Calculates and applies the force necessary to maintain the specified mean velocity averaged over the specified patch. More...

Inheritance diagram for patchMeanVelocityForce:

[legend]

Collaboration diagram for patchMeanVelocityForce:

[legend]

Public Member Functions
	TypeName ("patchMeanVelocityForce")
	Runtime type information. More...

	patchMeanVelocityForce (const word &sourceName, const word &modelType, const dictionary &dict, const fvMesh &mesh)
	Construct from explicit source name and mesh. More...

virtual bool	read (const dictionary &dict)
	Read dictionary. More...

Public Member Functions inherited from meanVelocityForce
	TypeName ("meanVelocityForce")
	Runtime type information. More...

	meanVelocityForce (const word &sourceName, const word &modelType, const dictionary &dict, const fvMesh &mesh)
	Construct from explicit source name and mesh. More...

	meanVelocityForce (const meanVelocityForce &)=delete
	Disallow default bitwise copy construction. More...

const vector &	Ubar () const
	Return the average velocity. More...

virtual wordList	constrainedFields () const
	Return the list of fields constrained by the fvConstraint. More...

virtual bool	constrain (fvMatrix< vector > &eqn, const word &fieldName) const
	Add the momentum source and set the 1/A coefficient. More...

virtual bool	constrain (volVectorField &U) const
	Correct the pressure gradient. More...

virtual void	updateMesh (const mapPolyMesh &)
	Update for mesh changes. More...

void	operator= (const meanVelocityForce &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from fvConstraint
	TypeName ("fvConstraint")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, fvConstraint, dictionary,(const word &name, const word &constraintType, const dictionary &dict, const fvMesh &mesh),(name, constraintType, dict, mesh))

	fvConstraint (const word &name, const word &constraintType, const dictionary &dict, const fvMesh &mesh)
	Construct from components. More...

autoPtr< fvConstraint >	clone () const
	Return clone. More...

virtual	~fvConstraint ()
	Destructor. More...

const word &	name () const
	Return const access to the source name. More...

const fvMesh &	mesh () const
	Return const access to the mesh database. More...

const dictionary &	coeffs () const
	Return dictionary. More...

virtual bool	constrainsField (const word &fieldName) const
	Return true if the given field is constrained. More...

	FOR_ALL_FIELD_TYPES (DEFINE_FV_CONSTRAINT_CONSTRAIN)
	Apply a constraint to an equation. More...

	FOR_ALL_FIELD_TYPES (DEFINE_FV_CONSTRAINT_CONSTRAIN_FIELD)
	Apply contraint to a field. More...

virtual bool	movePoints ()
	Update for mesh motion. More...

Additional Inherited Members
Static Public Member Functions inherited from fvConstraint
static autoPtr< fvConstraint >	New (const word &name, const dictionary &dict, const fvMesh &mesh)
	Return a reference to the selected fvConstraint. More...

Detailed Description

Calculates and applies the force necessary to maintain the specified mean velocity averaged over the specified patch.

Usage

Example usage:

patchMeanVelocityForce1
{
    type            patchMeanVelocityForce;

    selectionMode   all;

    U               U;          // Name of velocity field

    patch           inlet;      // Name of the patch

    Ubar            (10.0 0 0); // Desired mean velocity
    relaxation      0.2;        // Optional relaxation factor
   }

Note: Currently only handles kinematic pressure (incompressible solvers).

Source files

Definition at line 72 of file patchMeanVelocityForce.H.

Constructor & Destructor Documentation

◆ patchMeanVelocityForce()

patchMeanVelocityForce	(	const word &	sourceName,
		const word &	modelType,
		const dictionary &	dict,
		const fvMesh &	mesh
	)

Construct from explicit source name and mesh.

Definition at line 67 of file patchMeanVelocityForce.C.

References boundary(), GeometricField< Type, PatchField, GeoMesh >::boundaryField(), forAll, mesh, Foam::normalised(), UPstream::parRun(), patches, patchi, processorCyclicPolyPatch::patchIDs(), Foam::sum(), U, and Ubar().

Here is the call graph for this function:

Member Function Documentation

◆ TypeName()

TypeName ( "patchMeanVelocityForce" )

Runtime type information.

◆ read()

bool read ( const dictionary & dict )

virtual

Read dictionary.

Reimplemented from meanVelocityForce.

Definition at line 130 of file patchMeanVelocityForce.C.

References meanVelocityForce::read().
