Specified point samples. Optionally ordered into a continuous path. Ordering is an optimisation; it enables tracking from one point to the next. If ordering is off, each point is searched for individually. More...
Public Member Functions | |
| TypeName ("points") | |
| Runtime type information. More... | |
| points (const word &name, const polyMesh &mesh, const meshSearch &searchEngine, const dictionary &dict) | |
| Construct from dictionary. More... | |
| virtual | ~points () |
| Destructor. More... | |
 Public Member Functions inherited from sampledSet | |
| TypeName ("sampledSet") | |
| Runtime type information. More... | |
| declareRunTimeSelectionTable (autoPtr, sampledSet, word,(const word &name, const polyMesh &mesh, const meshSearch &searchEngine, const dictionary &dict),(name, mesh, searchEngine, dict)) | |
| sampledSet (const word &name, const polyMesh &mesh, const meshSearch &searchEngine, const word &axis) | |
| Construct from components. More... | |
| sampledSet (const word &name, const polyMesh &mesh, const meshSearch &searchEngine, const dictionary &dict) | |
| Construct from dictionary. More... | |
| autoPtr< sampledSet > | clone () const |
| Clone. More... | |
| virtual | ~sampledSet () |
| Destructor. More... | |
| const word & | name () const |
| Access the name. More... | |
| const polyMesh & | mesh () const |
| Access the mesh. More... | |
| const meshSearch & | searchEngine () const |
| Access the search engine. More... | |
| const labelList & | cells () const |
| Access the cells. More... | |
| const labelList & | faces () const |
| Access the faces. More... | |
| virtual void | movePoints () |
| Update for mesh point-motion. More... | |
| virtual void | topoChange (const polyTopoChangeMap &) |
| Update topology using the given map. More... | |
| virtual void | mapMesh (const polyMeshMap &) |
| Update from another mesh using the given map. More... | |
| virtual void | distribute (const polyDistributionMap &) |
| Redistribute or update using the given distribution map. More... | |
| Public Member Functions inherited from coordSet | |
| coordSet () | |
| Construct null. More... | |
| coordSet (const labelList &segments, const word &positionName=word::null, const pointField &positions=pointField::null(), const word &distanceName=word::null, const scalarField &distances=scalarField::null(), const word &axis=axisTypeNames_[axisType::DEFAULT]) | |
| Construct from components. More... | |
| coordSet (const bool contiguous, const word &positionName, const pointField &positions, const word &axis=axisTypeNames_[axisType::DEFAULT]) | |
| Construct from positions. More... | |
| coordSet (const bool contiguous, const word &distanceName, const scalarField &distances, const word &axis=axisTypeNames_[axisType::DEFAULT]) | |
| Construct from distances. More... | |
| label | size () const |
| Return the size. More... | |
| const labelList & | segments () const |
| Return the segments. More... | |
| word | axis () const |
| Return the axis name. More... | |
| bool | hasScalarAxis () const |
| Is the coordinate axis a scalar? More... | |
| bool | hasPointAxis () const |
| Is the coordinate axis a point? More... | |
| scalar | scalarCoord (const label index) const |
| Get scalar coordinate (axis is x, y, z or distance) More... | |
| tmp< scalarField > | scalarCoords () const |
| Get scalar coordinates (axis is x, y, z or distance) More... | |
| word | scalarName () const |
| Return the name of the scalar coordinates. More... | |
| point | pointCoord (const label index) const |
| Get vector coordinate (axis is xyz) More... | |
| tmp< pointField > | pointCoords () const |
| Get vector coordinate (axis is xyz) More... | |
| const pointField & | positions () const |
| Get the positions. More... | |
| word | pointName () const |
| Return the name of the point coordinates. More... | |
| labelList | vertices () const |
| Return a list of isolated vertices. These are the points that are. More... | |
| labelPairList | edges () const |
| Return a list of edges. These are adjacent pairs of points which. More... | |
| labelListList | lines () const |
