Class to represent a system of phases and model interfacial transfers between them. More...
Public Member Functions | |
| TypeName ("phaseSystem") | |
| Runtime type information. More... | |
| declareRunTimeSelectionTable (autoPtr, phaseSystem, dictionary,(const fvMesh &mesh),(mesh)) | |
| phaseSystem (const fvMesh &mesh) | |
| Construct from fvMesh. More... | |
| virtual | ~phaseSystem () |
| Destructor. More... | |
| const fvMesh & | mesh () const |
| Return the mesh. More... | |
| const pimpleNoLoopControl & | pimple () const |
| Return pimpleNoLoopControl. More... | |
| const phaseModelList & | phases () const |
| Return the phase models. More... | |
| phaseModelList & | phases () |
| Access the phase models. More... | |
| const phaseModelPartialList & | movingPhases () const |
| Return the models for phases that are moving. More... | |
| phaseModelPartialList & | movingPhases () |
| Access the models for phases that are moving. More... | |
| const phaseModelPartialList & | stationaryPhases () const |
| Return the models for phases that are stationary. More... | |
| phaseModelPartialList & | stationaryPhases () |
| Access the models for phases that are stationary. More... | |
| const phaseModelPartialList & | anisothermalPhases () const |
| Return the models for phases that have variable temperature. More... | |
| phaseModelPartialList & | anisothermalPhases () |
| Access the models for phases that have variable temperature. More... | |
| const phaseModelPartialList & | multicomponentPhases () const |
| Return the models for phases that have multiple species. More... | |
| phaseModelPartialList & | multicomponentPhases () |
| Access the models for phases that have multiple species. More... | |
| const phaseModel & | otherPhase (const phaseModel &phase) const |
| Return the phase not given as an argument in a two-phase system. More... | |
| const surfaceScalarField & | phi () const |
| Return the mixture flux. More... | |
| surfaceScalarField & | phi () |
| Access the mixture flux. More... | |
| const volScalarField & | dpdt () const |
| Return the rate of change of the pressure. More... | |
| volScalarField & | dpdt () |
| Access the rate of change of the pressure. More... | |
| const IOMRFZoneList & | MRF () const |
| Return MRF zones. More... | |
| Foam::fvModels & | fvModels (fvMesh &mesh) |
| Access the fvModels. More... | |
| const Foam::fvModels & | fvModels () const |
| Access the fvModels. More... | |
| Foam::fvConstraints & | fvConstraints (fvMesh &mesh) |
| Access the fvConstraints. More... | |
| const Foam::fvConstraints & | fvConstraints () const |
| Access the fvConstraints. More... | |
| template<class ModelType > | |
| word | modelName () const |
| Return the model name. This is the same as the model's typename. More... | |
| template<class ModelType , class ... InterfaceTypes> | |
| void | generateInterfacialModels (const dictionary &dict, const phaseInterface &interface, PtrList< phaseInterface > &interfaces, PtrList< ModelType > &models) const |
| Generate interfacial-model lists. More... | |
| template<class ModelType > | |
| void | generateInterfacialModels (const dictionary &dict, HashTable< autoPtr< ModelType >, phaseInterfaceKey, phaseInterfaceKey::hash > &models) const |
| Generate interfacial-model tables. More... | |
| template<class ModelType > | |
| void | generateInterfacialModels (HashTable< autoPtr< ModelType >, phaseInterfaceKey, phaseInterfaceKey::hash > &models) const |
| Generate interfacial-model tables. More... | |
| template<class ValueType > | |
| void | generateInterfacialValues (const dictionary &dict, HashTable< ValueType, phaseInterfaceKey, phaseInterfaceKey::hash > &values) const |
| Generate interfacial-model tables. More... | |
| template<class ValueType > | |
| void | generateInterfacialValues (const word &valueName, HashTable< ValueType, phaseInterfaceKey, phaseInterfaceKey::hash > &values) const |
| Generate interfacial-model tables. More... | |
| template<class ModelType > | |
| void | validateMassTransfer (const phaseInterface &interface) const |
| Check that mass transfer is supported across the given interface. More... | |
| template<class ModelType > | |
| bool | foundInterfacialModel (const phaseInterface &interface) const |
| Check availability of a sub model for a given interface. More... | |
| template<class ModelType > | |
| const ModelType & | lookupInterfacialModel (const phaseInterface &interface) const |
| Return a sub model for an interface. More... | |
| template<class Type , template< class > class PatchField, class GeoMesh > | |
| void | fillFields (const word &name, const dimensionSet &dims, PtrList< GeometricField< Type, PatchField, GeoMesh >> &fieldList) const |
| Fill up gaps in a phase-indexed list of fields with zeros. More... | |
| template<class Type , template< class > class PatchField, class GeoMesh > | |
| void | fillFields (const word &name, const dimensionSet &dims, HashPtrTable< GeometricField< Type, PatchField, GeoMesh >> &fieldTable) const |
| Fill up gaps in a phase-indexed table of fields with zeros. More... | |
| tmp< volScalarField > | rho () const |
| Return the mixture density. More... | |
| tmp< volVectorField > | U () const |
| Return the mixture velocity. More... | |
| tmp< volScalarField > | sigma (const phaseInterfaceKey &key) const |
| Return the surface tension coefficient for an interface. More... | |
| tmp< scalarField > | sigma (const phaseInterfaceKey &key, const label patchi) const |
| Return the surface tension coefficient for an interface on a. More... | |
| tmp< volScalarField > | nearInterface () const |
| Indicator of the proximity of the interface. More... | |
| const dimensionedScalar & | deltaN () const |
| Stabilisation for normalisation of the interface normal. More... | |
| virtual tmp< volScalarField > | dmdtf (const phaseInterfaceKey &key) const |
| Return the mass transfer rate for an interface. More... | |
| virtual PtrList< volScalarField > | dmdts () const |
| Return the mass transfer rates for each phase. More... | |
| virtual PtrList< volScalarField > | d2mdtdps () const |
| Return the mass transfer pressure implicit coefficients. More... | |
| bool | incompressible () const |
| Return incompressibility. More... | |
| virtual autoPtr< momentumTransferTable > | momentumTransfer ()=0 |
| Return the momentum transfer matrices for the cell-based. More... | |
| virtual autoPtr< momentumTransferTable > | momentumTransferf ()=0 |
| Return the momentum transfer matrices for the face-based. More... | |
| virtual PtrList< surfaceScalarField > | KdVmfs () const =0 |
| Return the implicit force coefficients for the face-based. More... | |
| virtual PtrList< surfaceScalarField > | Fs () const =0 |
| Return the force fluxes for the cell-based algorithm. More... | |
| virtual PtrList< surfaceScalarField > | Ffs () const =0 |
| Return the force fluxes for the face-based algorithm. More... | |
| virtual PtrList< surfaceScalarField > | KdPhis () const =0 |
| Return the force fluxes for the cell-based algorithm. More... | |
| virtual PtrList< surfaceScalarField > | KdPhifs () const =0 |
| Return the force fluxes for the face-based algorithm. More... | |
| virtual PtrList< volScalarField > | Kds () const =0 |
| Return the implicit part of the drag force. More... | |
| virtual PtrList< volVectorField > | KdUs () const =0 |
| Return the explicit part of the drag force. More... | |
| virtual bool | implicitPhasePressure (const phaseModel &phase) const |
| Returns true if the phase pressure is treated implicitly. More... | |
| virtual bool | implicitPhasePressure () const |
| Returns true if the phase pressure is treated implicitly. More... | |
| virtual tmp< surfaceScalarField > | alphaDByAf (const PtrList< volScalarField > &rAUs, const PtrList< surfaceScalarField > &rAUfs) const =0 |
| Return the phase diffusivity. More... | |
| virtual PtrList< surfaceScalarField > | ddtCorrs () const =0 |
| Return the flux corrections for the cell-based algorithm. More... | |
| virtual void | dragCorrs (PtrList< volVectorField > &dragCorrs, PtrList< surfaceScalarField > &dragCorrf) const =0 |
| Set the cell and faces drag correction fields. More... | |
| virtual void | partialElimination (const PtrList< volScalarField > &rAUs, const PtrList< volVectorField > &KdUs, const PtrList< surfaceScalarField > &alphafs, const PtrList< surfaceScalarField > &rAUfs, const PtrList< surfaceScalarField > &KdPhis)=0 |
