Wedge Lagrangian patch. This is used for the patches that have normals that point tangentially around an axisymmetric geometry. More...

Inheritance diagram for wedgeLagrangianPatch:

[legend]

Collaboration diagram for wedgeLagrangianPatch:

[legend]

Public Member Functions
	TypeName (wedgePolyPatch::typeName_())
	Runtime type information. More...

	wedgeLagrangianPatch (const polyPatch &, const LagrangianBoundaryMesh &)
	Construct from a patch and a boundary mesh. More...

virtual	~wedgeLagrangianPatch ()
	Destructor. More...

const wedgePolyPatch &	wedgePatch () const
	Return the wedge patch. More...

virtual const LagrangianSubMesh &	mesh () const
	Return the sub-mesh associated with this patch. More...

virtual void	evaluate (PstreamBuffers &, LagrangianMesh &, const LagrangianScalarInternalDynamicField &fraction) const
	Evaluate changes in elements that have tracked to this patch. More...

virtual void	partition () const
	Update following partitioning of the mesh. More...

Public Member Functions inherited from LagrangianPatch
	TypeName (polyPatch::typeName_())
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, LagrangianPatch, polyPatch,(const polyPatch &patch, const LagrangianBoundaryMesh &boundaryMesh),(patch, boundaryMesh))
	Declare run-time constructor selection tables. More...

	LagrangianPatch (const polyPatch &, const LagrangianBoundaryMesh &)
	Construct from a patch and a boundary mesh. More...

	LagrangianPatch (const LagrangianPatch &)=delete
	Disallow default bitwise copy construction. More...

virtual	~LagrangianPatch ()
	Destructor. More...

const polyPatch &	patch () const
	Return the patch. More...

virtual const word &	name () const
	Return name. More...

virtual bool	coupled () const
	Return whether or not this patch is coupled. More...

const LagrangianBoundaryMesh &	boundaryMesh () const
	Return the boundary mesh. More...

const objectRegistry &	db () const
	Return the local object registry. More...

template<class GeometricField , class Type >
const GeometricField::Patch &	lookupPatchField (const word &name)
	Lookup and return the patchField of the named field from the. More...

virtual void	initEvaluate (PstreamBuffers &, LagrangianMesh &mesh, const LagrangianScalarInternalDynamicField &fraction) const
	Initialise evaluation of changes in elements that have tracked to. More...

void	operator= (const LagrangianPatch &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from LagrangianPatch
static autoPtr< LagrangianPatch >	New (const word &type, const polyPatch &patch, const LagrangianBoundaryMesh &boundaryMesh)
	Return a pointer to a new LagrangianPatch of specified type. More...

static autoPtr< LagrangianPatch >	New (const polyPatch &patch, const LagrangianBoundaryMesh &boundaryMesh)
	Return a pointer to a new LagrangianPatch corresponding to the. More...

Detailed Description

Wedge Lagrangian patch. This is used for the patches that have normals that point tangentially around an axisymmetric geometry.

Source files

Definition at line 50 of file wedgeLagrangianPatch.H.

Constructor & Destructor Documentation

◆ wedgeLagrangianPatch()

wedgeLagrangianPatch	(	const polyPatch &	patch,
		const LagrangianBoundaryMesh &	boundaryMesh
	)

Construct from a patch and a boundary mesh.

Definition at line 47 of file wedgeLagrangianPatch.C.

◆ ~wedgeLagrangianPatch()

~wedgeLagrangianPatch ( )

virtual

Destructor.

Definition at line 61 of file wedgeLagrangianPatch.C.

Member Function Documentation

◆ TypeName()

TypeName ( wedgePolyPatch::typeName_() )

Runtime type information.

◆ wedgePatch()

const wedgePolyPatch& wedgePatch ( ) const

inline

Return the wedge patch.

Definition at line 87 of file wedgeLagrangianPatch.H.

◆ mesh()

const Foam::LagrangianSubMesh & mesh ( ) const

virtual

Return the sub-mesh associated with this patch.

Reimplemented from LagrangianPatch.

Definition at line 67 of file wedgeLagrangianPatch.C.

◆ evaluate()

void evaluate	(	PstreamBuffers &	,
		LagrangianMesh &	mesh,
		const LagrangianScalarInternalDynamicField &	fraction
	)		const

virtual

Evaluate changes in elements that have tracked to this patch.

Reimplemented from LagrangianPatch.

Definition at line 79 of file wedgeLagrangianPatch.C.

References Foam::tracking::crossWedge(), forAll, Foam::inCell, mesh, LagrangianSubMesh::start(), and LagrangianSubMesh::sub().

Here is the call graph for this function:

◆ partition()

void partition ( ) const

virtual

Update following partitioning of the mesh.

Reimplemented from LagrangianPatch.

Definition at line 116 of file wedgeLagrangianPatch.C.

References LagrangianPatch::partition().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/Lagrangian/Lagrangian/LagrangianMesh/LagrangianPatches/constraint/wedge/wedgeLagrangianPatch.H
src/Lagrangian/Lagrangian/LagrangianMesh/LagrangianPatches/constraint/wedge/wedgeLagrangianPatch.C
