Public Member Functions | |
| TypeName ("SaffmanMeiLift") | |
| Runtime type information. More... | |
| SaffmanMeiLift (const word &name, const LagrangianMesh &mesh, const dictionary &modelDict, const dictionary &stateDict) | |
| Construct from components. More... | |
| virtual wordList | addSupFields () const |
| Return the name of the velocity field. More... | |
| virtual void | addSup (const LagrangianSubScalarField &deltaT, const LagrangianSubVectorSubField &U, LagrangianEqn< vector > &eqn) const |
| Add a source term to the velocity equation. More... | |
| virtual void | addSup (const LagrangianSubScalarField &deltaT, const LagrangianSubScalarSubField &vOrM, const LagrangianSubVectorSubField &U, LagrangianEqn< vector > &eqn) const |
| Add a source term to the momentum equation. More... | |
 Public Member Functions inherited from LagrangianModel | |
| TypeName ("LagrangianModel") | |
| Runtime type information. More... | |
| declareRunTimeSelectionTable (autoPtr, LagrangianModel, dictionary,(const word &name, const LagrangianMesh &mesh, const dictionary &modelDict, const dictionary &stateDict),(name, mesh, modelDict, stateDict)) | |
| Declare run-time constructor selection table. More... | |
| LagrangianModel (const word &name, const LagrangianMesh &mesh) | |
| Construct from components. More... | |
| LagrangianModel (const LagrangianModel &)=delete | |
| Disallow default bitwise copy construction. More... | |
| autoPtr< LagrangianModel > | clone () const |
| Clone. More... | |
| virtual | ~LagrangianModel () |
| Destructor. More... | |
| const word & | name () const |
| The source name. More... | |
| const objectRegistry & | db () const |
| The database. More... | |
| const LagrangianMesh & | mesh () const |
| The mesh. More... | |
| virtual bool | addsSupToField (const word &) const |
| Return true if the LagrangianModel adds a source term to the. More... | |
| template<class Type , template< class > class PrimitiveField> | |
| bool | addsSupToField (const LagrangianSubField< Type, PrimitiveField > &field) const |
| Return true if the LagrangianModels adds a source term to the. More... | |
| virtual void | postConstruct () |
| Do post construction steps which require access to other models. More... | |
| virtual void | correct () |
| Correct the LagrangianModel. More... | |
| virtual void | preModify (const LagrangianMesh &mesh, DynamicList< elementModification > &elementModifications) const |
| Identify elements in the Lagrangian mesh which are to be. More... | |
| virtual LagrangianSubMesh | modify (LagrangianMesh &mesh, const LagrangianSubMesh &modifiedMesh) const |
| Instantaneously modify and/or create and remove elements in the. More... | |
| virtual void | calculate (const LagrangianSubScalarField &deltaT, const bool final) |
| Solve equations and/or update continually changing properties. More... | |
| virtual void | addSup (const LagrangianSubScalarField &deltaT, LagrangianSubScalarField &S) const |
| Add a fractional source term. More... | |
| virtual void | topoChange (const polyTopoChangeMap &) |
| Add a source term to an equation. More... | |
| virtual void | mapMesh (const polyMeshMap &) |
| Update from another mesh using the given map. More... | |
| virtual void | distribute (const polyDistributionMap &) |
| Redistribute or update using the given distribution map. More... | |
| virtual bool | read (const dictionary &modelDict) |
| Read dictionary. More... | |
| virtual bool | write (const bool write) const |
| Write data. More... | |
| void | operator= (const LagrangianModel &)=delete |
| Disallow default bitwise assignment. More... | |
| template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes> | |
| Foam::word | fieldName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields) |
| template<class AlphaRhoFieldType > | |
| Foam::word | fieldName (const AlphaRhoFieldType &alphaRhoField) |
| template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes> | |
| Foam::word | fieldsName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields) |
| template<class AlphaRhoFieldType > | |
| Foam::word | fieldsName (const AlphaRhoFieldType &alphaRhoField) |
| Public Member Functions inherited from stateModel | |
| stateModel () | |
| Construct null. More... | |
| stateModel (const stateModel &)=delete | |
| Disallow default bitwise copy construction. More... | |
| virtual | ~stateModel () |
| Destructor. More... | |
| bool | writeState (const bool write) const |
| Write state. More... | |
| virtual void | writeState (Ostream &os) const |
| Write state. More... | |
| virtual void | writeProcessorState (Ostream &os) const |
| Write processor state. More... | |
| void | operator= (const stateModel &)=delete |
| Disallow default bitwise assignment. More... | |
Public Attributes | |
| const CloudDerivedField< tensor > & | L |
| Lift force. More... | |
Additional Inherited Members | |
| Public Types inherited from LagrangianModel | |
| enum class | modification : label { change = 0 , remove = 1 } |
| Enumeration of the types of instantaneous modification. More... | |
| typedef LagrangianMesh::elementGroup< modification > | elementModification |
| Class containing an element-index and a modification-enumeration. More... | |
| Static Public Member Functions inherited from LagrangianModel | |
| template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes> | |
| static word | fieldName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields) |
| Return the name of the field associated with a source term. More... | |
| template<class AlphaRhoFieldType > | |
| static word | fieldName (const AlphaRhoFieldType &alphaRhoField) |
| Return the name of the field associated with a source term (base. More... | |
| template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes> | |
| static word | fieldsName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields) |
| Return the name of the product of the fields associated with a. More... | |
| template<class AlphaRhoFieldType > | |
| static word | fieldsName (const AlphaRhoFieldType &alphaRhoField) |
| Return the name of the product of the fields associated with a. More... | |
| static autoPtr< LagrangianModel > | New (const word &name, const LagrangianMesh &mesh, const dictionary &modelDict) |
| Selector. More... | |
| Static Public Member Functions inherited from stateModel | |
| static dictionary | stateDict (const word &name, const objectRegistry &db) |
| Construct and return the state dictionary for reading. More... | |
| Protected Member Functions inherited from LagrangianModel | |
| template<class Type > | |
| void | addSupType (const LagrangianSubScalarField &deltaT, const LagrangianSubSubField< Type > &field, LagrangianEqn< Type > &eqn) const |
| Add a source term to an equation. More... | |
| template<class Type > | |
| void | addSupType (const LagrangianSubScalarField &deltaT, const LagrangianSubScalarSubField &m, const LagrangianSubSubField< Type > &field, LagrangianEqn< Type > &eqn) const |
| Add a source term to a mass-weighted equation. More... | |
Definition at line 73 of file SaffmanMeiLift.H.
| SaffmanMeiLift | ( | const word & | name, |
| const LagrangianMesh & | mesh, | ||
| const dictionary & | modelDict, | ||
| const dictionary & | stateDict | ||
| ) |
Construct from components.
Definition at line 126 of file SaffmanMeiLift.C.
| TypeName | ( | "SaffmanMeiLift" | ) |
Runtime type information.
|
virtual |
Return the name of the velocity field.
Reimplemented from LagrangianModel.
Definition at line 151 of file SaffmanMeiLift.C.
References U.
|
virtual |
Add a source term to the velocity equation.
Definition at line 157 of file SaffmanMeiLift.C.
References U.
|
virtual |
Add a source term to the momentum equation.
Definition at line 170 of file SaffmanMeiLift.C.
References U.
| const CloudDerivedField<tensor>& L |
Lift force.
Definition at line 106 of file SaffmanMeiLift.H.
