Base class for Lagrangian injections. Minimal wrapper over LagrangianSource. Implements some utility functions, and reports that all fields require a source value to be specified. Also serves as a type that can be identified and cast to. More...

Inheritance diagram for LagrangianInjection:

[legend]

Collaboration diagram for LagrangianInjection:

[legend]

Public Member Functions
	TypeName ("LagrangianInjection")
	Runtime type information. More...

	LagrangianInjection (const word &name, const LagrangianMesh &mesh)
	Construct from components. More...

virtual	~LagrangianInjection ()
	Destructor. More...

virtual bool	addsSupToField (const word &fieldName) const
	Return true if the LagrangianModel adds a source term to the. More...

Public Member Functions inherited from LagrangianModel
	TypeName ("LagrangianModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, LagrangianModel, dictionary,(const word &name, const LagrangianMesh &mesh, const dictionary &modelDict, const dictionary &stateDict),(name, mesh, modelDict, stateDict))
	Declare run-time constructor selection table. More...

	LagrangianModel (const word &name, const LagrangianMesh &mesh)
	Construct from components. More...

	LagrangianModel (const LagrangianModel &)=delete
	Disallow default bitwise copy construction. More...

autoPtr< LagrangianModel >	clone () const
	Clone. More...

virtual	~LagrangianModel ()
	Destructor. More...

const word &	name () const
	The source name. More...

const objectRegistry &	db () const
	The database. More...

const LagrangianMesh &	mesh () const
	The mesh. More...

virtual wordList	addSupFields () const
	Return the list of fields for which the LagrangianModel adds. More...

template<class Type , template< class > class PrimitiveField>
bool	addsSupToField (const LagrangianSubField< Type, PrimitiveField > &field) const
	Return true if the LagrangianModels adds a source term to the. More...

virtual void	postConstruct ()
	Do post construction steps which require access to other models. More...

virtual void	correct ()
	Correct the LagrangianModel. More...

virtual void	preModify (const LagrangianMesh &mesh, DynamicList< elementModification > &elementModifications) const
	Identify elements in the Lagrangian mesh which are to be. More...

virtual LagrangianSubMesh	modify (LagrangianMesh &mesh, const LagrangianSubMesh &modifiedMesh) const
	Instantaneously modify and/or create and remove elements in the. More...

virtual void	calculate (const LagrangianSubScalarField &deltaT, const bool final)
	Solve equations and/or update continually changing properties. More...

virtual void	addSup (const LagrangianSubScalarField &deltaT, LagrangianSubScalarField &S) const
	Add a fractional source term. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Add a source term to an equation. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

virtual bool	read (const dictionary &modelDict)
	Read dictionary. More...

virtual bool	write (const bool write) const
	Write data. More...

void	operator= (const LagrangianModel &)=delete
	Disallow default bitwise assignment. More...

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
Foam::word	fieldName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)

template<class AlphaRhoFieldType >
Foam::word	fieldName (const AlphaRhoFieldType &alphaRhoField)

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
Foam::word	fieldsName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)

template<class AlphaRhoFieldType >
Foam::word	fieldsName (const AlphaRhoFieldType &alphaRhoField)

Public Member Functions inherited from stateModel
	stateModel ()
	Construct null. More...

	stateModel (const stateModel &)=delete
	Disallow default bitwise copy construction. More...

virtual	~stateModel ()
	Destructor. More...

bool	writeState (const bool write) const
	Write state. More...

virtual void	writeState (Ostream &os) const
	Write state. More...

virtual void	writeProcessorState (Ostream &os) const
	Write processor state. More...

void	operator= (const stateModel &)=delete
	Disallow default bitwise assignment. More...

Protected Member Functions
void	checkLocation (const LagrangianMesh::location, const point &) const
	Check the location and error or warn as appropriate. More...

void	checkLocation (const List< LagrangianMesh::location > &, const List< point > &) const
	Check the locations and error or warn as appropriate. More...

Protected Member Functions inherited from LagrangianModel
template<class Type >
void	addSupType (const LagrangianSubScalarField &deltaT, const LagrangianSubSubField< Type > &field, LagrangianEqn< Type > &eqn) const
	Add a source term to an equation. More...

template<class Type >
void	addSupType (const LagrangianSubScalarField &deltaT, const LagrangianSubScalarSubField &m, const LagrangianSubSubField< Type > &field, LagrangianEqn< Type > &eqn) const
	Add a source term to a mass-weighted equation. More...

