Public Member Functions | List of all members
cyclicAMILduInterface Class Referenceabstract

An abstract base class for cyclic AMI coupled interfaces. More...

Inheritance diagram for cyclicAMILduInterface:
Inheritance graph
[legend]

Public Member Functions

 TypeName ("cyclicAMILduInterface")
 Runtime type information. More...

 cyclicAMILduInterface ()
 Construct null. More...

virtual ~cyclicAMILduInterface ()
 Destructor. More...

virtual label neighbPatchID () const =0
 Return neighbour. More...

virtual bool owner () const =0
 Does this side own the interface? More...

virtual const cyclicAMILduInterface & neighbPatch () const =0
 Return processor number. More...

virtual const PtrList< AMIInterpolation > & AMIs () const =0
 Return a reference to the AMI interpolators. More...

virtual const List< vectorTensorTransform > & AMITransforms () const =0

virtual const tensorField & forwardT () const =0
 Return face transformation tensor. More...

virtual const tensorField & reverseT () const =0
 Return face reverse transformation tensor. More...


Detailed Description

An abstract base class for cyclic AMI coupled interfaces.

Source files

Definition at line 49 of file cyclicAMILduInterface.H.

Constructor & Destructor Documentation

◆ cyclicAMILduInterface()

cyclicAMILduInterface ( )
inline

Construct null.

Definition at line 61 of file cyclicAMILduInterface.H.

References cyclicAMILduInterface::AMIs(), cyclicAMILduInterface::AMITransforms(), cyclicAMILduInterface::forwardT(), cyclicAMILduInterface::neighbPatch(), cyclicAMILduInterface::neighbPatchID(), cyclicAMILduInterface::owner(), cyclicAMILduInterface::reverseT(), and cyclicAMILduInterface::~cyclicAMILduInterface().

Here is the call graph for this function:

◆ ~cyclicAMILduInterface()

~cyclicAMILduInterface ( )
virtual

Destructor.

Definition at line 38 of file cyclicAMILduInterface.C.

Referenced by cyclicAMILduInterface::cyclicAMILduInterface().

Here is the caller graph for this function:

Member Function Documentation

◆ TypeName()

TypeName ( "cyclicAMILduInterface"  )

Runtime type information.

◆ neighbPatchID()

virtual label neighbPatchID ( ) const
pure virtual

Return neighbour.

Implemented in cyclicAMIGAMGInterface, and cyclicAMIFvPatch.

Referenced by cyclicAMILduInterface::cyclicAMILduInterface(), and cyclicAMIGAMGInterface::neighbPatchID().

Here is the caller graph for this function:

◆ owner()

virtual bool owner ( ) const
pure virtual

Does this side own the interface?

Implemented in cyclicAMIGAMGInterface, and cyclicAMIFvPatch.

Referenced by cyclicAMILduInterface::cyclicAMILduInterface(), and cyclicAMIGAMGInterface::owner().

Here is the caller graph for this function:

◆ neighbPatch()

virtual const cyclicAMILduInterface& neighbPatch ( ) const
pure virtual

Return processor number.

Implemented in cyclicAMIGAMGInterface, and cyclicAMIFvPatch.

Referenced by cyclicAMILduInterface::cyclicAMILduInterface().

Here is the caller graph for this function:

◆ AMIs()

virtual const PtrList<AMIInterpolation>& AMIs ( ) const
pure virtual

Return a reference to the AMI interpolators.

Implemented in cyclicAMIGAMGInterface, cyclicAMIFvPatch, and cyclicACMIFvPatch.

Referenced by cyclicAMILduInterface::cyclicAMILduInterface().

Here is the caller graph for this function:

◆ AMITransforms()

virtual const List<vectorTensorTransform>& AMITransforms ( ) const
pure virtual

Implemented in cyclicAMIGAMGInterface, cyclicAMIFvPatch, and cyclicACMIFvPatch.

Referenced by cyclicAMILduInterface::cyclicAMILduInterface().

Here is the caller graph for this function:

◆ forwardT()

virtual const tensorField& forwardT ( ) const
pure virtual

Return face transformation tensor.

Implemented in cyclicAMIFvPatch, and cyclicAMIGAMGInterface.

Referenced by cyclicAMILduInterface::cyclicAMILduInterface(), and cyclicAMIGAMGInterface::forwardT().

Here is the caller graph for this function:

◆ reverseT()

virtual const tensorField& reverseT ( ) const
pure virtual

Return face reverse transformation tensor.

Implemented in cyclicAMIFvPatch, and cyclicAMIGAMGInterface.

Referenced by cyclicAMILduInterface::cyclicAMILduInterface(), and cyclicAMIGAMGInterface::reverseT().

Here is the caller graph for this function:
The documentation for this class was generated from the following files:
