Class for modelling the shape of particle aggregates using the concept of fractal geometry. Returns a collisional diameter. More...

Inheritance diagram for fractal:

[legend]

Collaboration diagram for fractal:

[legend]

Public Member Functions
	TypeName ("fractal")
	Runtime type information. More...

	fractal (const dictionary &dict, const sizeGroup &group, const dictionary &groupDict)
	Construct from dictionaries and sizeGroup. More...

	fractal (const fractal &)=delete
	Disallow default bitwise copy construction. More...

virtual	~fractal ()
	Destructor. More...

const dimensionedScalar &	Df () const
	Return the fractal dimension. More...

const dimensionedScalar &	alphaC () const
	Return the scaling prefactor. More...

virtual const volScalarField &	fld () const
	Return reference to secondary property field. More...

virtual volScalarField::Internal &	src ()
	Access to secondary property source. More...

virtual const tmp< volScalarField >	a () const
	Return representative surface area of the sizeGroup. More...

virtual const tmp< volScalarField >	d () const
	Return representative diameter of the sizeGroup. More...

virtual void	correct ()
	Correct the collisional diameter. More...

void	operator= (const fractal &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from SecondaryPropertyModel< shapeModel >
virtual const word &	type () const=0
	Runtime type information. More...

	SecondaryPropertyModel (const sizeGroup &group)
	Construct from sizeGroup. More...

	SecondaryPropertyModel (const SecondaryPropertyModel< shapeModel > &)=delete
	Disallow default bitwise copy construction. More...

virtual	~SecondaryPropertyModel ()
	Destructor. More...

virtual void	addCoalescence (const volScalarField::Internal &Su, const sizeGroup &fj, const sizeGroup &fk)
	Add coalescence contribution to secondary property source. More...

virtual void	addBreakup (const volScalarField::Internal &Su, const sizeGroup &fj)
	Add breakup contribution to secondary property source. More...

virtual void	reset ()
	Reset secondary property source. More...

void	operator= (const SecondaryPropertyModel< shapeModel > &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from shapeModel
	TypeName ("shapeModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, shapeModel, dictionary,(const dictionary &dict, const sizeGroup &group, const dictionary &groupDict),(dict, group, groupDict))

	shapeModel (const sizeGroup &group)
	Construct from sizeGroup. More...

	shapeModel (const shapeModel &)=delete
	Disallow default bitwise copy construction. More...

virtual	~shapeModel ()
	Destructor. More...

const sizeGroup &	group () const
	Return reference to size group. More...

void	operator= (const shapeModel &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from SecondaryPropertyModel< shapeModel >
static const SecondaryPropertyModel< shapeModel > &	model (const sizeGroup &fi)
	Return the secondary property model of a given size group. More...

Static Public Member Functions inherited from shapeModel
static autoPtr< shapeModel >	New (const dictionary &dict, const sizeGroup &group, const dictionary &groupDict)

static const shapeModel &	model (const sizeGroup &)
	Return the shape model for a given size group. More...

Protected Attributes inherited from shapeModel
const sizeGroup &	group_
	Reference to sizeGroup. More...

Detailed Description

Class for modelling the shape of particle aggregates using the concept of fractal geometry. Returns a collisional diameter.

$d_{c_i} = \frac{6}{\kappa_i} \left( \frac{v_i \kappa_i^3}{36 \pi \alpha_c} \right)^{1/D_{f_i}}\,,$

computed from a constant fractal dimension $D_{f_i}$ and a field-dependent surface area to volume ratio $\kappa_i$ , assuming that the primary particles in an aggregate have the same size.

Usage

Property	Description	Required	Default value
`Df`	Fractal dimension	yes
`alphaC`	Scaling prefactor	yes

See also: Foam::diameterModels::shapeModel

Source files

Definition at line 91 of file fractal.H.

Constructor & Destructor Documentation

◆ fractal() [1/2]

fractal	(	const dictionary &	dict,
		const sizeGroup &	group,
		const dictionary &	groupDict
	)

Construct from dictionaries and sizeGroup.

