Base class for poly patches which provides non-conformal mapping between two potentially non-globally conforming poly patches. More...

Inheritance diagram for nonConformalMappedPatchBase:

[legend]

Collaboration diagram for nonConformalMappedPatchBase:

[legend]

Public Member Functions
	TypeName ("nonConformalMappedPatchBase")
	Runtime type information. More...

	nonConformalMappedPatchBase (const nonConformalPolyPatch &ncPp)
	Construct from non-conformal patch. More...

	nonConformalMappedPatchBase (const nonConformalPolyPatch &ncPp, const word &nbrRegionName, const word &nbrPatchName, const cyclicTransform &transform, const bool owner)
	Construct from components. More...

	nonConformalMappedPatchBase (const nonConformalPolyPatch &ncPp, const dictionary &dict, const transformType tt)
	Construct from dictionary. More...

	nonConformalMappedPatchBase (const nonConformalPolyPatch &ncPp, const nonConformalMappedPatchBase &)
	Construct as copy, resetting patch. More...

virtual	~nonConformalMappedPatchBase ()
	Destructor. More...

bool	owner () const
	Does this side own the patch? More...

const patchToPatches::intersection &	intersection () const
	Access the intersection engine. More...

void	clearOut (const bool move)
	Clear out data on mesh change. More...

virtual void	write (Ostream &) const
	Write as a dictionary. More...

Public Member Functions inherited from mappedPatchBaseBase
	TypeName ("mappedPatchBaseBase")
	Runtime type information. More...

	mappedPatchBaseBase (const polyPatch &)
	Construct from patch. More...

	mappedPatchBaseBase (const polyPatch &pp, const word &nbrRegionName, const word &nbrPatchName, const cyclicTransform &transform)
	Construct from components. More...

	mappedPatchBaseBase (const polyPatch &pp, const dictionary &dict, const transformType tt)
	Construct from dictionary. More...

	mappedPatchBaseBase (const polyPatch &, const mappedPatchBaseBase &)
	Construct as copy, resetting patch. More...

virtual	~mappedPatchBaseBase ()
	Destructor. More...

const word &	nbrRegionName () const
	Name of the region to map from. More...

const word &	nbrPatchName () const
	Name of the patch to map from. More...

const transformer &	transform () const
	The transformation between the patches. More...

bool	sameRegion () const
	Is the neighbour region the same as for this patch? More...

bool	samePatch () const
	Is the neighbour patch the same as this patch? More...

bool	sameUntransformedPatch () const
	Is the neighbour patch the same as this patch with no transform? More...

bool	haveNbr () const
	Is the neighbour available? More...

const polyMesh &	nbrMesh () const
	Get the mesh for the region to map from. More...

const polyPatch &	nbrPolyPatch () const
	Get the patch to map from. More...

template<class PatchField , class FieldType >
void	validateForField (const PatchField &field, const FieldType &iF, const dictionary &context, const label froms=from::any) const
	Validate that the map is appropriate for the given. More...

template<class PatchFieldType , class FieldType >
void	validateMapForField (const PatchFieldType &field, const FieldType &iF, const dictionary &context, const label froms)

template<class PatchFieldType , class FieldType >
void	validateForField (const PatchFieldType &field, const FieldType &iF, const dictionary &context, const label froms) const

Protected Member Functions
bool	calcOwner () const
	Constructor helper for owner. More...

const nonConformalMappedPatchBase &	nbrMappedPatch () const
	Neighbour patch. More...

Protected Attributes
const nonConformalPolyPatch &	patch_
	Non-conformal patch to map to. More...

const bool	owner_
	Does this side own the patch? More...

label	intersectionIsValid_
	Is the intersection engine up to date? Zero if out of date. One if. More...

patchToPatches::intersection	intersection_
	Patch-to-patch intersection engine. More...

Protected Attributes inherited from mappedPatchBaseBase
const polyPatch &	patch_
	Patch to map to. More...

const coupleGroupIdentifier	coupleGroup_
	Couple group for the region/patch to map from. More...

word	nbrRegionName_
	Name of the region to map from. More...

word	nbrPatchName_
	Name of the patch to map from. More...

cyclicTransform	transform_
	The transformation between the patches. More...

const moveUpdate	moveUpdate_
	The condition that triggers re-calculation following motion. More...

Additional Inherited Members
Public Types inherited from mappedPatchBaseBase
enum class	transformType { none , defaultNone , specified }
	The type of the transformation permitted/required by this patch. More...

enum class	moveUpdate { always , detect , never }
	Enumeration for the condition that triggers re-calculation of the. More...

Static Public Member Functions inherited from mappedPatchBaseBase
template<class PatchField , class FieldType >
static void	validateMapForField (const PatchField &field, const FieldType &iF, const dictionary &context, const label froms=from::any)
	Validate that the map exists and is appropriate for the given. More...

static bool	moving (const polyPatch &patch, const polyPatch &nbrPatch)
	Return whether or not the patches have moved. More...

static bool	specified (const dictionary &dict)
	Return whether or not the given dictionary contains a. More...

Static Public Attributes inherited from mappedPatchBaseBase
static const NamedEnum< moveUpdate, 3 >	moveUpdateNames_ {"always", "detect", "never"}
	Names of the move-update conditions. More...

Detailed Description

Base class for poly patches which provides non-conformal mapping between two potentially non-globally conforming poly patches.

