &	globalToSlavePatch,
		const refinementParameters::cellSelectionPoints &	selectionPoints
	)

Split off (with optional buffer layers) unreachable areas.

of mesh. Does not introduce baffles.

Definition at line 2320 of file meshRefinementBaffles.C.

References DynamicList< T, SizeInc, SizeMult, SizeDiv >::append(), List< T >::clear(), Foam::endl(), f(), forAll, removeCells::getExposedFaces(), Foam::Info, refinementParameters::cellSelectionPoints::inside(), Foam::labelMax, Foam::max(), VectorSpace< Form, Cmpt, Ncmpts >::one, pFaces, Foam::reduce(), DynamicList< T, SizeInc, SizeMult, SizeDiv >::shrink(), List< T >::size(), syncTools::syncFaceList(), syncTools::syncPointList(), List< T >::transfer(), and WarningInFunction.

Here is the call graph for this function:

◆ dupNonManifoldPoints() [1/2]

Foam::autoPtr< Foam::polyTopoChangeMap > dupNonManifoldPoints ( const localPointRegion & regionSide )

Find boundary points that connect to more than one cell.

region and split them.

Definition at line 2590 of file meshRefinementBaffles.C.

References polyTopoChange::changeMesh(), Foam::endl(), Foam::Info, localPointRegion::meshPointMap(), Foam::name(), Foam::returnReduce(), duplicatePoints::setRefinement(), and HashTable< T, Key, Hash >::size().

Here is the call graph for this function:

◆ dupNonManifoldPoints() [2/2]

Foam::autoPtr< Foam::polyTopoChangeMap > dupNonManifoldPoints ( )

Find boundary points that connect to more than one cell.

region and split them.

Definition at line 2635 of file meshRefinementBaffles.C.

◆ createBaffles()

Foam::autoPtr< Foam::polyTopoChangeMap > createBaffles	(	const labelList &	ownPatch,
		const labelList &	nbrPatch
	)

Create baffle for every internal face where ownPatch != -1.

External faces get repatched according to ownPatch (nbrPatch should be -1 for these)

Redo the intersections on the newly create baffle faces. Note that

this changes also the cell centre positions.

Definition at line 271 of file meshRefinementBaffles.C.

References Foam::abort(), polyTopoChange::changeMesh(), Foam::endl(), Foam::faceMap(), Foam::FatalError, FatalErrorInFunction, forAll, HashSet< Key, Hash >::insert(), Foam::name(), List< T >::size(), faceSet::sync(), syncTools::syncFaceList(), and HashTable< T, Key, Hash >::toc().

Here is the call graph for this function:

◆ checkZoneFaces()

void checkZoneFaces ( ) const

Debug helper: check faceZones are not on processor patches.

Definition at line 397 of file meshRefinementBaffles.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, IOobject::name(), patchIdentifier::name(), patchi, polyPatch::start(), and ZoneList< ZoneType, ZonesType, MeshType >::whichZones().

Here is the call graph for this function:

◆ createZoneBaffles()

Foam::autoPtr< Foam::polyTopoChangeMap > createZoneBaffles	(	const labelList &	globalToMasterPatch,
		const labelList &	globalToSlavePatch,
		List< labelPair > &	baffles
	)

Create baffles for faces straddling zoned surfaces. Return.

baffles.

Definition at line 430 of file meshRefinementBaffles.C.

References Foam::abort(), HashTableCore::end(), Foam::endl(), Foam::faceMap(), Foam::FatalError, FatalErrorInFunction, HashTable< T, Key, Hash >::find(), UList< T >::first(), forAll, forAllConstIter, surfaceZonesInfo::getNamedSurfaces(), Foam::Info, Foam::name(), Foam::nl, Foam::Pout, Foam::returnReduce(), List< T >::setSize(), HashTable< T, Key, Hash >::size(), List< T >::size(), and Foam::vtkWriteOps::write().