| Solve the drag system for the new velocities and fluxes. More... | |
| virtual void | partialEliminationf (const PtrList< surfaceScalarField > &rAUfs, const PtrList< surfaceScalarField > &alphafs, const PtrList< surfaceScalarField > &KdPhifs)=0 |
| Solve the drag system for the new fluxes. More... | |
| void | setMixturePhi (const PtrList< surfaceScalarField > &alphafs, const surfaceScalarField &phim) |
| Re-normalise the flux of the phases. More... | |
| virtual autoPtr< heatTransferTable > | heatTransfer () const =0 |
| Return the heat transfer matrices. More... | |
| virtual autoPtr< specieTransferTable > | specieTransfer () const =0 |
| Return the specie transfer matrices. More... | |
| tmp< surfaceScalarField > | surfaceTension (const phaseModel &phase) const |
| Return the surface tension force. More... | |
| virtual void | solve (const PtrList< volScalarField > &rAUs, const PtrList< surfaceScalarField > &rAUfs) |
| Solve for the phase fractions. More... | |
| virtual void | correct () |
| Correct the fluid properties other than those listed below. More... | |
| virtual void | correctContinuityError () |
| Correct the continuity errors. More... | |
| virtual void | correctKinematics () |
| Correct the kinematics. More... | |
| virtual void | correctThermo () |
| Correct the thermodynamics. More... | |
| virtual void | correctReactions () |
| Correct the reactions. More... | |
| virtual void | correctSpecies () |
| Correct the species mass fractions. More... | |
| virtual void | predictMomentumTransport () |
| Predict the momentumTransport. More... | |
| virtual void | predictThermophysicalTransport () |
| Predict the energy transport e.g. alphat. More... | |
| virtual void | correctMomentumTransport () |
| Correct the momentumTransport. More... | |
| virtual void | correctThermophysicalTransport () |
| Correct the energy transport e.g. alphat. More... | |
| virtual void | meshUpdate () |
| Update the fluid properties for mesh changes. More... | |
| void | correctBoundaryFlux () |
| Correct fixed-flux BCs to be consistent with the velocity BCs. More... | |
| void | correctPhi (const volScalarField &p_rgh, const autoPtr< volScalarField > &divU, const pressureReference &pressureReference, nonOrthogonalSolutionControl &pimple) |
| virtual bool | read () |
| Read base phaseProperties dictionary. More... | |
| template<class Type > | |
| Foam::dictionary | interfacialDict (const word &name) const |
| template<class ModelType > | |
| Foam::word | modelName () const |
| template<class ModelType > | |
| const Foam::dictionary & | modelSubDict (const dictionary &dict) |
 Public Member Functions inherited from IOdictionary | |
| TypeName ("dictionary") | |
| IOdictionary (const IOobject &) | |
| Construct given an IOobject. More... | |
| IOdictionary (const IOobject &, const dictionary &) | |
| Construct given an IOobject and dictionary. More... | |
| IOdictionary (const IOobject &, Istream &) | |
| Construct given an IOobject and Istream. More... | |
| IOdictionary (const IOdictionary &) | |
| Copy constructor. More... | |
| IOdictionary (IOdictionary &&) | |
| Move constructor. More... | |
| virtual | ~IOdictionary () |
| Destructor. More... | |
| virtual bool | global () const |
| Return true as object is global, i.e. same for all processors. More... | |
| virtual bool | readData (Istream &) |
| ReadData function required for regIOobject read operation. More... | |
| virtual bool | writeData (Ostream &) const |
| WriteData function required for regIOobject write operation. More... | |
| void | operator= (const IOdictionary &) |
| Assignment of dictionary entries only. More... | |
| void | operator= (IOdictionary &&) |
| Move assignment of dictionary entries only. More... | |
| Public Member Functions inherited from regIOobject | |
| TypeName ("regIOobject") | |
| Runtime type information. More... | |
| regIOobject (const IOobject &, const bool isTime=false) | |
| Construct from IOobject. Optional flag for if IOobject is the. More... | |
| regIOobject (const regIOobject &) | |
| Copy constructor. More... | |
| regIOobject (const regIOobject &&) | |
| Move constructor. More... | |
| regIOobject (const regIOobject &, bool registerCopy) | |
| Copy constructor, transferring registry registration to copy. More... | |
| regIOobject (const word &newName, const regIOobject &, bool registerCopy) | |
| Copy constructor with new name, transferring registry registration. More... | |
| regIOobject (const IOobject &, const regIOobject &) | |
| Copy constructor with new IO parameters. More... | |
| virtual | ~regIOobject () |
| Destructor. More... | |
| virtual bool | globalFile () const |
| Return true if object is global, i.e. same for all processors. More... | |
| const fileName & | caseName () const |
| fileName | path () const |
| Return complete path. More... | |
| fileName | objectPath () const |
| Return complete path + object name. More... | |
| fileName | filePath () const |
| Return complete path + object name if the file exists. More... | |
| bool | checkIn () |
| Add object to registry. More... | |
| bool | checkOut () |
| Remove object from registry. More... | |
| void | addWatch () |
| Add file watch on object (if registered and READ_IF_MODIFIED) More... | |
| bool | registered () const |
| Is this object registered with the registry? More... | |
| bool | ownedByRegistry () const |
| Is this object owned by the registry? More... | |
| void | store () |
| Transfer ownership of this object to its registry. More... | |
| void | release () |
| Release ownership of this object from its registry. More... | |
| label | eventNo () const |
| Event number at last update. More... | |
| label & | eventNo () |
| Event number at last update. More... | |
| bool | upToDate (const regIOobject &) const |
| Return true if up-to-date with respect to given object. More... | |
| bool | upToDate (const regIOobject &, const regIOobject &) const |
| Return true if up-to-date with respect to given objects. More... | |
| bool | upToDate (const regIOobject &, const regIOobject &, const regIOobject &) const |
| Return true if up-to-date with respect to given objects. More... | |
| bool | upToDate (const regIOobject &, const regIOobject &, const regIOobject &, const regIOobject &) const |
| Return true if up-to-date with respect to given objects. More... | |
| void | setUpToDate () |
| Set up to date (obviously) More... | |
| virtual void | rename (const word &newName) |
| Rename. More... | |
| bool | headerOk () |
| Read and check header info. More... | |
| Istream & | readStream (const word &, const bool read=true) |
| Return Istream and check object type against that given. More... | |
| void | close () |
| Close Istream. More... | |
| const labelList & | watchIndices () const |
| Return file-monitoring handles. More... | |
| labelList & | watchIndices () |
| Return file-monitoring handles. More... | |
| virtual bool | modified () const |
| Return true if the object's file (or files for objectRegistry) More... | |
| virtual bool | readIfModified () |
| Read object if modified (as set by call to modified) More... | |
| virtual bool | writeObject (IOstream::streamFormat, IOstream::versionNumber, IOstream::compressionType, const bool write) const |
| Write using given format, version and compression. More... | |
| virtual bool | write (const bool write=true) const |
| Write using setting from DB. More... | |
| void | operator= (const IOobject &) |
| const fileName & | caseName (const bool global) const |
| fileName | path (const bool global) const |
| Return complete path including the processor sub-directory. More... | |
| fileName | objectPath (const bool global) const |
| Return complete path + object name including the processor. More... | |
| fileName | filePath (const word &typeName, const bool global) const |
| Return complete path + object name if the file exists. More... | |
| Public Member Functions inherited from IOobject | |
| TypeName ("IOobject") | |
| Runtime type information. More... | |
| IOobject (const word &name, const fileName &instance, const objectRegistry ®istry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true) | |
| Construct from name, instance, registry, io options. More... | |
