A sampledSurface from a triSurface. It samples on the points/triangles of the triSurface. It either samples cells or (non-coupled) boundary faces. More...

Inheritance diagram for triSurface:

[legend]

Collaboration diagram for triSurface:

[legend]

Public Types
enum	samplingSource { cells , insideCells , boundaryFaces }
	Types of communications. More...

Public Types inherited from MeshedSurface< face >
typedef face	FaceType
	Face type used. More...

Public Types inherited from PrimitivePatch< FaceList, PointField >
enum	surfaceTopo { MANIFOLD , OPEN , ILLEGAL }
	Enumeration defining the surface type. Used in check routines. More...

typedef FaceList	FaceListType

typedef std::remove_reference< FaceList >::type::value_type	FaceType

typedef PointField	PointFieldType

typedef std::remove_reference< PointField >::type::value_type	PointType

Public Member Functions
	TypeName ("triSurface")
	Runtime type information. More...

	triSurface (const word &name, const polyMesh &mesh, const word &surfaceName, const samplingSource sampleSource)
	Construct from components. More...

	triSurface (const word &name, const polyMesh &mesh, const dictionary &dict)
	Construct from dictionary. More...

	triSurface (const word &name, const polyMesh &mesh, const Foam::triSurface &surface, const word &sampleSourceName)
	Construct from triSurface. More...

virtual	~triSurface ()
	Destructor. More...

virtual bool	needsUpdate () const
	Does the surface need an update? More...

virtual bool	update ()
	Update the surface as required. More...

virtual const pointField &	points () const
	Points of surface. More...

virtual const faceList &	faces () const
	Faces of surface. More...

	FOR_ALL_FIELD_TYPES (DEFINE_SAMPLE)

	FOR_ALL_FIELD_TYPES (DEFINE_INTERPOLATE)

virtual void	movePoints ()
	Update for mesh point-motion. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

virtual void	print (Ostream &) const
	Write. More...

template<class Type >
Foam::tmp< Foam::Field< Type > >	sampleField (const VolField< Type > &vField) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	interpolateField (const interpolation< Type > &interpolator) const

Public Member Functions inherited from sampledSurface
	TypeName ("sampledSurface")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, sampledSurface, word,(const word &name, const polyMesh &mesh, const dictionary &dict),(name, mesh, dict))
	Declare run-time constructor selection table. More...

	sampledSurface (const word &name, const polyMesh &, const bool interpolate=false)
	Construct from name, mesh. More...

	sampledSurface (const word &name, const polyMesh &, const dictionary &)
	Construct from dictionary. More...

autoPtr< sampledSurface >	clone () const
	Clone. More...

virtual	~sampledSurface ()
	Destructor. More...

const polyMesh &	mesh () const
	Access to the underlying mesh. More...

const word &	name () const
	Name of surface. More...

bool	interpolate () const
	Interpolation requested for surface. More...

virtual wordList	fields () const
	Return the list of fields required. More...

virtual const vectorField &	Sf () const
	Return face area vectors. More...

virtual const scalarField &	magSf () const
	Return face area magnitudes. More...

virtual const vectorField &	Cf () const
	Return face centres as vectorField. More...

scalar	area () const
	The total surface area. More...

template<class Type >
Type	integrate (const Field< Type > &) const
	Integration of a field across the surface. More...

template<class Type >
Type	integrate (const tmp< Field< Type >> &) const
	Integration of a field across the surface. More...

template<class Type >
Type	average (const Field< Type > &) const
	Area-averaged value of a field across the surface. More...

tmp< Field< scalar > >	project (const Field< scalar > &) const
	Project field onto surface. More...

tmp< Field< scalar > >	project (const Field< vector > &) const
	Project field onto surface. More...

tmp< Field< vector > >	project (const Field< sphericalTensor > &) const
	Project field onto surface. More...

tmp< Field< vector > >	project (const Field< symmTensor > &) const
	Project field onto surface. More...

tmp< Field< vector > >	project (const Field< tensor > &) const
	Project field onto surface. More...

template<class Type >
Type	average (const tmp< Field< Type >> &) const
	Area-averaged value of a field across the surface. More...