Source files

Definition at line 51 of file nonConformalMappedPatchBase.H.

Constructor & Destructor Documentation

◆ nonConformalMappedPatchBase() [1/4]

nonConformalMappedPatchBase ( const nonConformalPolyPatch & ncPp )

Construct from non-conformal patch.

Definition at line 67 of file nonConformalMappedPatchBase.C.

◆ nonConformalMappedPatchBase() [2/4]

nonConformalMappedPatchBase	(	const nonConformalPolyPatch &	ncPp,
		const word &	nbrRegionName,
		const word &	nbrPatchName,
		const cyclicTransform &	transform,
		const bool	owner
	)

Construct from components.

Definition at line 80 of file nonConformalMappedPatchBase.C.

◆ nonConformalMappedPatchBase() [3/4]

nonConformalMappedPatchBase	(	const nonConformalPolyPatch &	ncPp,
		const dictionary &	dict,
		const transformType	tt
	)

Construct from dictionary.

Definition at line 97 of file nonConformalMappedPatchBase.C.

◆ nonConformalMappedPatchBase() [4/4]

nonConformalMappedPatchBase	(	const nonConformalPolyPatch &	ncPp,
		const nonConformalMappedPatchBase &	mpb
	)

Construct as copy, resetting patch.

Definition at line 112 of file nonConformalMappedPatchBase.C.

◆ ~nonConformalMappedPatchBase()

~nonConformalMappedPatchBase ( )

virtual

Destructor.

Definition at line 128 of file nonConformalMappedPatchBase.C.

Member Function Documentation

◆ calcOwner()

bool calcOwner ( ) const

protected

Constructor helper for owner.

Definition at line 39 of file nonConformalMappedPatchBase.C.

References polyPatch::boundaryMesh(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, polyBoundaryMesh::mesh(), IOobject::name(), patchIdentifier::name(), mappedPatchBaseBase::nbrPatchName(), mappedPatchBaseBase::nbrRegionName(), nonConformalPolyPatch::patch(), nonConformalMappedPatchBase::patch_, and Foam::regionName().

Here is the call graph for this function:

◆ nbrMappedPatch()

const Foam::nonConformalMappedPatchBase & nbrMappedPatch ( ) const

inlineprotected

Neighbour patch.

Definition at line 31 of file nonConformalMappedPatchBaseI.H.

References Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, patchIdentifier::name(), mappedPatchBaseBase::nbrPatchName_, mappedPatchBaseBase::nbrPolyPatch(), mappedPatchBaseBase::nbrRegionName_, and mappedPatchBaseBase::patch_.

Here is the call graph for this function:

◆ TypeName()

TypeName ( "nonConformalMappedPatchBase" )

Runtime type information.

◆ owner()

bool owner ( ) const

Does this side own the patch?

Definition at line 134 of file nonConformalMappedPatchBase.C.

◆ intersection()

const Foam::patchToPatches::intersection & intersection ( ) const

Access the intersection engine.

Definition at line 141 of file nonConformalMappedPatchBase.C.

References Foam::abort(), polyPatch::boundaryMesh(), Foam::FatalError, FatalErrorInFunction, polyBoundaryMesh::mesh(), mesh, Foam::min(), mappedPatchBaseBase::moving(), DemandDrivenMeshObject< polyMesh, MoveableMeshObject, nonConformalBoundary >::New(), mappedPatchBaseBase::patch_, and nonConformalBoundary::patchPointNormals().

Here is the call graph for this function:

◆ clearOut()

void clearOut ( const bool move )

Clear out data on mesh change.

Definition at line 197 of file nonConformalMappedPatchBase.C.

References Foam::min().

Referenced by nonConformalMappedWallPolyPatch::clearGeom(), nonConformalMappedWallPolyPatch::initCalcGeometry(), nonConformalMappedWallPolyPatch::initMovePoints(), and nonConformalMappedWallPolyPatch::initTopoChange().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Write as a dictionary.

Reimplemented from mappedPatchBaseBase.

Reimplemented in nonConformalMappedWallPolyPatch.

Definition at line 214 of file nonConformalMappedPatchBase.C.

References mappedPatchBaseBase::write(), and Foam::writeEntry().

Referenced by nonConformalMappedWallPolyPatch::write().

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

◆ patch_

const nonConformalPolyPatch& patch_

protected

Non-conformal patch to map to.

Definition at line 60 of file nonConformalMappedPatchBase.H.

Referenced by nonConformalMappedPatchBase::calcOwner().

◆ owner_

const bool owner_

protected

Does this side own the patch?

Definition at line 63 of file nonConformalMappedPatchBase.H.

◆ intersectionIsValid_

label intersectionIsValid_

mutableprotected

Is the intersection engine up to date? Zero if out of date. One if.

out of date (or potentially not out of date) because of motion. Two if up to date.

Definition at line 68 of file nonConformalMappedPatchBase.H.

◆ intersection_

patchToPatches::intersection intersection_

mutableprotected

Patch-to-patch intersection engine.

Definition at line 71 of file nonConformalMappedPatchBase.H.

The documentation for this class was generated from the following files:

src/meshTools/mappedPatches/nonConformalMappedPatchBase/nonConformalMappedPatchBase.H
src/meshTools/mappedPatches/nonConformalMappedPatchBase/nonConformalMappedPatchBase.C
src/meshTools/mappedPatches/nonConformalMappedPatchBase/nonConformalMappedPatchBaseI.H