Here is the call graph for this function:

◆ mergeBaffles()

Foam::autoPtr< Foam::polyTopoChangeMap > mergeBaffles ( const List< labelPair > & couples )

Merge baffles. Gets pairs of faces.

Definition at line 783 of file meshRefinementBaffles.C.

References polyTopoChange::changeMesh(), UList< T >::first(), forAll, polyTopoChange::modifyFace(), Foam::name(), polyTopoChange::removeFace(), List< T >::setSize(), and List< T >::size().

Here is the call graph for this function:

◆ zonify()

Foam::autoPtr< Foam::polyTopoChangeMap > zonify	(	const List< point > &	insidePoints,
		const bool	allowFreeStandingZoneFaces
	)

Put faces/cells into zones according to surface specification.

Returns null if no zone surfaces present. Region containing the insidePoint will not be put into a cellZone.

Per face index of faceZone or -1

Definition at line 2644 of file meshRefinementBaffles.C.

References surfaceZonesInfo::addCellZonesToMesh(), surfaceZonesInfo::addFaceZonesToMesh(), UIndirectList< T >::addressing(), polyTopoChange::changeMesh(), polyPatch::coupled(), Foam::endl(), HashTable< T, Key, Hash >::find(), forAll, surfaceZonesInfo::getClosedNamedSurfaces(), surfaceZonesInfo::getInsidePointNamedSurfaces(), syncTools::getMasterFaces(), surfaceZonesInfo::getNamedSurfaces(), Foam::Info, HashTable< T, Key, Hash >::insert(), insidePoints(), PrimitivePatch< FaceList, PointField >::localFaces(), PrimitivePatch< FaceList, PointField >::localPoints(), Foam::magSqr(), Pstream::mapCombineGather(), Pstream::mapCombineScatter(), n, Zone< ZoneType, ZonesType >::name(), Foam::name(), Foam::nl, patches, patchi, Foam::Pout, Foam::returnReduce(), UIndirectList< T >::size(), UPtrList< T >::size(), List< T >::size(), polyPatch::start(), syncTools::swapBoundaryCellList(), syncTools::syncFaceList(), and OBJstream::write().

Here is the call graph for this function:

◆ addMeshedPatch()

Foam::label addMeshedPatch	(	const word &	name,
		const dictionary &	patchInfo
	)

Add patch originating from meshing. Update meshedPatches_.

Definition at line 1936 of file meshRefinement.C.

References Foam::findIndex(), polyBoundaryMesh::findIndex(), forAll, Foam::name(), polyPatch::New(), patchi, dictionary::set(), and UPtrList< T >::size().

Here is the call graph for this function:

◆ meshedPatches()

Foam::labelList meshedPatches ( ) const

Get patchIDs for patches added in addMeshedPatch.

Definition at line 2001 of file meshRefinement.C.

References Foam::abort(), DynamicList< T, SizeInc, SizeMult, SizeDiv >::append(), polyPatch::constraintType(), Foam::endl(), Foam::FatalError, FatalErrorInFunction, forAll, patches, patchi, and Foam::type().

Here is the call graph for this function:

◆ selectSeparatedCoupledFaces()

void selectSeparatedCoupledFaces ( boolList & selected ) const

Select coupled faces that are not collocated.

Definition at line 2027 of file meshRefinement.C.

References forAll, patches, patchi, polyPatch::start(), coupledPolyPatch::transform(), and transformer::transformsPosition().

Here is the call graph for this function:

◆ findRegion()

Foam::label findRegion	(	const polyMesh &	mesh,
		const labelList &	cellRegion,
		const vector &	perturbVec,
		const point &	location
	)

static

Find region point is in. Uses optional perturbation to re-test.

Definition at line 2050 of file meshRefinement.C.

References polyMesh::findCell(), and Foam::reduce().