	FOR_ALL_FIELD_TYPES (DEFINE_SAMPLE)

	FOR_ALL_FIELD_TYPES (DEFINE_INTERPOLATE)

virtual void	rename (const word &newName)
	Rename. More...

template<class ReturnType , class Type >
Foam::tmp< Foam::Field< ReturnType > >	project (const tmp< Field< Type >> &field) const

Public Member Functions inherited from MeshedSurface< face >
	MeshedSurface ()
	Construct null. More...

	MeshedSurface (pointField &&, List< face > &&, surfZoneList &&)
	Construct by transferring components (points, faces, zones). More...

	MeshedSurface (pointField &&, List< face > &&, const labelUList &zoneSizes=labelUList(), const UList< word > &zoneNames=UList< word >())
	Construct by transferring components (points, faces). More...

	MeshedSurface (const MeshedSurface &)
	Copy constructor. More...

	MeshedSurface (const UnsortedMeshedSurface< face > &)
	Construct from a UnsortedMeshedSurface. More...

	MeshedSurface (const polyBoundaryMesh &, const bool globalPoints=false)
	Construct from a boundary mesh with local points/faces. More...

	MeshedSurface (const surfMesh &)
	Construct from a surfMesh. More...

	MeshedSurface (UnsortedMeshedSurface< face > &&)
	Construct by transferring the contents from a UnsortedMeshedSurface. More...

	MeshedSurface (MeshedSurface< face > &&)
	Construct by transferring the contents from a MeshedSurface. More...

	MeshedSurface (const fileName &)
	Construct from file name (uses extension to determine type) More...

	MeshedSurface (const fileName &, const word &ext)
	Construct from file name (uses extension to determine type) More...

	MeshedSurface (const Time &, const word &surfName="")
	Construct from database. More...

	MeshedSurface (const MeshedSurface< face > &surf)

	ClassName ("MeshedSurface")
	Runtime type information. More...

bool	isTri ()
	Specialisation for holding triangulated information. More...

	declareRunTimeSelectionTable (autoPtr, MeshedSurface, fileExtension,(const fileName &name),(name))

virtual	~MeshedSurface ()
	Destructor. More...

	declareMemberFunctionSelectionTable (void, UnsortedMeshedSurface, write, fileExtension,(const fileName &name, const MeshedSurface< face > &surf),(name, surf))

virtual void	write (const fileName &name) const
	Generic write routine. Chooses writer based on extension. More...

void	write (const Time &, const word &surfName="") const
	Write to database. More...

label	size () const
	The surface size is the number of faces. More...

const List< face > &	faces () const
	Return const access to the faces. More...

const List< surfZone > &	surfZones () const
	Const access to the surface zones. More...

List< surfZone > &	surfZones ()
	Non-const access to the surface zones. More...

virtual void	addZones (const UList< surfZone > &, const bool cullEmpty=false)
	Add surface zones. More...

virtual void	addZones (const labelUList &sizes, const UList< word > &names, const bool cullEmpty=false)
	Add surface zones. More...

virtual void	addZones (const labelUList &sizes, const bool cullEmpty=false)
	Add surface zones. More...

virtual void	removeZones ()
	Remove surface zones. More...

virtual void	clear ()
	Clear all storage. More...

virtual void	setPoints (const pointField &)
	Reset the points. More...

virtual void	scalePoints (const scalar)
	Scale points. A non-positive factor is ignored. More...

virtual void	reset (pointField &&points, List< face > &&faces, surfZoneList &&zones)
	Reset primitive data (points, faces and zones) More...

virtual void	reset (List< point > &&points, List< face > &&faces, surfZoneList &&zones)
	Reset primitive data (points, faces and zones) More...

virtual void	cleanup (const bool verbose)
	Remove invalid faces. More...

virtual bool	stitchFaces (const scalar tol=small, const bool verbose=false)

virtual bool	checkFaces (const bool verbose=false)

virtual label	triangulate ()
	Triangulate in-place, returning the number of triangles added. More...

virtual label	triangulate (List< label > &faceMap)
	Triangulate in-place, returning the number of triangles added. More...

label	triangulate ()
	Specialisation for holding triangulated information. More...

label	triangulate (List< label > &faceMap)
	Specialisation for holding triangulated information. More...

