Collaboration diagram for surfaceZonesInfo:

Public Types
enum	areaSelectionAlgo { INSIDE , OUTSIDE , INSIDEPOINT , NONE }
	Types of selection of area. More...

enum	faceZoneType { INTERNAL , BAFFLE , BOUNDARY }
	What to do with faceZone faces. More...

Public Member Functions
	surfaceZonesInfo (const searchableSurface &surface, const dictionary &surfacesDict)
	Construct from surfaces and dictionary. More...

	surfaceZonesInfo (const word &faceZoneNames, const word &cellZoneNames, const areaSelectionAlgo &zoneInside, const point &zoneInsidePoints, const faceZoneType &faceType)
	Construct from components. More...

	surfaceZonesInfo (const surfaceZonesInfo &)
	Copy constructor. More...

autoPtr< surfaceZonesInfo >	clone () const
	Return clone. More...

const word &	faceZoneName () const
	Per 'interface' surface : empty or name of faceZone to put. More...

const word &	cellZoneName () const
	Per 'interface' surface : empty or name of cellZone to put. More...

const areaSelectionAlgo &	zoneInside () const

const point &	zoneInsidePoint () const
	Get specified inside locations for surfaces with a cellZone. More...

const faceZoneType &	faceType () const
	How to handle face of surfaces with a faceZone. More...

void	operator= (const surfaceZonesInfo &)=delete
	Disallow default bitwise assignment. More...

Static Public Member Functions
static labelList	getUnnamedSurfaces (const PtrList< surfaceZonesInfo > &surfList)
	Get indices of unnamed surfaces (surfaces without faceZoneName) More...

static labelList	getNamedSurfaces (const PtrList< surfaceZonesInfo > &surfList)
	Get indices of named surfaces (surfaces with faceZoneName) More...

static labelList	getClosedNamedSurfaces (const PtrList< surfaceZonesInfo > &surfList, const searchableSurfaceList &allGeometry, const labelList &surfaces)
	Get indices of surfaces with a cellZone that are closed and. More...

static labelList	getUnclosedNamedSurfaces (const PtrList< surfaceZonesInfo > &surfList, const searchableSurfaceList &allGeometry, const labelList &surfaces)
	Get indices of surfaces with a cellZone that are unclosed. More...

static labelList	getAllClosedNamedSurfaces (const PtrList< surfaceZonesInfo > &surfList, const searchableSurfaceList &allGeometry, const labelList &surfaces)
	Get indices of surfaces with a cellZone that are closed. More...

static labelList	getInsidePointNamedSurfaces (const PtrList< surfaceZonesInfo > &surfList)
	Get indices of surfaces with a cellZone that have 'insidePoint'. More...

static labelList	addCellZonesToMesh (const PtrList< surfaceZonesInfo > &surfList, const labelList &namedSurfaces, polyMesh &mesh)

static labelList	addFaceZonesToMesh (const PtrList< surfaceZonesInfo > &surfList, const labelList &namedSurfaces, polyMesh &mesh)

Static Public Attributes
static const NamedEnum< areaSelectionAlgo, 4 >	areaSelectionAlgoNames

static const NamedEnum< faceZoneType, 3 >	faceZoneTypeNames

Detailed Description

Source files

Definition at line 56 of file surfaceZonesInfo.H.

Member Enumeration Documentation

◆ areaSelectionAlgo

enum areaSelectionAlgo

Types of selection of area.

Enumerator
INSIDE
OUTSIDE
INSIDEPOINT
NONE

Definition at line 61 of file surfaceZonesInfo.H.

◆ faceZoneType

enum faceZoneType

What to do with faceZone faces.

Enumerator
INTERNAL
BAFFLE
BOUNDARY

Definition at line 72 of file surfaceZonesInfo.H.

Constructor & Destructor Documentation

◆ surfaceZonesInfo() [1/3]

surfaceZonesInfo	(	const searchableSurface &	surface,
		const dictionary &	surfacesDict
	)

Construct from surfaces and dictionary.

Definition at line 54 of file surfaceZonesInfo.C.

