Abstract zoneGenerator which selects points, cells or faces with centres either inside a volume. More...

Inheritance diagram for volume:

[legend]

Collaboration diagram for volume:

[legend]

Public Member Functions
	volume (const word &name, const polyMesh &mesh, const dictionary &dict)
	Construct from dictionary. More...

virtual	~volume ()
	Destructor. More...

virtual zoneSet	generate () const =0
	Generate and return the zoneSet. More...

template<class ZoneType , class UnaryOp , class ZoneGenType >
Foam::labelList	select (const ZoneGenType &zoneGen, const vectorField &pts, const UnaryOp &uop) const

template<class ZoneType , class UnaryOp , class ZoneGenType >
Foam::labelList	select (const ZoneGenType &zoneGen, const zoneGeneratorList &zoneGenerators, const vectorField &pts, const UnaryOp &uop) const

template<class ZoneType , class ZoneGenType >
Foam::labelList	selectOp (const ZoneGenType &zoneGen, const zoneGeneratorList &zoneGenerators, const vectorField &pts) const

template<class UnaryOp , class ZoneGenType >
Foam::labelList	select (const ZoneGenType &zoneGen, const zoneGeneratorList &zoneGenerators, const vectorField &pts, boolList &flipMap, const UnaryOp &uop) const

template<class ZoneGenType >
Foam::labelList	selectOp (const ZoneGenType &zoneGen, const zoneGeneratorList &zoneGenerators, const vectorField &pts, boolList &flipMap) const

template<class ZoneGenType >
Foam::zoneSet	generate (const ZoneGenType &zoneGen) const

Public Member Functions inherited from zoneGenerator
	TypeName ("zoneGenerator")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, zoneGenerator, dictionary,(const word &name, const polyMesh &mesh, const dictionary &dict),(name, mesh, dict))

	zoneGenerator (const word &name, const polyMesh &mesh, const dictionary &dict)
	Construct from name, polyMesh and dictionary. More...

	zoneGenerator (const zoneGenerator &)=delete
	Disallow default bitwise copy construction. More...

virtual	~zoneGenerator ()
	Destructor. More...

const word &	name () const

const word &	zoneName () const

bool	moveUpdate () const
	Return true if the zoneGenerator updates any of the zones. More...

virtual zoneSet	movePoints () const
	Regenerate the zoneSet following mesh point motion. More...

void	operator= (const zoneGenerator &)=delete
	Disallow default bitwise assignment. More...

Protected Types
enum class	selection { inside , outside }
	Enumeration for inside/outside selection. More...

Protected Member Functions
template<class ZoneType , class UnaryOp , class ZoneGenType >
labelList	select (const ZoneGenType &zoneGen, const vectorField &pts, const UnaryOp &uop) const

template<class ZoneType , class UnaryOp , class ZoneGenType >
labelList	select (const ZoneGenType &zoneGen, const zoneGeneratorList &zoneGenerators, const vectorField &pts, const UnaryOp &uop) const

template<class ZoneType , class ZoneGenType >
labelList	selectOp (const ZoneGenType &zoneGen, const zoneGeneratorList &zoneGenerators, const vectorField &pts) const

template<class UnaryOp , class ZoneGenType >
labelList	select (const ZoneGenType &zoneGen, const zoneGeneratorList &zoneGenerators, const vectorField &pts, boolList &flipMap, const UnaryOp &uop) const

template<class ZoneGenType >
labelList	selectOp (const ZoneGenType &zoneGen, const zoneGeneratorList &zoneGenerators, const vectorField &pts, boolList &flipMap) const

template<class ZoneGenType >
zoneSet	generate (const ZoneGenType &zone) const
	Generate the zone of the given type. More...

Static Protected Member Functions
static NamedEnum< selection, 2 >::namesType	selectionNames_ ()
	Initialisation function for selection enumeration names. More...

Protected Attributes
zoneTypes	zoneType_

selection	select_
	Inside/outside selection. More...

zoneGeneratorList	zoneGenerators_
	Optional list of zoneGenerators which provide the zones to sub-set. More...

Protected Attributes inherited from zoneGenerator
const word	name_
	Name of zone generator. More...

const dictionary	dict_
	Dictionary cached for error context. More...

const word	zoneName_
	Name of the zone (defaults to the name of the generator) More...

const polyMesh &	mesh_
	Reference to the polyMesh. More...

bool	moveUpdate_
	Switch to update the zones if the mesh points are moved. More...

Static Protected Attributes
static const NamedEnum< selection, 2 >	selectionNames
	Enumeration names for inside/outside selection. More...

Additional Inherited Members
Static Public Member Functions inherited from zoneGenerator
static autoPtr< zoneGenerator >	New (const word &name, const polyMesh &mesh, const dictionary &dict)
	Select constructed from name, mesh and dictionary. More...

static autoPtr< zoneGenerator >	New (const word &name, const zoneTypes &zoneType, const polyMesh &mesh, const dictionary &dict)
	Select constructed from name, zoneType, mesh and dictionary. More...

static autoPtr< zoneGenerator >	New (const polyMesh &mesh, const dictionary &dict)
	Select constructed from mesh and first valid dictionary. More...

static labelList	indices (const boolList &selected)
	Return the list of selected indices. More...

Detailed Description

Abstract zoneGenerator which selects points, cells or faces with centres either inside a volume.

By default all the points, cells or faces of the mesh are tested for being inside or outside the volume but an optional single zone or list of zones may be provided and those points, cells or faces are tested instead. This provides an efficient method of hierarchical sub-division of space where an initial selection of points cells or faces is refined by selecting the sub-set inside or outside the given volume rather than having to generate another zone to intersect with.

