Defines the edge from the projection onto a surface (single surface) or intersection of two surfaces. More...

Inheritance diagram for projectCurveEdge:

Collaboration diagram for projectCurveEdge:

Public Member Functions
	TypeName ("projectCurve")
	Runtime type information. More...

	projectCurveEdge (const dictionary &dict, const label index, const searchableSurfaceList &geometry, const pointField &points, Istream &)
	Construct from Istream setting pointsList. More...

	projectCurveEdge (const projectCurveEdge &)=delete
	Disallow default bitwise copy construction. More...

virtual	~projectCurveEdge ()
	Destructor. More...

virtual point	position (const scalar) const
	Return the point positions corresponding to the curve parameters. More...

virtual tmp< pointField >	position (const scalarList &) const
	Return the point positions corresponding to the curve parameters. More...

virtual scalar	length () const
	Return the length of the curve. More...

void	operator= (const projectCurveEdge &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from blockEdge
	TypeName ("blockEdge")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, blockEdge, Istream,(const dictionary &dict, const label index, const searchableSurfaceList &geometry, const pointField &points, Istream &is),(dict, index, geometry, points, is))

	blockEdge (const pointField &points, const label start, const label end)
	Construct from components. More...

	blockEdge (const dictionary &dict, const label index, const pointField &, Istream &)
	Construct from Istream setting pointsList. More...

virtual autoPtr< blockEdge >	clone () const
	Clone function. More...

virtual	~blockEdge ()
	Destructor. More...

label	start () const
	Return label of start point. More...

label	end () const
	Return label of end point. More...

int	compare (const blockEdge &) const
	Compare the given start and end points with this curve. More...

int	compare (const edge &) const
	Compare the given start and end points with this curve. More...

int	compare (const label start, const label end) const
	Compare the given start and end points with this curve. More...

void	write (Ostream &, const dictionary &) const
	Write edge with variable backsubstitution. More...

Additional Inherited Members
Static Public Member Functions inherited from blockEdge
static autoPtr< blockEdge >	New (const dictionary &dict, const label index, const searchableSurfaceList &geometry, const pointField &, Istream &)
	New function which constructs and returns pointer to a blockEdge. More...

Static Protected Member Functions inherited from blockEdge
static pointField	appendEndPoints (const pointField &, const label start, const label end, const pointField &otherKnots)
	Return a complete point field by appending the start/end points. More...

Protected Attributes inherited from blockEdge
const pointField &	points_

const label	start_

const label	end_

Detailed Description

Defines the edge from the projection onto a surface (single surface) or intersection of two surfaces.

Source files

Definition at line 51 of file projectCurveEdge.H.

Constructor & Destructor Documentation

◆ projectCurveEdge() [1/2]

projectCurveEdge	(	const dictionary &	dict,
		const label	index,
		const searchableSurfaceList &	geometry,
		const pointField &	points,
		Istream &	is
	)

Construct from Istream setting pointsList.

Definition at line 45 of file projectCurveEdge.C.

References Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, searchableSurfaceList::findSurfaceID(), forAll, Foam::Info, List< T >::setSize(), List< T >::size(), and Foam::type().

Here is the call graph for this function:

◆ projectCurveEdge() [2/2]

projectCurveEdge ( const projectCurveEdge & )

delete

Disallow default bitwise copy construction.

◆ ~projectCurveEdge()

virtual ~projectCurveEdge ( )

inlinevirtual

Destructor.

Definition at line 86 of file projectCurveEdge.H.

Member Function Documentation

◆ TypeName()

TypeName ( "projectCurve" )

Runtime type information.

◆ position() [1/2]

virtual point position ( const scalar ) const

inlinevirtual

Return the point positions corresponding to the curve parameters.

0 <= lambda <= 1

Implements blockEdge.

Definition at line 94 of file projectCurveEdge.H.

◆ position() [2/2]

Foam::tmp< Foam::pointField > position ( const scalarList & lambdas ) const

virtual

Return the point positions corresponding to the curve parameters.

0 <= lambda <= 1

Reimplemented from blockEdge.

Definition at line 83 of file projectCurveEdge.C.

References Foam::e, Foam::endl(), searchableSurfacesQueries::findNearest(), forAll, Foam::Info, UList< T >::last(), Foam::mag(), Foam::magSqr(), Foam::name(), points, Foam::Pout, tmp< T >::ref(), autoPtr< T >::reset(), s(), List< T >::size(), Foam::sum(), autoPtr< T >::valid(), linearInterpolationWeights::valueWeights(), and VectorSpace< Form, Cmpt, Ncmpts >::zero.

Here is the call graph for this function:

◆ length()

virtual scalar length ( ) const

inlinevirtual

Return the length of the curve.

Implements blockEdge.

Definition at line 105 of file projectCurveEdge.H.

References NotImplemented.

◆ operator=()

void operator= ( const projectCurveEdge & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

src/mesh/blockMesh/blockEdges/projectCurveEdge/projectCurveEdge.H
src/mesh/blockMesh/blockEdges/projectCurveEdge/projectCurveEdge.C