Definition at line 77 of file fractal.C.

References Foam::exit(), Foam::FatalError, FatalErrorInFunction, dictionary::found(), shapeModel::group(), sizeGroup::group(), IOobject::groupName(), sizeGroup::i(), phaseModel::name(), IOobject::name(), sizeGroup::phase(), and velocityGroup::popBalName().

Here is the call graph for this function:

◆ fractal() [2/2]

fractal ( const fractal & )

delete

Disallow default bitwise copy construction.

◆ ~fractal()

~fractal ( )

virtual

Destructor.

Definition at line 132 of file fractal.C.

Member Function Documentation

◆ TypeName()

TypeName ( "fractal" )

Runtime type information.

◆ Df()

const dimensionedScalar& Df ( ) const

inline

Return the fractal dimension.

Definition at line 150 of file fractal.H.

Referenced by ParkRogakSurfaceAreaVolumeRatioFvScalarFieldSource::value().

Here is the caller graph for this function:

◆ alphaC()

const dimensionedScalar& alphaC ( ) const

inline

Return the scaling prefactor.

Definition at line 156 of file fractal.H.

Referenced by ParkRogakSurfaceAreaVolumeRatioFvScalarFieldSource::value().

Here is the caller graph for this function:

◆ fld()

const Foam::volScalarField & fld ( ) const

virtual

Return reference to secondary property field.

Implements SecondaryPropertyModel< shapeModel >.

Definition at line 139 of file fractal.C.

Referenced by KochFriedlanderSintering::KochFriedlanderSintering().

Here is the caller graph for this function:

◆ src()

Foam::volScalarField::Internal & src ( )

virtual

Access to secondary property source.

Implements SecondaryPropertyModel< shapeModel >.

Definition at line 146 of file fractal.C.

◆ a()

const Foam::tmp< Foam::volScalarField > a ( ) const

virtual

Return representative surface area of the sizeGroup.

Implements shapeModel.

Definition at line 238 of file fractal.C.

References Foam::constant::atomic::group.

◆ d()

const Foam::tmp< Foam::volScalarField > d ( ) const

virtual

Return representative diameter of the sizeGroup.

Implements shapeModel.

Definition at line 245 of file fractal.C.

Referenced by ParkRogakSurfaceAreaVolumeRatioFvScalarFieldSource::value().

Here is the caller graph for this function:

◆ correct()

void correct ( )

virtual

Correct the collisional diameter.

Reimplemented from shapeModel.

Definition at line 152 of file fractal.C.

References alpha(), phaseModel::alphaPhi(), word::capitalise(), fvConstraints::constrain(), Foam::correction(), Foam::fvm::ddt(), Foam::fvm::div(), sizeGroup::dSph(), populationBalanceModel::expansionSp(), populationBalanceModel::expansionSu(), fld(), populationBalanceModel::fluid(), phaseSystem::fvConstraints(), phaseSystem::fvModels(), sizeGroup::group(), Foam::constant::atomic::group, IOobject::groupName(), sizeGroup::i(), Foam::fvc::interpolate(), Foam::max(), IOobject::member(), Foam::min(), populationBalanceModel::modelSourceSu(), sizeGroup::phase(), velocityGroup::popBal(), fvMatrix< Type >::relax(), phaseModel::residualAlpha(), phaseModel::rho(), rho, UPtrList< T >::set(), populationBalanceModel::sizeGroups(), fvMatrix< Type >::solve(), fvModels::source(), populationBalanceModel::Sp(), and Foam::fvm::Sp().

Here is the call graph for this function:

◆ operator=()

void operator= ( const fractal & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

applications/modules/multiphaseEuler/populationBalance/diameterModels/velocityGroup/sizeGroup/shapeModels/fractal/fractal.H
applications/modules/multiphaseEuler/populationBalance/diameterModels/velocityGroup/sizeGroup/shapeModels/fractal/fractal.C