MeshedSurface	subsetMesh (const labelHashSet &include, labelList &pointMap, labelList &faceMap) const
	Return new surface. More...

MeshedSurface	subsetMesh (const labelHashSet &include) const
	Return new surface. More...

void	transfer (MeshedSurface< face > &)
	Transfer the contents of the argument and annul the argument. More...

void	transfer (UnsortedMeshedSurface< face > &)
	Transfer the contents of the argument and annul the argument. More...

bool	read (const fileName &, const word &ext)
	Read from file. Chooses reader based on explicit extension. More...

virtual bool	read (const fileName &)
	Read from file. Chooses reader based on detected extension. More...

void	writeStats (Ostream &os) const

void	operator= (const MeshedSurface< face > &)

	operator MeshedSurfaceProxy< face > () const
	Conversion operator to MeshedSurfaceProxy. More...

Public Member Functions inherited from PrimitivePatch< FaceList, PointField >
	PrimitivePatch (const FaceList &faces, const Field< PointType > &points)
	Construct from components. More...

	PrimitivePatch (FaceList &&faces, Field< PointType > &&points)
	Move constructor from components. More...

	PrimitivePatch (FaceList &faces, Field< PointType > &points, const bool reuse)
	Construct from components, reuse storage. More...

	PrimitivePatch (const PrimitivePatch< FaceList, PointField > &)
	Copy constructor. More...

	PrimitivePatch (PrimitivePatch< FaceList, PointField > &&)
	Move constructor. More...

autoPtr< PrimitivePatch< FaceList, PointField > >	clone () const
	Construct and return a clone. More...

	~PrimitivePatch ()
	Destructor. More...

const Field< PointType > &	points () const
	Return reference to global points. More...

label	nPoints () const
	Return number of points supporting patch faces. More...

label	nEdges () const
	Return number of edges in patch. More...

const edgeList &	edges () const
	Return list of edges, address into LOCAL point list. More...

label	nInternalEdges () const
	Number of internal edges. More...

bool	isInternalEdge (const label edgeI) const
	Is internal edge? More...

const labelList &	boundaryPoints () const
	Return list of boundary points,. More...

const labelListList &	faceFaces () const
	Return face-face addressing. More...

const labelListList &	edgeFaces () const
	Return edge-face addressing. More...

const labelListList &	faceEdges () const
	Return face-edge addressing. More...

const labelListList &	pointEdges () const
	Return point-edge addressing. More...

const labelListList &	pointFaces () const
	Return point-face addressing. More...

const List< FaceType > &	localFaces () const
	Return patch faces addressing into local point list. More...

const labelList &	meshPoints () const
	Return labelList of mesh points in patch. They are constructed. More...

const Map< label > &	meshPointMap () const
	Mesh point map. Given the global point index find its. More...

const Field< PointType > &	localPoints () const
	Return pointField of points in patch. More...

const labelList &	localPointOrder () const
	Return orders the local points for most efficient search. More...

label	whichPoint (const label gp) const
	Given a global point index, return the local point index. More...

label	whichEdge (const edge &) const
	Given an edge in local point labels, return its. More...

labelList	meshEdges (const edgeList &allEdges, const labelListList &cellEdges, const labelList &faceCells) const
	Return labels of patch edges in the global edge list using. More...

labelList	meshEdges (const edgeList &allEdges, const labelListList &pointEdges) const
	Return labels of patch edges in the global edge list using. More...

const Field< PointType > &	faceCentres () const
	Return face centres for patch. More...

const Field< PointType > &	faceAreas () const
	Return face areas for patch. More...

const Field< PointType > &	faceNormals () const
	Return face normals for patch. More...

const Field< PointType > &	pointNormals () const
	Return point normals for patch. More...

