Inheritance diagram for pointInjection:

Collaboration diagram for pointInjection:

Public Member Functions
	TypeName ("pointInjection")
	Runtime type information. More...

	pointInjection (const word &name, const LagrangianMesh &mesh, const dictionary &modelDict, const dictionary &stateDict)
	Construct from components. More...

virtual void	correct ()
	Correct the LagrangianModel. More...

LagrangianSubMesh	modify (LagrangianMesh &mesh, const LagrangianSubMesh &) const
	Create new elements in the Lagrangian mesh. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

virtual bool	read (const dictionary &modelDict)
	Read dictionary. More...

virtual void	writeState (Ostream &os) const
	Write state. More...

Public Member Functions inherited from LagrangianInjection
	TypeName ("LagrangianInjection")
	Runtime type information. More...

	LagrangianInjection (const word &name, const LagrangianMesh &mesh)
	Construct from components. More...

virtual	~LagrangianInjection ()
	Destructor. More...

virtual bool	addsSupToField (const word &fieldName) const
	Return true if the LagrangianModel adds a source term to the. More...

Public Member Functions inherited from LagrangianModel
	TypeName ("LagrangianModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, LagrangianModel, dictionary,(const word &name, const LagrangianMesh &mesh, const dictionary &modelDict, const dictionary &stateDict),(name, mesh, modelDict, stateDict))
	Declare run-time constructor selection table. More...

	LagrangianModel (const word &name, const LagrangianMesh &mesh)
	Construct from components. More...

	LagrangianModel (const LagrangianModel &)=delete
	Disallow default bitwise copy construction. More...

autoPtr< LagrangianModel >	clone () const
	Clone. More...

virtual	~LagrangianModel ()
	Destructor. More...

const word &	name () const
	The source name. More...

const objectRegistry &	db () const
	The database. More...

const LagrangianMesh &	mesh () const
	The mesh. More...

virtual wordList	addSupFields () const
	Return the list of fields for which the LagrangianModel adds. More...

template<class Type , template< class > class PrimitiveField>
bool	addsSupToField (const LagrangianSubField< Type, PrimitiveField > &field) const
	Return true if the LagrangianModels adds a source term to the. More...

virtual void	postConstruct ()
	Do post construction steps which require access to other models. More...

virtual void	preModify (const LagrangianMesh &mesh, DynamicList< elementModification > &elementModifications) const
	Identify elements in the Lagrangian mesh which are to be. More...

virtual void	calculate (const LagrangianSubScalarField &deltaT, const bool final)
	Solve equations and/or update continually changing properties. More...

virtual void	addSup (const LagrangianSubScalarField &deltaT, LagrangianSubScalarField &S) const
	Add a fractional source term. More...

virtual bool	write (const bool write) const
	Write data. More...

void	operator= (const LagrangianModel &)=delete
	Disallow default bitwise assignment. More...

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
Foam::word	fieldName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)

template<class AlphaRhoFieldType >
Foam::word	fieldName (const AlphaRhoFieldType &alphaRhoField)

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
Foam::word	fieldsName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)

template<class AlphaRhoFieldType >
Foam::word	fieldsName (const AlphaRhoFieldType &alphaRhoField)

Public Member Functions inherited from stateModel
	stateModel ()
	Construct null. More...

	stateModel (const stateModel &)=delete
	Disallow default bitwise copy construction. More...

virtual	~stateModel ()
	Destructor. More...

bool	writeState (const bool write) const
	Write state. More...

virtual void	writeProcessorState (Ostream &os) const
	Write processor state. More...

void	operator= (const stateModel &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Public Types inherited from LagrangianModel
enum class	modification : label { change = 0 , remove = 1 }
	Enumeration of the types of instantaneous modification. More...

typedef LagrangianMesh::elementGroup< modification >	elementModification
	Class containing an element-index and a modification-enumeration. More...

Static Public Member Functions inherited from LagrangianModel
template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
static word	fieldName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)
	Return the name of the field associated with a source term. More...

template<class AlphaRhoFieldType >
static word	fieldName (const AlphaRhoFieldType &alphaRhoField)
	Return the name of the field associated with a source term (base. More...

