Addressing for all faces on surface of mesh. Can either be read from polyMesh or from triSurface. Used for repatching existing meshes. More...

Public Types
typedef PrimitivePatch< faceList, const pointField >	rMesh
	Type of the mesh. More...

Public Member Functions
	ClassName ("repatchMesh")
	Runtime type information. More...

	repatchMesh ()
	Construct null. More...

	repatchMesh (const repatchMesh &)=delete
	Disallow default bitwise copy construction. More...

	~repatchMesh ()
	Destructor. More...

const rMesh &	mesh () const
	Access the boundary mesh. More...

const PtrList< repatchPatch > &	patches () const
	Access the patches. More...

const labelList &	meshFace () const
	Label of original face in polyMesh (before patchify(...)) More...

const pointField &	featurePoints () const
	Feature points. More...

const edgeList &	featureEdges () const
	Feature edges. Indices into featurePoints. More...

const labelList &	featureToEdge () const
	From index into featureEdge to index into meshedges,. More...

const labelList &	edgeToFeature () const
	From edge into featureEdges. More...

const labelListList &	featureSegments () const
	Lists of connected featureEdges. Indices into featureEdges. More...

void	read (const polyMesh &)
	Read from repatchMesh of polyMesh. More...

void	readTriSurface (const fileName &)
	Read from triSurface. More...

labelList	getNearest (const primitiveMesh &pMesh, const vector &searchSpan) const
	Get rMesh index of nearest face for every boundary face in. More...

label	whichPatch (const label facei) const
	Get index of patch face is in. More...

label	findIndex (const word &patchName) const
	Get index of patch by name. More...

void	addPatch (const word &patchName)
	Add to back of patch list. More...

void	deletePatch (const word &patchName)
	Delete from patch list. More...

void	changePatchType (const word &patchName, const word &type)
	Change patch. More...

void	setFeatureEdges (const scalar minCos)
	Set featureEdges, edgeToFeature, featureSegments according. More...

void	markFaces (const labelList &protectedEdges, const label facei, boolList &visited) const

void	operator= (const repatchMesh &)=delete
	Disallow default bitwise assignment. More...

Detailed Description

Addressing for all faces on surface of mesh. Can either be read from polyMesh or from triSurface. Used for repatching existing meshes.

Source files

Definition at line 57 of file repatchMesh.H.

Member Typedef Documentation

◆ rMesh

typedef PrimitivePatch<faceList, const pointField> rMesh

Type of the mesh.

Definition at line 64 of file repatchMesh.H.

Constructor & Destructor Documentation

◆ repatchMesh() [1/2]

repatchMesh ( )

Construct null.

Definition at line 327 of file repatchMesh.C.

◆ repatchMesh() [2/2]

repatchMesh ( const repatchMesh & )

delete

Disallow default bitwise copy construction.

◆ ~repatchMesh()

~repatchMesh ( )

Destructor.

Definition at line 342 of file repatchMesh.C.

Member Function Documentation

◆ ClassName()

ClassName ( "repatchMesh" )

Runtime type information.

◆ mesh()

const rMesh& mesh ( ) const

inline

Access the boundary mesh.

Definition at line 180 of file repatchMesh.H.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, and autoPtr< T >::valid().

Here is the call graph for this function:

◆ patches()

const PtrList<repatchPatch>& patches ( ) const

inline

Access the patches.

Definition at line 192 of file repatchMesh.H.

◆ meshFace()

const labelList& meshFace ( ) const

inline

Label of original face in polyMesh (before patchify(...))

Definition at line 198 of file repatchMesh.H.

◆ featurePoints()

const pointField& featurePoints ( ) const

inline

Feature points.

Definition at line 204 of file repatchMesh.H.

◆ featureEdges()

const edgeList& featureEdges ( ) const

inline

Feature edges. Indices into featurePoints.

Definition at line 210 of file repatchMesh.H.

◆ featureToEdge()

const labelList& featureToEdge ( ) const

inline

From index into featureEdge to index into meshedges,.

Definition at line 216 of file repatchMesh.H.

◆ edgeToFeature()

const labelList& edgeToFeature ( ) const

inline

From edge into featureEdges.

Definition at line 222 of file repatchMesh.H.

◆ featureSegments()

const labelListList& featureSegments ( ) const

inline

Lists of connected featureEdges. Indices into featureEdges.

Definition at line 228 of file repatchMesh.H.

◆ read()

void read ( const polyMesh & mesh )

Read from repatchMesh of polyMesh.

Definition at line 348 of file repatchMesh.C.

References polyMesh::boundaryMesh(), Foam::endl(), f(), forAll, PrimitivePatch< FaceList, PointField >::localFaces(), PrimitivePatch< FaceList, PointField >::localPoints(), mesh, patchIdentifier::name(), primitiveMesh::nFaces(), primitiveMesh::nInternalFaces(), patchi, patchIdentifier::physicalType(), polyMesh::points(), PrimitivePatch< FaceList, PointField >::points(), Foam::Pout, PtrList< T >::set(), UList< T >::size(), UPtrList< T >::size(), repatchPatch::size(), List< T >::size(), polyPatch::start(), repatchPatch::start(), and Foam::Zero.