template<class ToPatch >
List< objectHit >	projectPoints (const ToPatch &targetPatch, const Field< PointType > &projectionDirection, const intersection::algorithm=intersection::algorithm::fullRay, const intersection::direction=intersection::direction::vector) const
	Project vertices of patch onto another patch. More...

template<class ToPatch >
List< objectHit >	projectFaceCentres (const ToPatch &targetPatch, const Field< PointType > &projectionDirection, const intersection::algorithm=intersection::algorithm::fullRay, const intersection::direction=intersection::direction::vector) const
	Project vertices of patch onto another patch. More...

const labelListList &	edgeLoops () const
	Return list of closed loops of boundary vertices. More...

surfaceTopo	surfaceType () const
	Calculate surface type formed by patch. More...

bool	checkTopology (const bool report=false, labelHashSet *setPtr=nullptr) const
	Check surface formed by patch for manifoldness (see above). More...

bool	checkPointManifold (const bool report=false, labelHashSet *setPtr=nullptr) const
	Checks primitivePatch for faces sharing point but not edge. More...

void	clearOut ()

void	clearGeom ()

void	clearTopology ()

void	clearPatchMeshAddr ()

void	operator= (const PrimitivePatch< FaceList, PointField > &)
	Assignment operator. More...

void	operator= (PrimitivePatch< FaceList, PointField > &&)
	Move assignment operator. More...

template<class ToPatch >
Foam::List< Foam::objectHit >	projectPoints (const ToPatch &targetPatch, const Field< PointType > &projectionDirection, const intersection::algorithm alg, const intersection::direction dir) const

template<class ToPatch >
Foam::List< Foam::objectHit >	projectFaceCentres (const ToPatch &targetPatch, const Field< PointType > &projectionDirection, const intersection::algorithm alg, const intersection::direction dir) const

Static Public Attributes
static const NamedEnum< samplingSource, 3 >	samplingSourceNames_
	Names of communication types. More...

Static Public Attributes inherited from surfaceFormatsCore
static word	nativeExt
	The file extension corresponding to 'native' surface format. More...

Additional Inherited Members
Static Public Member Functions inherited from sampledSurface
static autoPtr< sampledSurface >	New (const word &name, const polyMesh &, const dictionary &)
	Return a reference to the selected surface. More...

Static Public Member Functions inherited from MeshedSurface< face >
static bool	isTri ()
	Face storage only handles triangulated faces. More...

static bool	canRead (const fileName &, const bool verbose=false)
	Can we read this file format? More...

static bool	canReadType (const word &ext, const bool verbose=false)
	Can we read this file format? More...

static bool	canWriteType (const word &ext, const bool verbose=false)
	Can we write this file format? More...

static wordHashSet	readTypes ()

static wordHashSet	writeTypes ()

static autoPtr< MeshedSurface >	New (const fileName &, const word &ext)
	Select constructed from filename (explicit extension) More...

static autoPtr< MeshedSurface >	New (const fileName &)
	Select constructed from filename (implicit extension) More...

static void	write (const fileName &, const MeshedSurface< face > &)
	Write to file. More...

Static Public Member Functions inherited from surfaceFormatsCore
static bool	checkSupport (const wordHashSet &available, const word &ext, const bool verbose, const word &functionName)
	... More...

Protected Member Functions inherited from sampledSurface
virtual void	clearGeom () const

Protected Member Functions inherited from MeshedSurface< face >
void	transcribe (MeshedSurface< face > &)
	Transfer points/zones and transcribe face -> triFace. More...

void	transcribe (MeshedSurface< face > &surf)

void	transcribe (MeshedSurface< face > &surf)

void	checkZones ()
	Basic sanity check on zones. More...

pointField &	storedPoints ()
	Non-const access to global points. More...

List< face > &	storedFaces ()
	Non-const access to the faces. More...

surfZoneList &	storedZones ()
	Non-const access to the zones. More...

void	sortFacesAndStore (List< face > &&unsortedFaces, List< label > &&zoneIds, const bool sorted)
	Sort faces by zones and store sorted faces. More...

virtual void	remapFaces (const labelUList &faceMap)
	Set new zones from faceMap. More...