| IOobject (const word &name, const fileName &instance, const fileName &local, const objectRegistry ®istry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true) | |
| Construct from name, instance, local, registry, io options. More... | |
| IOobject (const fileName &path, const objectRegistry ®istry, readOption r=NO_READ, writeOption w=NO_WRITE, bool registerObject=true) | |
| Construct from path, registry, io options. More... | |
| IOobject (const IOobject &io, const objectRegistry ®istry) | |
| Construct from copy resetting registry. More... | |
| IOobject (const IOobject &io, const word &name) | |
| Construct from copy resetting name. More... | |
| IOobject (const IOobject &io)=default | |
| Copy constructor. More... | |
| autoPtr< IOobject > | clone () const |
| Clone. More... | |
| autoPtr< IOobject > | clone (const objectRegistry ®istry) const |
| Clone resetting registry. More... | |
| virtual | ~IOobject () |
| Destructor. More... | |
| const Time & | time () const |
| Return time. More... | |
| const objectRegistry & | db () const |
| Return the local objectRegistry. More... | |
| const word & | name () const |
| Return name. More... | |
| const word & | headerClassName () const |
| Return name of the class name read from header. More... | |
| word & | headerClassName () |
| Return name of the class name read from header. More... | |
| string & | note () |
| Return non-constant access to the optional note. More... | |
| const string & | note () const |
| Return the optional note. More... | |
| bool & | registerObject () |
| Register object created from this IOobject with registry if true. More... | |
| bool | registerObject () const |
| Register object created from this IOobject with registry if true. More... | |
| readOption | readOpt () const |
| readOption & | readOpt () |
| writeOption | writeOpt () const |
| writeOption & | writeOpt () |
| word | group () const |
| Return group (extension part of name) More... | |
| word | member () const |
| Return member (name without the extension) More... | |
| const fileName & | rootPath () const |
| const fileName & | caseName (const bool global) const |
| fileName & | instance () const |
| Return the instance directory, constant, system, <time> etc. More... | |
| void | updateInstance () const |
| If the instance is a time directory update to the current time. More... | |
| const fileName & | local () const |
| fileName | path (const bool global) const |
| Return complete path including the processor sub-directory. More... | |
| fileName | objectPath (const bool global) const |
| Return complete path + object name including the processor. More... | |
| fileName | relativePath () const |
| Return the path relative to the case directory. More... | |
| fileName | relativeObjectPath () const |
| Return complete relativePath + object name. More... | |
| fileName | filePath (const word &typeName, const bool global) const |
| Return complete path + object name if the file exists. More... | |
| bool | readHeader (Istream &) |
| Read header. More... | |
| bool | headerOk () |
| Read header of local object without type-checking. More... | |
| template<class Type > | |
| void | warnNoRereading () const |
| Helper: warn that type does not support re-reading. More... | |
| bool | writeHeader (Ostream &) const |
| Write header. More... | |
| bool | writeHeader (Ostream &, const word &objectType) const |
| Write header. Allow override of type. More... | |
| bool | good () const |
| bool | bad () const |
| InfoProxy< IOobject > | info () const |
| Return info proxy. More... | |
| void | operator= (const IOobject &) |
| template<class Name > | |
| Foam::word | groupName (Name name, const word &group) |
| Public Member Functions inherited from dictionary | |
| ClassName ("dictionary") | |
| dictionary () | |
| Construct top-level dictionary null. More... | |
| dictionary (const fileName &name) | |
| Construct top-level empty dictionary with given name. More... | |
| dictionary (const fileName &name, const dictionary &parentDict, Istream &) | |
| Construct given the entry name, parent dictionary and Istream,. More... | |
| dictionary (Istream &, const bool keepHeader=false) | |
| Construct top-level dictionary from Istream,. More... | |
| template<class T , class ... KeysAndTs> | |
| dictionary (const keyType &k, const T &t, const KeysAndTs &... keysAndTs) | |
| Construct top-level dictionary with given T entries. More... | |
| template<class T , class ... KeysAndTs> | |
| dictionary (const fileName &name, const keyType &k, const T &t, const KeysAndTs &... keysAndTs) | |
| Construct top-level dictionary with given name and T entries. More... | |
| dictionary (const dictionary &parentDict, const dictionary &) | |
| Construct as copy given the parent dictionary. More... | |
| dictionary (const dictionary &) | |
| Construct top-level dictionary as copy. More... | |
| dictionary (const dictionary *) | |
| Construct top-level dictionary as copy from pointer to dictionary. More... | |
| dictionary (const dictionary &parentDict, dictionary &&) | |
| Move constructor transferring parameter contents. More... | |
| dictionary (dictionary &&) | |
| Move constructor. More... | |
| autoPtr< dictionary > | clone () const |
| Construct and return clone. More... | |
| virtual | ~dictionary () |
| Destructor. More... | |
| const dictionary & | parent () const |
| Return the parent dictionary. More... | |
| bool | isNull () const |
| Return whether this dictionary is null. More... | |
| const dictionary & | topDict () const |
| Return the top of the tree. More... | |
| word | topDictKeyword () const |
| Return the scoped keyword with which this dictionary can be. More... | |
| label | startLineNumber () const |
| Return line number of first token in dictionary. More... | |
| label | endLineNumber () const |
| Return line number of last token in dictionary. More... | |
| SHA1Digest | digest () const |
| Return the SHA1 digest of the dictionary contents. More... | |
| tokenList | tokens () const |
| Return the dictionary as a list of tokens. More... | |
| bool | found (const word &, bool recursive=false, bool patternMatch=true) const |
| Search dictionary for given keyword. More... | |
| const entry * | lookupEntryPtr (const word &, bool recursive, bool patternMatch) const |
| Find and return an entry data stream pointer if present. More... | |
| entry * | lookupEntryPtr (const word &, bool recursive, bool patternMatch) |
| Find and return an entry data stream pointer for manipulation. More... | |
| const entry * | lookupEntryPtrBackwardsCompatible (const wordList &, bool recursive, bool patternMatch) const |
| Find and return an entry data stream if present, trying a list. More... | |
| const entry & | lookupEntry (const word &, bool recursive, bool patternMatch) const |
| Find and return an entry data stream if present otherwise error. More... | |
| const entry & | lookupEntryBackwardsCompatible (const wordList &, bool recursive, bool patternMatch) const |
| Find and return an entry data stream if present, trying a list. More... | |
| ITstream & | lookup (const word &, bool recursive=false, bool patternMatch=true) const |
| Find and return an entry data stream. More... | |
| ITstream & | lookupBackwardsCompatible (const wordList &, bool recursive=false, bool patternMatch=true) const |
| Find and return an entry data stream, trying a list of keywords. More... | |
| template<class T > | |
| T | lookup (const word &, bool recursive=false, bool patternMatch=true) const |
| Find and return a T,. More... | |
| template<class T > | |
| T | lookupBackwardsCompatible (const wordList &, bool recursive=false, bool patternMatch=true) const |
| Find and return a T, trying a list of keywords in sequence. More... | |
| template<class T > | |
| T | lookupOrDefault (const word &, const T &, bool recursive=false, bool patternMatch=true) const |
| Find and return a T,. More... | |
| template<class T > | |
| T | lookupOrDefaultBackwardsCompatible (const wordList &, const T &, bool recursive=false, bool patternMatch=true) const |
| Find and return a T, trying a list of keywords in sequence. More... | |
| template<class T > | |
| T | lookupOrAddDefault (const word &, const T &, bool recursive=false, bool patternMatch=true) |
| Find and return a T, if not found return the given. More... | |
| template<class T > | |