Usage

Property	Description	Required	Default value
`type`	Type of volume	yes
`name`	Name of the zone	no	zoneGenerator name
`zoneType`	Type of zone	yes
`select`	Select either the inside or outside	no	inside
`moveUpdate`	Switch to update after mesh motion	no	false
`zone`	Optional zone to sub-set	no
`zones`	Optional list of zones to sub-set	no

Source files

Definition at line 111 of file volume.H.

Member Enumeration Documentation

◆ selection

enum selection

strongprotected

Enumeration for inside/outside selection.

Enumerator
inside
outside

Definition at line 122 of file volume.H.

Constructor & Destructor Documentation

◆ volume()

volume	(	const word &	name,
		const polyMesh &	mesh,
		const dictionary &	dict
	)

Construct from dictionary.

Definition at line 36 of file volume.C.

◆ ~volume()

~volume ( )

virtual

Destructor.

Definition at line 52 of file volume.C.

Member Function Documentation

◆ selectionNames_()

static NamedEnum<selection, 2>::namesType selectionNames_ ( )

inlinestaticprotected

Initialisation function for selection enumeration names.

Definition at line 128 of file volume.H.

◆ select() [1/6]

labelList select	(	const ZoneGenType &	zoneGen,
		const vectorField &	pts,
		const UnaryOp &	uop
	)		const

protected

◆ select() [2/6]

labelList select	(	const ZoneGenType &	zoneGen,
		const zoneGeneratorList &	zoneGenerators,
		const vectorField &	pts,
		const UnaryOp &	uop
	)		const

protected

◆ selectOp() [1/4]

labelList selectOp	(	const ZoneGenType &	zoneGen,
		const zoneGeneratorList &	zoneGenerators,
		const vectorField &	pts
	)		const

protected

◆ select() [3/6]

labelList select	(	const ZoneGenType &	zoneGen,
		const zoneGeneratorList &	zoneGenerators,
		const vectorField &	pts,
		boolList &	flipMap,
		const UnaryOp &	uop
	)		const

protected

◆ selectOp() [2/4]

labelList selectOp	(	const ZoneGenType &	zoneGen,
		const zoneGeneratorList &	zoneGenerators,
		const vectorField &	pts,
		boolList &	flipMap
	)		const

protected

◆ generate() [1/3]

zoneSet generate ( const ZoneGenType & zone ) const

protected

Generate the zone of the given type.

◆ generate() [2/3]

virtual zoneSet generate ( ) const

pure virtual

Generate and return the zoneSet.

Implements zoneGenerator.

Implemented in truncatedCone, sphere, insideSurface, hemisphere, cylinder, box, and annulus.

Referenced by annulus::generate(), box::generate(), cylinder::generate(), hemisphere::generate(), insideSurface::generate(), sphere::generate(), and truncatedCone::generate().

Here is the caller graph for this function:

◆ select() [4/6]

Foam::labelList select	(	const ZoneGenType &	zoneGen,
		const vectorField &	pts,
		const UnaryOp &	uop
	)		const

inline

Definition at line 32 of file volumeTemplates.C.

References forAll, zoneGenerator::indices(), List< T >::setSize(), and List< T >::size().

Here is the call graph for this function:

◆ select() [5/6]

Foam::labelList select	(	const ZoneGenType &	zoneGen,
		const zoneGeneratorList &	zoneGenerators,
		const vectorField &	pts,
		const UnaryOp &	uop
	)		const

inline

Definition at line 57 of file volumeTemplates.C.

References forAll, List< T >::size(), and zoneSet::zone().

Here is the call graph for this function:

◆ selectOp() [3/4]

Foam::labelList selectOp	(	const ZoneGenType &	zoneGen,
		const zoneGeneratorList &	zoneGenerators,
		const vectorField &	pts
	)		const

inline

Definition at line 92 of file volumeTemplates.C.

◆ select() [6/6]

Foam::labelList select	(	const ZoneGenType &	zoneGen,
		const zoneGeneratorList &	zoneGenerators,
		const vectorField &	pts,
		boolList &	flipMap,
		const UnaryOp &	uop
	)		const

inline

Definition at line 123 of file volumeTemplates.C.

References List< T >::clear(), faceZone::flipMap(), forAll, zoneSet::fZone(), faceZone::oriented(), List< T >::setSize(), and List< T >::size().

Here is the call graph for this function:

◆ selectOp() [4/4]

Foam::labelList selectOp	(	const ZoneGenType &	zoneGen,
		const zoneGeneratorList &	zoneGenerators,
		const vectorField &	pts,
		boolList &	flipMap
	)		const

inline

Definition at line 188 of file volumeTemplates.C.

◆ generate() [3/3]

Foam::zoneSet generate ( const ZoneGenType & zoneGen ) const

Definition at line 222 of file volumeTemplates.C.

References Foam::cell, Foam::face, Foam::point, and List< T >::size().

Here is the call graph for this function:

Member Data Documentation

◆ zoneType_

zoneTypes zoneType_

protected

Definition at line 119 of file volume.H.

◆ selectionNames

const Foam::NamedEnum< Foam::zoneGenerators::volume::selection, 2 > selectionNames

staticprotected

Enumeration names for inside/outside selection.

Definition at line 125 of file volume.H.

◆ select_

selection select_

protected

Inside/outside selection.

Definition at line 134 of file volume.H.

◆ zoneGenerators_

zoneGeneratorList zoneGenerators_

protected

Optional list of zoneGenerators which provide the zones to sub-set.

Default selection is all of the points, cells or faces

Definition at line 138 of file volume.H.

The documentation for this class was generated from the following files:

src/meshTools/zoneGenerators/volume/volume/volume.H
src/meshTools/zoneGenerators/volume/volume/volume.C
src/meshTools/zoneGenerators/volume/volume/volumeTemplates.C