Here is the call graph for this function:

◆ findRegions()

void findRegions	(	const polyMesh &	mesh,
		labelList &	cellRegion,
		const vector &	perturbVec,
		const refinementParameters::cellSelectionPoints &	selectionPoints
	)

static

Find regions points are in and update cellRegion.

Uses optional perturbation to re-test.

Definition at line 2081 of file meshRefinement.C.

References forAll, refinementParameters::cellSelectionPoints::inside(), primitiveMesh::nCells(), and refinementParameters::cellSelectionPoints::outside().

Here is the call graph for this function:

◆ splitMeshRegions()

Foam::autoPtr< Foam::polyTopoChangeMap > splitMeshRegions	(	const labelList &	globalToMasterPatch,
		const labelList &	globalToSlavePatch,
		const refinementParameters::cellSelectionPoints &	selectionPoints
	)

Split mesh according to selectionPoints.

Definition at line 2156 of file meshRefinement.C.

References DynamicList< T, SizeInc, SizeMult, SizeDiv >::append(), Foam::endl(), forAll, removeCells::getExposedFaces(), Foam::Info, refinementParameters::cellSelectionPoints::inside(), VectorSpace< Form, Cmpt, Ncmpts >::one, Foam::reduce(), Foam::returnReduce(), List< T >::setSize(), DynamicList< T, SizeInc, SizeMult, SizeDiv >::shrink(), List< T >::size(), and WarningInFunction.

Here is the call graph for this function:

◆ splitFaces()

Foam::autoPtr< Foam::polyTopoChangeMap > splitFaces	(	const labelList &	splitFaces,
		const labelPairList &	splits
	)

Split faces into two.

Definition at line 657 of file meshRefinement.C.

References polyTopoChange::addFace(), polyTopoChange::changeMesh(), Foam::endl(), f(), Foam::faceMap(), UList< T >::fcIndex(), forAll, polyTopoChange::modifyFace(), Foam::name(), patchi, Foam::Pout, Foam::renumber(), List< T >::setSize(), and List< T >::size().

Here is the call graph for this function:

◆ distribute()

void distribute ( const polyDistributionMap & map )

Update local numbering for mesh redistribution.

Definition at line 2256 of file meshRefinement.C.

References autoPtr< T >::clear(), polyDistributionMap::distributeFaceData(), Foam::e, treeBoundBox::extend(), Foam::faceMap(), forAll, meshBb(), and Foam::second().

Here is the call graph for this function:

◆ topoChange() [1/2]

void topoChange	(	const polyTopoChangeMap &	map,
		const labelList &	changedFaces
	)

Update for external change to mesh. changedFaces are in new mesh.

face labels.

Definition at line 2310 of file meshRefinement.C.

Referenced by meshRefinement::mergePatchFacesUndo().

Here is the caller graph for this function:

◆ updateList()

void updateList	(	const labelList &	newToOld,
		const T &	nullValue,
		List< T > &	elems
	)

static

Helper: reorder list according to map.

Definition at line 33 of file meshRefinementTemplates.C.

References forAll, List< T >::size(), and List< T >::transfer().

Referenced by snappyLayerDriver::addLayers(), and snappySnapDriver::doSnap().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ storeData()

void storeData	(	const labelList &	pointsToStore,
		const labelList &	facesToStore,
		const labelList &	cellsToStore
	)

Signal points/face/cells for which to store data.

Definition at line 2322 of file meshRefinement.C.

Referenced by meshRefinement::mergePatchFacesUndo().

Here is the caller graph for this function:

◆ topoChange() [2/2]

void topoChange	(	const polyTopoChangeMap &	map,
		const labelList &	changedFaces,
		const Map< label > &	pointsToRestore,
		const Map< label > &	facesToRestore,
		const Map< label > &	cellsToRestore
	)

Update local numbering + undo.

Data to restore given as new pointlabel + stored pointlabel (i.e. what was in pointsToStore)

Definition at line 2339 of file meshRefinement.C.