| bool | readIfPresent (const word &, T &, bool recursive=false, bool patternMatch=true) const |
| Find an entry if present, and assign to T. More... | |
| const entry * | lookupScopedEntryPtr (const word &, bool recursive, bool patternMatch) const |
| Find and return an entry data stream pointer if present. More... | |
| bool | isDict (const word &) const |
| Check if entry is a sub-dictionary. More... | |
| const dictionary * | subDictPtr (const word &) const |
| Find and return a sub-dictionary pointer if present. More... | |
| dictionary * | subDictPtr (const word &) |
| Find and return a sub-dictionary pointer if present. More... | |
| const dictionary & | subDict (const word &) const |
| Find and return a sub-dictionary. More... | |
| dictionary & | subDict (const word &) |
| Find and return a sub-dictionary for manipulation. More... | |
| const dictionary & | subDictBackwardsCompatible (const wordList &) const |
| Find and return a sub-dictionary, trying a list of keywords in. More... | |
| dictionary | subOrEmptyDict (const word &, const bool mustRead=false) const |
| Find and return a sub-dictionary as a copy, or. More... | |
| const dictionary & | optionalSubDict (const word &) const |
| Find and return a sub-dictionary if found. More... | |
| const dictionary & | scopedDict (const word &) const |
| Find and return a sub-dictionary by scoped lookup. More... | |
| dictionary & | scopedDict (const word &) |
| Find and return a sub-dictionary by scoped lookup. More... | |
| wordList | toc () const |
| Return the table of contents. More... | |
| wordList | sortedToc () const |
| Return the sorted table of contents. More... | |
| List< keyType > | keys (bool patterns=false) const |
| Return the list of available keys or patterns. More... | |
| bool | substituteKeyword (const word &keyword) |
| Substitute the given keyword prepended by '$' with the. More... | |
| bool | substituteScopedKeyword (const word &keyword) |
| Substitute the given scoped keyword prepended by '$' with the. More... | |
| bool | add (entry *, bool mergeEntry=false) |
| Add a new entry. More... | |
| void | add (const entry &, bool mergeEntry=false) |
| Add an entry. More... | |
| void | add (const keyType &, const word &, bool overwrite=false) |
| Add a word entry. More... | |
| void | add (const keyType &, const string &, bool overwrite=false) |
| Add a string entry. More... | |
| void | add (const keyType &, const label, bool overwrite=false) |
| Add a label entry. More... | |
| void | add (const keyType &, const scalar, bool overwrite=false) |
| Add a scalar entry. More... | |
| void | add (const keyType &, const dictionary &, bool mergeEntry=false) |
| Add a dictionary entry. More... | |
| template<class T > | |
| void | add (const keyType &, const T &, bool overwrite=false) |
| Add a T entry. More... | |
| void | set (entry *) |
| Assign a new entry, overwrite any existing entry. More... | |
| void | set (const entry &) |
| Assign a new entry, overwrite any existing entry. More... | |
| void | set (const keyType &, const dictionary &) |
| Assign a dictionary entry, overwrite any existing entry. More... | |
| template<class T > | |
| void | set (const keyType &, const T &) |
| Assign a T entry, overwrite any existing entry. More... | |
| template<class T , class ... KeysAndTs> | |
| void | set (const keyType &, const T &, const KeysAndTs &...) |
| Assign multiple T entries, overwriting any existing entries. More... | |
| bool | remove (const word &) |
| Remove an entry specified by keyword. More... | |
| bool | changeKeyword (const keyType &oldKeyword, const keyType &newKeyword, bool forceOverwrite=false) |
| Change the keyword for an entry,. More... | |
| bool | merge (const dictionary &) |
| Merge entries from the given dictionary. More... | |
| void | clear () |
| Clear the dictionary. More... | |
| void | transfer (dictionary &) |
| Transfer the contents of the argument and annul the argument. More... | |
| bool | read (Istream &, const bool keepHeader=false) |
| Read dictionary from Istream, optionally keeping the header. More... | |
| void | write (Ostream &, const bool subDict=true) const |
| Write dictionary, normally with sub-dictionary formatting. More... | |
| ITstream & | operator[] (const word &) const |
| Find and return entry. More... | |
| void | operator= (const dictionary &) |
| void | operator= (dictionary &&) |
| void | operator+= (const dictionary &) |
| Include entries from the given dictionary. More... | |
| void | operator|= (const dictionary &) |
| Conditionally include entries from the given dictionary. More... | |
| void | operator<<= (const dictionary &) |
| Unconditionally include entries from the given dictionary. More... | |
| template<class T , class ... KeysAndTs> | |
| void | set (const keyType &k, const T &t, const KeysAndTs &... keysAndTs) |
| Public Member Functions inherited from dictionaryName | |
| dictionaryName () | |
| Construct dictionaryName null. More... | |
| dictionaryName (const fileName &name) | |
| Construct dictionaryName as copy of the given fileName. More... | |
| dictionaryName (dictionaryName &&name) | |
| Move constructor. More... | |
| const fileName & | name () const |
| Return the dictionary name. More... | |
| fileName & | name () |
| Return the dictionary name. More... | |
| const word | dictName () const |
| Return the local dictionary name (final part of scoped name) More... | |
| void | operator= (const dictionaryName &name) |
| void | operator= (dictionaryName &&name) |
| Public Member Functions inherited from ILList< LListBase, T > | |
| ILList () | |
| Null construct. More... | |
| ILList (T *a) | |
| Construct given initial T. More... | |
| ILList (Istream &) | |
| Construct from Istream. More... | |
| ILList (const ILList< LListBase, T > &) | |
| Copy constructor. More... | |
| ILList (ILList< LListBase, T > &&) | |
| Move constructor. More... | |
| template<class CloneArg > | |
| ILList (const ILList< LListBase, T > &lst, const CloneArg &cloneArg) | |
| Copy constructor with additional argument for clone. More... | |
| template<class INew > | |
| ILList (Istream &, const INew &) | |
| Construct from Istream using given Istream constructor class. More... | |
| ~ILList () | |
| Destructor. More... | |
| bool | eraseHead () |
| Remove the head element specified from the list and delete it. More... | |
| bool | erase (T *p) |
| Remove the specified element from the list and delete it. More... | |
| void | clear () |
| Clear the contents of the list. More... | |
| void | transfer (ILList< LListBase, T > &) |
| Transfer the contents of the argument into this List. More... | |
| void | operator= (const ILList< LListBase, T > &) |
| Assignment operator. More... | |
| void | operator= (ILList< LListBase, T > &&) |
| Move assignment operator. More... | |
| Public Member Functions inherited from UILList< LListBase, T > | |
| UILList () | |
| Null construct. More... | |
| UILList (T *a) | |
| Construct given initial T. More... | |
| UILList (const UILList< LListBase, T > &) | |
| Copy constructor. More... | |
| UILList (UILList< LListBase, T > &&) | |
| Move constructor. More... | |
| T * | first () |
| Return the first entry. More... | |
| const T * | first () const |
| Return the first entry. More... | |
| T * | last () |
| Return the last entry. More... | |
| const T * | last () const |
| Return the last entry. More... | |
| T * | removeHead () |
| Remove and return head. More... | |
| T * | remove (T *p) |
| Remove and return element. More... | |
| T * | remove (iterator &it) |
| Remove and return specified by iterator. More... | |
| void | operator= (const UILList< LListBase, T > &) |
| Assignment operator. More... | |
| void | operator= (UILList< LListBase, T > &&) |
| Move assignment operator. More... | |
| iterator | begin () |
| const iterator & | end () |
| const_iterator | cbegin () const |
| const const_iterator & | cend () const |
| const_iterator | begin () const |
| const const_iterator & | end () const |
| const_reverse_iterator | crbegin () const |
| const const_reverse_iterator & | crend () const |
| const_reverse_iterator | rbegin () const |
| const const_reverse_iterator & | rend () const |
| bool | operator== (const UILList< LListBase, T > &) const |
| Equality operation on ULists of the same type. More... | |