| Return a list of lines. These are lists of points which are in the. More... | |
| Tuple2< coordSet, labelList > | gather () const |
| Combine coordinate sets onto the master. Return both the combined. More... | |
| template<class Type > | |
| Foam::tmp< Foam::Field< Type > > | gather (const Field< Type > &values, const labelList &order) |
Static Public Member Functions | |
| static void | calcSamples (const polyMesh &mesh, const meshSearch &searchEngine, const pointField &points, DynamicList< point > &samplingPositons, DynamicList< scalar > &samplingDistances, DynamicList< label > &samplingSegments, DynamicList< label > &samplingCells, DynamicList< label > &samplingFaces) |
| Calculate all the sampling points. More... | |
| Static Public Member Functions inherited from sampledSet | |
| static autoPtr< sampledSet > | New (const word &name, const polyMesh &mesh, const meshSearch &searchEngine, const dictionary &dict) |
| Return a reference to the selected sampledSet. More... | |
| Static Public Member Functions inherited from coordSet | |
| template<class Type > | |
| static tmp< Field< Type > > | gather (const Field< Type > &values, const labelList &order) |
| Combine a field using the ordering obtained from the coordinate set. More... | |
Additional Inherited Members | |
| Public Types inherited from coordSet | |
| enum class | axisType { XYZ , X , Y , Z , DISTANCE , DEFAULT } |
| Enumeration defining the output format for coordinates. More... | |
| Static Public Attributes inherited from coordSet | |
| static const NamedEnum< axisType, 6 > | axisTypeNames_ |
| String representation of axis enums. More... | |
| Protected Member Functions inherited from sampledSet | |
| void | setSamples (const List< point > &samplingPositions, const labelList &samplingSegments, const labelList &samplingCells, const labelList &samplingFaces) |
| Sets sample data. More... | |
| void | setSamples (const List< point > &samplingPositions, const List< scalar > &samplingDistances, const labelList &samplingSegments, const labelList &samplingCells, const labelList &samplingFaces) |
| Sets sample data. More... | |
| Protected Attributes inherited from sampledSet | |
| labelList | cells_ |
| Cell numbers. More... | |
| labelList | faces_ |
| Face numbers (-1 if not known) More... | |
| Protected Attributes inherited from coordSet | |
| labelList | segments_ |
| Connected segments. More... | |
| word | positionName_ |
| Name of the positions. More... | |
| autoPtr< pointField > | positions_ |
| Point positions. More... | |
| word | distanceName_ |
| Name of the distances. More... | |
| autoPtr< scalarField > | distances_ |
| Scalar distances. More... | |
| axisType | axis_ |
| Axis. More... | |
Specified point samples. Optionally ordered into a continuous path. Ordering is an optimisation; it enables tracking from one point to the next. If ordering is off, each point is searched for individually.
| Property | Description | Req'd? | Default |
|---|---|---|---|
points | The points to sample | yes | |
ordered | Are the points in order? | yes | |
axis | The coordinate axis that is written | yes |
Example specification:
{
type points;
points
(
(0.95 0 0.25)
(0.951251 0 0.250119)
(0.952468 0 0.250473)
(0.953618 0 0.251057)
(0.954669 0 0.251859)
(0.95559 0 0.252865)
(0.956353 0 0.254057)
(0.956931 0 0.255413)
(0.9573 0 0.256908)
(0.957441 0 0.258513)
);
ordered yes;
axis x;
}
| points | ( | const word & | name, |
| const polyMesh & | mesh, | ||
| const meshSearch & | searchEngine, | ||
| const dictionary & | dict | ||
| ) |
| TypeName | ( | "points" | ) |
Runtime type information.
|
static |
Calculate all the sampling points.
Definition at line 47 of file points.C.
References Cloud< ParticleType >::addParticle(), DynamicList< T, SizeInc, SizeMult, SizeDiv >::append(), b, Cloud< ParticleType >::clear(), meshSearch::findCell(), UILList< LListBase, T >::first(), Pair< Type >::first(), Foam::labelMax, Foam::mag(), sampledSet::mesh(), Cloud< ParticleType >::move(), UPstream::myProcNo(), Foam::returnReduce(), sampledSet::searchEngine(), Pair< Type >::second(), coordSet::size(), and List< T >::size().