References polyTopoChangeMap::faceMap(), Foam::first(), forAll, polyTopoChangeMap::reverseFaceMap(), List< T >::size(), and List< T >::transfer().

Here is the call graph for this function:

◆ mergePatchFacesUndo()

Foam::label mergePatchFacesUndo	(	const scalar	minCos,
		const scalar	concaveCos,
		const labelHashSet &	patchIDs,
		const dictionary &	motionDict,
		const labelList &	preserveFaces
	)

Merge coplanar faces. preserveFaces is != -1 for faces.

to be preserved

Definition at line 225 of file meshRefinementMerge.C.

References DynamicList< T, SizeInc, SizeMult, SizeDiv >::append(), primitiveMesh::cells(), polyTopoChange::changeMesh(), meshRefinement::checkData(), Foam::meshCheck::checkMesh(), Foam::endl(), polyMesh::faceOwner(), forAll, forAllConstIter, HashTable< T, Key, Hash >::found(), combineFaces::getMergeSets(), meshRefinement::growFaceCellFace(), Foam::Info, Foam::inplaceMapKey(), HashSet< Key, Hash >::insert(), IOobject::instance(), combineFaces::masterFace(), meshRefinement::MESH, meshRefinement::name(), primitiveMesh::nFaces(), primitiveMesh::nInternalFaces(), Foam::nl, regIOobject::objectPath(), Foam::Pout, Foam::returnReduce(), combineFaces::savedPointLabels(), polyMesh::setInstance(), combineFaces::setRefinement(), List< T >::setSize(), combineFaces::setUnrefinement(), DynamicList< T, SizeInc, SizeMult, SizeDiv >::shrink(), HashTable< T, Key, Hash >::size(), List< T >::size(), meshRefinement::storeData(), fvMesh::time(), combineFaces::topoChange(), meshRefinement::topoChange(), fvMesh::topoChange(), meshRefinement::write(), and regIOobject::write().

Here is the call graph for this function:

◆ doRemovePoints()

Foam::autoPtr< Foam::polyTopoChangeMap > doRemovePoints	(	removePoints &	pointRemover,
		const boolList &	pointCanBeDeleted
	)

Definition at line 554 of file meshRefinementMerge.C.

References polyTopoChange::changeMesh(), Foam::endl(), forAll, HashSet< Key, Hash >::insert(), Foam::name(), Foam::Pout, removePoints::savedFaceLabels(), removePoints::setRefinement(), List< T >::size(), and removePoints::topoChange().

Here is the call graph for this function:

◆ doRestorePoints()

Foam::autoPtr< Foam::polyTopoChangeMap > doRestorePoints	(	removePoints &	pointRemover,
		const labelList &	facesToRestore
	)

Definition at line 600 of file meshRefinementMerge.C.

References polyTopoChange::changeMesh(), Foam::endl(), forAll, removePoints::getUnrefimentSet(), HashSet< Key, Hash >::insert(), Foam::name(), Foam::Pout, removePoints::setUnrefinement(), List< T >::size(), and removePoints::topoChange().

Here is the call graph for this function:

◆ collectFaces()

Foam::labelList collectFaces	(	const labelList &	candidateFaces,
		const labelHashSet &	set
	)		const

Definition at line 662 of file meshRefinementMerge.C.

References Foam::findIndices(), forAll, HashTable< T, Key, Hash >::found(), and syncTools::syncFaceList().

Here is the call graph for this function:

◆ growFaceCellFace()

Foam::labelList growFaceCellFace ( const labelHashSet & set ) const

Definition at line 694 of file meshRefinementMerge.C.

References Foam::findIndices(), forAll, forAllConstIter, and syncTools::syncFaceList().

Referenced by meshRefinement::mergePatchFacesUndo().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ mergeEdgesUndo()

Foam::label mergeEdgesUndo	(	const scalar	minCos,
		const dictionary &	motionDict
	)

Merge edges, maintain mesh quality. Return global number.

of edges merged

Definition at line 735 of file meshRefinementMerge.C.