| bool | operator!= (const UILList< LListBase, T > &) const |
| The opposite of the equality operation. Takes linear time. More... | |
Static Public Member Functions | |
| static autoPtr< phaseSystem > | New (const fvMesh &mesh) |
| template<class ModelType > | |
| static const dictionary & | modelSubDict (const dictionary &dict) |
| Return the dictionary from which to construct a low-level. More... | |
| Static Public Member Functions inherited from regIOobject | |
| template<class Type > | |
| static Type & | store (Type *) |
| Transfer ownership of the given object pointer to its registry. More... | |
| template<class Type > | |
| static Type & | store (autoPtr< Type > &) |
| Transfer ownership of the given object pointer to its registry. More... | |
| Static Public Member Functions inherited from IOobject | |
| static bool | fileNameComponents (const fileName &path, fileName &instance, fileName &local, word &name) |
| Split path into instance, local, name components. More... | |
| template<class Name > | |
| static word | groupName (Name name, const word &group) |
| static word | group (const word &name) |
| Return group (extension part of name) More... | |
| static word | member (const word &name) |
| Return member (name without the extension) More... | |
| template<class Stream > | |
| static Stream & | writeBanner (Stream &os, bool noHint=false) |
| Write the standard OpenFOAM file/dictionary banner. More... | |
| template<class Stream > | |
| static Stream & | writeDivider (Stream &os) |
| Write the standard file section divider. More... | |
| template<class Stream > | |
| static Stream & | writeEndDivider (Stream &os) |
| Write the standard end file divider. More... | |
| Static Public Member Functions inherited from dictionary | |
| static autoPtr< dictionary > | New (Istream &) |
| Construct top-level dictionary on freestore from Istream. More... | |
Static Public Attributes | |
| static const word | propertiesName |
| Default name of the phase properties dictionary. More... | |
| Static Public Attributes inherited from IOdictionary | |
| static bool | writeDictionaries |
| Static Public Attributes inherited from regIOobject | |
| static float | fileModificationSkew |
| Static Public Attributes inherited from IOobject | |
| static constexpr const char * | foamFile = "FoamFile" |
| Keyword for the FoamFile header sub-dictionary. More... | |
| static const NamedEnum< fileCheckTypes, 4 > | fileCheckTypesNames |
| static fileCheckTypes | fileModificationChecking |
| Type of file modification checking. More... | |
| Static Public Attributes inherited from dictionary | |
| static const dictionary | null |
| Null dictionary. More... | |
| static bool | writeOptionalEntries |
| If true write optional keywords and values. More... | |
Protected Types | |
| typedef HashTable< autoPtr< interfaceSurfaceTensionModel >, phaseInterfaceKey, phaseInterfaceKey::hash > | interfaceSurfaceTensionModelTable |
| typedef HashTable< scalar, phaseInterfaceKey, phaseInterfaceKey::hash > | cAlphaTable |
Protected Member Functions | |
| tmp< surfaceScalarField > | calcPhi (const phaseModelList &phaseModels) const |
| Calculate and return the mixture flux. More... | |
| tmp< volScalarField > | sumAlphaMoving () const |
| Return the sum of the phase fractions of the moving phases. More... | |
| void | setMixtureU (const volVectorField &Um) |
| Re-normalise the velocity of the phases. More... | |
| tmp< surfaceVectorField > | nHatfv (const volScalarField &alpha1, const volScalarField &alpha2) const |
| Normal to interface between two phases. More... | |
| tmp< surfaceScalarField > | nHatf (const volScalarField &alpha1, const volScalarField &alpha2) const |
| Normal to interface between two phases dotted with face areas. More... | |
| tmp< volScalarField > | K (const phaseModel &alpha1, const phaseModel &alpha2) const |
| Curvature of interface between two phases. More... | |
| template<class Type > | |
| dictionary | interfacialDict (const word &name) const |
| Return the dictionary containing interfacial model or value. More... | |
| Protected Member Functions inherited from IOdictionary | |
| IOdictionary (const IOobject &io, const word &wantedType) | |
| Construct given an IOobject, supply wanted typeName. More... | |
| Protected Member Functions inherited from regIOobject | |
| bool | readHeaderOk (const IOstream::streamFormat defaultFormat, const word &typeName) |
| Read header, check readOpt flags and read data if necessary. More... | |
| Protected Member Functions inherited from IOobject | |
| void | setBad (const string &) |
| Set the object state to bad. More... | |
| template<class Type > | |
| bool | typeHeaderOk (const bool checkType) |
| Read header using typeGlobalFile to find file. More... | |
Static Protected Attributes | |
| static const bool | fillFields_ = false |
| Flag to indicate that returned lists of fields are "complete"; i.e.,. More... | |
Class to represent a system of phases and model interfacial transfers between them.
Definition at line 70 of file phaseSystem.H.
Definition at line 78 of file phaseSystem.H.
| typedef HashPtrTable<fvScalarMatrix> heatTransferTable |
Definition at line 80 of file phaseSystem.H.
Definition at line 82 of file phaseSystem.H.
| typedef PtrListDictionary<phaseModel> phaseModelList |
Definition at line 84 of file phaseSystem.H.
| typedef UPtrList<phaseModel> phaseModelPartialList |
Definition at line 86 of file phaseSystem.H.
Definition at line 95 of file phaseSystem.H.
| typedef HashPtrTable< HashPtrTable<volScalarField>, phaseInterfaceKey, phaseInterfaceKey::hash > dmidtfTable |
Definition at line 104 of file phaseSystem.H.
|
protected |
Definition at line 119 of file phaseSystem.H.
|
protected |
Definition at line 122 of file phaseSystem.H.
| phaseSystem | ( | const fvMesh & | mesh | ) |
Construct from fvMesh.
Definition at line 209 of file phaseSystem.C.
References phaseSystem::anisothermalPhaseModels_, IOobject::AUTO_WRITE, phaseSystem::cAlphas_, phaseSystem::correctKinematics(), forAll, dictionary::found(), phaseSystem::generateInterfacialModels(), phaseSystem::generateInterfacialValues(), phaseSystem::interfaceSurfaceTensionModels_, phaseModel::isothermal(), phaseSystem::mesh_, phaseSystem::movingPhaseModels_, phaseSystem::multicomponentPhaseModels_, IOobject::name(), word::null, phaseSystem::phaseModels_, phaseSystem::phases(), phaseSystem::phi_, phaseModel::pure(), phaseSystem::referencePhaseName_, UPtrList< T >::resize(), fvMesh::schemes(), UPtrList< T >::set(), fvSchemes::setFluxRequired(), phaseModel::stationary(), phaseSystem::stationaryPhaseModels_, and IOobject::writeOpt().
|
virtual |
Destructor.
Definition at line 345 of file phaseSystem.C.
|
protected |
Calculate and return the mixture flux.
Definition at line 54 of file phaseSystem.C.
References Foam::fvc::interpolate(), GeometricField< Type, PatchField, GeoMesh >::New(), phaseSystem::phi(), and tmp< T >::ref().
|
protected |
Return the sum of the phase fractions of the moving phases.
Definition at line 78 of file phaseSystem.C.
References GeometricField< Type, PatchField, GeoMesh >::New(), and tmp< T >::ref().
Referenced by phaseSystem::solve().
|
protected |
Re-normalise the velocity of the phases.
around the specified mixture mean
Definition at line 104 of file phaseSystem.C.
References forAll.
|
protected |
Normal to interface between two phases.
Used for interface compression
Definition at line 148 of file phaseSystem.C.
References Foam::fvc::grad(), Foam::fvc::interpolate(), and Foam::mag().
|
protected |
Normal to interface between two phases dotted with face areas.
Used for interface compression
Definition at line 174 of file phaseSystem.C.
Referenced by phaseSystem::solve().
|
protected |
Curvature of interface between two phases.
Used for interface compression
Definition at line 185 of file phaseSystem.C.
References Foam::correctContactAngle(), Foam::fvc::div(), tmp< T >::ref(), and phaseModel::U().
|
protected |
Return the dictionary containing interfacial model or value.
settings for the given name. Performs backwards compatibility conversions.
| TypeName | ( | "phaseSystem" | ) |
Runtime type information.
| declareRunTimeSelectionTable | ( | autoPtr | , |
| phaseSystem | , | ||
| dictionary | , | ||
| (const fvMesh &mesh) | , | ||
| (mesh) | |||
| ) |
|
static |
Definition at line 30 of file phaseSystemNew.C.
