shapeModel Class Reference

Base class for modelling the shape of the particles belonging to a size class through alternative diameters, e.g. a collisional diameter, which can then be utilised in population balance submodels, e.g. for modelling fractal aggregation. More...

Inheritance diagram for shapeModel:

Collaboration diagram for shapeModel:

Public Member Functions
	TypeName ("shapeModel")
	Runtime type information. More...
	declareRunTimeSelectionTable (autoPtr, shapeModel, dictionary,(const dictionary &dict, const sizeGroup &group, const dictionary &groupDict),(dict, group, groupDict))
	shapeModel (const sizeGroup &group)
	Construct from sizeGroup. More...
	shapeModel (const shapeModel &)=delete
	Disallow default bitwise copy construction. More...
virtual	~shapeModel ()
	Destructor. More...
const sizeGroup &	group () const
	Return reference to size group. More...
virtual const tmp< volScalarField >	a () const =0
	Return representative surface area of the sizeGroup. More...
virtual const tmp< volScalarField >	d () const =0
	Return representative diameter of the sizeGroup. More...
virtual void	correct ()
	Correct physical diameter. More...
virtual void	addCoalescence (const volScalarField::Internal &Su, const sizeGroup &fj, const sizeGroup &fk)
	Add coalescence contribution to secondary property source. More...
virtual void	addBreakup (const volScalarField::Internal &Su, const sizeGroup &fj)
	Add breakup contribution to secondary property source. More...
virtual void	reset ()
	Reset secondary property source. More...
void	operator= (const shapeModel &)=delete
	Disallow default bitwise assignment. More...

Static Public Member Functions
static autoPtr< shapeModel >	New (const dictionary &dict, const sizeGroup &group, const dictionary &groupDict)
static const shapeModel &	model (const sizeGroup &)
	Return the shape model for a given size group. More...

Protected Attributes
const sizeGroup &	group_
	Reference to sizeGroup. More...

Detailed Description

Base class for modelling the shape of the particles belonging to a size class through alternative diameters, e.g. a collisional diameter, which can then be utilised in population balance submodels, e.g. for modelling fractal aggregation.

See also

Foam::diameterModels::sizeGroup

Source files

• shapeModel.H
• shapeModel.C

Definition at line 60 of file shapeModel.H.

Constructor & Destructor Documentation

shapeModel() [1/2]

shapeModel

(

const sizeGroup &

group

)

Construct from sizeGroup.

Definition at line 43 of file shapeModel.C.

shapeModel() [2/2]

shapeModel ( const shapeModel &  )

delete

Disallow default bitwise copy construction.

~shapeModel()

~shapeModel ( )

virtual

Destructor.

Definition at line 80 of file shapeModel.C.

Member Function Documentation

TypeName()

TypeName

(

"shapeModel"

)

Runtime type information.

declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		shapeModel	,
		dictionary	,
		(const dictionary &dict, const sizeGroup &group, const dictionary &groupDict)	,
		(dict, group, groupDict)
	)

New()

Foam::autoPtr< Foam::diameterModels::shapeModel > New ( const dictionary &  dict, const sizeGroup &  group, const dictionary &  groupDict  )

static

Definition at line 52 of file shapeModel.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, and Foam::constant::atomic::group.

Here is the call graph for this function:

model()

const Foam::diameterModels::shapeModel & model ( const sizeGroup &  group )

static

Return the shape model for a given size group.

Definition at line 87 of file shapeModel.C.

References Foam::constant::atomic::group.

group()

const Foam::diameterModels::sizeGroup & group

(

)

const

Return reference to size group.

Definition at line 94 of file shapeModel.C.

Referenced by fractal::fractal().

Here is the caller graph for this function:

a()

virtual const tmp<volScalarField> a ( ) const

pure virtual

Return representative surface area of the sizeGroup.

Implemented in spherical, and fractal.

d()

virtual const tmp<volScalarField> d ( ) const

pure virtual

Return representative diameter of the sizeGroup.

Implemented in spherical, and fractal.

correct()

void correct ( )

virtual

Correct physical diameter.

Reimplemented in fractal.

Definition at line 100 of file shapeModel.C.

addCoalescence()

void addCoalescence ( const volScalarField::Internal &  Su, const sizeGroup &  fj, const sizeGroup &  fk  )

virtual

Add coalescence contribution to secondary property source.

Reimplemented in SecondaryPropertyModel< shapeModel >.

Definition at line 104 of file shapeModel.C.

addBreakup()

void addBreakup ( const volScalarField::Internal &  Su, const sizeGroup &  fj  )

virtual

Add breakup contribution to secondary property source.

Reimplemented in SecondaryPropertyModel< shapeModel >.

Definition at line 113 of file shapeModel.C.

reset()

void reset ( )

virtual

Reset secondary property source.

Reimplemented in SecondaryPropertyModel< shapeModel >.

Definition at line 121 of file shapeModel.C.

operator=()

void operator= ( const shapeModel &  )

delete

Disallow default bitwise assignment.

Member Data Documentation

group_

const sizeGroup& group_

protected

Reference to sizeGroup.

Definition at line 67 of file shapeModel.H.

---

The documentation for this class was generated from the following files:

• applications/modules/multiphaseEuler/populationBalance/diameterModels/velocityGroup/sizeGroup/shapeModels/shapeModel/shapeModel.H
• applications/modules/multiphaseEuler/populationBalance/diameterModels/velocityGroup/sizeGroup/shapeModels/shapeModel/shapeModel.C