References Foam::meshCheck::checkMesh(), removePoints::countPointUsage(), Foam::endl(), Foam::Info, IOobject::instance(), meshRefinement::MESH, n, Foam::name(), Foam::nl, regIOobject::objectPath(), Foam::Pout, Foam::returnReduce(), removePoints::savedFaceLabels(), HashTable< T, Key, Hash >::size(), List< T >::size(), regIOobject::write(), and Foam::vtkWriteOps::write().

Here is the call graph for this function:

◆ checkData()

void checkData ( )

Debugging: check that all faces still obey start()>end()

Definition at line 405 of file meshRefinement.C.

References Foam::endl(), localPointRegion::findDuplicateFaces(), forAll, Foam::identityMap(), Foam::Pout, List< T >::size(), syncTools::swapBoundaryFaceList(), syncTools::syncBoundaryFacePositions(), and WarningInFunction.

Referenced by meshRefinement::mergePatchFacesUndo().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ testSyncPointList() [1/2]

void testSyncPointList	(	const string &	msg,
		const polyMesh &	mesh,
		const List< scalar > &	fld
	)

static

Definition at line 311 of file meshRefinement.C.

References Foam::abort(), Foam::endl(), Foam::FatalError, FatalErrorInFunction, fld(), forAll, Foam::mag(), Foam::nl, primitiveMesh::nPoints(), polyMesh::points(), Foam::Pout, and syncTools::syncPointList().

Here is the call graph for this function:

◆ testSyncPointList() [2/2]

void testSyncPointList	(	const string &	msg,
		const polyMesh &	mesh,
		const List< point > &	fld
	)

static

Definition at line 358 of file meshRefinement.C.

References Foam::abort(), Foam::endl(), Foam::FatalError, FatalErrorInFunction, fld(), forAll, Foam::mag(), Foam::nl, primitiveMesh::nPoints(), polyMesh::points(), Foam::Pout, syncTools::syncPointList(), and VectorSpace< Form, Cmpt, Ncmpts >::zero.

Here is the call graph for this function:

◆ testSyncBoundaryFaceList()

void testSyncBoundaryFaceList	(	const scalar	mergeDistance,
		const string &	msg,
		const UList< T > &	faceData,
		const UList< T > &	syncedFaceData
	)		const

Compare two lists over all boundary faces.

Definition at line 99 of file meshRefinementTemplates.C.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::mag(), patchIdentifier::name(), patches, patchi, UList< T >::size(), polyPatch::start(), and Foam::T().

Here is the call graph for this function:

◆ collectAndPrint()

void collectAndPrint	(	const UList< point > &	points,
		const UList< T > &	data
	)

static

Print list according to (collected and) sorted coordinate.

Definition at line 156 of file meshRefinementTemplates.C.

References UPstream::blocking, Foam::endl(), forAll, Foam::identityMap(), Foam::Info, Foam::mag(), UPstream::msgType(), UPstream::nProcs(), points, List< T >::size(), Foam::sortedOrder(), and UPstream::worldComm.

Here is the call graph for this function:

◆ getMasterPoints()

Foam::PackedBoolList getMasterPoints	(	const polyMesh &	mesh,
		const labelList &	meshPoints
	)

static

Determine master point for subset of points. If coupled.

chooses only one

Definition at line 2473 of file meshRefinement.C.

References forAll, Foam::labelMax, List< T >::size(), and syncTools::syncPointList().

Referenced by snappySnapDriver::calcNearestSurface(), and snappySnapDriver::detectNearSurfaces().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getMasterEdges()

Foam::PackedBoolList getMasterEdges	(	const polyMesh &	mesh,
		const labelList &	meshEdges
	)

static

Determine master edge for subset of edges. If coupled.

chooses only one

Definition at line 2510 of file meshRefinement.C.

