A field derived from other state fields of the cloud. Stores and virtualises a function or a method which generates the field. Caches the result to prevent unnecessary re-evaluation during a calculation step. Provides convenient access for a variety of contexts; i.e., full mesh, sub-mesh and model. More...
Classes | |
| class | AllFieldToField |
| class | Function |
| Class to store an evaluation function. More... | |
| class | Functor |
| class | Method |
| Class to store an evaluation method. More... | |
Public Member Functions | |
| template<class F > | |
| CloudDerivedField (const word &name, const F &f) | |
| Construct from a name and a function. More... | |
| template<class F > | |
| CloudDerivedField (const F &f) | |
| Construct from a function. More... | |
| template<class C > | |
| CloudDerivedField (const word &name, const C &c, tmp< LagrangianSubField< Type >>(C::*m)(const LagrangianModelRef &, const LagrangianSubMesh &) const) | |
| Construct from a name, class and a method. More... | |
| template<class C > | |
| CloudDerivedField (const C &c, tmp< LagrangianSubField< Type >>(C::*m)(const LagrangianModelRef &, const LagrangianSubMesh &) const) | |
| Construct from a class and a method. More... | |
| CloudDerivedField (const CloudDerivedField &)=delete | |
| Disallow default bitwise copy construction. More... | |
| tmp< LagrangianInternalField< Type > > | field (const LagrangianMesh &mesh) const |
| Compute and return an independent copy of the entire field. More... | |
| LagrangianSubSubField< Type > & | ref (const LagrangianSubMesh &) const |
| Access a part of the field. More... | |
| void | clear (const bool final) |
| Clear. More... | |
| tmp< LagrangianInternalField< Type > > | operator() (const LagrangianMesh &mesh) const |
| Compute and return the entire field. This will be a slice of the. More... | |
| const LagrangianSubField< Type > & | operator() (const LagrangianSubMesh &subMesh) const |
| Compute and access a part of the field. More... | |
| const LagrangianSubField< Type > & | operator() (const LagrangianModelRef &model, const LagrangianSubMesh &subMesh) const |
| Compute and access a part of the field associated with a model. More... | |
| void | operator= (const CloudDerivedField &)=delete |
| Disallow default bitwise assignment. More... | |
A field derived from other state fields of the cloud. Stores and virtualises a function or a method which generates the field. Caches the result to prevent unnecessary re-evaluation during a calculation step. Provides convenient access for a variety of contexts; i.e., full mesh, sub-mesh and model.
Definition at line 56 of file CloudDerivedField.H.
| CloudDerivedField | ( | const word & | name, |
| const F & | f | ||
| ) |
Construct from a name and a function.
Definition at line 220 of file CloudDerivedField.C.
| CloudDerivedField | ( | const F & | f | ) |
Construct from a function.
Definition at line 229 of file CloudDerivedField.C.
| CloudDerivedField | ( | const word & | name, |
| const C & | c, | ||
| tmp< LagrangianSubField< Type >>(C::*)(const LagrangianModelRef &, const LagrangianSubMesh &) const | m | ||
| ) |
Construct from a name, class and a method.
Definition at line 238 of file CloudDerivedField.C.
| CloudDerivedField | ( | const C & | c, |
| tmp< LagrangianSubField< Type >>(C::*)(const LagrangianModelRef &, const LagrangianSubMesh &) const | m | ||
| ) |
Construct from a class and a method.
Definition at line 256 of file CloudDerivedField.C.
|
delete |
Disallow default bitwise copy construction.
| Foam::tmp< Foam::LagrangianInternalField< Type > > field | ( | const LagrangianMesh & | mesh | ) | const |
Compute and return an independent copy of the entire field.
Definition at line 275 of file CloudDerivedField.C.
References DimensionedField< Type, GeoMesh, PrimitiveField >::dimensions(), mesh, IOobject::name(), DimensionedField< Type, GeoMesh, PrimitiveField >::New(), DimensionedField< Type, GeoMesh, PrimitiveField >::primitiveField(), and tmp< T >::ref().
| Foam::LagrangianSubSubField< Type > & ref | ( | const LagrangianSubMesh & | subMesh | ) | const |
Access a part of the field.
Definition at line 295 of file CloudDerivedField.C.
References LagrangianSubMesh::index().
| void clear | ( | const bool | final | ) |
Clear.
Definition at line 325 of file CloudDerivedField.C.
Referenced by CloudAverageField< Type >::add(), CloudAverageField< Type >::correct(), CloudAverageField< Type >::remove(), CloudAverageField< Type >::reset(), and CarrierField< Type >::reset().
| Foam::tmp< Foam::LagrangianInternalField< Type > > operator() | ( | const LagrangianMesh & | mesh | ) | const |
Compute and return the entire field. This will be a slice of the.
cached sub-all-field, for which the lifetime is not guaranteed. If the result is being stored (e.g., by a function object) then this might not be appropriate, and the 'field' method should be used instead.
Definition at line 349 of file CloudDerivedField.C.
References mesh.
| const Foam::LagrangianSubField< Type > & operator() | ( | const LagrangianSubMesh & | subMesh | ) | const |
Compute and access a part of the field.
Definition at line 365 of file CloudDerivedField.C.
| const Foam::LagrangianSubField< Type > & operator() | ( | const LagrangianModelRef & | model, |
| const LagrangianSubMesh & | subMesh | ||
| ) | const |
Compute and access a part of the field associated with a model.
Definition at line 376 of file CloudDerivedField.C.
References Foam::name(), and Foam::notNull().
|
delete |
Disallow default bitwise assignment.