Here is the call graph for this function:

◆ readTriSurface()

void readTriSurface ( const fileName & fName )

Read from triSurface.

Definition at line 474 of file repatchMesh.C.

References List< T >::clear(), UList< T >::empty(), Foam::endl(), forAll, geometricSurfacePatch::geometricType(), SortableList< T >::indices(), HashTable< T, Key, Hash >::insert(), PrimitivePatch< FaceList, PointField >::localFaces(), PrimitivePatch< FaceList, PointField >::localPoints(), OSstream::name(), geometricSurfacePatch::name(), Foam::name(), triSurface::patches(), patchi, Foam::Pout, labelledTri::region(), List< T >::setSize(), HashTable< T, Key, Hash >::size(), repatchPatch::size(), List< T >::size(), SortableList< T >::sort(), and repatchPatch::start().

Here is the call graph for this function:

◆ getNearest()

Foam::labelList getNearest	(	const primitiveMesh &	pMesh,
		const vector &	searchSpan
	)		const

Get rMesh index of nearest face for every boundary face in.

pMesh. Gets passed initial search box. If not found returns -1 for the face.

Definition at line 650 of file repatchMesh.C.

References DynamicList< T, SizeInc, SizeMult, SizeDiv >::append(), boundBox::avgDim(), Foam::e, Foam::endl(), f(), primitiveMesh::faceAreas(), primitiveMesh::faceCentres(), primitiveMesh::faces(), forAll, PointIndexHit< Point >::hit(), PointIndexHit< Point >::hitPoint(), PointIndexHit< Point >::index(), Foam::mag(), Foam::magSqr(), boundBox::max(), Foam::max(), mesh, boundBox::min(), n, primitiveMesh::nFaces(), primitiveMesh::nInternalFaces(), points, primitiveMesh::points(), Foam::Pout, DynamicList< T, SizeInc, SizeMult, SizeDiv >::shrink(), Foam::sign(), List< T >::size(), Vector< Cmpt >::x(), Vector< Cmpt >::y(), and Vector< Cmpt >::z().

Here is the call graph for this function:

◆ whichPatch()

Foam::label whichPatch ( const label facei ) const

Get index of patch face is in.

Definition at line 1106 of file repatchMesh.C.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, forAll, patchi, repatchPatch::size(), and repatchPatch::start().

Here is the call graph for this function:

◆ findIndex()

Foam::label findIndex ( const word & patchName ) const

Get index of patch by name.

Definition at line 1127 of file repatchMesh.C.

References forAll, Foam::name(), and patchi.

Here is the call graph for this function:

◆ addPatch()

void addPatch ( const word & patchName )

Add to back of patch list.

Definition at line 1141 of file repatchMesh.C.

References Foam::endl(), forAll, mesh, patchIdentifier::name(), patchi, patchIdentifier::physicalType(), Foam::Pout, repatchPatch::size(), and repatchPatch::start().

Here is the call graph for this function:

◆ deletePatch()

void deletePatch ( const word & patchName )

Delete from patch list.

Definition at line 1178 of file repatchMesh.C.

References Foam::abort(), Foam::clone(), Foam::endl(), Foam::FatalError, FatalErrorInFunction, Foam::findIndex(), forAll, patchIdentifier::name(), patchi, patchIdentifier::physicalType(), Foam::Pout, PtrList< T >::set(), repatchPatch::size(), and repatchPatch::start().

Here is the call graph for this function:

◆ changePatchType()

void changePatchType	(	const word &	patchName,
		const word &	type
	)

Change patch.

Definition at line 1233 of file repatchMesh.C.

References Foam::abort(), Foam::clone(), Foam::FatalError, FatalErrorInFunction, Foam::findIndex(), forAll, patchIdentifier::index(), patchIdentifier::name(), patchi, PtrList< T >::set(), repatchPatch::size(), and repatchPatch::start().

Here is the call graph for this function:

◆ setFeatureEdges()

void setFeatureEdges ( const scalar minCos )

Set featureEdges, edgeToFeature, featureSegments according.

to angle of faces across edge

Definition at line 905 of file repatchMesh.C.

References DynamicList< T, SizeInc, SizeMult, SizeDiv >::append(), Foam::e, primitiveMesh::edgeFaces(), primitiveMesh::edges(), forAll, mesh, nPoints, polyMesh::points(), and List< T >::size().

Here is the call graph for this function:

◆ markFaces()

void markFaces	(	const labelList &	protectedEdges,
		const label	facei,
		boolList &	visited
	)		const

Definition at line 1284 of file repatchMesh.C.

References forAll, mesh, and List< T >::setSize().

Here is the call graph for this function:

◆ operator=()

void operator= ( const repatchMesh & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

src/polyTopoChange/repatchMesh/repatchMesh.H
src/polyTopoChange/repatchMesh/repatchMesh.C