References TimePaths::constant(), Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::Info, dictionary::lookup(), phaseSystem::mesh(), IOobject::MUST_READ_IF_MODIFIED, IOobject::NO_WRITE, phaseSystem::propertiesName, and fvMesh::time().
|
inline |
Return the mesh.
Definition at line 28 of file phaseSystemI.H.
References phaseSystem::mesh_.
Referenced by coupledMultiphaseTemperatureFvPatchScalarField::getNbr(), coupledMultiphaseTemperatureFvPatchScalarField::getThis(), MovingPhaseModel< BasePhaseModel >::MovingPhaseModel(), and phaseSystem::New().
|
inline |
Return pimpleNoLoopControl.
Definition at line 34 of file phaseSystemI.H.
Referenced by velocityGroup::correct().
|
inline |
Return the phase models.
Definition at line 41 of file phaseSystemI.H.
Referenced by alphatPhaseChangeWallFunctionBase::activeInterface(), wallBoilingHeatTransfer::activePhaseInterface(), BlendedInterfacialModel< ModelType >::BlendedInterfacialModel(), mixtureKEpsilon< BasicMomentumTransportModel >::bubbleG(), linearTsub::correct(), mixtureKEpsilon< BasicMomentumTransportModel >::Ct2(), deposition::dmdtf(), coupledMultiphaseTemperatureFvPatchScalarField::getNbr(), coupledMultiphaseTemperatureFvPatchScalarField::getThis(), phaseInterface::identifyPhases(), phaseSystem::interfacialDict(), AttouFerschneider::K(), wallBoilingHeatTransfer::K(), phaseInterface::nameToNameParts(), phaseInterface::oldNamePartsToName(), phaseForces::phaseForces(), phaseSystem::phaseSystem(), mixtureKEpsilon< BasicMomentumTransportModel >::rhogEff(), phaseSystem::solve(), JohnsonJacksonParticleSlipFvPatchVectorField::updateCoeffs(), JohnsonJacksonParticleThetaFvPatchScalarField::updateCoeffs(), alphatWallBoilingWallFunctionFvPatchScalarField::updateCoeffs(), and uniformFixedMultiphaseHeatFluxFvPatchScalarField::updateCoeffs().
|
inline |
Access the phase models.
Definition at line 48 of file phaseSystemI.H.
|
inline |
Return the models for phases that are moving.
Definition at line 55 of file phaseSystemI.H.
Referenced by phaseSystem::solve().
|
inline |
Access the models for phases that are moving.
Definition at line 62 of file phaseSystemI.H.
|
inline |
Return the models for phases that are stationary.
Definition at line 69 of file phaseSystemI.H.
Referenced by phaseSystem::solve().
|
inline |
Access the models for phases that are stationary.
Definition at line 76 of file phaseSystemI.H.
|
inline |
Return the models for phases that have variable temperature.
Definition at line 83 of file phaseSystemI.H.
|
inline |
Access the models for phases that have variable temperature.
Definition at line 90 of file phaseSystemI.H.
|
inline |
Return the models for phases that have multiple species.
Definition at line 97 of file phaseSystemI.H.
|
inline |
Access the models for phases that have multiple species.
Definition at line 104 of file phaseSystemI.H.
|
inline |
Return the phase not given as an argument in a two-phase system.
An error is generated if the system is not two-phase
Definition at line 110 of file phaseSystemI.H.
References Foam::exit(), Foam::FatalError, and FatalErrorInFunction.
Referenced by NicenoKEqn< BasicMomentumTransportModel >::bubbleG(), LaheyKEpsilon< BasicMomentumTransportModel >::bubbleG(), NicenoKEqn< BasicMomentumTransportModel >::correctNut(), SmagorinskyZhang< BasicMomentumTransportModel >::correctNut(), continuousGasKEpsilon< BasicMomentumTransportModel >::correctNut(), LaheyKEpsilon< BasicMomentumTransportModel >::correctNut(), continuousGasKEqn< BasicMomentumTransportModel >::liquidTurbulence(), continuousGasKEpsilon< BasicMomentumTransportModel >::liquidTurbulence(), IATEsource::otherPhase(), and continuousGasKEpsilon< BasicMomentumTransportModel >::rhoEff().
|
inline |
Return the mixture flux.
Definition at line 133 of file phaseSystemI.H.
Referenced by phaseSystem::calcPhi().
|
inline |
Access the mixture flux.
Definition at line 139 of file phaseSystemI.H.
|
inline |
Return the rate of change of the pressure.
Definition at line 145 of file phaseSystemI.H.
|
inline |
Access the rate of change of the pressure.
Definition at line 151 of file phaseSystemI.H.
|
inline |
Return MRF zones.
Definition at line 157 of file phaseSystemI.H.
|
inline |
Access the fvModels.
Definition at line 163 of file phaseSystemI.H.
References dictionary::New().
|
inline |
Access the fvModels.
Definition at line 169 of file phaseSystemI.H.
References dictionary::New().
|
inline |
Access the fvConstraints.
Definition at line 175 of file phaseSystemI.H.
References dictionary::New().
|
inline |
Access the fvConstraints.
Definition at line 181 of file phaseSystemI.H.
References dictionary::New().
| word modelName | ( | ) | const |
Return the model name. This is the same as the model's typename.
but without "Model" on the end.
Referenced by BlendedInterfacialModel< ModelType >::BlendedInterfacialModel().
| void generateInterfacialModels | ( | const dictionary & | dict, |
| const phaseInterface & | interface, | ||
| PtrList< phaseInterface > & | interfaces, | ||
| PtrList< ModelType > & | models | ||
| ) | const |
Generate interfacial-model lists.
Definition at line 255 of file phaseSystemTemplates.C.
References hashedWordList::append(), PtrList< T >::append(), dict, autoPtr< T >::empty(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, forAllConstIter, hashedWordList::found(), Foam::name(), phaseInterface::New(), Foam::compressible::New(), Foam::notNull(), autoPtr< T >::ptr(), PtrList< T >::set(), autoPtr< T >::set(), and autoPtr< T >::valid().
Referenced by BlendedInterfacialModel< ModelType >::BlendedInterfacialModel(), phaseSystem::phaseSystem(), and SidedInterfacialModel< ModelType >::SidedInterfacialModel().
| void generateInterfacialModels | ( | const dictionary & | dict, |
| HashTable< autoPtr< ModelType >, phaseInterfaceKey, phaseInterfaceKey::hash > & | models | ||
| ) | const |
Generate interfacial-model tables.
Definition at line 335 of file phaseSystemTemplates.C.
References dict, forAll, and PtrList< T >::set().
| void generateInterfacialModels | ( | HashTable< autoPtr< ModelType >, phaseInterfaceKey, phaseInterfaceKey::hash > & | models | ) | const |
Generate interfacial-model tables.
Definition at line 367 of file phaseSystemTemplates.C.
References phaseSystem::generateInterfacialModels().
Referenced by phaseSystem::generateInterfacialModels().
| void generateInterfacialValues | ( | const dictionary & | dict, |
| HashTable< ValueType, phaseInterfaceKey, phaseInterfaceKey::hash > & | values | ||
| ) | const |
Generate interfacial-model tables.
Definition at line 386 of file phaseSystemTemplates.C.
References dict, forAllConstIter, HashTable< T, Key, Hash >::insert(), and phaseInterface::New().
Referenced by phaseSystem::phaseSystem().
| void generateInterfacialValues | ( | const word & | valueName, |
| HashTable< ValueType, phaseInterfaceKey, phaseInterfaceKey::hash > & | values | ||
| ) | const |
Generate interfacial-model tables.
Definition at line 405 of file phaseSystemTemplates.C.
|
static |
Return the dictionary from which to construct a low-level.
sub-model. Checks that there is just one sub-dictionary then returns it.