Static Protected Member Functions
template<class ... OtherFields>
static void	filter (barycentricField &coordinates, labelField &celli, labelField &facei, labelField &faceTrii, OtherFields &... otherFields)
	Filter out injected elements that are on other processes. These. More...

Additional Inherited Members
Public Types inherited from LagrangianModel
enum class	modification : label { change = 0 , remove = 1 }
	Enumeration of the types of instantaneous modification. More...

typedef LagrangianMesh::elementGroup< modification >	elementModification
	Class containing an element-index and a modification-enumeration. More...

Static Public Member Functions inherited from LagrangianModel
template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
static word	fieldName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)
	Return the name of the field associated with a source term. More...

template<class AlphaRhoFieldType >
static word	fieldName (const AlphaRhoFieldType &alphaRhoField)
	Return the name of the field associated with a source term (base. More...

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
static word	fieldsName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)
	Return the name of the product of the fields associated with a. More...

template<class AlphaRhoFieldType >
static word	fieldsName (const AlphaRhoFieldType &alphaRhoField)
	Return the name of the product of the fields associated with a. More...

static autoPtr< LagrangianModel >	New (const word &name, const LagrangianMesh &mesh, const dictionary &modelDict)
	Selector. More...

Static Public Member Functions inherited from stateModel
static dictionary	stateDict (const word &name, const objectRegistry &db)
	Construct and return the state dictionary for reading. More...

Detailed Description

Base class for Lagrangian injections. Minimal wrapper over LagrangianSource. Implements some utility functions, and reports that all fields require a source value to be specified. Also serves as a type that can be identified and cast to.

Source files

Definition at line 53 of file LagrangianInjection.H.

Constructor & Destructor Documentation

◆ LagrangianInjection()

LagrangianInjection	(	const word &	name,
		const LagrangianMesh &	mesh
	)

Construct from components.

Definition at line 93 of file LagrangianInjection.C.

◆ ~LagrangianInjection()

~LagrangianInjection ( )

virtual

Destructor.

Definition at line 105 of file LagrangianInjection.C.

Member Function Documentation

◆ checkLocation() [1/2]

void checkLocation	(	const LagrangianMesh::location	location,
		const point &	p
	)		const

protected

Check the location and error or warn as appropriate.

Definition at line 40 of file LagrangianInjection.C.

References Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, LagrangianMesh::inCell, LagrangianMesh::onBoundary, LagrangianMesh::outsideMesh, p, and WarningInFunction.

Here is the call graph for this function:

◆ checkLocation() [2/2]

void checkLocation	(	const List< LagrangianMesh::location > &	locations,
		const List< point > &	points
	)		const

protected

Check the locations and error or warn as appropriate.

Definition at line 67 of file LagrangianInjection.C.

References p, points, and List< T >::size().

Here is the call graph for this function:

◆ filter()

void filter	(	barycentricField &	coordinates,
		labelField &	celli,
		labelField &	facei,
		labelField &	faceTrii,
		OtherFields &...	otherFields
	)

staticprotected

Filter out injected elements that are on other processes. These.

are identified by cell/face/faceTri indices equal to -1.

Definition at line 31 of file LagrangianInjectionTemplates.C.

References Foam::tracking::coordinates(), forAll, and List< T >::resize().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "LagrangianInjection" )

Runtime type information.

◆ addsSupToField()

bool addsSupToField ( const word & fieldName ) const

virtual

Return true if the LagrangianModel adds a source term to the.

given field's transport equation. Returns false. Injections are instantaneous. They do not create continuous sources.

Reimplemented from LagrangianModel.

Definition at line 111 of file LagrangianInjection.C.

The documentation for this class was generated from the following files:

src/Lagrangian/Lagrangian/LagrangianModels/LagrangianInjection/LagrangianInjection.H
src/Lagrangian/Lagrangian/LagrangianModels/LagrangianInjection/LagrangianInjection.C
src/Lagrangian/Lagrangian/LagrangianModels/LagrangianInjection/LagrangianInjectionTemplates.C