Static Protected Member Functions inherited from surfaceFormatsCore
template<class Container >
static List< surfZone >	oneZone (const Container &container, const word &name="zone0")
	Return a list with a single entry,. More...

static string	getLineNoComment (IFstream &)
	Read non-comment line. More...

Detailed Description

A sampledSurface from a triSurface. It samples on the points/triangles of the triSurface. It either samples cells or (non-coupled) boundary faces.

There are 6 possible modes:

source=cells, interpolate=false: Finds per triangle centre the nearest cell centre and uses its value.
source=cells, interpolate=true Finds per triangle centre the nearest cell centre. Per surface point checks if this nearest cell is the one containing point; otherwise projects the point onto the nearest point on the boundary of the cell (to make sure interpolateCellPoint gets a valid location)
source=insideCells, interpolate=false: Finds per triangle centre the cell containing it and uses its value. Trims triangles outside mesh.
source=insideCells, interpolate=true Per surface point interpolate cell containing it.
source=boundaryFaces, interpolate=false: Finds per triangle centre the nearest point on the boundary (uncoupled faces only) and uses the value (or 0 if the nearest is on an empty boundary).
source=boundaryFaces, interpolate=true: Finds per triangle centre the nearest point on the boundary (uncoupled faces only). Per surface point projects the point onto this boundary face (to make sure interpolateCellPoint gets a valid location)

Since it finds a nearest per triangle each triangle is guaranteed to be on one processor only. So after stitching (by sampledSurfaces) the original surface should be complete.

Example:

{
    type        triSurface;
    surface     "surface.stl";
    source      cells;
    interpolate yes;
}

Usage

Property	Description	Required	Default value
`surface`	the surface file (within constant/triSurface)	yes
`source`	see above	yes	no
`interpolate`	see above	no	no

Source files

Definition at line 126 of file sampledTriSurface.H.

Member Enumeration Documentation

◆ samplingSource

enum samplingSource

Types of communications.

Enumerator
cells
insideCells
boundaryFaces

Definition at line 136 of file sampledTriSurface.H.

Constructor & Destructor Documentation

◆ triSurface() [1/3]

triSurface	(	const word &	name,
		const polyMesh &	mesh,
		const word &	surfaceName,
		const samplingSource	sampleSource
	)

Construct from components.

Definition at line 148 of file sampledTriSurface.C.

◆ triSurface() [2/3]

triSurface	(	const word &	name,
		const polyMesh &	mesh,
		const dictionary &	dict
	)

Construct from dictionary.

Definition at line 177 of file sampledTriSurface.C.

◆ triSurface() [3/3]

triSurface	(	const word &	name,
		const polyMesh &	mesh,
		const Foam::triSurface &	surface,
		const word &	sampleSourceName
	)

Construct from triSurface.

Definition at line 205 of file sampledTriSurface.C.

◆ ~triSurface()

~triSurface ( )

virtual

Destructor.

Definition at line 237 of file sampledTriSurface.C.

Member Function Documentation

◆ TypeName()

TypeName ( "triSurface" )

Runtime type information.

◆ needsUpdate()

bool needsUpdate ( ) const

virtual

Does the surface need an update?

Implements sampledSurface.

Definition at line 243 of file sampledTriSurface.C.

◆ update()

bool update ( )

virtual

Update the surface as required.

Do nothing (and return false) if no update was needed

Implements sampledSurface.

Definition at line 249 of file sampledTriSurface.C.