References forAll, Foam::labelMax, List< T >::size(), syncTools::syncEdgeList(), and globalIndex::toGlobal().

Here is the call graph for this function:

◆ printMeshInfo()

void printMeshInfo	(	const bool	debug,
		const string &	msg
	)		const

Print some mesh stats.

Definition at line 2547 of file meshRefinement.C.

References Foam::endl(), forAll, syncTools::getMasterFaces(), syncTools::getMasterPoints(), Foam::gMax(), Foam::Info, Pstream::listCombineGather(), Pstream::listCombineScatter(), globalMeshData::nTotalCells(), Foam::Pout, and Foam::returnReduce().

Here is the call graph for this function:

◆ name()

Foam::word name ( ) const

Replacement for Time::name() : return oldInstance (if.

overwrite_)

Definition at line 2614 of file meshRefinement.C.

Referenced by meshRefinement::mergePatchFacesUndo(), and snappySnapDriver::preSmoothPatch().

Here is the caller graph for this function:

◆ setInstance()

void setInstance ( const fileName & inst )

Set instance of all local IOobjects.

Definition at line 602 of file meshRefinement.C.

◆ write() [1/2]

bool write ( ) const

Write mesh and all data.

Definition at line 2434 of file meshRefinement.C.

References forAll, Foam::name(), and s().

Referenced by meshRefinement::mergePatchFacesUndo(), and snappySnapDriver::preSmoothPatch().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ dumpRefinementLevel()

void dumpRefinementLevel ( ) const

Write refinement level as volScalarFields for postprocessing.

Definition at line 2627 of file meshRefinement.C.

References IOobject::AUTO_WRITE, Foam::dimless, forAll, DemandDrivenMeshObject< polyMesh, RepatchableMeshObject, pointMesh >::New(), IOobject::NO_READ, IOobject::NO_WRITE, and regIOobject::write().

Here is the call graph for this function:

◆ dumpIntersections()

void dumpIntersections ( const fileName & prefix ) const

Debug: Write intersection information to OBJ format.

Definition at line 2688 of file meshRefinement.C.

References Foam::endl(), forAll, OFstream::name(), Foam::nl, Foam::Pout, List< T >::size(), and Foam::meshTools::writeOBJ().

Here is the call graph for this function:

◆ write() [2/2]

void write	(	const debugType	debugFlags,
		const writeType	writeFlags,
		const fileName &	prefix
	)		const

Do any one of above IO functions.

Definition at line 2768 of file meshRefinement.C.

References Foam::vtkWriteOps::write().

Here is the call graph for this function:

◆ gAverage()

T gAverage	(	const PackedBoolList &	isMasterElem,
		const UList< T > &	values
	)

static

Helper: calculate average.

Definition at line 57 of file meshRefinementTemplates.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, n, Foam::reduce(), PackedList< nBits >::size(), UList< T >::size(), Foam::sum(), Foam::T(), and Foam::Zero.

Referenced by snappySnapDriver::calcNearestSurface().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ writeLevel() [1/2]

Foam::meshRefinement::writeType writeLevel ( )

static

Get/set write level.

Definition at line 2798 of file meshRefinement.C.

Referenced by snappyLayerDriver::addLayers(), snappySnapDriver::doSnap(), snappySnapDriver::preSmoothPatch(), and snappySnapDriver::smoothDisplacement().

Here is the caller graph for this function:

◆ writeLevel() [2/2]

void writeLevel ( const writeType flags )

static

Definition at line 2804 of file meshRefinement.C.

◆ outputLevel() [1/2]

Foam::meshRefinement::outputType outputLevel ( )

static

Get/set output level.

Definition at line 2810 of file meshRefinement.C.

◆ outputLevel() [2/2]

void outputLevel ( const outputType flags )

static

Definition at line 2816 of file meshRefinement.C.

