Classes | Public Member Functions | Static Public Member Functions | Protected Attributes | List of all members
binaryBreakupModel Class Referenceabstract

Base class for binary breakup models that provide a breakup rate between a size class pair directly, i.e. without explicitly stating the daughter size distribution function. More...

Inheritance diagram for binaryBreakupModel:
Inheritance graph
[legend]
Collaboration diagram for binaryBreakupModel:
Collaboration graph
[legend]

Classes

class  iNew
 Class used for the read-construction of. More...


Public Member Functions

 TypeName ("binaryBreakupModel")
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, binaryBreakupModel, dictionary,(const populationBalanceModel &popBal, const dictionary &dict),(popBal, dict))

 binaryBreakupModel (const populationBalanceModel &popBal, const dictionary &dict)

autoPtr< binaryBreakupModel > clone () const

virtual ~binaryBreakupModel ()
 Destructor. More...

virtual void precompute ()
 Precompute diameter independent expressions. More...

virtual void addToBinaryBreakupRate (volScalarField::Internal &binaryBreakupRate, const label i, const label j)=0
 Add to binary breakupRate. More...


Static Public Member Functions

static autoPtr< binaryBreakupModel > New (const word &type, const populationBalanceModel &popBal, const dictionary &dict)


Protected Attributes

const populationBalanceModel & popBal_
 Reference to the populationBalanceModel. More...


Detailed Description

Base class for binary breakup models that provide a breakup rate between a size class pair directly, i.e. without explicitly stating the daughter size distribution function.

See also
Foam::diameterModels::populationBalanceModel
Source files

Definition at line 55 of file binaryBreakupModel.H.

Constructor & Destructor Documentation

◆ binaryBreakupModel()

binaryBreakupModel ( const populationBalanceModel &  popBal,
const dictionary &  dict
)

Definition at line 72 of file binaryBreakupModel.C.

◆ ~binaryBreakupModel()

virtual ~binaryBreakupModel ( )
inlinevirtual

Destructor.

Definition at line 134 of file binaryBreakupModel.H.

Member Function Documentation

◆ TypeName()

TypeName ( "binaryBreakupModel"  )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable ( autoPtr  ,
binaryBreakupModel  ,
dictionary  ,
(const populationBalanceModel &popBal, const dictionary &dict)  ,
(popBal, dict)
)

◆ clone()

autoPtr<binaryBreakupModel> clone ( ) const
inline

Definition at line 116 of file binaryBreakupModel.H.

References NotImplemented.

◆ New()

Foam::autoPtr< Foam::diameterModels::binaryBreakupModel > New ( const word &  type,
const populationBalanceModel &  popBal,
const dictionary &  dict
)
static

Definition at line 43 of file binaryBreakupModel.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::Info, IOobject::name(), Foam::nl, and Foam::type().

Referenced by binaryBreakupModel::iNew::operator()().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ precompute()

void precompute ( )
virtual

Precompute diameter independent expressions.

Reimplemented in LuoSvendsen, and Liao.

Definition at line 84 of file binaryBreakupModel.C.

◆ addToBinaryBreakupRate()

virtual void addToBinaryBreakupRate ( volScalarField::Internal &  binaryBreakupRate,
const label  i,
const label  j
)
pure virtual

Add to binary breakupRate.

Implemented in powerLawUniformBinary, LuoSvendsen, Liao, and LehrMilliesMewes.

Member Data Documentation

◆ popBal_

const populationBalanceModel& popBal_
protected

Reference to the populationBalanceModel.

Definition at line 62 of file binaryBreakupModel.H.

The documentation for this class was generated from the following files:
