LandauTellerReactionRate Class Reference

Landau-Teller reaction rate. More...

Public Member Functions
	LandauTellerReactionRate (const scalar A, const scalar beta, const scalar Ta, const scalar B, const scalar C)
	Construct from components. More...
	LandauTellerReactionRate (const speciesTable &species, const dictionary &dict)
	Construct from dictionary. More...
scalar	operator() (const scalar p, const scalar T, const scalarField &c) const
void	write (Ostream &os) const
	Write to stream. More...

Static Public Member Functions
static word	type ()
	Return the type name. More...

Friends
Ostream &	operator<< (Ostream &, const LandauTellerReactionRate &)

Detailed Description

Landau-Teller reaction rate.

Source files

• LandauTellerReactionRate.H
• LandauTellerReactionRateI.H

Definition at line 56 of file LandauTellerReactionRate.H.

Constructor & Destructor Documentation

LandauTellerReactionRate() [1/2]

LandauTellerReactionRate ( const scalar  A, const scalar  beta, const scalar  Ta, const scalar  B, const scalar  C  )

inline

Construct from components.

Definition at line 29 of file LandauTellerReactionRateI.H.

LandauTellerReactionRate() [2/2]

LandauTellerReactionRate ( const speciesTable &  species, const dictionary &  dict  )

inline

Construct from dictionary.

Definition at line 46 of file LandauTellerReactionRateI.H.

Member Function Documentation

type()

static word type ( )

inlinestatic

Return the type name.

Definition at line 92 of file LandauTellerReactionRate.H.

References Foam::constant::universal::c, p, Foam::T(), and LandauTellerReactionRate::write().

Here is the call graph for this function:

operator()()

Foam::scalar operator() ( const scalar  p, const scalar  T, const scalarField &  c  ) const

inline

Definition at line 62 of file LandauTellerReactionRateI.H.

References Foam::cbrt(), Foam::exp(), Foam::mag(), Foam::pow(), and T.

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

inline

Write to stream.

Definition at line 101 of file LandauTellerReactionRateI.H.

References token::END_STATEMENT, Foam::nl, and Ostream::writeKeyword().

Referenced by LandauTellerReactionRate::type().

Here is the call graph for this function:

Here is the caller graph for this function:

Friends And Related Function Documentation

operator<<

Ostream& operator<< ( Ostream &  , const LandauTellerReactionRate &    )

friend

---

The documentation for this class was generated from the following files:

• src/thermophysicalModels/specie/reaction/reactionRate/LandauTellerReactionRate/LandauTellerReactionRate.H
• src/thermophysicalModels/specie/reaction/reactionRate/LandauTellerReactionRate/LandauTellerReactionRateI.H