Referenced by diffusiveMassTransferModel::New(), phaseTransferModel::New(), interfaceCompositionModel::New(), interfaceSaturationTemperatureModel::New(), interfaceSurfaceTensionModel::New(), liftModel::New(), turbulentDispersionModel::New(), wallLubricationModel::New(), dragModel::New(), heatTransferModel::New(), and virtualMassModel::New().
| void validateMassTransfer | ( | const phaseInterface & | interface | ) | const |
Check that mass transfer is supported across the given interface.
Definition at line 442 of file phaseSystemTemplates.C.
References Foam::exit(), Foam::FatalError, FatalErrorInFunction, phaseInterface::name(), phaseInterface::phase1(), phaseInterface::phase2(), and phaseModel::stationary().
| bool foundInterfacialModel | ( | const phaseInterface & | interface | ) | const |
Check availability of a sub model for a given interface.
Definition at line 459 of file phaseSystemTemplates.C.
References IOobject::groupName(), and phaseInterface::name().
Referenced by kineticTheoryModel::correct(), linearTsub::correct(), phaseForces::phaseForces(), and alphatWallBoilingWallFunctionFvPatchScalarField::updateCoeffs().
| const ModelType & lookupInterfacialModel | ( | const phaseInterface & | interface | ) | const |
Return a sub model for an interface.
Definition at line 473 of file phaseSystemTemplates.C.
References IOobject::groupName(), and phaseInterface::name().
Referenced by NicenoKEqn< BasicMomentumTransportModel >::bubbleG(), LaheyKEpsilon< BasicMomentumTransportModel >::bubbleG(), mixtureKEpsilon< BasicMomentumTransportModel >::bubbleG(), kineticTheoryModel::correct(), linearTsub::correct(), continuousGasKEpsilon< BasicMomentumTransportModel >::correctNut(), mixtureKEpsilon< BasicMomentumTransportModel >::Ct2(), wallBoilingHeatTransfer::K(), continuousGasKEpsilon< BasicMomentumTransportModel >::rhoEff(), and mixtureKEpsilon< BasicMomentumTransportModel >::rhogEff().
| void fillFields | ( | const word & | name, |
| const dimensionSet & | dims, | ||
| PtrList< GeometricField< Type, PatchField, GeoMesh >> & | fieldList | ||
| ) | const |
Fill up gaps in a phase-indexed list of fields with zeros.
Definition at line 157 of file phaseSystemTemplates.C.
References forAll, IOobject::groupName(), phaseModel::name(), and Foam::name().
| void fillFields | ( | const word & | name, |
| const dimensionSet & | dims, | ||
| HashPtrTable< GeometricField< Type, PatchField, GeoMesh >> & | fieldTable | ||
| ) | const |
Fill up gaps in a phase-indexed table of fields with zeros.
Definition at line 193 of file phaseSystemTemplates.C.
References forAll, IOobject::groupName(), phaseModel::name(), and Foam::name().
| Foam::tmp< Foam::volScalarField > rho | ( | ) | const |
| Foam::tmp< Foam::volVectorField > U | ( | ) | const |
| Foam::tmp< Foam::volScalarField > sigma | ( | const phaseInterfaceKey & | key | ) | const |
Return the surface tension coefficient for an interface.
Definition at line 406 of file phaseSystem.C.
References interfaceSurfaceTensionModel::dimSigma, and GeometricField< Type, PatchField, GeoMesh >::New().
Referenced by IATEsource::sigma().
| Foam::tmp< Foam::scalarField > sigma | ( | const phaseInterfaceKey & | key, |
| const label | patchi | ||
| ) | const |
Return the surface tension coefficient for an interface on a.
patch
Definition at line 425 of file phaseSystem.C.
References patchi.
| Foam::tmp< Foam::volScalarField > nearInterface | ( | ) | const |
Indicator of the proximity of the interface.
Field values are 1 near and 0 away for the interface.
Definition at line 442 of file phaseSystem.C.
References Foam::dimless, forAll, Foam::max(), GeometricField< Type, PatchField, GeoMesh >::New(), Foam::pos0(), and tmp< T >::ref().
|
inline |
Stabilisation for normalisation of the interface normal.
Definition at line 187 of file phaseSystemI.H.
|
virtual |
Return the mass transfer rate for an interface.
Definition at line 467 of file phaseSystem.C.
References Foam::dimDensity, Foam::dimTime, IOobject::groupName(), Foam::name(), and GeometricField< Type, PatchField, GeoMesh >::New().
|
virtual |
Return the mass transfer rates for each phase.
Definition at line 481 of file phaseSystem.C.
|
virtual |
Return the mass transfer pressure implicit coefficients.
for each phase
Definition at line 487 of file phaseSystem.C.
| bool incompressible | ( | ) | const |
|
pure virtual |
Return the momentum transfer matrices for the cell-based.
algorithm
|
pure virtual |
Return the momentum transfer matrices for the face-based.
algorithm
|
pure virtual |
Return the implicit force coefficients for the face-based.
algorithm
|
pure virtual |
Return the force fluxes for the cell-based algorithm.
|
pure virtual |
Return the force fluxes for the face-based algorithm.
|
pure virtual |
Return the force fluxes for the cell-based algorithm.
|
pure virtual |
Return the force fluxes for the face-based algorithm.
|
pure virtual |
Return the implicit part of the drag force.
|
pure virtual |
Return the explicit part of the drag force.
|
virtual |
Returns true if the phase pressure is treated implicitly.
in the phase fraction equation
Definition at line 507 of file phaseSystem.C.
|
virtual |
Returns true if the phase pressure is treated implicitly.
in the phase fraction equation for any phase
Definition at line 513 of file phaseSystem.C.
Referenced by phaseSystem::solve().
|
pure virtual |
Return the phase diffusivity.
divided by the momentum central coefficient
Referenced by phaseSystem::solve().
|
pure virtual |
Return the flux corrections for the cell-based algorithm.
|
pure virtual |
Set the cell and faces drag correction fields.
|
pure virtual |
Solve the drag system for the new velocities and fluxes.
|
pure virtual |
Solve the drag system for the new fluxes.
| void setMixturePhi | ( | const PtrList< surfaceScalarField > & | alphafs, |
| const surfaceScalarField & | phim | ||
| ) |
Re-normalise the flux of the phases.
around the specified mixture mean
Definition at line 124 of file phaseSystem.C.
References forAll.
|
pure virtual |
Return the heat transfer matrices.
|
pure virtual |
Return the specie transfer matrices.
| Foam::tmp< Foam::surfaceScalarField > surfaceTension | ( | const phaseModel & | phase | ) | const |
Return the surface tension force.
Definition at line 519 of file phaseSystem.C.
References forAll, Foam::fvc::interpolate(), K, GeometricField< Type, PatchField, GeoMesh >::New(), tmp< T >::ref(), Foam::constant::physicoChemical::sigma, and Foam::fvc::snGrad().
|
virtual |
Solve for the phase fractions.
Definition at line 44 of file phaseSystemSolve.C.