References surfaceZonesInfo::areaSelectionAlgoNames, Foam::dimLength, Foam::endl(), surfaceZonesInfo::faceZoneTypeNames, searchableSurface::hasVolumeType(), surfaceZonesInfo::INSIDE, surfaceZonesInfo::INSIDEPOINT, IOWarningInFunction, dictionary::lookup(), surfaceZonesInfo::OUTSIDE, and dictionary::readIfPresent().

Referenced by surfaceZonesInfo::clone().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ surfaceZonesInfo() [2/3]

surfaceZonesInfo	(	const word &	faceZoneNames,
		const word &	cellZoneNames,
		const areaSelectionAlgo &	zoneInside,
		const point &	zoneInsidePoints,
		const faceZoneType &	faceType
	)

Construct from components.

Definition at line 130 of file surfaceZonesInfo.C.

◆ surfaceZonesInfo() [3/3]

surfaceZonesInfo ( const surfaceZonesInfo & surfZone )

Copy constructor.

Definition at line 147 of file surfaceZonesInfo.C.

Member Function Documentation

◆ clone()

autoPtr<surfaceZonesInfo> clone ( ) const

inline

Return clone.

Definition at line 130 of file surfaceZonesInfo.H.

References surfaceZonesInfo::surfaceZonesInfo().

Here is the call graph for this function:

◆ faceZoneName()

const word& faceZoneName ( ) const

inline

Per 'interface' surface : empty or name of faceZone to put.

faces into

Definition at line 142 of file surfaceZonesInfo.H.

◆ cellZoneName()

const word& cellZoneName ( ) const

inline

Per 'interface' surface : empty or name of cellZone to put.

cells into

Definition at line 149 of file surfaceZonesInfo.H.

◆ zoneInside()

const areaSelectionAlgo& zoneInside ( ) const

inline

Definition at line 154 of file surfaceZonesInfo.H.

◆ zoneInsidePoint()

const point& zoneInsidePoint ( ) const

inline

Get specified inside locations for surfaces with a cellZone.

Definition at line 160 of file surfaceZonesInfo.H.

◆ faceType()

const faceZoneType& faceType ( ) const

inline

How to handle face of surfaces with a faceZone.

Definition at line 166 of file surfaceZonesInfo.H.

◆ getUnnamedSurfaces()

Foam::labelList getUnnamedSurfaces ( const PtrList< surfaceZonesInfo > & surfList )

static

Get indices of unnamed surfaces (surfaces without faceZoneName)

Definition at line 157 of file surfaceZonesInfo.C.

References forAll, List< T >::setSize(), and UPtrList< T >::size().

Referenced by snappySnapDriver::calcNearestSurface(), snappySnapDriver::detectNearSurfaces(), and snappySnapDriver::repatchToSurface().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getNamedSurfaces()

Foam::labelList getNamedSurfaces ( const PtrList< surfaceZonesInfo > & surfList )

static

Get indices of named surfaces (surfaces with faceZoneName)

Definition at line 178 of file surfaceZonesInfo.C.

References forAll, PtrList< T >::set(), List< T >::setSize(), and UPtrList< T >::size().

Referenced by snappySnapDriver::calcNearestSurface(), meshRefinement::createZoneBaffles(), snappySnapDriver::detectNearSurfaces(), snappySnapDriver::mergeZoneBaffles(), snappySnapDriver::repatchToSurface(), and meshRefinement::zonify().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getClosedNamedSurfaces()

Foam::labelList getClosedNamedSurfaces	(	const PtrList< surfaceZonesInfo > &	surfList,
		const searchableSurfaceList &	allGeometry,
		const labelList &	surfaces
	)

static

Get indices of surfaces with a cellZone that are closed and.

have 'inside' or 'outside' selection.

Definition at line 203 of file surfaceZonesInfo.C.

References forAll, surfaceZonesInfo::INSIDE, surfaceZonesInfo::OUTSIDE, PtrList< T >::set(), List< T >::setSize(), and UPtrList< T >::size().

