Processor patch. More...

Inheritance diagram for processorCyclicFvPatch:

Collaboration diagram for processorCyclicFvPatch:

Public Member Functions
	TypeName (processorCyclicPolyPatch::typeName_())
	Runtime type information. More...

	processorCyclicFvPatch (const polyPatch &patch, const fvBoundaryMesh &bm)
	Construct from components. More...

virtual int	tag () const
	Return message tag used for sending. More...

label	referPatchIndex () const
	Return the referring patch ID. More...

const cyclicFvPatch &	referPatch () const
	Return a reference to the referring patch. More...

virtual const transformer &	transform () const
	Return transformation between the coupled patches. More...

Public Member Functions inherited from processorFvPatch
	TypeName (processorPolyPatch::typeName_())
	Runtime type information. More...

	processorFvPatch (const polyPatch &patch, const fvBoundaryMesh &bm)
	Construct from components. More...

virtual label	comm () const
	Return communicator used for comms. More...

virtual int	myProcNo () const
	Return processor number. More...

virtual int	neighbProcNo () const
	Return neighbour processor number. More...

virtual bool	coupled () const
	Return true if running parallel. More...

virtual void	makeWeights (scalarField &w) const
	Make patch weighting factors. More...

virtual tmp< vectorField >	delta () const
	Return delta (P to N) vectors across coupled patch. More...

virtual tmp< labelField >	interfaceInternalField (const labelUList &internalData) const
	Return the values of the given internal data adjacent to. More...

virtual void	initInternalFieldTransfer (const Pstream::commsTypes commsType, const labelUList &internalData) const
	Initialise neighbour field transfer. More...

virtual tmp< labelField >	internalFieldTransfer (const Pstream::commsTypes commsType, const labelUList &internalData) const
	Return neighbour field. More...

virtual void	initInternalFieldTransfer (const Pstream::commsTypes commsType, labelUList &iF) const
	Inherit initInternalFieldTransfer from coupledFvPatch. More...

virtual void	initInternalFieldTransfer (const Pstream::commsTypes commsType, const labelUList &iF) const
	Inherit initInternalFieldTransfer from coupledFvPatch. More...

Public Member Functions inherited from coupledFvPatch
	TypeName (coupledPolyPatch::typeName_())
	Runtime type information. More...

	coupledFvPatch (const polyPatch &patch, const fvBoundaryMesh &bm)
	Construct from polyPatch. More...

virtual	~coupledFvPatch ()
	Destructor. More...

virtual bool	owner () const
	Does this side own the patch ? More...

virtual bool	neighbour () const
	Does the coupled side own the patch ? More...

virtual const labelUList &	faceCells () const
	Return faceCell addressing. More...

virtual void	initInternalFieldTransfer (const Pstream::commsTypes commsType, labelUList &iF) const
	Initialise neighbour field transfer. More...

virtual void	initInternalFieldTransfer (const Pstream::commsTypes commsType, const labelUList &iF) const
	Inherit initInternalFieldTransfer from lduInterface. More...

Public Member Functions inherited from lduInterface
	TypeName ("lduInterface")
	Runtime type information. More...

	lduInterface ()
	Construct null. More...

	lduInterface (const lduInterface &)=delete
	Disallow default bitwise copy construction. More...

virtual	~lduInterface ()
	Destructor. More...

void	operator= (const lduInterface &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from fvPatch
	TypeName (polyPatch::typeName_())
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, fvPatch, polyPatch,(const polyPatch &patch, const fvBoundaryMesh &bm),(patch, bm))

	fvPatch (const polyPatch &, const fvBoundaryMesh &)
	Construct from polyPatch and fvBoundaryMesh. More...

	fvPatch (const fvPatch &)=delete
	Disallow default bitwise copy construction. More...

virtual	~fvPatch ()
	Destructor. More...

const polyPatch &	patch () const
	Return the polyPatch. More...