◆ readFlags()

int readFlags	(	const Enum &	namedEnum,
		const wordList &	words
	)

static

Helper: convert wordList into bit pattern using provided.

NamedEnum

Definition at line 201 of file meshRefinementTemplates.C.

References forAll.

◆ operator=()

void operator= ( const meshRefinement & )

delete

Disallow default bitwise assignment.

Member Data Documentation

◆ IOdebugTypeNames

const Foam::NamedEnum< Foam::meshRefinement::IOdebugType, 5 > IOdebugTypeNames

static

Definition at line 98 of file meshRefinement.H.

◆ IOoutputTypeNames

const Foam::NamedEnum< Foam::meshRefinement::IOoutputType, 1 > IOoutputTypeNames

static

Definition at line 114 of file meshRefinement.H.

◆ IOwriteTypeNames

const Foam::NamedEnum< Foam::meshRefinement::IOwriteType, 5 > IOwriteTypeNames

static

Definition at line 130 of file meshRefinement.H.

The documentation for this class was generated from the following files:

src/mesh/snappyHexMesh/meshRefinement/meshRefinement.H
src/mesh/snappyHexMesh/meshRefinement/meshRefinement.C
src/mesh/snappyHexMesh/meshRefinement/meshRefinementBaffles.C
src/mesh/snappyHexMesh/meshRefinement/meshRefinementMerge.C
src/mesh/snappyHexMesh/meshRefinement/meshRefinementProblemCells.C
src/mesh/snappyHexMesh/meshRefinement/meshRefinementRefine.C
src/mesh/snappyHexMesh/meshRefinement/meshRefinementTemplates.C

Public Types

Public Member Functions

Static Public Member Functions

Static Public Attributes

Detailed Description

Member Enumeration Documentation

◆ IOdebugType

◆ debugType

◆ IOoutputType

◆ outputType

◆ IOwriteType

◆ writeType

◆ mapType

Constructor & Destructor Documentation

◆ meshRefinement() [1/2]

◆ meshRefinement() [2/2]

Member Function Documentation

◆ ClassName()

◆ mesh() [1/2]

◆ mesh() [2/2]

◆ mergeDistance()

◆ overwrite()

◆ oldInstance()

◆ surfaces()

◆ features()

◆ shells()

◆ meshCutter()

◆ surfaceIndex() [1/2]

◆ surfaceIndex() [2/2]

◆ userFaceData() [1/2]

◆ userFaceData() [2/2]

◆ countHits()

◆ balance()

◆ intersectedFaces()

◆ intersectedPoints()

◆ makePatch()

◆ makeDisplacementField()

◆ checkCoupledFaceZones()

◆ calculateEdgeWeights()

◆ weightedSum()

◆ isGap()

◆ isNormalGap()

◆ refineCandidates()

◆ refine()

◆ refineAndBalance()

◆ balanceAndRefine()

◆ baffleAndSplitMesh()

◆ splitMesh()

◆ dupNonManifoldPoints() [1/2]

◆ dupNonManifoldPoints() [2/2]

◆ createBaffles()

◆ checkZoneFaces()

◆ createZoneBaffles()

◆ mergeBaffles()

◆ zonify()

◆ addMeshedPatch()

◆ meshedPatches()

◆ selectSeparatedCoupledFaces()

◆ findRegion()

◆ findRegions()

◆ splitMeshRegions()

◆ splitFaces()

◆ distribute()

◆ topoChange() [1/2]

◆ updateList()

◆ storeData()

◆ topoChange() [2/2]

◆ mergePatchFacesUndo()

◆ doRemovePoints()

◆ doRestorePoints()

◆ collectFaces()

◆ growFaceCellFace()

◆ mergeEdgesUndo()

◆ checkData()

◆ testSyncPointList() [1/2]

◆ testSyncPointList() [2/2]

◆ testSyncBoundaryFaceList()

◆ collectAndPrint()

◆ getMasterPoints()

◆ getMasterEdges()