Referenced by meshRefinement::zonify().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ getUnclosedNamedSurfaces()

Foam::labelList getUnclosedNamedSurfaces	(	const PtrList< surfaceZonesInfo > &	surfList,
		const searchableSurfaceList &	allGeometry,
		const labelList &	surfaces
	)

static

Get indices of surfaces with a cellZone that are unclosed.

Definition at line 235 of file surfaceZonesInfo.C.

References forAll, PtrList< T >::set(), List< T >::setSize(), and UPtrList< T >::size().

Here is the call graph for this function:

◆ getAllClosedNamedSurfaces()

Foam::labelList getAllClosedNamedSurfaces	(	const PtrList< surfaceZonesInfo > &	surfList,
		const searchableSurfaceList &	allGeometry,
		const labelList &	surfaces
	)

static

Get indices of surfaces with a cellZone that are closed.

Definition at line 262 of file surfaceZonesInfo.C.

References forAll, PtrList< T >::set(), List< T >::setSize(), and UPtrList< T >::size().

Here is the call graph for this function:

◆ getInsidePointNamedSurfaces()

Foam::labelList getInsidePointNamedSurfaces ( const PtrList< surfaceZonesInfo > & surfList )

static

Get indices of surfaces with a cellZone that have 'insidePoint'.

section.

Definition at line 290 of file surfaceZonesInfo.C.

References forAll, surfaceZonesInfo::INSIDEPOINT, PtrList< T >::set(), List< T >::setSize(), and UPtrList< T >::size().

Referenced by meshRefinement::zonify().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ addCellZonesToMesh()

Foam::labelList addCellZonesToMesh	(	const PtrList< surfaceZonesInfo > &	surfList,
		const labelList &	namedSurfaces,
		polyMesh &	mesh
	)

static

Definition at line 316 of file surfaceZonesInfo.C.

References polyMesh::cellZones(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, PtrListDictionary< T >::findIndex(), forAll, Pstream::gatherList(), mesh, UPstream::myProcNo(), Foam::nl, UPstream::nProcs(), word::null, Pstream::scatterList(), PtrListDictionary< T >::set(), PtrList< T >::setSize(), UPtrList< T >::size(), List< T >::size(), and DictionaryBase< IDLListType, T >::toc().

Referenced by meshRefinement::zonify().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ addFaceZonesToMesh()

Foam::labelList addFaceZonesToMesh	(	const PtrList< surfaceZonesInfo > &	surfList,
		const labelList &	namedSurfaces,
		polyMesh &	mesh
	)

static

Definition at line 380 of file surfaceZonesInfo.C.

References Foam::exit(), polyMesh::faceZones(), Foam::FatalError, FatalErrorInFunction, PtrListDictionary< T >::findIndex(), forAll, Pstream::gatherList(), mesh, UPstream::myProcNo(), Foam::nl, UPstream::nProcs(), Pstream::scatterList(), PtrListDictionary< T >::set(), PtrList< T >::setSize(), UPtrList< T >::size(), List< T >::size(), and DictionaryBase< IDLListType, T >::toc().

Referenced by meshRefinement::zonify().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator=()

void operator= ( const surfaceZonesInfo & )

delete

Disallow default bitwise assignment.

Member Data Documentation

◆ areaSelectionAlgoNames

const Foam::NamedEnum< Foam::surfaceZonesInfo::areaSelectionAlgo, 4 > areaSelectionAlgoNames

static

Initial value:

{
    "inside",
    "outside",
    "insidePoint",
    "none"
}

Definition at line 69 of file surfaceZonesInfo.H.

Referenced by refinementSurfaces::findInside(), and surfaceZonesInfo::surfaceZonesInfo().

◆ faceZoneTypeNames

const Foam::NamedEnum< Foam::surfaceZonesInfo::faceZoneType, 3 > faceZoneTypeNames

static

Initial value:

{
    "internal",
    "baffle",
    "boundary"
}

Definition at line 79 of file surfaceZonesInfo.H.

Referenced by surfaceZonesInfo::surfaceZonesInfo().

The documentation for this class was generated from the following files:

src/mesh/snappyHexMesh/refinementSurfaces/surfaceZonesInfo.H
src/mesh/snappyHexMesh/refinementSurfaces/surfaceZonesInfo.C