References Foam::fvc::absolute(), alpha(), alphaControls, phaseSystem::alphaDByAf(), phaseModel::alphaMax(), phaseModel::alphaPhi(), phaseModel::alphaPhiRef(), phaseModel::alphaRhoPhiRef(), phaseSystem::cAlphas_, HashTable< scalar, phaseInterfaceKey, phaseInterfaceKey::hash >::const_iterator, phaseModel::correctInflowOutflow(), Foam::fvc::ddt(), Foam::fvm::ddt(), Foam::dimless, Foam::dimTime, Foam::fvc::div(), phaseModel::divU(), Foam::e, HashTable< T, Key, Hash >::empty(), localEulerDdt::enabled(), HashTableCore::end(), UILList< LListBase, T >::end(), Foam::endl(), Foam::MULES::explicitSolve(), HashTable< T, Key, Hash >::find(), fvMatrix< Type >::flux(), Foam::fvc::flux(), forAll, IOobject::groupName(), phaseSystem::implicitPhasePressure(), phaseModel::index(), Foam::Info, surfaceInterpolationScheme< Type >::interpolate(), Foam::fvc::interpolate(), Foam::fvm::laplacian(), Foam::MULES::limit(), Foam::MULES::limitSum(), localEulerDdt::localRSubDeltaT(), Foam::mag(), fvMesh::magSf(), Foam::max(), GeometricField< Type, PatchField, GeoMesh >::maxMin(), phaseSystem::mesh_, Foam::min(), phaseSystem::movingPhases(), nAlphaCorr(), nAlphaSubCycles(), phaseModel::name(), IOobject::name(), dimensioned< Type >::name(), DimensionedField< Type, GeoMesh >::New(), phaseSystem::nHatf(), word::null, phaseSystem::phases(), phaseModel::phi(), phaseSystem::phi_, GeometricField< Type, PatchField, GeoMesh >::primitiveField(), phaseSystem::referencePhaseName_, phaseModel::rho(), PtrList< T >::set(), UPtrList< T >::set(), UPtrList< T >::setSize(), UPtrList< T >::size(), Foam::fvc::snGrad(), fvMesh::solution(), fvMatrix< Type >::solve(), solution::solverDict(), Foam::fvc::Sp(), phaseSystem::stationaryPhases(), Foam::fvc::Su(), phaseSystem::sumAlphaMoving(), fvMesh::time(), phaseModel::U(), fvMesh::V(), Foam::blendedInterfacialModel::valid(), and DimensionedField< Type, GeoMesh >::weightedAverage().
|
virtual |
Correct the fluid properties other than those listed below.
Definition at line 558 of file phaseSystem.C.
References forAll.
|
virtual |
Correct the continuity errors.
Definition at line 567 of file phaseSystem.C.
References alpha(), phaseModel::correctContinuityError(), Foam::dimDensity, Foam::dimTime, forAll, fvModels(), IOobject::groupName(), phaseModel::index(), phaseModel::name(), GeometricField< Type, PatchField, GeoMesh >::New(), phaseModel::rho(), rho, and PtrList< T >::set().
|
virtual |
Correct the kinematics.
Definition at line 602 of file phaseSystem.C.
References Foam::fvc::ddt(), and forAll.
Referenced by phaseSystem::phaseSystem(), and multiphaseEuler::pressureCorrector().
|
virtual |
|
virtual |
|
virtual |
Correct the species mass fractions.
Definition at line 639 of file phaseSystem.C.
References forAll.
|
virtual |
|
virtual |
Predict the energy transport e.g. alphat.
Definition at line 657 of file phaseSystem.C.
References forAll.
|
virtual |
|
virtual |
Correct the energy transport e.g. alphat.
Definition at line 675 of file phaseSystem.C.
References forAll.
|
virtual |
Update the fluid properties for mesh changes.
Definition at line 684 of file phaseSystem.C.
Referenced by multiphaseEuler::moveMesh().
| void correctBoundaryFlux | ( | ) |
Correct fixed-flux BCs to be consistent with the velocity BCs.
Definition at line 698 of file phaseSystem.C.
References GeometricField< Type, PatchField, GeoMesh >::boundaryFieldRef(), forAll, patchi, phaseModel::phiRef(), and phaseModel::U().
| void correctPhi | ( | const volScalarField & | p_rgh, |
| const autoPtr< volScalarField > & | divU, | ||
| const pressureReference & | pressureReference, | ||
| nonOrthogonalSolutionControl & | pimple | ||
| ) |
Definition at line 729 of file phaseSystem.C.
References alpha(), GeometricField< Type, PatchField, GeoMesh >::boundaryFieldRef(), Foam::fv::correctPhi(), Foam::dimless, Foam::dimPressure, GeometricBoundaryField< Type, PatchField, GeoMesh >::evaluate(), forAll, phaseModel::index(), Foam::fvc::interpolate(), Foam::fvc::makeRelative(), GeometricField< Type, PatchField, GeoMesh >::New(), patchi, pimple(), psi, fluidThermo::psi(), phaseModel::rho(), PtrList< T >::set(), phaseModel::thermo(), U, phaseModel::UfRef(), phaseModel::URef(), and Foam::Zero.
Referenced by multiphaseEuler::moveMesh().
|
virtual |
Read base phaseProperties dictionary.
Reimplemented from regIOobject.
Definition at line 831 of file phaseSystem.C.
References forAll, and regIOobject::read().
| Foam::dictionary interfacialDict | ( | const word & | name | ) | const |
Definition at line 88 of file phaseSystemTemplates.C.
References dictionary::add(), dict, forAll, dictionary::found(), IOobject::groupName(), dictionary::isDict(), dictionary::lookup(), dictionaryName::name(), word::null, phaseInterface::oldNamePartsToName(), phaseSystem::phases(), sidedPhaseInterface::separator(), and dictionary::subDict().
| Foam::word modelName | ( | ) | const |
Definition at line 229 of file phaseSystemTemplates.C.
References Foam::name().
| const Foam::dictionary& modelSubDict | ( | const dictionary & | dict | ) |
Definition at line 416 of file phaseSystemTemplates.C.
References dict, Foam::exit(), Foam::FatalError, FatalErrorInFunction, UILList< LListBase, T >::first(), Foam::nl, and dictionary::toc().
|
protected |
Reference to the mesh.
Definition at line 128 of file phaseSystem.H.
Referenced by phaseSystem::mesh(), phaseSystem::phaseSystem(), and phaseSystem::solve().
|
protected |
Reference to pimpleNoLoopControl.
Definition at line 131 of file phaseSystem.H.
|
protected |
Optional MRF zones.
Definition at line 134 of file phaseSystem.H.
|
protected |
Name of optional reference phase which is not solved for.
but obtained from the sum of the other phases
Definition at line 138 of file phaseSystem.H.
Referenced by phaseSystem::phaseSystem(), and phaseSystem::solve().
|
protected |
Phase models.
Definition at line 141 of file phaseSystem.H.
Referenced by phaseSystem::phaseSystem().
|
protected |
Moving phase models.
Definition at line 144 of file phaseSystem.H.
Referenced by phaseSystem::phaseSystem().
|
protected |
Stationary phase models.
Definition at line 147 of file phaseSystem.H.
Referenced by phaseSystem::phaseSystem().
|
protected |
Anisothermal phase models.
Definition at line 150 of file phaseSystem.H.
Referenced by phaseSystem::phaseSystem().
|
protected |
Multi-component phase models.
Definition at line 153 of file phaseSystem.H.
Referenced by phaseSystem::phaseSystem().
|
protected |
Total volumetric flux.
Definition at line 156 of file phaseSystem.H.
Referenced by phaseSystem::phaseSystem(), and phaseSystem::solve().
|
protected |
Rate of change of pressure.
Definition at line 159 of file phaseSystem.H.
|
protected |
Interface compression coefficients.
Definition at line 162 of file phaseSystem.H.
Referenced by phaseSystem::phaseSystem(), and phaseSystem::solve().
|
protected |
Stabilisation for normalisation of the interface normal.
Definition at line 165 of file phaseSystem.H.
|
protected |
Surface tension models.
Definition at line 171 of file phaseSystem.H.
Referenced by phaseSystem::phaseSystem().
|
staticprotected |
Flag to indicate that returned lists of fields are "complete"; i.e.,.
that an absence of force is returned as a constructed list of zeros, rather than a null pointer
Definition at line 177 of file phaseSystem.H.
|
static |
Default name of the phase properties dictionary.
Definition at line 238 of file phaseSystem.H.
Referenced by coupledMultiphaseTemperatureFvPatchScalarField::getNbr(), coupledMultiphaseTemperatureFvPatchScalarField::getThis(), phaseSystem::New(), JohnsonJacksonParticleSlipFvPatchVectorField::updateCoeffs(), JohnsonJacksonParticleThetaFvPatchScalarField::updateCoeffs(), alphatWallBoilingWallFunctionFvPatchScalarField::updateCoeffs(), and uniformFixedMultiphaseHeatFluxFvPatchScalarField::updateCoeffs().
1.9.1