virtual const word &	name () const
	Return name. More...

virtual label	start () const
	Return start label of this patch in the polyMesh face list. More...

virtual label	size () const
	Return size. More...

label	index () const
	Return the index of this patch in the fvBoundaryMesh. More...

const fvBoundaryMesh &	boundaryMesh () const
	Return boundaryMesh reference. More...

const objectRegistry &	db () const
	Return the local object registry. More...

template<class T >
const List< T >::subList	patchSlice (const List< T > &l) const
	Slice list to patch. More...

const vectorField &	Cf () const
	Return face centres. More...

tmp< vectorField >	Cn () const
	Return neighbour cell centres. More...

const vectorField &	Sf () const
	Return face area vectors. More...

const scalarField &	magSf () const
	Return face area magnitudes. More...

tmp< vectorField >	nf () const
	Return face normals. More...

tmp< scalarField >	polyFaceFraction () const
	Return the fraction of the poly-face that each fv-face in this. More...

const scalarField &	weights () const
	Return patch weighting factors. More...

virtual const scalarField &	deltaCoeffs () const
	Return the face - cell distance coefficient. More...

template<class Type >
tmp< Field< Type > >	patchInternalField (const UList< Type > &) const
	Return given internal field next to patch as patch field. More...

template<class Type >
void	patchInternalField (const UList< Type > &, Field< Type > &) const
	Return given internal field next to patch as patch field. More...

template<class GeometricField , class Type >
const GeometricField::Patch &	patchField (const GeometricField &) const
	Return the corresponding patchField of the named field. More...

template<class GeometricField , class Type >
GeometricField::Patch &	patchField (GeometricField &) const
	Return the corresponding patchField reference of the named field. More...

template<class GeometricField , class Type >
const GeometricField::Patch &	lookupPatchField (const word &name) const
	Lookup and return the patchField of the named field from the. More...

void	operator= (const fvPatch &)=delete
	Disallow default bitwise assignment. More...

template<class Type >
Foam::tmp< Foam::Field< Type > >	patchInternalField (const UList< Type > &f) const

Public Member Functions inherited from processorLduInterface
	TypeName ("processorLduInterface")
	Runtime type information. More...

	processorLduInterface ()
	Construct null. More...

virtual	~processorLduInterface ()
	Destructor. More...

template<class Type >
void	send (const Pstream::commsTypes commsType, const UList< Type > &) const
	Raw send function. More...

template<class Type >
void	receive (const Pstream::commsTypes commsType, UList< Type > &) const
	Raw field receive function. More...

template<class Type >
tmp< Field< Type > >	receive (const Pstream::commsTypes commsType, const label size) const
	Raw field receive function returning field. More...

template<class Type >
void	compressedSend (const Pstream::commsTypes commsType, const UList< Type > &) const
	Raw field send function with data compression. More...

template<class Type >
void	compressedReceive (const Pstream::commsTypes commsType, UList< Type > &) const
	Raw field receive function with data compression. More...

template<class Type >
tmp< Field< Type > >	compressedReceive (const Pstream::commsTypes commsType, const label size) const
	Raw field receive function with data compression returning field. More...

template<class Type >
Foam::tmp< Foam::Field< Type > >	receive (const Pstream::commsTypes commsType, const label size) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	compressedReceive (const Pstream::commsTypes commsType, const label size) const

Additional Inherited Members
Static Public Member Functions inherited from fvPatch
static autoPtr< fvPatch >	New (const polyPatch &, const fvBoundaryMesh &)
	Return a pointer to a new patch created on freestore from polyPatch. More...

static bool	constraintType (const word &pt)
	Return true if the given type is a constraint type. More...

static wordList	constraintTypes ()
	Return a list of all the constraint patch types. More...

Protected Member Functions inherited from coupledFvPatch
void	makeWeights (scalarField &w, const vectorField &nbrSf, const vectorField &nbrDelta) const
	Make patch weighting factors. More...