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
static word	fieldsName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)
	Return the name of the product of the fields associated with a. More...

template<class AlphaRhoFieldType >
static word	fieldsName (const AlphaRhoFieldType &alphaRhoField)
	Return the name of the product of the fields associated with a. More...

static autoPtr< LagrangianModel >	New (const word &name, const LagrangianMesh &mesh, const dictionary &modelDict)
	Selector. More...

Static Public Member Functions inherited from stateModel
static dictionary	stateDict (const word &name, const objectRegistry &db)
	Construct and return the state dictionary for reading. More...

Protected Member Functions inherited from LagrangianInjection
void	checkLocation (const LagrangianMesh::location, const point &) const
	Check the location and error or warn as appropriate. More...

void	checkLocation (const List< LagrangianMesh::location > &, const List< point > &) const
	Check the locations and error or warn as appropriate. More...

Protected Member Functions inherited from LagrangianModel
template<class Type >
void	addSupType (const LagrangianSubScalarField &deltaT, const LagrangianSubSubField< Type > &field, LagrangianEqn< Type > &eqn) const
	Add a source term to an equation. More...

template<class Type >
void	addSupType (const LagrangianSubScalarField &deltaT, const LagrangianSubScalarSubField &m, const LagrangianSubSubField< Type > &field, LagrangianEqn< Type > &eqn) const
	Add a source term to a mass-weighted equation. More...

Static Protected Member Functions inherited from LagrangianInjection
template<class ... OtherFields>
static void	filter (barycentricField &coordinates, labelField &celli, labelField &facei, labelField &faceTrii, OtherFields &... otherFields)
	Filter out injected elements that are on other processes. These. More...

Detailed Description

Definition at line 96 of file pointInjection.H.

Constructor & Destructor Documentation

◆ pointInjection()

pointInjection	(	const word &	name,
		const LagrangianMesh &	mesh,
		const dictionary &	modelDict,
		const dictionary &	stateDict
	)

Construct from components.

Definition at line 76 of file pointInjection.C.

Member Function Documentation

◆ TypeName()

TypeName ( "pointInjection" )

Runtime type information.

◆ correct()

void correct ( )

virtual

Correct the LagrangianModel.

Reimplemented from LagrangianModel.

Definition at line 102 of file pointInjection.C.

References TimeState::deltaT(), mesh, p, fvMesh::time(), and dimensioned< Type >::value().

Here is the call graph for this function:

◆ modify()

Foam::LagrangianSubMesh modify	(	LagrangianMesh &	mesh,
		const LagrangianSubMesh &
	)		const

virtual

Create new elements in the Lagrangian mesh.

Reimplemented from LagrangianModel.

Definition at line 142 of file pointInjection.C.

References Foam::tracking::coordinates(), TimeState::deltaT(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, LagrangianMesh::fractionName, mesh, Foam::none, fvMesh::time(), timeIndex, and dimensioned< Type >::value().

Here is the call graph for this function:

◆ topoChange()

void topoChange ( const polyTopoChangeMap & )

virtual

Update topology using the given map.

Reimplemented from LagrangianModel.

Definition at line 251 of file pointInjection.C.

◆ mapMesh()

void mapMesh ( const polyMeshMap & )

virtual

Update from another mesh using the given map.

Reimplemented from LagrangianModel.

Definition at line 257 of file pointInjection.C.

◆ distribute()

void distribute ( const polyDistributionMap & )

virtual

Redistribute or update using the given distribution map.

Reimplemented from LagrangianModel.

Definition at line 263 of file pointInjection.C.

◆ read()

bool read ( const dictionary & modelDict )

virtual

Read dictionary.

Reimplemented from LagrangianModel.

Definition at line 269 of file pointInjection.C.

References LagrangianModel::read().

Here is the call graph for this function:

◆ writeState()

void writeState ( Ostream & os ) const

virtual

Write state.

Reimplemented from stateModel.

Definition at line 283 of file pointInjection.C.

References Foam::writeEntry(), and stateModel::writeState().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/Lagrangian/cloud/LagrangianModels/pointInjection/pointInjection.H
src/Lagrangian/cloud/LagrangianModels/pointInjection/pointInjection.C
