A zoneGenerator which selects the elements which are in all the zones generated by the given list of zoneGenerators. More...

Inheritance diagram for intersection:

[legend]

Collaboration diagram for intersection:

[legend]

Public Member Functions
	TypeName ("intersection")
	Runtime type information. More...

	intersection (const word &name, const polyMesh &mesh, const dictionary &dict)
	Construct from dictionary. More...

virtual	~intersection ()
	Destructor. More...

virtual zoneSet	generate () const
	Generate and return the zoneSet. More...

Public Member Functions inherited from zoneGenerator
	TypeName ("zoneGenerator")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, zoneGenerator, dictionary,(const word &name, const polyMesh &mesh, const dictionary &dict),(name, mesh, dict))

	zoneGenerator (const word &name, const polyMesh &mesh, const dictionary &dict)
	Construct from name, polyMesh and dictionary. More...

	zoneGenerator (const zoneGenerator &)=delete
	Disallow default bitwise copy construction. More...

virtual	~zoneGenerator ()
	Destructor. More...

const word &	name () const

const word &	zoneName () const

bool	moveUpdate () const
	Return true if the zoneGenerator updates any of the zones. More...

virtual zoneSet	movePoints () const
	Regenerate the zoneSet following mesh point motion. More...

void	operator= (const zoneGenerator &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from zoneGenerator
static autoPtr< zoneGenerator >	New (const word &name, const polyMesh &mesh, const dictionary &dict)
	Select constructed from name, mesh and dictionary. More...

static autoPtr< zoneGenerator >	New (const word &name, const zoneTypes &zoneType, const polyMesh &mesh, const dictionary &dict)
	Select constructed from name, zoneType, mesh and dictionary. More...

static autoPtr< zoneGenerator >	New (const polyMesh &mesh, const dictionary &dict)
	Select constructed from mesh and first valid dictionary. More...

static labelList	indices (const boolList &selected)
	Return the list of selected indices. More...

Protected Attributes inherited from zoneGenerator
const word	name_
	Name of zone generator. More...

const dictionary	dict_
	Dictionary cached for error context. More...

const word	zoneName_
	Name of the zone (defaults to the name of the generator) More...

const polyMesh &	mesh_
	Reference to the polyMesh. More...

bool	moveUpdate_
	Switch to update the zones if the mesh points are moved. More...

Detailed Description

A zoneGenerator which selects the elements which are in all the zones generated by the given list of zoneGenerators.

An intersection of faceZones is oriented if any of the faceZones combined are oriented, otherwise the returned faceZone is unoriented.

Usage

Property	Description	Required	Default value
`type`	Type: intersection	yes
`name`	Name of the zone	no	zoneGenerator name
`zoneType`	Type of zone	no	all the zone types
`moveUpdate`	Switch to update after mesh motion	no	false

These options are followed by a list of any number of zoneGenerators which can either generate the zones locally or return zones from the lists of zones held by the mesh using the zoneGenerators::lookup zoneGenerator.

Each zoneGenerator returns a zoneSet containing a pointZone and/or a cellZone and/or a faceZone, the zoneGenerators::intersection operation combines each of the zone types unless the zoneType is specified in which case only the zones of that type are combined.

A cellZone named coneAnnulus containing the cells with centres inside the intersection of the predefined cone1 cellZone which is looked-up from the cellZoneList and are also inside the locally defined annulus is be generated by

        coneAnnulus
        {
            type        intersection;

            cone1;

            annulus1
            {
                type        annulus;
                zoneType    cell;

                point1      (-0.0075 0 -1);
                point2      (-0.003 0.0025 1);
                outerRadius 0.002;
                innerRadius 0.001;
            }
        }