References indexedOctree< Type >::bb(), cells, primitiveMesh::cells(), meshSearch::cellTree(), List< T >::clear(), treeBoundBox::contains(), PointHit< Point >::distance(), Foam::endl(), f(), Foam::faceMap(), Foam::facePlanes, polyMesh::faces(), indexedOctree< Type >::findInside(), UList< T >::first(), forAll, Foam::Info, sampledSurface::interpolate(), globalIndex::isLocal(), Foam::labelMax, Pstream::listCombineGather(), Pstream::listCombineScatter(), Foam::magSqr(), mesh, OFstream::name(), meshSearch::New(), newPointi, Foam::pointInCellFacePlanes(), points, Foam::Pout, PointHit< Point >::rawPoint(), s(), Foam::second(), List< T >::setSize(), indexedOctree< Type >::shapes(), List< T >::size(), Foam::sqr(), Foam::dimensions::time, globalIndex::toGlobal(), globalIndex::toLocal(), triFace::triFaceFace(), and OBJstream::write().

Here is the call graph for this function:

◆ points()

virtual const pointField& points ( ) const

inlinevirtual

Points of surface.

Implements sampledSurface.

Definition at line 237 of file sampledTriSurface.H.

References PrimitivePatch<::Foam::List< Face >, pointField >::points().

Here is the call graph for this function:

◆ faces()

virtual const faceList& faces ( ) const

inlinevirtual

Faces of surface.

Implements sampledSurface.

Definition at line 243 of file sampledTriSurface.H.

References MeshedSurface< Face >::faces().

Here is the call graph for this function:

◆ FOR_ALL_FIELD_TYPES() [1/2]

FOR_ALL_FIELD_TYPES ( DEFINE_SAMPLE )

◆ FOR_ALL_FIELD_TYPES() [2/2]

FOR_ALL_FIELD_TYPES ( DEFINE_INTERPOLATE )

◆ movePoints()

void movePoints ( )

virtual

Update for mesh point-motion.

Implements sampledSurface.

Definition at line 660 of file sampledTriSurface.C.

References MeshedSurface< Face >::clear(), and sampledSurface::clearGeom().

Here is the call graph for this function:

◆ topoChange()

void topoChange ( const polyTopoChangeMap & )

virtual

Update topology using the given map.

Implements sampledSurface.

Definition at line 673 of file sampledTriSurface.C.

◆ mapMesh()

void mapMesh ( const polyMeshMap & )

virtual

Update from another mesh using the given map.

Implements sampledSurface.

Definition at line 679 of file sampledTriSurface.C.

◆ distribute()

void distribute ( const polyDistributionMap & )

virtual

Redistribute or update using the given distribution map.

Implements sampledSurface.

Definition at line 685 of file sampledTriSurface.C.

◆ print()

void print ( Ostream & os ) const

virtual

Write.

Reimplemented from sampledSurface.

Definition at line 691 of file sampledTriSurface.C.

References Foam::name(), and points.

Here is the call graph for this function:

◆ sampleField()

Foam::tmp<Foam::Field<Type> > sampleField ( const VolField< Type > & vField ) const

Definition at line 33 of file sampledTriSurfaceTemplates.C.

References polyMesh::boundary(), GeometricField< Type, GeoMesh, PrimitiveField >::boundaryField(), triSurface::cells, forAll, triSurface::insideCells, sampledSurface::mesh(), primitiveMesh::nFaces(), primitiveMesh::nInternalFaces(), patchi, tmp< T >::ref(), UPtrList< T >::size(), List< T >::size(), and Foam::Zero.

Here is the call graph for this function:

◆ interpolateField()

Foam::tmp<Foam::Field<Type> > interpolateField ( const interpolation< Type > & interpolator ) const

Definition at line 89 of file sampledTriSurfaceTemplates.C.

References cells, forAll, mesh, and tmp< T >::ref().

Here is the call graph for this function:

Member Data Documentation

◆ samplingSourceNames_

const Foam::NamedEnum< Foam::sampledSurfaces::triSurface::samplingSource, 3 > samplingSourceNames_

static

Initial value:

{
    "cells",
    "insideCells",
    "boundaryFaces"
}

Names of communication types.

Definition at line 144 of file sampledTriSurface.H.

The documentation for this class was generated from the following files:

src/sampling/sampledSurface/sampledTriSurface/sampledTriSurface.H
src/sampling/sampledSurface/sampledTriSurface/sampledTriSurface.C
src/sampling/sampledSurface/sampledTriSurface/sampledTriSurfaceTemplates.C
